Tellabs® ONT140C, ONT140CL Installation and Turnup Guide

Table of Contents

Need help?

Do you have a question about the ONT140C and is the answer not in the manual?

Questions and answers

Summary of Contents for Tellabs ONT140C

Page 2: Tellabs® Information
Information in this publication is subject to change without notice. Trademarks The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United ® ®...
Page 3: Table Of Contents
Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Table of Contents Tellabs® ONT140C, ONT140CL Installation and Turnup Guide..................1 Tellabs® Information..........................2 Copyright................................2 Trademarks................................2 Proprietary................................2 Tellabs® ONT140C/ONT140CL Installation and Turnup Guide............4 Description................................6 Precautions............................... 15 Preparation................................ 18 Installation................................. 23 Adding to Panorama PON Manager........................ 39 Contact Us.................................
Page 4: Tellabs® Ont140C/Ont140Cl Installation And Turnup Guide
The Tellabs ® ONT140C and 140CL are part of the Tellabs 100 series of ONTs for Gigabit Passive Optical Networks (GPON). When connected to a Tellabs 1100-series optical line terminal (1150/1150E, 1134, FlexSym OLT1, FlexSym OLT6, FlexSym OLT-mini), the ONT140C/140CL...
Page 6: Description
ONT140C/140CL Optical Network Terminal (ONT) is part of the Tellabs 100 series of optical network terminals (ONT) for Gigabit Passive Optical Networks (GPON). The ONT140C/140C provides four (4) gigabit Ethernet connections and delivers up to 60W of remote power, supporting the IEEE 802.3af and 802.3at standards; including Class-4 negotiations.
Page 7 ® ONT140CL Optical Network Terminal (ONT) has all the same features and look and feel as the ONT140C with the following exceptions: 1. The buzzer was removed. 2. The 140CL is no longer plenum rated and is marked with "Not Plenum Rated" see Figure 3.
Page 8 · VLAN trunking and stacking · IP capable for enterprise services · PoE: 802.3af/at, class 0-4, up to 30W per port (PoE Switching only active on ONT140C) · IEEE 802.3az Energy-efficient Ethernet · Network Access Control (NAC) with Dynamic VLAN, and Guest VLAN ·...
Page 9 Security Tellabs has implemented unique advanced security features to protect enterprise networks. The ONT140C/140C supports security across the optical distribution network and end-to-end over the OLAN system, such as encryption of traffic on the PON using the Advanced Encryption Standard AES-128 and Access Control Lists (ACL) at Layer 2 through 4 levels.
Page 10 The front face of the ONT140C/140CL has four (4) Gigabit Ethernet connectors (GE1-GE4): The rear face of the ONT140C/140CL has four (4) distinct connectors: · Optical Fiber Connector - to connect the ONT140C/140CL to an optical splitter back to the OLT.
Page 11 Description Optical fiber single-mode connector Eight-pin connector used for the Tellabs AC power supply and the Battery Backup Unit (BBU) Barrel connector used for the external AC power module RJ-45 cable connector used to provide DC power from a remote power source when CAT5 cabling...
Page 12 Link / Green Blink Activity on the link. PoE is provided, if requested, on ONT140C only Activity Alternating Green/Amber PoE power has been denied on ONT140C only, or a power fault, such as a short Amber Port is locked out Dark 10Mbps...
Page 13 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Manual Controls and Switches The ONT140C/140CL has only one user-operable control; the Reset Button. The Reset Button is accessible through a small hole on the front face of the unit. The reset button can be used to perform the following: ·...
Page 14 Connector used to provide DC power from a remote power source (PoE not active on ONT140CL) Barrel Connector Connector used for the external A/C power module. ONT140C PoE Output to PDs (When powered remotely or from the AC Adapter) Class per IEEE802.3 Total Pwr (Watts) No.
Page 15: Precautions
Electrical Safety Warning! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Page 15 of 43 © 2023,Tellabs Enterprise, Inc. All rights reserved.
Page 16 Electrostatic Discharge (ESD) Observe and follow all ESD instructions while handling Tellabs plug-in equipment. Caution! The Tellabs plug-in equipment uses semiconductor devices that can be damaged by electrostatic discharge (ESD). Do not remove a plug-in from a protective packing box or equipment rack until time of installation or replacement.
Page 17 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Items such as integrated batteries can be disposed of along with the product; they will be separated at recycling centers. By participating in the separate collection of identified products, you will help with the correct disposal of these items and contribute to the ongoing protection of our environment and human health.
Page 18: Preparation
ONT. Physical Mounting Options The ONT140C/140CL can be deployed in a wide variety of ways. It can be installed in most locations; from desktops and flat surfaces to wall and under-surface mounting, or integration into modular office furniture.
Page 19 Note: The PoE Switch is only active on ONT140C, the ONT140CL will receive and throughput power. The ONT140C/140CL requires 48~56 VDC at up to a maximum of 1.38 amps (at full power load). This DC power can be obtained locally, using an optional AC power adapter, Battery Backup Unit (BBU), or remotely from a bulk 54-volt DC power supply.
Page 20 DC power wiring inside a single jacket. Remote DC power is delivered to the ONT140C/140CL through the RJ-45 connector located on the rear face of the unit. The following table shows the pinouts of the RJ-45 connector for 1, 2, or 4 power pairs...
Page 21 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Tools and Supplies The tools and supplies needed for a ONT140C/140CL installation vary depending on the location and type of installation. The items listed below assume that the optical fiber cable drop (and remote bulk DC power cable, if used) are already installed.
Page 22 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Unpacking and Inspection The Tellabs ONT and related accessories may arrive in a single shipping container, or in multiple containers. When unpacking the boxes, check each item against the installation work order and for obvious shipping damage.
Page 23: Installation
· Verifying the Installation · Installation Overview This page provides guidance on installing the Tellabs ONT140C/140CL and any required accessories. The procedure involves the following steps: 1. Physically mount the ONT and accessories 2. Connect the ONT to DC power 3.
Page 24 Following are the physical mounting procedures for typical installations. Desktop The ONT140C/140CL can simply be placed on top of a desk, table, shelf, or other flat surface. This allows the user to adjust its position, have easy access to the connectors on the back, and see the LED indicators on the top as the ONT operates.
Page 25 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Wall Mounting Bracket The ONT140C/140CL can be attached to a wall or other indoor surface using an optional Wall Mounting Bracket. Before mounting the ONT, consider the location and orientation appropriate for access and ease of use. Consider the power cable, optical fiber and ethernet cables that will be attached to the ONT.
Page 26 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide 3. Place the Wall Mounting Bracket on the mounting surface and position it to hold the ONT in the desired orientation. 4. Mark the mounting surface for the two surface mount holes in the bottom of the bracket.
Page 27 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Attach the ONT140C/140CL to the Wall Mounting Bracket 1. Wrap any excess fiber inside the bracket, as shown in the illustration. 2. Ensure that the fiber will not be pinched or crimped when attaching the ONT to the wall mounting bracket, maintaining a 3-inch bend radius.
Page 28 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide 4. Press the ONT onto the bracket to engage the keyholes and compress the bracket spring clips as shown below 5. Slide the ONT away from the bracket spring clips until they pop up and lock the ONT into place.
Page 29 1. Place the labeled plenum bracket on its side (face up) so that the two screws are visible on the fixture bracket inside the plenum bracket. 2. Align the 2 keyholes on the bottom of the ONT140C over the 2 center mounting studs on the fixture bracket, as illustrated, and slide the ONT down and forward.
Page 30 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Install the Plenum Bracket on a Wall 1. Locate a suitable position, within reach of a wall outlet, to install the plenum bracket. 2. Drill two level holes, to accommodate the 2 - 1/4-inch screws, into the wall, as shown in the example.
Page 31 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Note: If installing the plenum bracket in sheetrock, a wall anchor should be used. 3. Insert the 2 - 1/4-inch screws into the drilled holes and tighten the screws through the holes in the bracket and into the wall, as illustrated below: Note: If using wall anchors, drill pilot holes into the sheetrock, matching the diameter of the anchor.
Page 32 1. If installing the plenum bracket on a cable raceway railing or similar structure, use the plenum bracket lip and set screw to install the plenum bracket. Note: The ONT140C can be mounted on a railing up to 1/2” wide. 2. Ensure the railing is clear of any surrounding equipment.
Page 33 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Connecting to Power The Tellabs ONT140C/140CL is DC powered. This power can be sourced locally from an optional AC power adapter or Battery Backup Unit (BBU). The ONT140C/140CL can be sourced remotely from a bulk 54-volt DC power supply.
Page 34 Note: The BBU must be purchased from Tellabs®. Contact your sales representative for further details. Note: When the ONT140C is powered by the BBU, the total PoE available for end devices is reduced from 60W to 28W. Use the following procedure to connect the BBU to the ONT140C/140CL: 1.
Page 35 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide To mount the BBU using the wall mounting bracket use the following procedure. The optional wall mounting bracket for the BBU is shown below: 1. Identify a suitable location for the BBU. The BBU cables must span the distance between the ONT140C/140CL and an available wall outlet.
Page 36 Remote Bulk DC Power Supply Remote DC power is delivered to the ONT140C/140CL through the RJ-45 connector located on the rear face of the ONT. The DC power may be transported over an an ethernet cable (CAT5 or later) or optical/copper composite cable.
Page 37 It is especially important to manage and protect slack optical fiber cable. If the ONT140C/140CL has been installed using the wall mounting bracket, use the fiber management system integrated into the bracket to manage and protect this slack.
Page 38 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Velcro cable ties to hold the coiled fiber together in several places. Nylon zip ties can be used if care is taken to not crush the cable and to remove sharp points after cutting off excess cable tie length.
Page 39: Adding To Panorama Pon Manager
Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Adding to Panorama PON Manager Adding an ONT to Panorama An ONT must be added to the EMS from the EMS GUI. This can be done in one of several ways: · Configuration via the Unexpected ONT menus ·...
Page 40 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide · Configure (Y/N): Whether or not to configure the ONT. Selecting N will ignore that ONT and leave it in the unconfigured state. If the EMS has already put N in this field it is typically because the ONT already exists in the system and needs to be deleted from its previous location.
Page 41 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Once selected, the user will be prompted to select the ONT type, the ONT serial number, ONT ID and User Label for the ONT. Auto Configuration and ONT Templates You can learn more about configuring ONTs via Auto configuration and using Templates to define...
Page 42 Tellabs® ONT140C, ONT140CL Installation and Turnup Guide Bulk Configuration For bulk configuration, see the Application note on Bulk Configuration. Previous | Next Page 42 of 43 © 2023,Tellabs Enterprise, Inc. All rights reserved.
Page 43: Contact Us
France: 01 85 64 04 05, option 6 Tellabs Technical Assistance Center Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
