 KSI6300000.3XX (Versione universale in diversi colori/Universal version in several colors)
 KSI6301000.3XX (Versione KS‐BUS/KS‐BUS version in several colors)
Manuale di installazione/
Quick Installation Guide
Sirene da esterno imago
TM
www.kseniasecurity.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the imago KSI6300000.3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ksenia imago KSI6300000.3 Series

  • Page 1  KSI6300000.3XX (Versione universale in diversi colori/Universal version in several colors)   KSI6301000.3XX (Versione KS‐BUS/KS‐BUS version in several colors) Manuale di installazione/ Quick Installation Guide Sirene da esterno imago www.kseniasecurity.com...
  • Page 2 Queste  apparecchiature  sono  state  sviluppate  secondo  criteri  di  qualità, affidabilità e prestazioni adottati dalla Ksenia Security. Si raccomanda di verificare il corretto funzionamento del sistema almeno una volta al mese. Le procedure per il collaudo dipendono dalla configurazione del sistema. Chiedere all’installatore del sistema le procedure da seguire. Ksenia  Security  srl  declina  ogni  responsabilità  nel  caso  in  cui  le  apparecchiature  vengano manomesse  da  personale  non  autorizzato.  Il  contenuto  di  questo  manuale  può  essere soggetto a modifiche senza preavviso e non rappresenta un impegno da parte della KSENIA SECURITY.
  • Page 3: Dati Tecnici E Funzionalità

    INTRODUZIONE La  sirena  da  esterno  autoalimentata  imago™  è  più  propriamente  un  avvisatore  acustico  e luminoso di livello professionale che presenta un design unico ed esclusivo, estremamente compatto e sottile (solo 6 cm. nel punto di maggiore spessore) unitamente ad una  tecnologia d'avanguardia  per  ottenere  prestazioni  d'eccellenza  con  il  massimo  risparmio  energetico: elevata pressione sonora,  lampeggiatore LED da 3W e led di segnalazione ausiliaria ad alta efficienza e bassi consumi. La sirena è completamente gestita da un microcontrollore che ne verifica tutte le condizioni e le segnala opportunamente.  imago™ (versione universale) dispone di nr. 3 ingressi per attivare le segnalazioni acustiche e luminose, facilmente abbinabili a qualunque centrale di allarme grazie alla programmazione della polarità degli ingressi. Alla prima accensione la sirena legge tutti gli ingressi ed abbina il corretto  stato  di  riposo  senza  bisogno  di  programmarli  manualmente,  salvando  la programmazione ...
  • Page 4 Coperchio  Perni (2) in acciaio INOX Sottocoperchio  Viti (2) di fissaggio sottocoperchio Asola per attivazione antisabotaggio Fondo trasparente Fori (5) di fissaggio fondo Fori (2) di fissaggio sottocoperchio  Foro per antistrappo 10. Asola per passaggio cavi 11. Mensola per batteria (1,2Ah) 12. Inserti (4) per fissaggio tromba 13. Inserti (4) per fissaggio scheda 14. Guidacavi (2)  15. Tromba esponenziale  16. Batteria 17. Scheda elettronica (morsetti) 18. Cavi (2)  r/n con faston 19. Morsettiera collegamenti 20. Microcontrollore 21. Microswitch (2) antisabotaggio/antistrappo 22. Connettore per tromba 23. Jumper  (3)  di  programmazione  (JP1‐JP3) (solo imago™ versione universale) 24.
  • Page 5: Funzionamento

    FUNZIONAMENTO La  scheda  elettronica  è  il  cuore  della  sirena  imago™  e  ne  permette  il  suo  corretto funzionamento, l'interfacciamento con la centrale, il controllo dei dispositivi annessi come la batteria  e  la  rispondenza  alle  normative  applicabili.  In  Figura  2  viene  riportata  l'immagine della  scheda  con  le  relative  parti  rilevanti  in  cui  l'installatore  è  chiamato  ad  impostare  e programmare le funzioni disponibili per le proprie esigenze.
  • Page 6 Alimentazione Morsetti di alimentazione 13,8V  Gli ingressi possono essere pilotati mediante uscite OC normalmente aperte o normalmente chiuse  (negativo  a  dare/mancare),  ma  anche  mediante  dei  relè  che  danno  o  tolgono  una tensione a 12 V (positivo a dare/mancare). All'accensione deve essere prevista una fase di apprendimento in cui la sirena stabilisce i valori di riposo. Tabella 2: imago™ versione KS-BUS MORSETTO TIPO DESCRIZIONE [A] [B] KS‐BUS Morsetti BUS Ksenia ‐ +  Alimentazione Morsetti di alimentazione 13,8V  Procedura di accensione La corretta procedura di accensione della sirena imago™ prevede inizialmente l'alimentazione tramite batteria (6V 1,2Ah Dimensioni: 98x50x22 ‐ non in dotazione) e poi il collegamento dei 13,8V proveniente dalla centrale antifurto. È fondamentale rispettare questo ordine. Qualora si fornisse prima l'alimentazione dei 13,8V, la sirena rimarrà in attesa del collegamento dei 6V tramite la batteria. Sirene da esterno imago...
  • Page 7 Una volta alimentata, la sirena emetterà un lampeggio singolo del led di potenza ed un breve suono sul buzzer questo per verificarne il funzionamento e farà lampeggiare i led rossi (1Hz ‐ lento) finché la sirena stessa sarà aperta (interruttori antisabotaggio aperti). Una volta chiuso il coperchio, i led lampeggeranno velocemente (2Hz) per 20s al termine del quale se la sirena sarà alimentata anche dalla 13,8V inizierà a far lampeggiare (300/700ms) il led di potenza per 20s, al termine del quale, se previsto acquisirà lo stato di riposo degli ingressi ed inizierà il funzionamento completo, altrimenti si metterà in modalità di basso consumo in attesa della presenza della alimentazione esterna. Se dovesse essere riaperta, riaccenderà di nuovo i led rossi,  tornando  allo  stato  precedente.  Una  volta  rilevata  la  presenza  della  alimentazione esterna la sirena farà lampeggiare il led di potenza per 20s, dopo ciò, se previsto acquisirà lo stato di riposo degli ingressi e inizierà il funzionamento completo.  La sirena imago™ suona e accende il led di potenza 300ms ON / 700ms OFF quando: 1 Viene a mancare l'alimentazione esterna (taglio fili) (tensione minore di 7,6V) 2 Va in allarme l'ingresso [AL] (solo imago™ versione universale). 3 La sirena viene aperta e JP1 è inserito (solo imago™ versione universale). 4 La sirena viena aperta (solo imago™ versione KS‐BUS) Nel caso 1 e 2 la condizione di allarme perdura finché sono attive le condizioni (mancanza di alimentazione  o  ingresso  in  allarme),  in  ogni  caso  per  il  tempo  massimo  di  allarme programmato da JP2, alla scadenza del quale se le condizioni di allarme sono ancora attive rimarrà ...
  • Page 8: Installazione

    Protezione  e test batteria La  sirena  imago™  andrà  in  modalità  di  basso  consumo  spegnendo  tutte  le  segnalazioni quando la tensione della batteria scenderà al di sotto di 5V. Aprirà il relè di sabotaggio, ed attiverà  l'uscita  guasto.  La  sirena  controllerà  l'efficienza  della  batteria  ogni  13  ore  per segnalare  un  eventuale  guasto  aprendo  l'uscita  OpenCollector  [F]  (solo  imago™  versione universale) (normalmente chiusa ‐ 500mA max). Funzione soft‐stop Se la tensione di alimentazione decresce lentamente (slew rate < 100mV/minuto) la sirena imago™ non suonerà per mancanza di alimentazione. Questo decremento è valido se rilevato...
  • Page 9 11 Verificare la procedura di accensione (pag.6) 12 Reinserire il sottocoperchio facendo attenzione a non toccare  il circuito ed avvitare  13 Chiudere il coperchio a scatto  (Figura 3) RUOTARE Figura 3.  Apertura della sirena. Sirene da esterno imago  ...
  • Page 10 DESCRIZIONE DEI MORSETTI  Positivo di alimentazione 13,8V ‐ Negativo di alimentazione M4 Antisabotaggio 24h bilanc. 10K Uscita Open Collector 1 Uscita Open Collector 2 Ingresso di zona N.B.: I nomi dei morsetti si riferiscono alle  centrali  Ksenia  serie  lares.  La sirena  imago™  può  essere interfacciata  a  qualsiasi  centrale antifurto  con  morsetti  aventi  le stesse funzionalità. Figura 4.  Collegamenti con la centrale L'alimentazione dei 13,8V sui morsetti [+] e [‐] della sirena, serve a  mantenere  carica  la  batteria  tampone  e  ad  ottenere  una protezione contro il taglio dei fili. ...
  • Page 11 The  complete  Declaration  of  Conformity  for  each  Device  can  be  found  at: www.kseniasecurity.com. Installation of these systems must be carried out strictly in accordance with the instructions described in this manual, and in compliance with the local laws and bylaws in force. imago™ has been designed and made with the highest standards of quality and performance adopted by Ksenia Security. Is recommended that the installed system should be completely tested at least once a month. Test procedures depends on the system configuration. Ask to the installer for  the  procedures  to  be  followed.  Ksenia  Security  srl  shall  not  be  responsible  for  damage arising from improper installation or maintenance by unauthorized personnel. The content of this guide can change without prior notice from KSENIA SECURITY. CERTIFICATIONS Region Certifications TM  Outdoor siren imago...
  • Page 12: Technical Data And Functions

    INTRODUCTION The outdoor self‐supplied siren imago™ is an acoustic/luminous professional alarm with an unique and exclusive, extremely compact and slim design (its maximum thickness is 6 cm.) together with an advanced technology to obtain performance of excellence with the highest energy  conservation:  high  sonic  pressure;    3  W  LED  blinker  and  auxiliary  high‐efficiency low‐consumption warning LED. The siren is completely managed by a micro‐controller which verify all conditions and report them opportunely.  imago™ (universal version only) has n° 3 inputs to activate acoustic and luminous alarms, easy to mach with any alarm station thanks to the input programmable polarity. During the first start‐up the siren reads all the inputs and matches the correct default status with no need to program them manually, saving the programming  on a flash memory: imago™ matches each one  of  the  three  inputs  (positive/negative  missing  or  start  with  positive/negative)  to  the correct function. The battery is kept under constant supervision and any malfunction or  out of energy is immediately signalled to the alarm station. imago™ is protected against cable cut, opening or removal from wall (tamper protection), and, despite of his small dimension, hides in the inside a tough metallic anti‐ breakthrough under‐cover. The used material (high quality PC with UV protection) and the sophisticated project grant long time endurance against all atmospheric agent.
  • Page 13 Cover  Stainless steel hinges (2) Undercover  Undercover locking screws (2) Tamper protection activation eyelet  Transparent base Base locking holes (5) Undercover locking holes (2)  Anti‐tear hole 10. Eyleto for cable pass‐through 11. Battery base (1,2Ah) 12. Horn docking inserts (4)  13. Board docking Inserts (4)  14. Chock (2)  15. Exponential Horn 16. Battery 17. PCB ‐ BOARD 18. Cables (2)  r/n with faston 19. Connection clamps 20. Microcontroller 21. Tamper protection/anti‐tear micro‐switch (2) 22. Horn Connector  23. Programming Jumper (3) (JP1‐JP3) 24. Debug Connector (not used) 25. Power central LED 3W 26.
  • Page 14: Operation

    OPERATION The PCB board is the  main component of the imago™ siren and allows its correct operation, the interface with the alarm station, the control of the related device (i.e. the battery) and the conformity with the applicable normative. Figure 2 shows the PCB board and its relevant parts for which the installer has to set and program the available function in accordance with the user needs.  Universal  version  imago™ jumper JP1 = Tamper Jumper inserted: Tamper ON Jumper removed: Tamper OFF JP2 = Alarm Time setting Jumper  inserted:  Alarm  time  3 min. Jumper  removed:  Alarm  time 10 min. JP3 = Inputs configuration Jumper  inserted:  polarity erasure. Jumper  removed:    polarity recording. Universal version KS‐ BUS version Figure 2.  PCB Board. outdoor siren imago...
  • Page 15 Power Supply Power supply  clamps 13.8V  The  inputs  are  controller  with  OC  outputs  normally  open  or  closed  (Start  with  negative/ negative missing), or with a power relay that give or  cut a 12V voltage (Start with negative/ positive missing). During the start up, an auto‐learning stage has to be set  to establish the default values.  Table 2: KS-BUS version imago™ [A][B] KS‐BUS Ksenia bus terminals ‐ +  Power Supply Power supply  clamps 13.8V  START UP Procedure The correct powering procedure of imago™ siren foreseen initially to power up through the battery (6V. 1,2Ah Dimensions: 98x50x22 mm ‐ not included) and then to power the 13,8Vdc coming from the Control Panel. It is fundamental to respect this order. Once powered, the siren will give just a single flash from its main power LED and the buzzer will  sound  for  a  second  to  verify  the  correct  functioning  of  all  parts  ;  moreover  the  red signaling ...
  • Page 16  If the siren will be re‐opened, the red LEDs will turn on, getting back to the previous mode.  Once the external power will be detected, the siren will let the power LED flash for 20 sec. and after that, if foreseen, the siren will then acquire the input stand‐by condition and start its full functioning.  The siren imago™ will sound  and the power LED will be flushing ( 300ms ON / 700ms OFF) when:  1 External power is missing (wire cutting‐ voltage is below 7,6Vdc). 2 The input [AL] goes in alarm (Universal version imago™ only). 3 The siren is being opened and JP1 is inserted (Tamper ON)(Universal version imago™ only). 4 The siren is being opened (KS‐BUS version imago™ only). In the case 1 e 2 the alarm situation will last until all conditions therefore are active (power missing or alarm input), in any case for the maximum alarm time programmed by JP2, at the end of which  if the alarm conditions still exist, the power LED will keep flashing with setting 300ms ON / 1700ms OFF. To re‐activate the acoustic signal it is necessary to reestablish the alarm condition. In  the  case  3  the  siren  activates  the  alarm  acoustic/flashing  for  the  programmed  time, regardless from the restoration of the tamper condition. Programming (universal version imago™ only) imago™ is available with the following functions, programmable through Jumpers: 1 Tamper signal on/off (JP1) 2 Buzzer timing set‐up (3 or 10 minutes) (JP2) 3 Inputs configuration (JP3) Programmable inputs (universal version imago™ only) During the start‐up, if JP3 is inserted, the siren will delete the settings of the inputs polarity,...
  • Page 17: Installation

    Protection and battery test  When  the  battery  voltage  is  lower  than  5V  the  imago™  siren  will  set  the  low  energy consumption mode. It will open the tamper protection relay and it will activate  the "failure" output. The siren will check the battery efficiency each 13 hours to report a possible failure opening the "Open collector" output [F] (universal version imago™ only)(normally closed ‐ 500 mA max). Soft‐stop function When the power supply voltage slowly decreases (slew rate < 100 mV/minute) the imago™ siren will not emit any acoustic alarm due to loss of power supply. This slew rate is effective if detected starting from the initial voltage (higher than 12V) to 10,5V, then the alarm activation will be prevented even in case of a sudden loss of voltage. This peculiar function allows to avoid the acoustic warning and to impair the efficiency and life‐time of the battery in case of protracted loss of power supply.  INSTALLATION The siren has to be installed in a hardly accessible location to deter tamper attempt. The wall chosen  must  not  have  any  depression  or  protrusion  in  order  to  avoid  compromising  the tamper ...
  • Page 18 TWIST Figure 3.  Siren opening. outdoor siren imago...
  • Page 19 [O1]  and  [O2]  of  the  alarm  station.  Moreover  the  failure  output  [F]  is connected to a zone input  [i1] of the alarm station (i.e. to program an action as the activation of a vocal call or SMS or e‐mail with a "Battery failure" message). TERMINALS DESCRIPTIONS  Power positive 13,8Vdc ‐ Power negative Ω M4 Tamper 24hr balanced 10K Open Collector 1 output Open Collector 2 output Zone input N.B.:  The  terminals  names  refer  to Ksenia Control Panel seris lares. The imago™ Universal siren can interface any  Intrusion  Control  Panel  having terminals with same functions. Figure 4.  Connections with the alarm stations. 13,8V voltage of the terminals  [+] and [‐] of the siren, keeps the backup battery charged and provides a protection against cables cut.  If the alarm station doesn't have open collector outputs, relay free exchange of the alarm station can be used to simulate the required voltage (start with positive) on the input terminal of the imago™ siren. Example: There’s the need to have the siren LED blinking when an ...
  • Page 20            imago™ è stato progettato con le seguenti caratteristiche per ridurne l'impatto  ambientale: • Assenza di PVC                                                                                 • Laminati per circuiti stampati senza piombo e bromo   • Basso assorbimento • Imballo realizzato per la maggior parte con fibre riciclate e materiali provenienti da  fonti rinnovabili          imago™ was designed with the following characteristics to reduce environmental impact: • No PVC • The laminates for the printed circuit‐boards are lead and bromine‐free • Low adsorbtion • Packaging made mainly with recycled fibres and material from renewable sources.    we care ! Direttiva Rifiuti di apparecchiature elettriche ed elettroniche (RAEE ‐ WEEE) Questo prodotto NON deve essere smaltito insieme ai rifiuti domestici. Riciclare presso impianto adeguato. Directive on Waste from electrical and electronic equipment (RAEE ‐ WEEE)  This product must not be disposed of together with domestic waste.  To be taken to an appropriate site for re‐cycling. www.kseniasecurity.com...
