Raypak AVIA 404 Installation & Operation Manual
Gas-fired pool and spa heater
Hide thumbs
Also See for AVIA 404:
- Quick reference manual (49 pages) ,
- Installation and operation manual (158 pages)
Table of Contents
Advertisement
Quick Links
INSTALLATION & OPERATION MANUAL
Gas-Fired Pool
and Spa Heater
Models: 264 and 404
NOTICE
SCAN WITH QR EQUIPPED SMART
DEVICE FOR ONLINE MANUAL.
WARNING: If the information is not followed exactly, a fire or explosion may result causing property
damage, personal injury or death.
— Do not store or use gasoline or other flammable vapors and liquids or other combustible materials
in the vicinity of this or any other appliance. To do so may result in an explosion or fire.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This manual should be maintained in legible condition and kept adjacent to the heater or in a safe place for future
reference.
™
HE AT EX CH AN G ER T EC H N OL OG Y
Effective: 06-21-24
Replaces: 04-15-24
P/N: 100-10000111 Rev. 08
