- Page 1 ORIGINAL INSTRUCTIONS AUTOFEED SCREW DRIVER Model: FPVP520 Feider 32,rue AristideBergès-ZI31270Cugnaux-France CAUTION: READ INSTRUCTIONS BEFORE USING THIS TOOL...
-
Page 4: General Power Tool Safety Warnings
ENGLISH (Original instructions) General power tool safety warnings WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 5 ENGLISH (Original instructions) f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. NOTE The term “residual current device (RCD)” can be replaced by the term “ground fault circuit interrupter (GFCI)”...
- Page 6 ENGLISH (Original instructions) 4. Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
- Page 7 ENGLISH (Original instructions) Hold the power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring or its own cord. Fasteners contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
-
Page 8: Specific Safety Rules
ENGLISH (Original instructions) Specific Safety Rules Warning! Know your drywall screwdriver. Do not plug the tool into the power source until you have read and understand this Instruction Manual. Learn the tool’s applications and limitations, as well as the specific potential hazards related to this tool. -
Page 9: Assembly And Operating
ENGLISH (Original instructions) The level of risk from exposure to these chemicals varies, according to how often this type of work is performed. In order to reduce exposure to these chemicals, work in a well-ventilated area, and use approved safety equipment, such as a dust mask that is specifically designed to filter out microscopic particles. - Page 10 ENGLISH (Original instructions) Note: The screwdriver will turn at its slowest speed when the variable speed trigger switch is depressed slightly. The screwdriver will turn at its fastest speed when the variable speed trigger switch is fully depressed. 2. To stop the screwdriver, release the variable speed trigger switch (5). Lock-on button (Fig.
-
Page 11: Safety Recommendations
ENGLISH (Original instructions) Safety Recommendations Check the following every time you use the screwdriver: 1. Wear safety glasses or a mask. 2. Use hearing protection. 3. The screwdriver tip is the right size and it is in good condition. 4. No power cables “live” where you are inserting the screws. Note: Failure to follow these safety rules will significantly increase the risk of injury. -
Page 12: Maintenance
ENGLISH (Original instructions) • Place the drywall screw on the screwdriver bit. The magnetic bit holder will hold any steel screw for easy starting. • Press the screw against the drywall with steady even pressure and squeeze the variable speed trigger switch. -
Page 13: Protecting The Environment
ENGLISH (Original instructions) injury. It will also void the warranty. Lubrication All of the bearings in this tool are lubricated with a sufficient amount of high-grade lubricant for the life of the unit under normal conditions. Therefore, no further lubrication is required. Cleaning Use only mild soap and a slightly damp cloth to clean your angle grinder. -
Page 14: Specifications
ENGLISH (Original instructions) Specifications Model FPVP520 Power 520W Voltage 230V Frequency 50Hz No-load speed 0-4500/min Weight 1.45kg Sound power level: 92 dB(A); K=3 dB(A) Sound pressure level: 81 dB(A); K=3 dB(A) Vibration value: 9,1 m/s² K= 1,5 m/s² The following information: −the declared vibration total value(s) and the declared noise emission value(s) have been... - Page 15 ENGLISH (Original instructions) WARRANTY We guarantee this product for 2 full years. The warranty period for this item starts on the day of purchase. You can prove the date of purchase by sending us the original receipt. We insure over the entire warranty period: •...
- Page 16 32, rue Aristide Bergès -Z1 31270 Cugnaux - France Tel: +33 (0) 5.34.508.508 Fax: +33 (0) 5.34.508.509 Declare that the machine designated below: AUTOFEED SCREW DRIVER Model: FPVP520 Serial number: 20200815905-20200816204 Conforms to the provisions of the Machinery Directive 2006/42 / EC and the national regulations transposing it;...
