COMPX TYPE300 Dimensional Drawing

5
.20
41.9
1.65

PART NUMBERS:

CB-301 NICKEL FINISH
CB-305 BRASS FINISH
CB-307 SATIN NICKEL FINISH
COMPONENTS ARE BAGGED TOGETHER IN POLYBAG
CYLINDER BODY ROTATES
THROUGH HOLE IN GLASS
32.4
1.28
23.2
.92
30.5
1.20
22.2
.88
7/8" DIAMETER HOLE
BORED IN GLASS
CENTERED 7/8" FROM EDGE
22.2
.88
CAM IN LOCKED
POSITION
DATE
DESCRIPTION
TYPE 300 GLASS DOOR CAM LOCK
915 Sherwood Drive
Lake Bluff, IL 60044
FINISH CAP IS
ATTACHED TO
GIVE FINISHED
APPEARANCE
NUT WASHER IS
HAND TIGHTENED
TO FASTEN CYLINDER BODY
TO GLASS
CAM IN UNLOCKED
POSITION
DRAWING#
03/24/03
CB-30X
Phone: 847-234-1864
Fax: 847-234-7922
