Meatest 9010+ User Manual

Multifunction calibrator
Hide thumbs Also See for 9010+:
Table of Contents

Advertisement

Quick Links

Download this manual
meatest
EN, rev. 18 FW ver. 2.043
9010+ Multifunction Calibrator
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9010+ and is the answer not in the manual?

Questions and answers

Related Manuals for Meatest 9010+

Summary of Contents for Meatest 9010+

  • Page 1 EN, rev. 18 FW ver. 2.043 9010+ Multifunction Calibrator user manual...

  • Page 3: Table Of Contents

    Calibration menu structure ................................55 Calibration point adjustment ..............................56 List of calibration points .................................. 57 Maintenance ..............................62 Fuse replacement ....................................62 External surface cleaning ................................62 Firmware update ....................................62 Error messages ....................................... 63 Specifications ...............................64 Voltage ..........................................65 Current ..........................................67 Meatest 9010+ User Manual...
  • Page 4 Figure 2 Input/output terminals ...................................7 Figure 3 Display..........................................8 Figure 4 Softkeys and menu buttons ................................9 Figure 5 Function buttons ......................................9 Figure 6 Rear panel ........................................10 Figure 7 Starting Screen......................................14 Figure 8 Factory default screen ...................................14 Meatest 9010+ User Manual...
  • Page 5 Figure 47 Meter limits function ..................................45 Figure 48 Password entry......................................55 Figure 49 Calibration menu with out-of-date calibration data ....................55 Figure 50 Calibration point adjustment – direct ..........................56 Figure 51 Calibration point adjustment – indirect ..........................56 Meatest 9010+ User Manual...

  • Page 6: Introduction

    Front panel overview Main control segments of the calibrator are: Figure 1 Front panel 1. Output terminals 2. Display 3. Numeric and navigation keys 4. Function keys 5. Input terminals 6. Softkeys (sky blue) and menu keys (grey) Meatest 9010+ User Manual...

  • Page 7: Figure 2 Input/Output Terminals

    Adapter terminals are described on the adapters themselves. 11. COM. Acts as zero potential for all METER functions (option MER). 12. A. Measures current signals in METER function, relative to COM (option MER). Meatest 9010+ User Manual...

  • Page 8: Figure 3 Display

    8. Input status. Indicates meter status (grey means disconnected, green means measuring) and shows diagram of active input terminals. 9. Meter reading. Meter function can be changed using FUNC button in METER group. Meatest 9010+ User Manual...

  • Page 9: Figure 4 Softkeys And Menu Buttons

    Values can be edited with cursor keys and rotary knob as well. Use  and  buttons to shift through digits and  and  buttons to increment or decrement that digit. Knob rotation works as either  /  or  /  buttons, knob push toggles between the two modes. Meatest 9010+ User Manual...

  • Page 10: Rear Panel Overview

    5. RS-232 connector 6. External signal synchronization input 7. External signal synchronization output 8. MSI connectors (2x) for control or synchronization with other Meatest devices 9. Fan outlet cover Options and accessories Every 9010+ Multifunction Calibrator delivery includes following items:...

  • Page 11: Table 1 Integrated Options

    When controlled remotely, maximum ratings of calibrator’s output signals as well as all other specifications are the same as in manual mode. Meatest software package WinQbase + Caliber is recommended for best automation results. This system is designed for automated and semi automated calibrations of digital and analogue meters including uncertainty calculation, result evaluation and certificate printing according to ISO 17025 standard.
  • Page 12 1.4.2. SCPI commands and protocol See 9010 SCPI manual for complete SCPI reference, more details on communication setup and troubleshooting. Meatest 9010+ User Manual...

  • Page 13: Getting Started

    - Use test leads rated for at least 1000 V and 30 A in all core functions and at least 2000 V in HVR high voltage resistance function. - Keep hands away from all Product terminals and exposed metal cable parts during operation. High voltage on those may be cause death or serious injury. Meatest 9010+ User Manual...

  • Page 14: Power On And Warm-Up

    By default the Startup preset is set to VDC function, 10 V with output switched off. Warm-up Specified parameters are guaranteed 30 minutes after switching the calibrator on and stabilizing it in reference conditions. Figure 8 Factory default screen Meatest 9010+ User Manual...

  • Page 15: Function Setup

    With MER option installed you can also take advantage of integrated multimeter and its measurement capabilities. Meter input can be activated and deactivated by pushing FUNC button. Similarly to calibrator output, meter input state is indicated by LED light in FUNC button and green rectangle next to Meter label. Meatest 9010+ User Manual...

  • Page 16: What To Do In Case Of Failure

    - proximity to sources of intensive influence, whose products are spread through the mains or propagated by the electromagnetic field - strong electrostatic or electromagnetic field which can cause major instability during calibration using higher impedance. Meatest 9010+ User Manual...

  • Page 17: Menu Reference

    Device menu is divided according to calibrator functions that gives access to additional function related settings, hazardous voltage protection, master limits and unlock code function. Unlock code function will allow you to enable, disable or set some calibrator properties after entering a password. Meatest 9010+ User Manual...

  • Page 18: Figure 11 Device/Setup Menu

    It helps protect DUT against user error. Values set here are subsequently taken as the maximum settable values for any calibrator function. User is informed that limitation is from this functionality when trying to exceed them. Figure 13 Maser limits Meatest 9010+ User Manual...

  • Page 19: System Menu

    Date/Time settings in Information menu. 4. Calibration date. Calibration date is updated automatically upon calibration data adjustment or just by manual confirmation (if calibration doesn‘t require adjustment). 5. Calibration interval. Recommended interval is 12 months. Meatest 9010+ User Manual...

  • Page 20: Preset Menu

    While editing functions, parameters are stored in temporary RAM until another preset is selected or the device is restarted. Preset doesn’t include harmonic distortion parameters nor main menu settings except those mentioned above. For harmonic preset feature see chapter 4.1.3. Meatest 9010+ User Manual...

  • Page 21: Calibration Examples

    - Ramp Up - Ramp Down - Harmonic adjustable harmonic products To select requested waveform push the soft key SHAPE, highlight requested item using softkeys , cursor keys or rotary button and confirm with ENTER. Meatest 9010+ User Manual...

  • Page 22: Figure 16 Harmonic Products Setting

    Push the soft key Bar to display relative level of harmonic products setting in frequency domain. Fundamental component is displayed in yellow, higher harmonics in red colour. Push the soft key PREWIEV to see the signal waveform in time domain. Figure 17 Signal preview Meatest 9010+ User Manual...

  • Page 23: Figure 18 List Of Harmonic Presets

    See specification for detailed differences. Push SELECT key until field Output mode is not activated. Change setting from Active to Passive using soft key arrow keys, soft key List or rotary knob. Meatest 9010+ User Manual...

  • Page 24: Figure 19 Voltage Setup Screen

    5 MHz. Fixed Sample multipliers multiply previously described Sync output instead of main signal frequency. Sample state On/Off. Turning Sample state ON will cause sampling signal to start when reference signal passes through zero. Sample multiplier Auto/8/16/32/64/128/256/512/1024/2048 Meatest 9010+ User Manual...

  • Page 25: Ac/Dc Current

    1s per 2s in real time. Maximum limit is 5 min – 30 minutes based on set current value, time[s] = 172710 (current[I] – 324,3) specifically: Figure 21 30A range output time limit Meatest 9010+ User Manual...

  • Page 26: Figure 22 Current Setup Screen

    30 % of amplitude of fundament signal. See chapter 4.1.2. and 4.1.3. for setting waveform parameters. 4.2.4. Current SETUP Current function SETUP can be activated using SETUP SOURCE key. Following screen will appear: Figure 22 Current SETUP screen Meatest 9010+ User Manual...
  • Page 27 5 MHz. Fixed Sample multipliers multiply previously described Sync output instead of main signal frequency. Sample state On/Off. Turning Sample state ON will cause sampling signal to start when reference signal passes through zero. Sample multiplier Auto/8/16/32/64/128/256/512/1024/2048 Meatest 9010+ User Manual...

  • Page 28: Resistance

    1500V 20V PK SCOPE 10V PK 1 00V PK 2V PK OPER STBY METER METER FUNC NULL 25V PK 10V PK 50V PK MAX 50 V PK MAX SELECT SETUP SYSTEM Figure 23 Two-wire resistance calibration Meatest 9010+ User Manual...

  • Page 29: Figure 24 Four-Wire Resistance Calibration

    WIRE soft key to select either two-wire or four-wire connection. Selection of individual fix value positions can be done using softkeys , or cursor keys or using rotary button. Numerical keypad is not active in this mode. Calibration value is displayed on the display. Meatest 9010+ User Manual...

  • Page 30: Capacitance

    The function is designed for calibration of standard resistance function of various multimeters which use low level signals. The mode is signed VARIABLE. Except the VARIABLE mode the calibrator offers more accurate resistance in FIXED mode. In this mode only fix nominal decadic values are available. Meatest 9010+ User Manual...

  • Page 31: Electric Power Meters, Analyzers And Energy Meters

    Electric power meters, analyzers and energy meters Calibrator can supply output voltage and current at the same time. The function is designed for calibration of electric power meters and power analyzers. Push function key POWER to select Power/energy mode. Meatest 9010+ User Manual...

  • Page 32: Figure 27 Ac Power

    50 V PK MAX SELECT SETUP SYSTEM Figure 28 Power meter calibration Calibrator features with floating current channel. Setting of grounded or floating output can be done in SETUP menu. Sign of AC wave indicates SIN mode without distortion. Meatest 9010+ User Manual...

  • Page 33: Figure 29 Harmonic Mode

    Figure 30 Energy mode Set requested time for which output signals should be connected to the output terminals. Use SELECT soft key to move active window. Both SINE and Harmonic mode can be applied in Energy mode. Meatest 9010+ User Manual...

  • Page 34: Figure 31 Power/Energy Soft Keys

    Energy softkey activates line for entering either requested energy portion in field ENERGY or requested time in field TIME. Except one-touch buttons calibrator has its own parameter setting under SETUP. Push SOURCE SETUP key to call out menu with parameter setting. Figure 32 Power SETUP screen Meatest 9010+ User Manual...
  • Page 35 5 MHz. Fixed Sample multipliers multiply previously described Sync output instead of main signal frequency. Sample state On/Off. Turning Sample state ON will cause sampling signal to start when reference signal passes through zero. Sample multiplier Auto/8/16/32/64/128/256/512/1024/2048 Meatest 9010+ User Manual...

  • Page 36: Sco & Sc1 Scope Extensions

    Table 2 Scope option modes Select SCOPE function using SCOPE key, following screen will appear: Figure 33 Scope option Push the SCOPE key repeatedly to swap between Voltage – SINE – PWM – Time marker mode. Meatest 9010+ User Manual...

  • Page 37: Figure 34 Scope Option Sine Screen

    - Cable loss compensation profile Push the OPER key to connect signal to the output terminals (N connector). Select SCOPE function using SCOPE key and press SCOPE again, following screen will appear: Figure 34 Scope option sine screen Meatest 9010+ User Manual...

  • Page 38: Figure 35 Scope Option Cable Edit Screen

    Push the OPER key to connect signal to the output terminals. Indicated pulse width is calculated by formula Δ = 1/f * R/100 [s], where f is frequency of output signal and R is duty cycle ratio in %. Meatest 9010+ User Manual...

  • Page 39: Time Marker Mode

    Impedance is measured at HF terminal (N connector). 50Ω oscilloscope inputs shall be measured in 100Ω range, 1MΩ inputs shall be measured in 2MΩ range. 4.6.6. Scope SETUP Scope SETUP can be activated using SETUP SOURCE key. Following screen will appear: Figure 38 SCO option Device/Setup menu Meatest 9010+ User Manual...

  • Page 40: Temperature Sensor Simulation

    If the line is hidden, push any key for value setting cursor key, rotary button or SELECT arrow key. Resistance is connected to HI – LO and +I – -I terminals in 4W configuration. HI – LO terminals are “power” terminals, +I – -I terminals are “sense” terminals. Meatest 9010+ User Manual...

  • Page 41: Figure 40 Tc Temperature Sensor Simulation

    4. Select Manual RJ mode and enter cold junction temperature into RJ field. With Adapter 91 connected as in picture below you can also use Auto compensation mode: Figure 41 Thermocouple simulation using Adapter 91 5. Enter requested temperature value into main field on the display to simulate temperature sensor. Meatest 9010+ User Manual...

  • Page 42: Mer Multimeter Extension

    Multimeter field appears on the screen after pushing the key METER FUNC. Information line with multimeter readings and basic setting is displayed then in bottom part of the screen. Figure 42 Process multimeter Meatest 9010+ User Manual...

  • Page 43: Figure 43 Thermocouple Measurement Using Adapter 91

    Reading on the display can be nulled at any time with NULL button. When Null function is active, LED key NULL lit and symbol NULL is displayed in METER information field on the screen. To cancel nulling function push NULL key again. Meatest 9010+ User Manual...

  • Page 44: Softkey Functions

    - Custom unit and Custom unit label. Custom unit with length up to 4 alphanumerical characters can be defined. Use navigation buttons or rotary knob to enter requested letters, switch between uppercase and lowercase using A ↔ a softkey and enable this feature by turning Custom unit ON. Meatest 9010+ User Manual...

  • Page 45: Figure 46 Meter Statistics Function

    Indication of reading versus limits is displayed in METER field using LIMIT label with arrows showing if the reading is below, inside or up. The LIMITS function is applicable in all meter functions. Figure 47 Meter limits function Meatest 9010+ User Manual...

  • Page 46: Table 3 Multimeter Setup

    Scaling, Statistics and Limits. The mathematic functions which have been switch on have indication with yellow bar in soft key description in the bottom line. label is simultaneously displayed in METER field showing that mathematic function has been applied. Meatest 9010+ User Manual...

  • Page 47: Performance Verification

    Specifications of this calibrator are defined for 1 year period so it should be periodically tested (and adjusted if necessary) within the same period of time. If you don’t have the necessary equipment or can’t do the calibration on your own, please ask local Meatest representative to help you calibrate this device.

  • Page 48: Test Points

    -2.09994 2.099944 2.100056 3.999925 4.000075 5.999905 6.000095 7.999885 8.000115 9.999865 10.00014 11.99985 12.00016 13.99983 14.00018 15.99981 16.0002 17.99979 18.00022 18.99978 19.00023 19.99977 20.00024 21.9995 22.0005 89.9985 90.0015 109.998 110.0021 199.9966 200.0034 299.991 300.001 1000 899.979 900.022 Meatest 9010+ User Manual...
  • Page 49 19.9961 20.0039 21.991 22.009 89.9788 90.0212 109.9702 110.0298 199.954 200.046 299.895 300.105 1000 749.76 750.24 19.888 20.112 199.51 200.49 1.9957 2.0043 AC Voltage 8½ digit DMM 120 Hz Square Shape 19.958 20.042 99.79 100.21 199.58 200.42 Meatest 9010+ User Manual...
  • Page 50 100.205 0.999 1.0011 1.89819 1.90182 9.994 10.006 1 kHz 18.9904 19.0096 99.94 100.06 AC Current 8½ digit DMM 189.904 190.096 SINE 0.99942 1.00058 1.89899 1.90101 9.9885 10.0115 20.5 18.9818 19.0183 120 Hz 20.9698 21.0302 28.9602 29.0398 Meatest 9010+ User Manual...
  • Page 51 -0.000015 +0.000015 (min and max 8½ digit DMM relative to kΩ -0.00015 +0.00015 calibration kΩ values) -0.0015 +0.0015 MΩ -0.00003 +0.00003 MΩ 2W, low voltage mode -0.0013 +0.0013 -0.1 +0.1 MΩ 1000 1000 -2.5 +2.5 MΩ Meatest 9010+ User Manual...

  • Page 52: Table 4 List Of Main Test Points

    Function Range Nominal Min value Max value Unit Standard unit Test parameters ° 100V/2A/50Hz/PF=1 -0.15 0.15 ° 200V/20A/50Hz/PF=1 Phase shift Phase meter ° 100V/2A/50Hz/PF=0.5 59.85 60.15 ° 200V/20A/50HzPF=0.5 Table 6 List of phase shift test points Meatest 9010+ User Manual...
  • Page 53 SINE mode 1500 96.45 103.55 RF voltmeter Voltage 100 MHz 1500 773.35 826.65 1500 96.05 103.95 400 MHz 1500 770.15 829.85 10.5 0.09985 0.10015 LF mode 10.5 0.99895 1.00105 8½ digit DMM DC Voltage 10.5 9.98995 10.01005 Meatest 9010+ User Manual...

  • Page 54: Table 7 List Of Options' Test Points

    - cal. val. + terminals (Hu to LO, Lu to HI, Hi to I- and Li kΩ 0.002 0.002 to I+) and use resistance source as standard. Table 7 List of options’ test points Meatest 9010+ User Manual...

  • Page 55: Adjustment

    As with any other menu you can navigate through the tree structure using cursor buttons, rotary knob or softkeys. symbol indicates calibration tree branches with out-of-date or otherwise invalid calibration data: Figure 49 Calibration menu with out-of-date calibration data Meatest 9010+ User Manual...

  • Page 56: Calibration Point Adjustment

    Figure 43 below shows an example of 100Ω point of fixed resistance function which has been adjusted by measuring resistance on output terminals with standard meter and typing in the standard readout (99.9955 Ω) Figure 51 Calibration point adjustment – indirect Meatest 9010+ User Manual...

  • Page 57: List Of Calibration Points

    20.5 A 0.000 0 A 0.000 0 A +19.000 0 A -19.000 0 A 30 A 21.000 0 A -21.000 0 A +29.000 0 A -29.000 0 A Table 8 Calibration points – DC voltage and current Meatest 9010+ User Manual...

  • Page 58: Table 9 Calibration Points - Ac Voltage And Current

    Table 9 Calibration points – AC voltage and current Harmonic calibration points are not used only for harmonic functions, but they are also used for all non-sine shapes (like symmetrical square, ramp up, ramp down, triangle, truncated sinus with THD 13.45 %) Meatest 9010+ User Manual...

  • Page 59: Table 10 Calibration Points - Variable Resistance

    120 Hz 100 µF 100 µF 55 µF 1 mF constant discharge 1 mF 10 mF 1.1 mF 9 mF constant discharge constant discharge 120 mF 11 mF 90 mF Table 11 Calibration points – Variable capacitance Meatest 9010+ User Manual...

  • Page 60: Table 12 Calibration Points - Hvr Option

    N connector output. This should be compensated directly at output N connector without connected cable. In this point there is no need of 50 Ω HF terminator resistor, but standard useable for 1 kHz can be used. Meatest 9010+ User Manual...

  • Page 61: Table 14 Calibration Points - Sc1 Option

    100 Ohms instead of 1 kOhm. Keep in mind that this might push the upper end of the range (typically 2 kOhm) outside specified limits. Table 15 Calibration points – MER option 6.3.9. Cold junction compensator calibration For calibration of cold junction compensator look up: AN108 Option 91 Verification and Calibration manual. Meatest 9010+ User Manual...

  • Page 62: Maintenance

    (.upl) for your device. If your device is not listed, contact Meatest support and ask for firmware update file for your device. 2. Check if the update file version is greater than yours, installed FW version can be found in MENU >...

  • Page 63: Error Messages

    Service Center. 7021: Source function is unavailable. Ask Meatest for possible upgrades. 7022: Meter function is unavailable. Ask Meatest for MER option upgrade. 7100-7999 Protective element has been triggered and output/input has been shut off in order to prevent calibrator damage.

  • Page 64: Specifications

    Safety class I according to IEC 61010 ed. 2 ESD class I according to EN 61326 Overvoltage CAT II Pollution Degree 2 Dimensions (W x H x D): 434 x 191 x 641 mm Weight: 24 kg (basic version) Meatest 9010+ User Manual...

  • Page 65: Voltage

    + 10 mV + 40 mV + 40 mV 280.000 – 1050.000 V + 30 mV + 30 mV Frequency is limited to 15 – 10000 Hz above 200 V. Frequency is limited to 20 – 1000 Hz. Meatest 9010+ User Manual...
  • Page 66 THD 13.45 %, harmonics Voltage range: 1.00000 mV – 200.0000 V (282 V max.) Frequency range: 15.000 – 1000.00 Hz Peak value uncertainty: 0.21 % + 70 µV Meatest 9010+ User Manual...

  • Page 67: Current

    + 4 mA + 4 mA 1 200 20.50000 – 30.00000 A + 5 mA Accuracy not specified below 10 µA. 30 min – 5 min maximum continuous output time. Depleted time regenerates 2x slower. See chapter 4.2.1. Meatest 9010+ User Manual...
  • Page 68 8.2.2. Current coil (option 0950) Applicable multiplier: 2 – 200 Max. simulated current: multiplier × 30 A (1025 A with 0950 Current Coil) Frequency range: 45 – 65 Hz Uncertainty adder: user defined (0.3 % by default) Meatest 9010+ User Manual...

  • Page 69: Resistance

    Floor (Ω) x I at 100mV / Iactual. For example, for 10 Ω resistance and 1 mA test current, the floor adder is: 2 mΩ x 10mA/1mA =20 mΩ instead of 2 mΩ. For test currents higher than 10 mA and lower than specified 100 mA the adder Meatest 9010+ User Manual...
  • Page 70 15. Uncertainty is valid for relative humidity RH ≤50 %. For operation at ambient RH in the range 50 % to 70 % and resistance output values 100.0 MΩ to 10.00 GΩ, add 0.02 x specified uncertainty/ % RH. For resistance range 100 GΩ add 0.05 x specified uncertainty / % RH. Meatest 9010+ User Manual...

  • Page 71: Capacitance

    1.000000 nF 1.25 % 1000 Hz 10.00000 nF 0.35 % 1000 Hz 100.0000 nF 0.25 % 500 Hz 1.000000 µF 0.25 % 300 Hz 10.00000 µF 0.35 % 300 Hz 100.0000 µF 0.45 % 300 Hz Meatest 9010+ User Manual...

  • Page 72: Power And Energy

    = [1 – sin (φ + dφ) / sin (φ)] ∙ 100 for reactive power dPF = 0 for apparent power where: -  is set phase shift between voltage and current - d is uncertainty of set phase shift Meatest 9010+ User Manual...
  • Page 73 - dt = 0.01 % + 0.3 s = 0.11 % of 5 minute period AC energy uncertainty is then calculated as dE =  (0.035 + 0.08 + 0.0003 + 0.11 + 0.03 ) = 0.14 % Meatest 9010+ User Manual...

  • Page 74: Harmonics

    0.2 % of fundamental harmonic range Max. frequency: 5 kHz Phase shift range: 0.00 – 360.00 ° Phase shift uncertainty: 5 µs (typical) 2 × full range of fundamental harmonic Amplitude limitation of complex distorted signal Max peak amplitude: Meatest 9010+ User Manual...

  • Page 75: Temperature Sensor Simulation

    : 200 Ω Pt385 0.04 0.04 0.05 0.08 0.12 0.15 : 500 Ω Pt385 0.03 0.04 0.05 0.09 0.11 0.14 : 1000 Ω Type -80 – 0 0 – 100 100 – 260 Ni 120 0.05 0.08 0.14 Meatest 9010+ User Manual...
  • Page 76 2080 – 2315 uncertainty 0.72 0.49 0.35 0.39 Automatic cold junction compensation (Adapter 91) Sensor type: Pt100 Temperature uncertainty: 0.1 °C with calibration constants saved in 9010+, 0.3 °C otherwise Typical sensor stability: < 0.05 °C/year Meatest 9010+ User Manual...

  • Page 77: Sco And Sc1 Scope Options

    Sine voltage 1 MΩ 0 – 200 V 0.10 % + 0.005% + 30 µV 50 Ω 0 – 3.5 V 0.40 % + 0.15% Square voltage 1 MΩ 0 – 200 V 0.25 % + 0.15% Meatest 9010+ User Manual...

  • Page 78: Input Impedance Measurement

    Amplitude uncertainty: 10 % Jitter: < 2 ns Rise time: < 1 ns 8.8.5. Input impedance measurement Ranges: 100 Ω, 2 MΩ Measurement uncertainty: 0.1 % of value in 10 % – 100 % of range Meatest 9010+ User Manual...

  • Page 79: Mer Integrated Multimeter Option

    : 200 Ω Pt385 0.08 0.08 0.10 0.16 0.24 0.30 : 500 Ω Pt385 0.08 0.08 0.10 0.18 0.22 0.28 : 1000 Ω Type -80 – 0 0 – 100 100 – 260 Ni 120 0.15 0.24 0.42 Meatest 9010+ User Manual...
  • Page 80 0 – 100 100 – 280 280 – 1830 1830 – 2315 uncertainty 0.46 0.38 0.63 0.94 range 100 – 200 200 – 430 430 – 2080 2080 – 2315 uncertainty 1.00 0.67 0.46 0.51 Meatest 9010+ User Manual...

  • Page 81: Revisions

    Change 9 (19.08.2024) - Added verification points for SC1 LF mode DC Voltage in chapter 5.3.2. Change 10 (21.08.2024) - Added verification for AC Phase in chapter 5.3.1. - Added additional information about relative humidity in chapter 8.3.3. Meatest 9010+ User Manual...

  • Page 82: Change 11 (22.04.2025)

    Change 11 (22.04.2025) - Updated note in chapter 4.4.1. - Additional information in chapter 5.2., - Added test points for AC Voltage Square Shape, AC Current Square Shape in chapter 5.3. Meatest 9010+ User Manual...

  • Page 83: Declaration Of Conformity

    Declaration of conformity According to EN ISO/IEC 17050-1:2010 standard as well as 2014/30/EU and 2014/35/EU directives of European Parliament and European Council, MEATEST, spol. s r. o., manufacturer of 9010+ Multifunction Calibrator, based in Železná 3, 619 00 Brno, Czech Republic, declares that its product conforms to following specifications: - EN 61010-1 ed.
