Mark-10 WT-205 Quick Start Manual

USER'S GUIDES LINKS
Model WT-205
mark-10.com/manualwt-205
Model WT-205M
mark-10.com/manualwt-205m
Download user's guides,
data sheets, software,
solid models, and more.
mark-10.com/resources
11 Dixon Avenue, Copiague, NY 11726
888-MARK-TEN  Tel: 631-842-9200
www.mark-10.com  info@mark-10.com
Wire Crimp Pull Testers
Models WT-205 / WT-205M
Thank you!
Thank you for purchasing a Mark-10 WT-205 / WT-205M wire crimp pull tester,
designed for applications up to 200 lbF (1,000 N). With proper usage, we are
confident that you will get many years of great service with this product. Mark-10
instruments are ruggedly built for laboratory and industrial environments. Please
read through this quick start guide and the complete user's guide before using the
tester.
IMPORTANT SAFETY CONSIDERATIONS
Wire crimp pull testers are sensitive instruments that must be treated with care.
Please review the yellow safety information card included in the box, as well as the
safety information provided in the user's guide prior to operating the tester.
POWER
Model WT-205
Press the button to power on the tester. Press and hold to power off. The tester
may be powered either by the internal rechargeable battery or an AC adapter. The
battery will last approximately 7 hours with the backlight turned on, or 24 hours
with the backlight turned off.
Model WT-205M
Plug one end of the power cord into its receptacle at the rear of the tester and
the other end into a wall outlet with local earth ground (3-prong connector). Then,
toggle the power switch adjacent to the power cord receptacle. Follow all safety
information provided in the user's guide.
32-1276
0525
QUICK START GUIDE
1
