Summary of Contents for Meatest M160
- Page 6 Precision DC calibrator M160 is an accurate source of DC voltage and DC current. It offers thermocouple and RTD simulation and some other features suitable for process calibrations. Calibrator is designed for use in production, but can be used also for development or in calibration laboratories.
- Page 7 All input and output terminals are located on left side of front panel. 1. Voltage/Current terminals - HI / LO are two wire output terminals. LO terminal is floating up to 50Vpk against the case (PE). 2. Voltage sense terminals - S / S are sense terminals for four wire voltage configuration. 3.
- Page 8 Display is divided into several sections with following meaning: 1. Selected function. Symbol on the left indicates system status ( standby, settling in, ► running). 2. Softkey labels. Softkeys below the display change their function dynamically based on current workspace, these labels describe Softkey functions at any given time.
- Page 9 3. RJ-45 (Ethernet) connector for remote control 4. USB connector for remote control 5. GPIB IEEE-488 connector for remote control Every M160 Precision DC Calibrator delivery includes following items: - USB stick with user manual 1 pc - Factory calibration certificate...
- Page 10 When controlled remotely, maximum ratings of calibrator’s output signals as well as all other specifications are the same as in manual mode. Meatest software package WinQbase + Caliber is recommended for best automation results. This system is designed for automated and semi automated calibrations of digital and analogue meters including...
- Page 11 LAN communication uses Telnet/TCP/UDP protocol. Default log-in for client is “M160_SNxxxxxx 23”, where “xxxxxx” stands for serial number and 23 is default communication port (22 for TCP and UDP protocol). See M160 SCPI manual for complete SCPI reference, more details on communication setup and troubleshooting.
- Page 12 Inspect package contents when unboxing the calibrator for the first time. See chapter 1.3 for complete list of accessories. Place the instrument on a level surface before powering on and let it stabilize for at least one hour if the instrument has been stored outside of reference temperatures beforehand.
- Page 13 The calibrator must be powered by 230/115 V – 50/60 Hz mains. Before connecting the instrument to the mains, check the position of the mains voltage selector located on the rear panel. Set appropriate voltage selector position either 115 V or 230 V. Plug one end of the power cord into connector on the rear panel and connect the other end of the power cord into a wall outlet.
- Page 14 Function can be changed after pressing „Function“ softkey. New function is selected using cursor keys ▲,▼ or display softkeys. Selection must be confirmed by pressing SELECT key, ENTER key or „OK“ softkey. Calibrator output can be turned on by pushing OPER button. Pressing OPER button again turns output off.
- Page 15 If an obvious failure occurs during the operation (e.g. the display is not lit, the fan is not turning), the calibrator must be switched off immediately. First, check the fuse located in the power cord receptacle. Procedure is following: - Remove the end of power cord from the mains connector at the rear panel. - Insert the blade of a flat screwdriver into the opening cut in the mains voltage selector and pry out the fuse holder.
- Page 16 Main menu is displayed after pressing „Menu“ softkey. Main Menu allows configuration and calibration of the device Four buttons on the front panel give access to main menu sections: Main menu is the most comprehensive setup tool of the calibrator, containing information like serial number, calibration date or display brightness as well as remote control interface setup or calibration constants.
- Page 17 Interface menu contains remote control connection settings: Calibration menu contains internal calibration constants and other tools for device adjustment and is therefore password protected. See chapter 6 for more details on M160 adjustment. Calibration menu has following items: 1. Data. Contains current calibration data. Structure of this menu is described in chapter 6.1.
- Page 18 Backup function allows you to save and recall entire sets of calibration data. Calibration data are also saved automatically when any calibration value gets changed, creating a record with “Auto” storage (or overwriting an existing one if the last change occurred within last 90 days). Use softkeys to save and recall previously stored calibration data sets: 1.
- Page 19 Offers direct setting of DC voltage. Limit: 1.00 mA - 50.00 mA Maximum output current without limiting the output voltage. Parameter can be changed in the switch position “Adjustable”. In the switch position “Maximum” is set to maximum value. When this value is exceeded on device terminals, terminal overload indicator lights up: Range:...
- Page 20 Offers direct setting of DC current. Limit: 1.00 V - 100.00 V Maximum output voltage without limiting the output current. Parameter can be changed in the switch position “Adjustable”. In the switch position “Maximum” is set to maximum value. When this value is exceeded on device terminals, terminal overload indicator lights up: Range:...
- Page 21 Offers direct setting of TC temperature. TC type: R, S, B, J, T, E, K, N, M, C, D, G2 RJ mode: Manual, Extern Reference junction compensation. Reference junction temperature. Red measured value for Extern RJ mode. Blue editable value for Manual RJ mode. Limit: When 50mA or the Master limit value is exceeded on device terminals, terminal overload indicator lights up:...
- Page 22 Offers direct setting of frequency (period) of generated pulses. Duty: 0.50% - 99.50%, duty cycle of generated signal Count: 0 - 9999999, number of generated pulses Pulses generator must be set to On in Settings. Pull-Up: Off, On Actual: Actual number of generated pulses Expression: Frequency, Period Pulses generator:...
- Page 23 Offers direct setting of temperature of simulated resistance thermometer. RTD Type: Platinum, Nickel Standard: PT385 (68), PT385 (90), PT3916, PT3926, PT User 100 Ω - 1000 Ω Wire connection: 2W, 4W Two or four wire output configuration. Terminal ground: On, Off Connects Li and Lu terminals with the protective earth (PE) terminal in On state.
- Page 24 Offers direct setting of Resistance. Short: Off, On Short circuit simulation. Also the short circuit must be connected to the output terminals by the OPER key. Wire connection: 2W, 4W Two or four wire output configuration. Terminal ground: On, Off Connects Li and Lu terminals with the protective earth (PE) terminal in On state.
- Page 25 Sequence is defined by table of time intervals and corresponding function values, all of which can be edited. Maximum number of tables is 64 with each table having up to 100 time intervals. Sequence is started by pressing OPER button or sending OUTP ON command via remote control. Manual table setup →...
- Page 26 Delete – delete selected point. Cancel – deactivate the Lookup Table and allow for curve saving. Save – closes the table and saves current settings. Cancel – closes the table and does not save current settings. Existing table can be edited in the same way as it can be created. Editable entries (Sequence name, Timing table points) are selected using the key.
- Page 27 - Instrument sets the new value. - The value is copied to the appropriate field in the screen and the input box disappears. Note: All parameters have limits (high and low). If the entered value is outside these limits warning message is displayed „Value too high (low)“...
- Page 28 If you don’t have the necessary equipment or can’t do the calibration on your own, please ask local Meatest representative to help you calibrate this device. Following instruments are required for performance verification test: - Keysight 3458A, Fluke 8508A or similar 8½...
- Page 31 Access to the calibration mode is from the setup Menu. Correct password must be entered before calibration. Without correct password the access to the calibration mode is refused. Default factory set calibration code is “2”. Return to standard mode is possible after pushing the CANCEL key.
- Page 32 Following instruments are required for full adjustment: - Keysight 3458A, Fluke 8508A or similar 8½ DMM with 10 ppm accuracy in DC voltage or better - Keysight 53181A, Keysight 53131A or similar counter with 10 ppm accuracy or better Go to “Calibration->Data” and using softkeys, select function and then range to be adjusted. All data points shall be adjusted in shown order in one go, see chapter “Adjustment points”...
- Page 33 The following is a list of all functions and their adjustment points. The instrument can be partially adjusted as well but in order to achieve best overall accuracy you should adjust all points in one go and in the same order as listed below.
- Page 35 Autocalibration offsets are based on internal measurements of output terminals. This is to compensate for small daily drifts caused by material or temperature changes. Zero offsets can be measured in “Calibration->Data->Advanced->Source Autocalibration”, 4W connection offset against 2W can be set in “Calibration->Data->Advanced->Source voltage terminal sense”.
- Page 36 (.upl) for your device. If your device is not listed, contact Meatest support and ask for firmware update file for your device. 2. Check if the update file version is greater than yours, installed FW version can be found in MENU >...
- Page 37 The following table lists an overview of error codes that you might come across.
- Page 38 Uncertainties include long-term stability, temperature coefficient, linearity, line regulation and the traceability of factory and National calibration standards. Specified accuracy is valid after 30-minute warm up in temperature range 23°C ± 10 °C. Specified accuracy is one year accuracy. +13 C - +33 C (Voltage, Current, TC, Frequency) Reference conditions: +20 C - +26 C (RTD, Resistance) +5 C - +45 C...
- Page 39 Summary range: 0 to 100 Vdc 6½ digits Voltage resolution: Typical linearity: 2 ppm 4W sense compensation limit 0.2 V Summary range: 0 to 50 mAdc Current resolution: 6 digits Typical linearity: 15 ppm...
- Page 40 Summary range: 10 mHz to 15 kHz Open collector: max. 30 V/50 mA or internal pull up 100R to +5V (±10 %) Summary range: 10 mHz to 100 kHz 5½ digits Frequency resolution: ±50 ppm Accuracy: Ranges: 5 mA, 25 mA, 50 mA (based on current limit setting) 10 µA Resolution: ±...
- Page 41 0.01 °C Resolution: manual or automatic (with Adapter 91) in range 0.00 – 40.00 °C Cold junction compensation: 0.3 °C; 0.1 °C with calibration constants saved in M160 Uncertainty: < 0.05 °C/year (typical) Stability:...
- Page 42 -200 °C to +850 °C Pt summary range: -60 °C to +300 °C Ni summary range: 0.01 °C Resolution: -200 °C to +850 °C Pt summary range: -60 °C to +300 °C Ni summary range: 0.01 °C Resolution: 10 to 300 k Summary range: Short resistance: <...
- Page 43 Terminals: Hi, Li (adapter) 10 to 300 k Summary range: Specification: add 10 m to the 4W specification Short resistance: < 200 m Maximum dissipation power: 0.3 W Maximum current: 0.2 A Maximum voltage: 50 Vpk...
- Page 44 According to EN ISO/IEC 17050-1:2010 standard as well as 2014/30/EU and 2014/35/EU directives of European Parliament and European Council, MEATEST, spol. s r. o., manufacturer of M160 Precision DC Calibrator, based in Železná 3, 619 00 Brno, Czech Republic, declares that its product conforms to following specifications: - EN 61010-1 ed.
