- Page 1 HSC-1600-M MULTI-WIRE CONTROLLER INSTRUCTION MANUAL 888.203.1179 915 Overland Street, North Salt Lake, UT 84054, USA www.HydroRain.com...
-
Page 2: Table Of Contents
HSC-1600-M INSTALLATION & USER MANUAL TABLE OF CONTENTS WELCOME TO THE HYDRO-RAIN FAMILY ® HSC CONTROLLER B-HYVE ® NEED HELP? KEY FEATURES SYMBOL DEFINITIONS HSC HARDWARE ETHERNET CONNECTION (1) USB POWER PORT (2) ANTENNA (3) DISPLAY (4) BUTTONS (5) CELLULAR ANTENNA (6) - Page 3 ASSIGN MASTER VALVE AND PUMP STARTS FLOW SENSORS RAIN SENSORS LED LIGHTS MODULE LED’S TROUBLESHOOTING UPDATE FIRMWARE APP ISSUES COMMUNICATION PROBLEMS BEHAVIOR THAT IS NOT UNUSUAL WI-FI HARDWARE ISSUES FACTORY RESET CONTROLLER SHEETS 19-20 DECLARATION OF CONFORMITY PRODUCT SPECIFICATIONS Copyright© 2024 Hydro-Rain All Rights Reserved...
-
Page 4: Welcome To The Hydro-Rain ® Family
Pro app to program the HSC Controller ® from your app store or scan the relevant QR code below. Need Help? Contact Hydro-Rain Product Support : 1-888-493-7672 ® The friendly Hydro-Rain® Product Support team is available to help with setup, programming, and troubleshooting questions. -
Page 5: Key Features
10 – 200% • App and Dashboard training • The SMART scheduling engine optimizes available at the Hydro-Rain Academy by seven factors like plant type, soil, professional.training.hydrorain.com sprinkler, sun exposure, and slope • 2 integrated flow meter inputs, assignable by zone •... -
Page 6: Symbol Definitions
HSC-1600-M INSTALLATION & USER MANUAL Symbol Definitions The following symbols represent safety codes specific to this product. These are noted in this installation manual for protection and safe operation of this product. A property damage only hazard, meaning no An immediately hazardous situation. If the NOTICE personal injury is possible. -
Page 7: Getting Started
Getting Started Prior to installing the new HSC controller, take a moment to inspect the enclosure and contents of the package (see Figure 1). It should include: • The HSC controller • Two keys, model CH751 • Three stainless steel screws •... -
Page 8: Installing The Controller
Evaluate the Wi-Fi signal at the controller’s proposed location by viewing the signal strength of the network in the device settings of a mobile phone. If the signal strength is low, consider purchasing a Wi-Fi range extender. If outdoors, Hydro-Rain recommends an extender rated ®... -
Page 9: Wall Mounting Instructions
Wall Mounting Instructions Step 1 – Remove the outer door and set it aside where it won’t be damaged during installation. Step 2 – Drill the top hole first at the appropriate height, so the user can see the display. Insert the anchor, if needed, and the screw. -
Page 10: Wiring
Remove the appropriately sized knockout for the field wire you have. Run the wire path in conduit until it is below grade. Hydro-Rain recommends using approved electrical conduit and watertight connectors going into the HSC enclosure. Conduit to 120 V/240 V source... -
Page 11: Transformer
Transformer The HSC has a dual-voltage transformer behind a safety enclosure. The HSC controller’s transformer is adaptable to single phase 120 and 240 voltage inputs. WARNING: TURN OFF THE POWER TO THE CONTROLLER BEFORE WORKING WITH THE TRANSFORMER AND WIRING. TURNING THE ON/OFF SWITCH DOES NOT TURN OFF THE POWER INTO THE TRANSFORMER. ALWAYS FOLLOW APPLICABLE ELECTRICAL CODES. -
Page 12: Multi-Wire Module
HSC-1600-M INSTALLATION & USER MANUAL 120-VOLT WIRING 240-VOLT WIRING DIAGRAM DIAGRAM BLACK (HOT) BLACK (NOT USED) BLUE (NOT USED) BLUE (HOT) LEVERED LEVERED WIRE WIRE CONNECTORS CONNECTORS INCLUDED INCLUDED WHITE (NEUTRAL) WHITE (HOT) GREEN WITH GREEN WITH YELLOW STRIPE YELLOW STRIPE (GROUND) (GROUND) Figure 7. -
Page 13: Grounding
When adding modules to the HSC, first turn off the power to the controller at the On/Off Switch. Look at the slots on the back of the module. The slots are configured so that the alignment pins insert into the middle of the slot. The module should then be able to slide up into the ten-pin connector of the HSC or the module above it. - Page 14 HSC-1600-M INSTALLATION & USER MANUAL Step 2 - Install a #6 AWG solid copper wire from the grounding lug in the controller to a ground rod and ground plate. FOR INDOOR INSTALLATIONS OF THE IRRIGATION CONTROLLER, LOCATE AND SECURE THE NOTICE GROUND WIRE TO A COLD-WATER PIPE.
-
Page 15: Setup At The Controller
Setup at the Controller When the HSC first powers on, it will show the controller MAC ID, firmware version, and the display will show, “For full functionality use the B-hyve Pro app.” ® The HSC controller was designed with the intention of having the phone app be the primary interface. -
Page 16: Master Valve / Pump Start
HSC-1600-M INSTALLATION & USER MANUAL Master Valve / Pump Start WIRE RUNS SHOULD BE CONTINUOUS WITHOUT ANY WIRE SPLICES. NOTICE IT IS RECOMMENDED THAT SOME MARKING OR IDENTIFICATION BE NOTED ON THE INSIDE DOOR NOTICE OF THE HSC CONTROLLER, SO THE EXISTENCE OF MASTER VALVES AND PUMPS IS KNOWN WHEN TROUBLESHOOTING. -
Page 17: Rain Sensors
To attach a rain sensor, remove the small piece of wire or “wire jumper” from the terminal and connect the rain sensor wiring according to manufacturer’s instructions. Hydro-Rain recommends using HRC-100 series rain sensors, but any manufacturer’s power-interrupt-style sensor will work. This includes soil moisture sensors that operate on the power-interrupt principle. -
Page 18: Led Lights
HSC-1600-M INSTALLATION & USER MANUAL LED Lights on the Controller & Modules The LED lights on the HSC illuminate with distinct colors and flashing patterns to let you know where or when an Alert, Caution, or irrigation is taking place. These can be helpful when troubleshooting the controller. -
Page 19: Module Leds
Module LEDs The LEDs on the Multi-wire modules can also help you understand what is happening with specific zones and troubleshoot issues with the controller. Colors and pattern are in the chart below. COLOR PATTERN MEANING SOLID Zone Fault, or No Flow (if a Flow Sensor is installed) YELLOW SOLID Rain Sensor Delay... -
Page 20: Communication Problems
HSC-1600-M INSTALLATION & USER MANUAL Communication Problems Like any connected device, the HSC must be reconnected if you have trouble with the router, change your Wi-Fi service, or the ethernet provider changes security settings (like firewalls). Update your settings as needed. If your B-hyve Pro app says the HSC is disconnected, try the following steps to reconnect. -
Page 21: Hardware Issues
Rain sensor jumper wire: removing the rain sensor jumper wire when a rain sensor is not attached will cause the controller to act abnormally. Any wire connected from the negative terminal to the positive terminal (top to bottom) can function as a jumper. Hydro-Rain recommends an insulated wire so accidental shorts cannot take place. - Page 22 HSC-1600-M INSTALLATION & USER MANUAL...
-
Page 24: Fcc & Ic Statement
HSC-1600-M INSTALLATION & USER MANUAL FCC & IC Statement This device complies with Part 15 of the FCC Rules and Industry Canada license exempt RSS standards. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 25: Declaration Of Conformity
EU & UK Declaration of Conformity Pro-Mark, LLC 845 Overland Rd. North Salt Lake, UT. 84054, USA Declares under our sole responsibility, that the products: High Station Count Controller HSC-1600-M (Model # 04550) and HSC-6300-D (Model # 04554) comply with the following: European Directive 2014/53/EU and UKCA Radio Equipment Regulations 2017, SI 2017:1206 (as amended by SI 2019:696) with reference to the following standards:... -
Page 26: Product Specifications
HSC-1600-M INSTALLATION & USER MANUAL Product Specifications Enclosure Specifications Water-resistant, NEMA 3R Wall Mount Enclosure Height: 16 3/8 inch (14.6 cm) Width: 11 1/4 inch (28.6 cm) Depth: 5 1/4 inch (13.3 cm) Weight: 15 lbs 6 oz (6.97 kg) See knockouts and through-holes on page seven and in Figure 4. - Page 28 04550-50 rB 888.203.1179 915 Overland Street, North Salt Lake, UT 84054, USA www.HydroRain.com...
