- Page 1 ONT140W Installation and Turnup Guide ® Copyright © 2022 Tellabs All Rights Reserved...
-
Page 2: Tellabs ® Information
Tellabs Enterprise, Inc. Although every precaution has been taken in the preparation of this publication, Tellabs Enterprise, Inc. assumes no (i) responsibility for errors or omissions contained herein or (ii) liability for any damages resulting from the use of information contained herein. -
Page 3: Table Of Contents
ONT140W Installation and Turnup Guide ® Information ......................2 Tellabs Copyright.............................2 Trademarks ..........................2 Proprietary ..........................2 Introduction ........................5 Document Revisions ........................5 Intended Audience ........................5 Related Documentation ......................6 Description ......................... 6 Features ............................7 Passive Optical Network ........................... 7 IP/Ethernet ................................8 Operations, Administration and Maintenance (OAM) ................... - Page 4 Add Via Unexpected ONT Menu ........................31 Manual Pre-Configuration ..........................32 Auto Configuration and ONT Templates....................... 34 Bulk Configuration ............................34 Contact Us ........................34 Tellabs Warranty & Repair Center ..................34 Tellabs Technical Assistance Center ..................35 Page 4 of 35...
-
Page 5: Introduction
® The Tellabs ONT140W is part of the Tellabs 100 series of ONTs for Gigabit Passive Optical Networks (GPON). When connected to a Tellabs 1100-series optical line terminal (1150/1150E, 1134, FlexSym OLT1, FlexSym OLT6, FlexSym OLT-mini), the... -
Page 6: Related Documentation
IEEE 802.3af and 802.3at standards, including Class-4 negotiations. It is designed to be installed inside a standard wall outlet using a single form factor. The ONT140W can be deployed with the Tellabs OLT1150/OLT1150E, OLT1134AC, FlexSym OLT1, FlexSym OLT6, and the FlexSym OLT-mini optical line terminals. -
Page 7: Features
ONT140W Installation and Turnup Guide Features The ONT140W provides the following features: Passive Optical Network • Fully ITU-T G.984-compliant framing • APD Receiver / DFB Transmitter • .5-5dBm launch power, -27 dBm sensitivity and -8 dBm overload • Bi-directional AES-128 encryption with 60 second churning of keys •... -
Page 8: Ip/Ethernet
ONT140W Installation and Turnup Guide IP/Ethernet • Four (4) 10/100/1000 Base-T Gigabit Ethernet RJ-45 connectors • MAC address limiting to prevent flooding attacks and limiting the number of devices attached to a port • IGMP v2/v3 snooping • IEEE 802.1x Port-Based Authentication/MAB •... -
Page 9: Operations, Administration And Maintenance (Oam)
• Remote image download over OMCI as well as activation and rebooting Security Tellabs has implemented unique advanced security features to protect enterprise networks. The ONT140W supports security across the optical distribution network and end-to-end over the OLAN system, such as encryption of traffic on the PON using the Advanced Encryption Standard AES-128 and Access Control Lists (ACL) at Layer 2 through 4 levels. -
Page 10: Components
ONT140W Installation and Turnup Guide Components The ONT140W is modular in design so that its Power Module, ONT Module and Faceplate can be purchased and installed separately. Power Module The ONT140W Power Module contains: • internal power board • 2-pin input power connector for -54 Vdc input The ONT Power Module fits inside the wall and has a power socket for the 2-pin input power connector that is provided to power the ONT140W. -
Page 11: Faceplate
ONT140W Installation and Turnup Guide • 1 GPON connector • Identification label for ONT serial number Faceplate The front faceplate cover fits over the ONT Module and provides visibility to the LEDs and access to the ports and reset button, located on the ONT Module. It hides the fiber connection on the ONT Module and has two identification slots used for labeling. -
Page 12: Connectors And Indicators
ONT140W Installation and Turnup Guide Connectors and Indicators The ONT140W contains the ONT/PON uplink interfaces shown on the front view and the 2-pin power input connector socket and fiber exit point located on the rear view of the ONT. Page 12 of 35... -
Page 13: Led Behavior
ONT140W Installation and Turnup Guide LED Behavior Indications Comments The LED Hold Time has expired, the ONT does not have power or the Dark ONT is damaged. No optical signal. Red Blinking Kernel and application software is being loaded Green Blinking The device is attempting to establish the PON connection. -
Page 14: Specifications
ONT140W Installation and Turnup Guide Specifications The ONT140W specifications are listed in the following table: ONT140W Specifications Power Input 58 VDC @ 1.3A (75W) Physical Base - 1.85 x 1.28 x 2.56 in (W x D x H) (4.69 x 3.25 x 6.50 cm) •... -
Page 15: Precautions
ONT140W Installation and Turnup Guide Class 4 (802.3at) 25.5 Standards Compliance GPON ITU-T G.984.1, G.984.2, G.984.2 amd1, G.984.3, G.984.4, G.983.2 EMI/EMC FCC 47 CFR part 15 (Class B) Laser ITU-T Rec.G.984.2 (Class B+), G983.3 Class I, IEC 60825-1, Class 1 Ethernet IEEE 802.1ad, 802.1d, 802.1q, 802.3 Safety and... -
Page 16: Laser Safety
Never look into the end of a Fiber or into a Fiber connector on a cable or a device. Permanent eye damage or blindness can occur quickly from laser radiation. Electrical Safety Do not open the enclosure unless directed to do so by Tellabs technical ANGER support. Doing so is dangerous and voids the warranty. -
Page 17: Product Disposal
ONT140W Installation and Turnup Guide • Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but will not operate until the polarity is corrected. • Do not install electrical equipment in wet or damp conditions. •... -
Page 18: Preparation
ONT140W Installation and Turnup Guide Preparation Installation Planning The installation must seek to balance user preference with the environmental, power, and cabling requirements of the ONT and any subtending equipment. The following items need to be planned for prior to installing the ONT. Physical Mounting Options The ONT140W is designed to be installed into a wall, similar to how an AC wall outlet is installed. -
Page 19: Environmental Requirements
ONT140W Installation and Turnup Guide Environmental Requirements The ONT140C operates in temperatures ranging from 32°~104°F (0°~40°C) with non-condensing relative humidity ranging from 5% to 85%. Power Requirements The ONT140C requires 48~56 VDC at up to a maximum of 1.38 amps (at full PoE load). -
Page 20: Supplies
• Sharpie or other fine-point permanent marker Unpacking and Inspection The Tellabs ONT and related accessories may arrive in a single shipping container, or in multiple containers. When unpacking the boxes, check each item against the installation work order and for obvious shipping damage. If a shortage or damage is found, contact the Tellabs Warranty/Repair and Return Center immediately. -
Page 21: Installation
DC power termination with back 10 Pack Note: The ONT140W faceplate cover can be made to order in a color of your choice (in bulk). Please contact your Tellabs sales representative for more ordering details. Installation Installation Overview This page provides guidance on installing the Tellabs ONT140W and any required accessories. -
Page 22: Installation Procedure
Power Module o ONT Module o Faceplate cover 2. If any damage is found, contact the Tellabs® Warranty/Repair and Return Center immediately. 3. Place all components on a work bench or table. 4. Find a suitable location for the ONT140W. - Page 23 ONT140W Installation and Turnup Guide 6. Open the adjustable mounting wings and secure the mounting bracket by tightening the wing screws, once the bracket is inside the wall. 7. If using a dual-gang or single-gang utility box, depicted in Figures A or C, remove one of the conduit plugs from the top of the utility box, as shown in the illustration.
- Page 24 ONT140W Installation and Turnup Guide 11. Attach the reducer plate to the dual-gang utility box, using the 4 screws to secure the reducer plate to the utility box. Then, attach the ONT Power Module to the reducer plate, using 2 screws and tighten the screws. Note: If using a deep single-gang utility box, use a reducer plate.
- Page 25 ONT140W Installation and Turnup Guide 15. Using a small screwdriver, tighten the 2 corner screws on the ONT Module to secure both modules. 16. Strip the insulation from the copper wire and then insert the bare copper wire into the 2-pin male input connector. Page 25 of 35...
- Page 26 ONT140W Installation and Turnup Guide 17. Use a small screwdriver to tighten the screws to grip the copper wire as shown below. 18. Observe the positive and negative polarity label above the input connector socket for proper polarity orientation. 19. Remove the protective plug from the fiber compartment unit on the ONT Module.
- Page 27 ONT140W Installation and Turnup Guide Page 27 of 35...
- Page 28 ONT140W Installation and Turnup Guide 21. Route the fiber through the cable guide, looping it 180°, and then insert the fiber connector into the socket, shown in the illustration. 22. Plug the fiber connector inside the fiber compartment unit until an audible click is heard.
-
Page 29: Verifying The Installation
ONT140W Installation and Turnup Guide 25. After installation, indicate the unit’s physical location using the two identification slots on the faceplate cover Verifying the Installation Once the installation, software download, and bootup is complete, use the following procedure to verify ONT status: Page 29 of 35... -
Page 30: Adding To Panorama Pon
If the PON LED is not Solid Green, contact the systems administrator for activation assistance. Have the following information available: ▪ Vendor: Tellabs ▪ ONT Model Number: 140W ▪ ONT Serial Number: Located on a sticker on the bottom of the Services are provisioned and turned up remotely via the Panorama PON EMS. -
Page 31: Add Via Unexpected Ont Menu
ONT140W Installation and Turnup Guide • Auto Configuration via Templates • Bulk configuration via Excel Files Add Via Unexpected ONT Menu The unexpected ONT menu can be found by right clicking at the OLT, OIU, or PON level and Selecting Unexpected ONT. All ONTs that have not been accepted onto the PON will be shown in the dialog and each can be configured and accepted onto the PON. -
Page 32: Manual Pre-Configuration
ONT140W Installation and Turnup Guide put N in this field it is typically because the ONT already exists in the system and needs to be deleted from its previous location. • ONT ID: An unused ONT ID is suggested and can be overridden if desire with any available ID. - Page 33 ONT140W Installation and Turnup Guide From the Panorama GUI, select the correct PON and then right click and select Add ONT. Once selected, the user will be prompted to select the ONT type, the ONT serial number, ONT ID and User Label for the ONT. Page 33 of 35...
-
Page 34: Auto Configuration And Ont Templates
For bulk configuration, see the Application note on Bulk Configuration. Contact Us Tellabs Warranty & Repair Center The Tellabs Repair Center is staffed Monday-Friday 6:00 AM-4:00 PM CT, excluding Tellabs company holidays. If you have a technical or hardware emergency after hours, please contact the Tellabs TAC. -
Page 35: Tellabs Technical Assistance Center
France: 01 85 64 04 05, option 6 Tellabs Technical Assistance Center Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
