Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide

Table of Contents

Need help?

Do you have a question about the FlexSym OLT-mini Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Tellabs FlexSym OLT-mini Plus

Page 2: Tellabs® Information
Information in this publication is subject to change without notice. Trademarks The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United ® ®...
Page 3: Table Of Contents
Add ONT · Contact Us · This document provides instructions to install and turnup the Tellabs® FlexSym OLT-mini optical line terminal. This document is intended for technicians responsible for: Page 3 of 71 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 4: Document Revisions
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Selecting and preparing the install location · Unpacking and assembling any accessories · Mounting the Wall-Mount Swing Rack on the wall (if used) · Installing the CBA1048 in the Wall-Mount Swing Rack or a standard equipment rack ·...
Page 5: Related Documentation
DC/Alarm Cable Assembly · The Tellabs FlexSym OLT-mini Plus supports both ITU-T 984 G-PON and ITU-T G.9807/G.987 XGS-PON 10G connectivity to Optical Network Terminals (ONT). It provides flexible choices for designing a modern enterprise network to exactly align with contemporary connectivity such as IoT, wireless, open/shared office and smart buildings Page 5 of 71 ©...
Page 6: General Features
104°F (-10°C to 40°C). SSHv2 CLI Interface: The standard Tellabs CLI craft interface is supported for turn up and debugging of the · unit. Standard Panorama PON Interface: The Tellabs Panorama PON software will manage the OLT-mini Plus ·...
Page 7: Software Support
· SECURITY Tellabs has implemented unique advanced security features to protect enterprise networks. The OLT-mini Plus supports security across the optical distribution network and end-to-end over the OLAN system; such as encryption of traffic on the PON using the Advanced Encryption Standard AES-128 and Access Control Lists (ACL) at Layer 2 through 4 levels.
Page 8 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 2x PON Ports: The OLT-mini Plus supports 2x PON ports. The ports can be either GPON or XGS-PON. The · PON modes cannot be mixed. 4x 10/1 SFP+ Ports: The OLT-mini Plus supports 4x OLT PON ports, typically intended to be daisy chained to ·...
Page 9 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Green Blink Fast When the ACTV indication is green blinking fast (Initializing), the LED blinks at a ½ second (½ second on, ½ second off) duty cycle to indicate the unit is currently in the process of initializing.
Page 10: Operations, Administration And Maintenance (Oam)
OLT-MINI PLUS CARD CAGE The Tellabs 1048 CBA is a compact card cage with a PCB backplane designed for Tellabs 1000 Series plug-in cards. It has four common control slots for processing and power cards, and 10 multipurpose slots for narrowband and broadband cards.
Page 11 The fans in the Fan Tray are temperature-controlled variable-speed units for quiet, efficient operation and are alarmed. Note: Tellabs recommends that a Fan Tray always be used to ensure adequate cooling of cards installed in a shelf card cage. Overheated cards may exhibit reduced reliability and shorter service life.
Page 12 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide CBA1048 FEATURES The Tellabs 1048 CBA has the following features: 5 Slots for Tellabs OIU2 cards (each card is double wide) · Tri-bus backplane 6.2 Gbps (TDM, ATM, and High-Speed) · Front panel craft port (RS-232) ·...
Page 13 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide INSIDE THE CBA1048 BOX Because there are various Tellabs 1048 CBA card cage mounting and optional accessory configurations, the CBA1048 and all accessories are sold separately. The Tellabs 1048 CBA box contains: Tellabs 1048 MSAP Channel Bank Assembly (CBA) card cage ·...
Page 14 The swing rack has room for the Tellabs 1048 CBA card cage in the middle, and a Rectifier Shelf above and a Fan Tray below the CBA1048 card cage (both optional). Standard 12-24 Telco rack screws secure the equipment to the rack.
Page 15 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Inside the Wall Mount Swing Rack Box The Wall-Mount Swing Rack, when ordered as a separate accessory, is shipped flat and must be assembled before installation. Note: When the CBA1048 is ordered as a complete, pre-assembled unit, assembly of the swing rack is not required.
Page 16 EQUIPMENT RACK MOUNTING BRACKET FOR 19-INCH RACKS The Equipment Rack Mounting Bracket allows the Tellabs 1048 CBA card cage, Rectifier Shelf, and a Fan Tray to be installed in a standard 19-inch equipment rack. It is made from heavy-gauge zinc-plated steel and has mounting holes in the appropriate locations.
Page 17 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Slots punched near the bottom of the mounting bracket allow cables from the front of the CBA1048 card cage, Rectifier Shelf, and Fan Tray to be routed to the rear without taking up additional vertical rack space. The rear surface of the mounting bracket provides an area to manage excess cable lengths using magnetic cable anchors.
Page 18 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Physical · Height: 1.7 in (4.3 cm), 1 RU · Dimensions Width: 9.8 in (24.9 cm) · Depth: 11.3 in (28.7 cm) Weight 7 lbs (3.2 kg) Material Zinc-plated steel Airflow 800 CFM, maximum (200 CFM per fan) Expected service life 70,000 hours at 77º...
Page 19: Rectifier Shelf
The Rectifier Shelf is 1 RU tall and 10 inches wide, and has space for two 600-Watt, hot-swappable, Rectifier Modules (sold separately). It mounts in the top location of the Wall-Mount Swing Rack, above the Tellabs 1048 CBA card cage.
Page 20: Rectifier Modules
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide RECTIFIER MODULES Rectifier Modules for the Rectifier Shelf are hot-swappable and convert AC line power to 53.5 VDC at up to about 16 Amps, maximum. With a 120 VAC input, the Rectifier Module is limited to 600 Watts output.
Page 21 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide The Rectifier Module monitors itself for under- and over-voltage output, output overload, and over-temperature conditions. If any parameter is found to be out of range, the Rectifier Module shuts off. AC Input...
Page 22 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide EMI FRONT COVER The EMI Front Cover reduces electromagnetic emissions emanating from the front of the Tellabs 1048 CBA and helps direct airflow from the Fan Tray (optional) upward through the plug-in cards installed in the CBA1048.
Page 23: Fuse Locations And Ratings
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide An in-line fuse block assembly is part of the cable and attaches to the inside of the left panel of the Wall-Mount Swing Rack with two screws. The cable ships with fuses pre-installed.
Page 24: Site Preparation
(optional), and the Fan Tray alarm output to the CBA1048 fan alarm input. DC supply A and B wires are pigtails, allowing the greatest connection flexibility to the DC supply. It is intended for use with external (non Tellabs-supplied) fuse/breaker panels and DC power sources.
Page 25 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide TOOLS The following tools should cover most typical CBA1048 installations: Screwdrivers: · Medium slot (3/16 to 1/4 inch) Numbers 0, 1, and 2 Phillips Number 2 Robertson square drive Large slot (1/2 inch) — one with a very long shaft (>13 inches) will be handy for tightening the thumbscrews on the right side of the Wall- Mount Swing Rack, particularly in installations with limited clearance on the right side.
Page 26: Unpacking And Checking
· UNPACKING AND CHECKING The Tellabs CBA1048 and related accessories to be installed may arrive in a single shipping container, in multiple containers, or fully assembled in a single box. When unpacking the boxes, check the contents against the installation work order and check each item for obvious shipping damage.
Page 27: Site Requirements
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide SITE REQUIREMENTS The facility grounding system must comply with EIA/TIA-607 Grounding and Bonding Requirements for Telecommunications in Commercial Buildings, United States Department of Agriculture Rural Utilities Service (RUS) Bulletin 1751F-810, and/or local practices, as applicable.
Page 28: Equipment Rack
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide AC Power When installed in the optional Wall-Mount Swing Rack, power for the CBA1048 will typically come from the optional Rectifier Shelf mounted in the top position of the swing rack. One or two Rectifier Modules can be installed in the Rectifier Shelf.
Page 29 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide WALL MOUNT SWING RACK The optional Wall-Mount Swing Rack can be attached to a wall or other surface that can support the 40-pound (18.1 kg) weight of the fully-loaded swing rack. A flat area of a wall that is approximately 14 inches tall by 29 inches wide is required.
Page 30 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Wall Area Required The swing rack needs a clear, flat area on the wall (or other surface) that is about 14 inches tall and 29 inches wide to allow the rack to swing a full 90 degrees for best access to the rear of the CBA1048 backplane. The supplied paper template is this size when cut out with scissors.
Page 31: Safety Precautions
Warning! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but ·...
Page 32: Electrostatic Discharge (Esd)
Electrostatic Discharge (ESD) Observe and follow all ESD instructions while handling Tellabs plug-in equipment. Caution! The Tellabs plug-in equipment uses semiconductor devices that can be damaged by electrostatic discharge (ESD). Do not remove a plug-in from a protective packing box or equipment rack until time of installation or replacement. To equalize the static charge on the plug-in, establish a body path to ground using an ESD wrist strap connected to a ESD ground.
Page 33: Product Disposal
Personnel installing Tellabs equipment on walls or other surfaces must be certain that the wall and fasteners used can support the weight of the equipment (approximately 40 lbs (18.1 kg), maximum).
Page 34 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Connecting the DC Power/Alarm Wiring to CBA1048 Backplane · Installing the Fuse Block Assembly · Installing the CBA1048 Card Cage · Installing the Fan Tray · Installing the Rectifier Shelf · Installing the Rectifier Modules in the Rectifier Shelf ·...
Page 35 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Installation will generally include the following tasks: 1. Assembling the Wall-Mount Swing Rack 2. Mounting the swing rack on the wall or other surface 3. Connecting ground, and DC power and fan alarm wiring to the CBA1048 card cage 4.
Page 36 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Assembling the Wall Mount Swing Rack The optional Wall-Mount Swing Rack, when ordered as a separate accessory, is shipped flat and must be assembled before mounting on a wall or other surface.
Page 37 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 1. Select a work area that is large enough to lay the swing rack parts out in their relative positions. The empty swing rack weighs about 11 pounds and has lots of pointy corners and some exposed hex screw heads, so pick a work surface that will not matter if it gets some scratches and a few gouges as the swing rack is assembled.
Page 38 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 8. Orient the right side panel/crossmember assembly so that it is resting on the three wall mounting brackets and hinge again if its orientation was changed. 9. Place the left side panel in its approximate final position, with the flanges to the right and the crossmembers inside the flanges.
Page 39 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Have the assembled swing rack, paper template, scissors, and the tools and fasteners that will be needed for this task nearby. 1. Select the general location for the installation in accordance with the details in the Site Selection section, above (wall material, proximity to power and other equipment).
Page 40 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 9. Label the swing rack wall mounting brackets 1, 2, 3, from top to bottom, then mark the outboard hole (furthest to the right) on each. Loosen and disengage the thumbscrews from the three wall mount brackets along the right side of the swing rack.
Page 41 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide DC supply A and B wires have Molex connectors that match those on the Rectifier Shelf on the input, and end in ring terminals that must be attached to the DC power input terminal block on the CBA1048 backplane. The fan alarm cable ends in a small Nylon connector that plugs into the backplane.
Page 42 Note: The wire color/terminal name assignments are different from those used when the CBA1048 is installed in the Wall-Mount Swing Rack. Note: If the DC power polarity is reversed, the Tellabs equipment will NOT be damaged. It just will not operate until the DC power polarity is corrected.
Page 43 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Installing the Fuse Block Assembly The Fuse Block Assembly is part of the DC/Alarm/Fuse Block Cable Assembly, which is generally used only with the Wall-Mount Swing Rack. The fuse block assembly must be installed on the left side panel, inside the swing rack: 1.
Page 44: Installing The Fan Tray
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 10. Hold the fuse block assembly metal housing flanges against the left side panel and position it so that its mounting holes are over the holes in the left side panel. Again, make sure that no wires are under the edge of the metal housing.
Page 45 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide INSTALLING THE RECTIFIER SHELF The Rectifier Shelf is installed in the top position of the Wall-Mount Swing Rack: 1. Place the Rectifier Shelf in the swing rack at the top position and push it all the way in.
Page 46 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 4. The front panel of the Rectifier Module has an ejector lever on each side. Only the lever on the left side is used with the Rectifier Shelf. 5. Use a small slotted or #0 Phillips screwdriver to loosen the captive screw at the top of the left side ejection lever and pull the lever down to its fully open position —...
Page 47 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide To remove a Rectifier Module: 1. Follow steps 1 through 3 of the Rectifier Module installation procedure, above. 2. Use a small slot or #0 Phillips screwdriver to loosen the captive screw at the top of the left side ejection lever of the module to be removed.
Page 48: Equipment Rack Installation
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Previous Next Equipment Rack Installation The CBA1048 and Fan Tray accessory can be installed in a standard 19-inch equipment rack using an optional Equipment Rack Mounting Bracket. Ensure that an Equipment Rack Mounting Bracket of the appropriate size is available.
Page 49 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Installation will generally include the following tasks: 1. Connecting DC power and fan alarm wiring to the CBA1048 card cage 2. Attaching the Fan Tray, Rectifier Shelf, and CBA1048 card cage to the Equipment Rack Mounting Bracket 3.
Page 50 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide the Nylon cable ties can be tightened later after installation is complete and the final layout of the cable is determined. 5. Using a #2 Phillips or medium slot screwdriver, loosen the following five screws from the CBA1048 barrier...
Page 51 A/B N+ = Red A/B P+ = Black Note: If the DC power polarity is reversed, the Tellabs equipment will NOT be damaged. It just will not operate until the DC power polarity is corrected. 7. Plug the fan alarm cable connector (P30) into the P30 connector on the CBA1048 backplane.
Page 52 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Attaching the CBA 1048 and Fan Tray to the Equipment Rack Bracket The CBA1048 card cage and Fan Tray are attached to the Equipment Rack Bracket with standard rack screws. 1. Set the Fan Tray on the work surface with the front panel nearest you.
Page 53: Oiu2 Card Installation
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Installing the CBA1048/Fan Tray Assembly Ensure the installation location in the equipment rack has at least 7 rack units of vertical space available. While the CBA1048/Fan Tray/Rectifier Shelf assembly is 6 RU high, an additional 1 RU of empty space should be allowed below the Fan Tray to provide unobstructed airflow for the Fan Tray intake.
Page 54: Splitter Installation
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Observe and follow all ESD instructions while handling Tellabs plug-in equipment. Caution! The Tellabs plug-in equipment uses semiconductor devices that can be damaged by electrostatic discharge (ESD). Do not remove a plug-in from a protective packing box or equipment rack until time of installation or replacement. To equalize the static charge on the plug-in, establish a body path to ground using an ESD wrist strap connected to a ESD ground.
Page 55 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Caution : Do not bend the fiber optic cable to a diameter smaller than 7.5cm/3 inches. Doing so may damage the fiber or prevent the signal from passing through properly. Splitters in Passive Optical Networking (PON) installations are used to split the light coming from the OLT laser into multiple ONT fibers that go to each of the ONTs.
Page 56: Olt Turnup
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 6. It is important that the secondary PON fiber not be connected until after the PPG has been configured when using PON protection. Plugging both in without a PPG configured will cause both to transmit light and interfere which prevents the system from bringing up the ONTs properly. ...
Page 57 The OLT is equipped with an embedded μUSB (microUSB) to serial port interface which provides direct access to the Command Line Interface (CLI) found on all Tellabs OLTs. To use this interface, attach a cable from the OLT μUSB port to a USB2 or USB3 port on a PC.
Page 58 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 2. Log into the OLT CLI. The initial username and password for the system is: admin/tellabs login as: _ Connect from xxx.xxx.xxx.xxx password for (admin): _ 3. On initial login, the administrative password must be changed. The system will prompt for the current Enter password in order to allow the change.
Page 59 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Note 2: CLI commands, parameters and options can be entered using abbreviations. The abbreviations are specified using capitalization in the help listings and context menus. For example, the wizard command is displayed in the help listing as .
Page 60 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Note: The example below assumes that only 1 uplink module was initially installed. The management VLAN and IP configuration used in the example are for demonstration purposes only. Use the appropriate data for your specific installation.
Page 61 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Number of Ports The number of ports to be bundled in the uplink LAG. Up to four (4) ports are allowed. On initial turnup, it is easiest to have only 1 port installed and configured in the NET1 Interface. Additional ports can be installed and provisioned once the OLT is added to Panorama PON.
Page 62 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide 9. When the Wizard finishes gathering data, a summary is displayed for confirmation. To accept the Enter configuration and perform the turnup, input at the prompt and press . The turnup configuration will be applied and the OLT restarted if necessary.
Page 63: Add Oiu2 To Panorama Pon
Add OIU2 to Panorama PON After the OIU2 or OLT-mini has been initially configured (or turned up) it can be added to the Tellabs Panorama PON element management system (Panorama). Panorama is a graphical user interface (GUI) that provides end-to-end management of the Optical LAN.
Page 64 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Selecting the ERASE option tells the system to cleanup any residual provisioning that might result from component reuse. The data collected during the OLT turnup process will not be erased. Fill in the OLT Configuration Dialog for the OLT-mini or OLT-mini Plus: ·...
Page 65 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Select the radio button for the Type of OLT-mini: OLT-mini or OLT-mini Plus Verify that the slot number is correct for the installation Enter the Target Identifier (TID) in the Target Identifier text box.
Page 66: Add Ont
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Finish Panorama will add the OLT. This will take a few minutes. When the add is completed, click the button. · Previous | Next Add ONT Page 66 of 71 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 67 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide ADDING AN ONT TO PANORAMA An ONT must be added to the EMS from the EMS GUI. This can be done in one of several ways: Configuration via the Unexpected ONT menus ·...
Page 68 Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide User Label: You can give a name or label to the ONT that can be used to indicate its location or how it is being · used. The Serial Number and PON AID are automatically populated.
Page 69: Bulk Configuration
Tellabs® FlexSym OLT-mini Plus Installation and Turnup Guide Once selected, the user will be prompted to select the ONT type, the ONT serial number, ONT ID and User Label for the ONT. Auto Configuration and ONT Templates You can learn more about configuring ONTs via Auto configuration and using Templates to define all the default...
Page 70: Contact Us
Contact Us TELLABS TECHNICAL ASSISTANCE CENTER Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
