  • Page 1 OLT6 and 1134 Description Installation and Turnup Guide Copyright © 2021 Tellabs ® All Rights Reserved...

  • Page 2: Tellabs® Information

    Tellabs Enterprise, Inc. Although every precaution has been taken in the preparation of this publication, Tellabs Enterprise, Inc. assumes no (i) responsibility for errors or omissions contained herein or (ii) liability for any damages resulting from the use of information contained herein.

  • Page 3: Table Of Contents

    OLT6 and 1134 Description Installation and Turnup Guide Table of Contents Tellabs® Information......................2 Copyright...........................2 Trademarks..........................2 Proprietary..........................2 1. Tellabs® 1134/OLT6 Optical Line Terminal Description, Installation, and Turn Up Guide......................... 4 1.1. Description.........................5 1.2. Safety Precautions......................8 1.3. Site Preparation....................... 10 1.4. Installation........................18 1.4.1.

  • Page 4: Tellabs® 1134/Olt6 Optical Line Terminal Description, Installation, And Turn Up Guide

    This document provides instructions to install and turnup the Tellabs® FlexSym OLT6 optical line terminal and the Tellabs® FlexSym OLT 1134. These two OLTs only differ by the backplane capacity of the shelf. The two shelves are identical in installation practices, line cards supported, and troubleshooting practices.

  • Page 5: Description

    OLT6 Shelf with Cover On OLT6 Shelf with Cover Off The Tellabs® FlexSym OLT6 and the Tellabs® FlexSym OLT 1134 are Optical Line Terminals in the Tellabs family of OLAN PON products. The Tellabs FlexSym® Optical Line Terminal Six (OLT6) and Tellabs® FlexSym OLT 1134 distribution shelves are designed for mid-size and larger enterprise deployments.
  • Page 6 OLT6 and 1134 Description Installation and Turnup Guide Line Terminal Six (OLT6) and Tellabs® FlexSym OLT 1134 are scalable for enterprise Optical LAN support of G-PON 2.5G, symmetrical XGS-PON 10G. The Tellabs FlexSym OLT6 shelf is ideal for space-challenged installations in data centers, communications closets and outdoor remote cabinets.
  • Page 7 OLT6 and 1134 Description Installation and Turnup Guide · OLT6 can be mounted in both outdoor and indoor environments including space challenged data centers, communications closets and outdoor remote cabinets.  It supports mounting via either 19" or 23" bracket options. ·...

  • Page 8: Safety Precautions

    Permanent eye damage or blindness can occur quickly from laser radiation. Electrical Safety Danger! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Page 8 of 50...
  • Page 9 OLT6 and 1134 Description Installation and Turnup Guide · Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but will not operate until the polarity is corrected. · Do not install electrical equipment in wet or damp conditions. ·...

  • Page 10: Site Preparation

    OLT6 and 1134 Description Installation and Turnup Guide 1.3. Site Preparation Power Considerations Prior to beginning the installation, ensure that the following power related items are considered: 1. Verify that proper ground connections are available for correct terminal operation. 2. Verify that the power outlet connector type matches the power cable end ordered with the OLT.
  • Page 11 OLT6 and 1134 Description Installation and Turnup Guide It is important that the shelf has a solid ground for both safety and signal integrity of the system. Ensure that the shelf is properly grounded per the standards cited above and the installation guidance given in this document. Racks and Cable Management The OLT6/OLT1134 is designed to be mounted in a 19 inch equipment rack or in a 23 inch equipment rack if the optional 23 inch rack mounting kit was procured.
  • Page 12 OLT6 and 1134 Description Installation and Turnup Guide · 2nd AC-DC Rectifier module if configured with a 2nd rectifier · Power cords with the appropriate connector · 23" Rack mounting kit if required · Rack screws/clips · ESU32 Switching Unit ·...
  • Page 13 OLT6 and 1134 Description Installation and Turnup Guide · PON Lasers: Ensure you have purchased the appropriate Tellabs supported PON Optical Modules shown in the "OLT Laser Part Numbers" table shown below. OLT Part Numbers OLT6 AC Part Numbers Description Quantity Required 81.11S-OLT6...
  • Page 14 10G Multimode XFP XO192SR1851M 10GBASE-ER/OC-192 IR-2 C.11T- Multi-rate 40km Industrial Temp 40km 2xLC 10G 40km XFP XO192IR21550 1xSC 2.5/1.25G Bidi 81.11T-XFPGPON-IT Tellabs GPON Laser 20km UPC(blue) GPON Laser 1xSC 10G/10G Bidi XGS- 81.11T-XFPXGSPON Tellabs XGS-PON Laser 20km UPC(blue) PON Laser Power Requirements...
  • Page 15 OLT6 and 1134 Description Installation and Turnup Guide Card Type Power Draw (Watts) Ethernet Switch Unit (ESU30) Ethernet Switch Unit (ESU32) Quad-port Optical Interface Unit (QOIU7) 8 Port Optical Interface Unit (OIU8) Note: The 1134 shelf does not have a power on/off switch as it is not intended to power down the shelf while it is in service.
  • Page 16 Tellabs® 1134/OLT6 in an environment compatible with the maximum operating temperature specified “Specifications”. · Reduced Air Flow - Installation of the Tellabs® 1134/OLT6 in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised.
  • Page 17 (e.g. use of power strips). Figure 1: 19-in Tellabs® 1134/OLT6 Optical Line Terminal Note: Shelf extensions are required if the Tellabs® OLT6 shelf is to be installed in a 23-inch rack and must be ordered separately Page 17 of 50...

  • Page 18: Installation

    OLT6 and 1134 Description Installation and Turnup Guide 1.4. Installation Installation Overview Installation will require the following steps: · Inspection of the Chassis for Installation Damage · Shelf Installation and Grounding · AC Power Supply Installation or DC power install ·...

  • Page 19: Inspect Olt Chassis

    1.4.1. Inspect OLT Chassis 1. Locate the package containing the OLT chassis. 2. Open the package and examine the OLT for any apparent damage. 3. If damage is noted, do not proceed and contact your Tellabs sales representative for a replacement unit. 4. See the section...

  • Page 20: Shelf Installation And Grounding

    OLT6 and 1134 Description Installation and Turnup Guide 1.4.2. Shelf Installation and Grounding 1. If the rack to be installed into is a 23" rack, the 23" rack mounting kit will be required. a. Remove the existing 19" rack mounting brackets from the OLT. b.
  • Page 21 OLT6 and 1134 Description Installation and Turnup Guide good path to earth ground.  The ground wire should never be connected directly to any power supply ground or return lead as this can introduce noise into the system. Page 21 of 50...

  • Page 22: Ac Power Installation

    1. Locate the package containing the rectifier/power supply. 2. Open the package and examine the rectifier for any apparent damage. 3. If damage is noted, do not proceed and contact TAC or your Tellabs sales representative for a replacement unit.
  • Page 23 OLT6 and 1134 Description Installation and Turnup Guide 4. Remove the rectifier cover from the rear of the OLT6 shelf by removing the 2 securing knurled nuts and pulling the cover away from the chassis. 5. Prior to installing the first rectifier, use a #2 Phillips screwdriver and loosen the two captive screws on the two latches on either side of the rectifier and pull the top of the latches away from the rectifier.
  • Page 24 OLT6 and 1134 Description Installation and Turnup Guide 6. Install the rectifier onto the top rectifier slot guide and fully insert the rectifier into the OLT6 chassis. 7. Close the latches and secure the 2 captive screws. 8. Install an AC power cable into the correct power input socket of the OLT.  Page 24 of 50...
  • Page 25 OLT6 and 1134 Description Installation and Turnup Guide 9. Observe the following rectifier activity. 10. Power LED illuminates. 11. Fan starts up. 12. The Minor and Major alarm LEDs illuminate momentarily as the rectifier logic stabilizes. 13. The rectifier should stabilize in approximately 8 seconds. 14.

  • Page 26: Dc Power Installation

    Tighten the two upper mounting screws to ensure the shelf is secure. 5. Locate the Tellabs® OLT6 power cable (which contains –48V A and B Feeds, Returns, and Digital Grounds). Typically, the -48V A and B should be fed from different circuits with different inputs and circuit breakers to ensure the system continues running even if a single feed fails. ...
  • Page 27 OLT6 and 1134 Description Installation and Turnup Guide 8. Replace the Tellabs® cover if previously removed. 9. Route the power cable assembly up the rack side rail, dressing the cable as needed. 10. Turn on the 48V Supply and the chassis should be ready for the next installation step.

  • Page 28: Install Optical Fan Assembly

    1. If not already removed, remove the OLT6 cover by sliding the two cover latches toward the center and lifting the cover from the chassis. Figure 9: Tellabs® OLT6/OLT1134 2. Connect an approved Electrostatic Discharge (ESD) strap to a ground on the equipment rack.
  • Page 29 OLT6 and 1134 Description Installation and Turnup Guide Tellabs Sales Representative for a replacement unit. Page 29 of 50...
  • Page 30 OLT6 and 1134 Description Installation and Turnup Guide Page 30 of 50...
  • Page 31 OLT6 and 1134 Description Installation and Turnup Guide Figure 10: Optical Fan Assembly (OFA1) 4. Insert the OFA1 fan tray into the chassis. Slide the unit in until it engages with the connectors on the chassis backplane. 5. The STAT LED on the OFA1 fan tray will illuminate RED and then transition to GREEN indicating correct operation.

  • Page 32: Card Installation

    OLT6 and 1134 Description Installation and Turnup Guide 1.4.6. Card Installation This section will detail the installation of the cards into the shelf. Install Master Ethernet Switch Unit Danger! To avoid eye injuries, never look directly into a bare or connectorized fiber end or optical equipment ports.
  • Page 33 4. Unpack and inspect the ESU card for any apparent damage. If there is apparent damage then use the Contact Us section to contact Tellabs support for replacement. 5. Carefully insert the card into the card guides until the card contacts the backplane connector.
  • Page 34 1. Remove the blank faceplate from the appropriate I/O slot of the chassis. 2. Unpack the OIU card (QOIU7 or OIU8) and inspect for any apparent damage. If there is damage, use the Contact Us link to contact Tellabs about options for replacement. Page 34 of 50...
  • Page 35 OLT6 and 1134 Description Installation and Turnup Guide 3. Carefully insert the card into the card guides until the card contacts the backplane connector. Then apply equal pressure on both upper and lower ejectors. 4. Upon insertion, the STAT LED illuminates RED while the card performs internal power up diagnostics.

  • Page 36: Splitter Installation

    2:N splitter as the cost differential is small and future proofs the network should protection be needed at a later date. Typical split ratios supported by Tellabs OLAN are: · 2:32 - 2 OLT inputs and 32 ONT outputs. This is the most common option and supports up to 20km reach.
  • Page 37 OLT6 and 1134 Description Installation and Turnup Guide 3. Insert the two remaining screws into the bottom mounting holes and tighten as required. Tighten the two upper mounting screws to ensure the splitter shelf is secure. 4. Obtain an SC/UPC to SC/APC jumper cable of appropriate length. Connect SC/UPC (OLT side, blue connector) to the correct OLT PON port, then connect the SC/APC (splitter side, green connector) to the #1 port on the input side of the splitter.

  • Page 38: Olt Turnup

    Connect from xxx.xxx.xxx.xxx password for (admin): _ · On initial login, the administrative password must be changed. The system will prompt for the current password in order to allow the change. Type tellabs at Enter the prompt and press Password expired, you must change your password to continue.
  • Page 39 OLT6 and 1134 Description Installation and Turnup Guide · The password policy settings and new password prompt are displayed. Enter a Enter new password, in accordance with the security policy and press . Confirm the new password when prompted. Password Policy - Password must: contain at least 0 upper case letters, 0 lower case letters, 1 numbers, and 1 special characters...
  • Page 40 OLT6 and 1134 Description Installation and Turnup Guide logout - Exits this craft session mcast - Displays downstream multicast info mccount - Statistics on all multicast channels menu - Launches the menu interface mstibstat - Display MSTI Bridge Parameters/Status msticonfig - Read MST Configuration Identifier mstilist - Display Currently Created MST instances...
  • Page 41 OLT6 and 1134 Description Installation and Turnup Guide Number of ESU cards: ............. [2] : 2 Number of Uplink Interfaces (NETs/LAGs) for element management: (1-2)..... [1] : 1 Configuration Details for Uplink Interface #1: AID of Uplink Interface #1: (NET1)........... [NET1] : NET1 Port speed for NET1: (1G(1), 10G(2))..........
  • Page 42 OLT6 and 1134 Description Installation and Turnup Guide AID of Uplink Interface Accept the system default (NET1). A Link Aggregate Group (LAG) or uplink interface can have the values NET1..NET12 on the OLT. Number of Ports The number of ports to be bundled in the uplink LAG. Up to eight(8) 1G ports or four(4) 10G ports are allowed.
  • Page 43 OLT6 and 1134 Description Installation and Turnup Guide Enter prompt and press . The turnup configuration will be applied and the OLT restarted if necessary. | Element Management Configuration |=========================================================================================== ====| | Bridge Configuration Bridging Type : 802.1q | Network Interface(s) Interface ID : NET1 Admin State...
  • Page 44 OLT6 and 1134 Description Installation and Turnup Guide IPv4 Configuration IP Address : 192.168.1.201 Network Mask : 255.255.255.0 IP Static Route Configuration Default Gateway : 192.168.1.1 Element Management Admin State : Enabled IP Stack Type : IPv4 VLAN Priority |=========================================================================================== ====| Apply this Element Management configuration(may trigger a restart): (y/n) ....[n]: _...

  • Page 45: Add Olt To Panorama Pon

    1.6. Add OLT to Panorama PON Adding the OLT to Panorama PON After the OLT has been initially configured (or turned up) it can be added to the Tellabs Panorama PON element management system (Panorama). Panorama is a graphical user interface (GUI) that provides end-to-end management of the Optical LAN.
  • Page 46 OLT6 and 1134 Description Installation and Turnup Guide · Enter the IP address of the OLT in the IP Address text field, select the ERASE configuration data from the OLT radio button and click the Next button. Selecting the ERASE option tells the system to cleanup any residual provisioning that might result from component reuse.
  • Page 47 OLT6 and 1134 Description Installation and Turnup Guide · Enter the Target Identifier (TID) in the Target Identifier text box and enter the appropriate time zone data. Click the Next button. The Template section of this dialog provides a mechanism for automatic discovery and provisioning of PONs, ONTs and Ethernet ports.
  • Page 48 OLT6 and 1134 Description Installation and Turnup Guide · Click the Confirm and Apply Button. · Panorama will add the OLT. This will take a few minutes. When the add is completed, click the Finish button. Page 48 of 50...

  • Page 49: Contact Us

    1.7. Contact Us Tellabs Technical Assistance Center Tellabs TAC is available 24X7X365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
  • Page 50 OLT6 and 1134 Description Installation and Turnup Guide · International: +1 630 798 9900, option 6 · France: 01 85 64 04 05, option 6 Page 50 of 50...
