INSTALLATION AND
OPERATION MANUAL
Gas-Fired Pool
and Spa Heater
Low NOx Models 207A, 266L,
267A, 337A, 399L, and 407A
WARNING: If the information is not followed exactly, a fire or explosion may result causing property
damage, personal injury or death.
— Do not store or use gasoline or other flammable vapors and liquids or other combustible materials
in the vicinity of this or any other appliance. To do so may result in an explosion or fire.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This manual should be maintained in legible condition and kept adjacent to the heater or in a safe place for future
reference.
Catalog No. 6000.592A
Effective: 11-15-19
Replaces: 10-01-19
P/N 241793 Rev 1
Advertisement
Table of Contents
Related Manuals for Raypak Low NOx Series
Summary of Contents for Raypak Low NOx Series
- Page 1 INSTALLATION AND OPERATION MANUAL Gas-Fired Pool and Spa Heater Low NOx Models 207A, 266L, 267A, 337A, 399L, and 407A WARNING: If the information is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. —...
- Page 2 QUICK START GUIDE CLEARANCES WATER CHEMISTRY † Space required: See page 11. † Water chemistry requirements: See page 5. † Minimum and service clearances: See page 7 for clearances table. Note that local codes prevail. POWER † Supply voltage: See page 20 for acceptable input voltages.
-
Page 3: Table Of Contents
CONTENTS 1. WARNINGS ............. 4 5. ELECTRICAL WIRING ......... 19 Pay Attention to These Terms ......... 4 Electrical Power Draw ........... 20 Transformer Wiring ..........20 2. WATER CHEMISTRY ..........5 6. WIRING DIAGRAM ..........21 Automatic Chlorinators and Chemical Feeders..5 3. -
Page 4: Warnings
1. WARNINGS Pay Attention to These Terms Indicates the presence of immediate hazards which will cause severe personal injury, death or DANGER substantial property damage if ignored. Indicates the presence of hazards or unsafe practices which could cause severe personal injury, WARNING death or substantial property damage if ignored. -
Page 5: Water Chemistry
For your health and the protection of your pool equipment, CAUTION: Elevated water temperature can be it is essential that your water be chemically balanced. The hazardous. The U.S. Consumer Product Safety following levels must be used as a guide for balanced Commission has these guidelines: water. -
Page 6: Before Installation
Be sure that you receive the number of packages indicated 3. BEFORE INSTALLATION on the Bill of Lading. Receiving equipment Rating and certifications The manufacturer recommends that this manual be reviewed thoroughly before installing the pool/spa heater. If These heaters are design-certified and tested under the there are any questions that this manual does not answer, latest requirements of the ANSI Z21.56 / CSA 4.7 Standard please contact the factory or your local representative. -
Page 7: Installation Codes
When installed according to the listed minimum clearances WARNING: Improper installation, adjustment, from combustible construction, the pool heater can still be alteration, service or maintenance may damage the serviced without removing permanent construction around equipment, create a hazard resulting in asphyxiation, the heater. - Page 8 surface of the heater shall be at least 3' (0.9 m) above Distance Description Location any forced air inlet, or intake ducts located within 10' (3 m) in. (mm) horizontally. Back 9 (229) Right 9 (229) For Canadian installations, pool heaters shall not be a.
-
Page 9: Combustion And Ventilation Air
or Canada CAN/CSA-B149) and any local codes that For Canada, indoor installation is restricted to an enclosure may have jurisdiction. The most common approach is that is not occupied and does not directly communicate the "2-opening" method, with combustion air opening no with an occupied area. - Page 10 Florida and Texas Building Code: Wind Speed = 150 mph 3 sec gust Exposure = C 31-13/16" Model (792 mm) in. (mm) 207A 20 (508) 266L/267A 23 (584) 337A 26 (660) F10649 399L/407A 29 (737) 28" (709 mm) 2" x 6" x 1/8" Pallet Anchor Bracket (4 Total) (Kit# 011636) 3"...
- Page 11 Specifications and Dimensions Amp Draw 120 VAC, 1 Ph, 60 Hz 240 VAC, 1 Ph, 60 Hz FLUE 10" (254 mm) 8-7/8" (225 mm) 4-3/8" (6-5/8" ASME) (111 mm) INDOOR (168 mm ASME) DRAFTHOOD 34" (867 mm) STACKLESS 31-13/16 " OUTDOOR (792 mm) 26-1/2"...
-
Page 12: Vent Piping
