- Page 1 ORIGINAL INSTRUCTIONS >EN CORDLESS DRILL FPV20V2B2B-A USER GUIDE CAUTION: Read this manual before using this machine!
-
Page 2: Table Of Contents
CONTENTS 1. INTENDED USE..............................3 2. SAFETY INSTRUCTIONS........................... 3 3. YOUR PRODUCT..............................8 4. OPERATION................................9 5. CLEANING AND MAINTENANCE........................12 6. TECHNICAL DETAILS............................13 7. DISPOSAL................................13 8. DECLARATION OF CONFORMITY........................ 14 9. WARRANTY.................................15 10. PRODUCT FAILURE............................16 11. WARRANTY EXCLUSIONS..........................17... -
Page 3: Intended Use
1. INTENDED USE The power tool is intended for driving and drilling through wood, metal, plastics and masonry. Not suitable for professional use. WARNING: For your own safety, read this manual and the general safety instructions carefully before using the appliance. Your power tool should only be given to other users together with these instructions. - Page 4 power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
- Page 5 Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion.
- Page 6 explosion and/or intense burning may result. Under extreme conditions, battery leakage may occur. When you notice liquid on the battery, proceed as follows: Carefully wipe the liquid off using a cloth. Avoid skin contact. In case of skin or eye contact, follow the instructions below: ...
- Page 7 CAUTION: Do not recharge non-rechargeable batteries. 2.5 SYMBOLS Conforms to relevant safety standards To reduce the risk of injury, the user must read and understand this manual before using this product. Wear ear protectors. Exposure to noise can cause hearing loss. Wear eye protection.
-
Page 8: Your Product
3. YOUR PRODUCT 3.1 DESCRIPTION Keyless chuck LED work light 1a. Ring A Battery pack release button Torque adjustment ring Battery capacity indicator Two speed selector 10. Button for battery capacity indicator On/off switch trigger 11. Belt clip Battery pack 12. -
Page 9: Operation
4) Forward/reverse selector (right/left rotation selector) (6) The drill has a forward/reverse selector located above the switch trigger. CAUTION: To prevent damage to the gearbox, always allow the chuck to come to a complete stop before changing the direction of rotation or selecting another speed (HI-LO). To stop, release the trigger switch. - Page 10 NOTE: If the battery does not fit properly, disconnect it and confirm that the battery pack is the correct model for this charger as shown on the specification chart. Do not charge any other battery pack or any battery pack that does not securely fit the charger. NOTE: If battery is hot after continuous use in the tool, allow it to cool down to room temperature before charging.
- Page 11 4.8 VARIABLE SPEED This tool has a variable speed switch that delivers higher speed and torque with increased trigger pressure. Speed is controlled by the amount of switch trigger depression. 4.9 ADJUSTING THE TORQUE The torque is adjusted by rotating the torque setting ring; the torque is greater when the torque setting is ...
-
Page 12: Cleaning And Maintenance
2) Wood drilling For maximum performance, use high speed steel bits for wood drilling. Turn the function mode selector on the drill mode “ ”. Begin drilling at a very low speed to prevent the bit from slipping off the starting point. Increase the speed as the drill bit bites into the material. -
Page 13: Technical Details
20V d.c. Chuck 13mm, keyless Gear Train 2 Speed No Load Speed 0-400/0-1600min Torque adjustment 19+1 Positions FPV20V2B2B-A Input：220-240V~ 50-60Hz, 65W Charger type Output：21V d.c., 2.5A FPV20V2B2B-A Battery type 20V d.c. 2Ah Lithium-ion LpA =75dB(A) Sound pressure level LpA Uncertainty: K=5 dB(A) -
Page 14: Declaration Of Conformity
Product: Cordless drill 20V Trade mark: FEIDER Model: FPV20V2B2B-A Serial number: 20220917072-20220917571 Is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration. -
Page 15: Warranty
9. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identifed as defective by the designated distributor. -
Page 16: Product Failure
10. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 17: Warranty Exclusions
11. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 18 BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France MADE IN PRC...
