COMPX TYPE310 Dimensional Drawing

32.4
1.28
23.2
.92
30.5
1.20

PART NUMBERS:

CB-311 NICKEL FINISH
CB-315 BRASS FINISH
CB-317 SATIN NICKEL FINISH

COMPONENTS ARE BAGGED TOGETHER IN POLYBAG

7/8" DIAMETER HOLE
BORED IN GLASS
CENTERED 7/8" FROM EDGE
CYLINDER BODY ROTATES
THROUGH HOLE IN GLASS
5
.20
41.9
1.65
22.2
.88
22.2
.88
DATE
03/24/03
DESCRIPTION
TYPE 310 GLASS DOOR CAM LOCK
915 Sherwood Drive
Lake Bluff, IL 60044
FINISH CAP IS
ATTACHED TO
GIVE FINISHED
APPEARANCE
NUT WASHER IS
HAND TIGHTENED
TO FASTEN CYLINDER BODY
TO GLASS
CAM IN UNLOCKED
POSITION
CAM IN LOCKED
POSITION
DRAWING#
CB-31X
Phone: 847-234-1864
Fax: 847-234-7922
