Kohler Katalyst Air R99062T Installation Instructions

INSTALLATION INSTRUCTIONS
R99062T
R99063T
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. The highest working pressure for handshower is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer
is needed. The highest water and environment temperature is 60°C. Please keep handshower, shower head and
the shower arm away from heater, or it may become damaged and cause injury to the user.
STANDARD APPLICABLE
Special model meets or exceeds the following at date of manufacture: TIS
ROUGH-IN DIMENSIONS
Ø110
G1/2˝
INSTALLATION
Flush both water supply
installed.
Install check valve(2) and regulator(3) into the handshower inlet if needed.
Put the screen washer(4) into the shower hose(5) connector. Connect the
handshower to shower hose. NOTE: Don't over tighten.
Connect another end of shower hose to the water supply.
1260105-2A-A
Katalyst Air Multi-function Handshower-Geometric
Katalyst Air Multi-function Handshower-Organic
R99062T
for about one minute before the handshower(1) is
Ø110
G1/2˝
R99063T
BETTER
1
5
2
3
4
1
