FlexSym
OLT-mini Installation and Turnup Guide
©
®
Copyright
2021 Tellabs
All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexSym OLT-mini and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tellabs FlexSym OLT-mini

Summary of Contents for Tellabs FlexSym OLT-mini

  • Page 1 © FlexSym OLT-mini Installation and Turnup Guide © ® Copyright 2021 Tellabs All Rights Reserved...

  • Page 2: Tellabs Information

    Tellabs Enterprise, Inc. Although every precaution has been taken in the preparation of this publication, Tellabs Enterprise, Inc. assumes no (i) responsibility for errors or omissions contained herein or (ii) liability for any damages resulting from the use of information contained herein.

  • Page 3: Table Of Contents

    ® Information ......................2 Tellabs Copyright.............................2 Trademarks ..........................2 Proprietary ..........................2 ® FlexSym OLT-mini Installation and Turnup Guide ........4 Tellabs Description ..........................5 Site Preparation ..........................7 Safety Precautions ........................10 Installation ..........................12 OLT Turnup ..........................19 Add OLT to Panorama PON ....................26 Add ONT ............................

  • Page 4: Tellabs Flexsym Olt-Mini Installation And Turnup Guide

    © FlexSym OLT-mini Installation and Turnup Guide ® Tellabs FlexSym OLT-mini Installation and Turnup Guide This document provides instructions to install and turnup the Tellabs® FlexSym OLT- mini optical line terminal. Document Revisions Revision Date Notes Initial Release of Document...

  • Page 5: Description

    FlexSym OLT-mini Installation and Turnup Guide Description The Tellabs FlexSym® OLT-mini is a small line size outdoor OLT with industrial temp ratings. This OLT is designed to be utilized for small installations without temperature control. The OLT-mini supports the following features: •...
  • Page 6 • Wall Mount:Supports standard mounting bracket for mounting of the OLT-mini on walls or backboards. • SSHv2 CLI Interface: The standard Tellabs CLI interface is supported for turn up and debugging of the unit. • Standard Panorama PON Interface: The Tellabs Panorama PON software will manage the OLT-mini using the standard GUI and web interfaces.

  • Page 7: Site Preparation

    • Power Wiring: If using DC wiring, 20 AWG wiring or better is recommended. • Uplink Lasers: Ensure you have purchased the appropriate Tellabs supported Modules shown in the "OLT Laser Part Numbers" table shown below. • M6 or 7/32" Allen Wrench: The enclosure is opened using either an M6 or 7/32"...
  • Page 8 10km SMF 2xLC Long Range 1G Wideband Laser C11T-S1GBER450030 Copper1G SFP 100m RJ45 Copper 1G SFP 81.11T-XFPGPON-IT Tellabs GPON Laser 20km 1xSC UPC(blue) 2.5/1.25G Bidi GPON Laser 81.11T-XFPXGSPON Tellabs XGS-PON Laser 20km 1xSC UPC(blue) 10G/10G Bidi XGS-PON Laser Page 8 of 35...
  • Page 9 © FlexSym OLT-mini Installation and Turnup Guide OLT-mini Power Requirements The OLT-mini has the following AC power requirements when powered by AC: AC Power Specifications Value Comments AC Input Voltage 100-240VAC AC Input Line Frequency 50-60Hz (nominal) AC Current Rating .7 A @ 100VAC, .3 A @ 240VAC Max AC Input Power 72 W...

  • Page 10: Safety Precautions

    © FlexSym OLT-mini Installation and Turnup Guide Safety Precautions Product Disposal Symbol The Waste Electrical and Electronic Equipment (WEEE) symbol will accompany specific products that must be collected and disposed of separately from household waste. The black bar under the symbol signifies the product was placed on the market after August 13, 2005.
  • Page 11 Never look into the end of a Fiber or into a Fiber connector on a cable or a device. Permanent eye damage or blindness can occur quickly from laser radiation. Electrical Safety Do not open the enclosure unless directed to do so by Tellabs technical ANGER support. Doing so is dangerous and voids the warranty.

  • Page 12: Installation

    © FlexSym OLT-mini Installation and Turnup Guide Installation Mounting the OLT-mini • Power Wiring and Grounding • Optical Module Installation • Powering up the OLT-mini • LED Behavior • The following steps should be followed for installation of the OLT-mini: •...
  • Page 13 © FlexSym OLT-mini Installation and Turnup Guide The OLT-mini comes with a pre-installed mounting plate that has 4 slotted mounting holes. The OLT-mini is mounted using 4x 1/4" screws to a backboard or wall of a type appropriate for the material the OLT is being mounted on. The screws must be adequate for the OLT-mini's 29.2 pounds.
  • Page 14 © FlexSym OLT-mini Installation and Turnup Guide A ground lug is provided on the bottom of the unit. This should be connected to a proper earth ground. Optical Module Installation Optical Modules must be installed into the OLT-mini. To access the optical modules, remove the access door from the enclosure.
  • Page 15 © FlexSym OLT-mini Installation and Turnup Guide The optical modules used should be selected from the modules listed in the site preparation section of this document. Both PON modules must be of the same PON type, i.e. both GPON or XGS-PON. GPON and XGS-PON modules cannot be mixed in the OLT-mini.
  • Page 16 © FlexSym OLT-mini Installation and Turnup Guide The PON fibers must be single mode SC/UPC. The uplink fibers are typically LC/UPC and must match the module type (MMF or SMF). Once the modules are all installed and the fibers routed, replace the Optical Module Access Door to ensure a weather tight seal of the enclosure.
  • Page 17 © FlexSym OLT-mini Installation and Turnup Guide Powering up the OLT-mini Once the power and fiber routing is completed, apply power to the OLT. The OLT-mini will begin displaying LED indications to provide information on the health of the unit. The device is labeled to indicate the position of each link and its associated LEDs.
  • Page 18 © FlexSym OLT-mini Installation and Turnup Guide LED Behavior Indications Comments Board has failed power up self test or has detected a hardware fault and must Red Solid be replaced. FAIL Red Blink Board hardware Initializing and performing Power On Self Test Dark Power is off or board is in normal state.

  • Page 19: Olt Turnup

    © FlexSym OLT-mini Installation and Turnup Guide OLT Turnup OLT-mini Initial Configuration • Connecting to the OLT-mini • Connect via μUSB • Connect via SSHv2 • Turning up the OLT-mini • OLT-mini Initial Configuration As shipped, the OLT-mini is configured to facilitate quick and easy out of box setup and testing.
  • Page 20 The OLT-mini is equipped with an embedded μUSB (microUSB) to serial port interface which provides direct access to the Command Line Interface (CLI) found on all Tellabs OLTs. To use this interface, attach a cable from the OLT μUSB port to a USB2 or USB3 port on a PC.
  • Page 21 Connect from xxx.xxx.xxx.xxx password for (admin): _ • On initial login, the administrative password must be changed. The system will prompt for the current password in order to allow the change. Type tellabs at the prompt and press NTER. Password expired, you must change your password to continue.
  • Page 22 © FlexSym OLT-mini Installation and Turnup Guide • Enter at the command prompt to display a list of commands available in the current context. XPON2P4A> _ Commands: adduser - Allows Admin user to add local users to the database alarms - alarm related operations cistbstat - Display CIST Bridge Parameters/Status...
  • Page 23 © FlexSym OLT-mini Installation and Turnup Guide CLI commands, parameters and options can be entered using abbreviations. The abbreviations are specified with capitalization in the help listings and context menus. For example, the wizard command is displayed in the help listing as WIZard. This case convention indicates that the command can be invoked using either wizard or the abbreviated form wiz.
  • Page 24 © FlexSym OLT-mini Installation and Turnup Guide Element Management Traffic Tagging Select tagged(2) or untagged(1). It is recommended that management traffic be tagged to isolate it from untagged user traffic. This setting must agree with the upstream switch setting for the management VLAN. VLAN ID for Element management Communication This specifies the VLAN ID for management traffic between the OLT and Panorama.
  • Page 25 © FlexSym OLT-mini Installation and Turnup Guide • When the Wizard finishes gathering data, a summary is displayed for confirmation. To accept the configuration and perform the turnup, type at the prompt and press NTER. The turnup configuration will be applied and the OLT restarted if necessary.

  • Page 26: Add Olt To Panorama Pon

    Add OLT to Panorama PON After the OLT-mini has been initially configured (or turned up) it can be added to the Tellabs Panorama PON element management system (Panorama). Panorama is a graphical user interface (GUI) that provides end-to-end management of the Optical LAN.
  • Page 27 © FlexSym OLT-mini Installation and Turnup Guide • Enter the IP address of the OLT-mini in the IP Address text field, select the ERASE configuration data from the OLT radio button and click the Next button. Selecting the ERASE option tells the system to cleanup any residual provisioning that might result from component reuse.
  • Page 28 © FlexSym OLT-mini Installation and Turnup Guide • If Panorama is able to communicate with the OLT, it will display a summary of its turnup data. Confirm the data and click the Next button. Page 28 of 35...
  • Page 29 © FlexSym OLT-mini Installation and Turnup Guide • Enter the Target Identifier (TID) in the Target Identifier text box and enter the appropriate time zone data. Click the Next button. The Template section of this dialog provides a mechanism for automatic discovery and provisioning of PONs, ONTs and Ethernet ports.
  • Page 30 © FlexSym OLT-mini Installation and Turnup Guide • Click the Confirm and Apply Button. • Panorama will add the OLT. This will take a few minutes. When the add is completed, click the Finish button. Page 30 of 35...

  • Page 31: Add Ont

    © FlexSym OLT-mini Installation and Turnup Guide Add ONT An ONT must be added to the EMS from the EMS GUI. This can be done in one of several ways: • Configuration via the Unexpected ONT menus • Manual Pre-configuration •...
  • Page 32 © FlexSym OLT-mini Installation and Turnup Guide • Configure (Y/N): Whether or not to configure the ONT. Selecting N will ignore that ONT and leave it in the unconfigured state. If the EMS has already put N in this field it is typically because the ONT already exists in the system and needs to be deleted from its previous location.
  • Page 33 © FlexSym OLT-mini Installation and Turnup Guide From the Panorama GUI, select the correct PON and then right click and select Add ONT. Once selected, the user will be prompted to select the ONT type, the ONT serial number, ONT ID and User Label for the ONT. Page 33 of 35...
  • Page 34 © FlexSym OLT-mini Installation and Turnup Guide Auto Configuration and ONT Templates You can learn more about configuring ONTs via Auto configuration and using Templates to define all the default settings for ONT configuration in the following Application Note: ENG-010407 ONT Auto Configuration Support Bulk Configuration For bulk configuration, see the Application note on Bulk Configuration.

  • Page 35: Contact Us

    Contact Us Tellabs Technical Assistance Center Tellabs TAC is available 24X7X365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
