Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operating high-power devices such as, for example, electrical
arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Projector
FLB141 #1 LED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLB141 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WE-EF FLB141

Summary of Contents for WE-EF FLB141

  • Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Projector FLB141 #1 LED Surge Protection Do not open during installation This product is factory-sealed. This product features built-in surge protection circuitry in compliance Refer to the instructions contained in this with applicable standards.
  • Page 2 Projector FLB141 #1 IP66, IK08. Class I. ta = 40°C Weight for FLB141 #1 LED Windage area m² for FLB141 #1 LED 0.038 Orientation: all directions Mounting Accessories SF-FLD1 for FLB141 #1 145-9535 CF-FLD1 for FLB141 #1 145-9536...

  • Page 3: Maintenance

    Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried Warning: Do not open luminaire while mains supply is switched on.

  • Page 4: Installation

    Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Notice: no longer be valid and shall become the full responsibility of the modifying person/organisation. Claims based on defects attributable to improper installation and/or application, and the consequences thereof, are excluded.

  • Page 5: Installation Procedure

    Installation Procedure 2) Check that rating shown on luminaire label conforms with mains electrical supply. 07/18 IP66 FLB141-LED 220-240V50-60/Hz 161-XXXX SOE XXXXXXX LED 3000K 18W item no. XXX (example) 3) Feed cable A from luminaire B through pivot and Drill relevant holes E and insert nylon plugs.
  • Page 6 5) Loosen screws F 6) Turn luminaire towards object to be while pulling cable A through hole. seated on pivot, then tighten screws F. 7) Connect cable A with mains supply cable. 8) Loosen screw G. Aim luminaire in desired a) ON/OFF (L = Phase, N = Neutral, direction and tighten screw G.
  • Page 7 2) Check that rating shown on luminaire label conforms with mains electrical supply. 07/18 IP66 FLB141-LED 220-240V50-60/Hz 161-XXXX SOE XXXXXXX LED 3000K 18W item no. XXX (example) 3) Drill screw holes A and cable entry hole B on C in position. Insert column.
  • Page 8 5) Loosen screws F. Feed cable D from luminaire 6) Turn luminaire E towards object to be E through pivot and cable entry hole B. Connect luminaire E C by seated on pivot, then tighten screws F. 7) Connect cable D with mains supply cable. 8) Loosen screw G.
  • Page 9 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9250W0823 © WE-EF 2023 Technical specifications are subject to change.
  • Page 10 WE-EF LEUCHTEN Installation and Maintenance Instructions Accessories Flat surface tter Ground Spike Column tter Junction box Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance Refer to the instructions contained with applicable standards.
  • Page 11 Accessories Suitability 1. FLB100 Spigot mounted 2. FLC300 Spigot mounted 3. FLD100 Spigot mounted Flat sur ace tter 145-9535 Ground spike 310-9102 Colu n tter 145-9536 Junction box (Side entry - cable) 310-9002 Junction box (Side entry - conduit) 310-9022 Junction box (Wall entry) 310-9025...
  • Page 12 Installation The product must be installed and maintained by a suitably quali ed professional in compliance with latest building/construction and/or electrical regulations and relevant legislation. Warning: Switch o mains electrical supply prior to installing and connecting the luminaire. Notice: If the luminaire is modi ed by anybody other than the original manufacturer, then the warranty will no longer be valid and shall become the full responsibility of the modifying person/organisation.
  • Page 13 Installation Procedure Flat sur ace tter 1) Feed cable from luminaire through pivot 2) Determine position for xing screws D. and cable gland of at surface tter A. Drill relevant holes E and insert nylon plugs R. Insert and tighten screws D. After installation of luminaire, tighten cable gland.
  • Page 14 Ground Spike 1) Note: It is the responsibility to installer to 2) Place ground spike H into the ground. ensure the suitability of the ground spike for site-speci c conditions. 3) Feed cable from luminaire through pivot and cable gland I. After installation of luminaire, tighten cable gland I.

  • Page 15: Junction Box

    Junction box 1) Loosen screws K and remove cover L from 2) Feed main supply cable R through wall entry body M. or side entry of body M. For side entry installations, replace the pre-installed plugs with provided cable glands as required.
  • Page 16 5) After installation of luminaire, place cover L on body M and tighten screws K.
  • Page 17 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9253W0722 © WE-EF 2022 Technical specifications are subject to change.
