ND-70918(E)

ISSUE 1

CCIS System Manual

DECEMBER, 1999

NEC Corporation

Table of Contents

Advertisement

Need help?

Need help?

Do you have a question about the NEAX2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for NEC NEAX2000

Page 1 ND-70918(E) ISSUE 1 CCIS System Manual DECEMBER, 1999 NEC Corporation...
Page 2 NEC Corporation reserves the right to change the specifications, functions, or features, at any time, without notice. NEC Corporation has prepared this document for use by its employees and customers. The information contained herein is the property of NEC Corporation and shall not be reproduced without prior written approval from NEC Corporation.
Page 3 ISSUE 1 Addendum-001 SEPTEMBER, 2000 GENERAL This addendum supplements the “NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual [ND-70918(E)]”. REASON FOR ISSUED The addendum is issued in order to add the Series 2100 software (R2.2 software) enhancements and to correct errors of the manual.
Page 5 PAGE No. PAGE No. 61-1 61-2 64-1 64-2 ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE SEPTEMBER, 2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual Addendum Revision Sheet 1/5 ND-70918(E) ISSUE 1...
Page 6 106-2 86-1 86-2 125-1 125-2 130-1 130-2 ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE SEPTEMBER, 2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual Addendum Revision Sheet 2/5 ND-70918(E) ISSUE 1...
Page 7 179-2 179-3 179-4 152-1 152-2 152-3 152-4 ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE SEPTEMBER, 2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual Addendum Revision Sheet 3/5 ND-70918(E) ISSUE 1...
Page 8 259-1 259-2 267-1 267-2 267-3 267-4 273-1 ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE SEPTEMBER, 2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual Addendum Revision Sheet 4/5 ND-70918(E) ISSUE 1...
Page 9 285-1 285-2 285-3 Blank 285-4 285-5 285-6 ADDENDUM-001 ADDENDUM-002 ADDENDUM-003 ADDENDUM-004 DATE SEPTEMBER, 2000 DATE DATE DATE ADDENDUM-005 ADDENDUM-006 ADDENDUM-007 ADDENDUM-008 DATE DATE DATE DATE NEAX2000 IVS /NEAX2000/NEAX7400 ICS M100MX CCIS System Manual Addendum Revision Sheet 5/5 ND-70918(E) ISSUE 1...
Page 11 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX CCIS System Manual Revision Sheet 1/5 ND-70918(E)
Page 12 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX CCIS System Manual Revision Sheet 2/5 ND-70918(E)
Page 13 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX CCIS System Manual Revision Sheet 3/5 ND-70918(E)
Page 14 ISSUE No. ISSUE No. PAGE No. PAGE No. ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX CCIS System Manual Revision Sheet 4/5 ND-70918(E)
Page 15 ISSUE No. ISSUE No. PAGE No. PAGE No. Blank ISSUE 1 ISSUE 2 ISSUE 3 ISSUE 4 DATE DECEMBER,1999 DATE DATE DATE ISSUE 5 ISSUE 6 ISSUE 7 ISSUE 8 DATE DATE DATE DATE NEAX 2000/NEAX 7400 ICS M100MX CCIS System Manual Revision Sheet 5/5 ND-70918(E)
Page 17: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............................PURPOSE ............................. OUTLINE OF THIS MANUAL ......................TERMS IN THIS MANUAL ......................REFERENCE MANUAL ........................CHAPTER 1 GENERAL INFORMATION ..................SYSTEM OUTLINE ................................................................................................................................................No. 7 CCIS ............................Digital Network ........................... Analog Network ..........................
Page 18 TABLE OF CONTENTS Mounting DTI Card ......................... Mounting CCH Card ........................Mounting CCT Card ........................61-1 Mounting EXPMEM Card ....................... Mounting AP00 Card ........................Mounting CONN Card ........................Mounting M10 Card ........................Selection of PLO in MP Card ....................... Cable Connection via MDF ......................
Page 19 TABLE OF CONTENTS CENTRALIZED E911-CCIS ......................179-1 CENTRALIZED MAT-CCIS ......................CONSULTATION HOLD-ALL CALLS-CCIS ................DATA LINE SECURITY-CCIS ......................DELUXE TRAVELING CLASS MARK-CCIS ................DIAL ACCESS TO ATTENDANT-CCIS ..................DIRECT-IN TERMINATION-CCIS ....................DISTINCTIVE RINGING-CCIS ....................... DO NOT DISTURB-CCIS ........................ DUAL HOLD-CCIS ...........................
Page 20 TABLE OF CONTENTS PN-30DTC-C (DTI) ........................... 285-1 PN-SC00 (CCH) ..........................PZ-M537 (EXPMEM) ........................PZ-M542 (CONN) ..........................PZ-M557 (CONN) ..........................PN-2LDTA (LDT) ..........................PN-M10 (M10) ........................... PN-2ODTA (ODT) ..........................PN-2ODTB (ODT) ..........................CHAPTER 5 OPERATION TEST ....................... LOOP-BACK TEST ........................... INTEROFFICE TRANSMISSION LINE TEST ................
Page 21: Introduction
PURPOSE/OUTLINE OF THIS MANUAL INTRODUCTION PURPOSE This manual explains the hardware installation and programming procedure for providing Com- mon Channel Inter-Ofﬁce Signaling (CCIS) system to the NEAX2000 IVS /NEAX7400 ICS M100MX/NEAX2000 INTEGRATED VOICE SERVER. OUTLINE OF THIS MANUAL This manual consists of ﬁve chapters. The contents of CHAPTER 1 through 5 are outlined below.
Page 22: Terms In This Manual
When we must draw a clear line between the PBX systems, they are designated as follows. 2000 IVS : NEAX2000 IVS /NEAX7400 ICS M100MX/NEAX2000 INTEGRATED VOICE SERV- : NEAX2400 IMS (IMX)/NEAX7400 ICS M140MX or more/NEAX7400 IMX M240 or more REFERENCE MANUAL...
Page 23: General Information
CHAPTER 1 GENERAL INFORMATION CHAPTER 1 GENERAL INFORMATION This chapter explains the system outline, the name and functions of circuit cards required, system capacity, time slot assignment condi- tion, system speciﬁcations, available service features with No. 7 CCIS, and network structure considerations for CCIS system. SYSTEM OUTLINE ..............
Page 24: System Outline
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE SYSTEM OUTLINE This system can be interfaced with a Public Network or Tie Line Network by No. 7 CCIS Signal- ing. The system is conﬁgured with the 24/30 channel DTI (Digital Trunk Interface) for digital net- work or LDT (Loop Dial Trunk)/ODT (2 wire E&M or 4 wire E&M Trunk) for analog network via MODEM, a PLO (Phase Locked Oscillator) for digital network synchronization, and a CCH (Com- mon Channel Handler) for receiving/transmitting common signaling data from/to the distant of-...
Page 25: Dti
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE The Digital Trunk Interface (DTI) interfaces the 2000 IVS directly to a 24/30-channel PCM trans- mission line. The DTI has the following functions. For 24DTI: Unipolar/Bipolar Conversion (AMI Format) • Alarm Detection/Insertion • Digital PAD on Voice Signal Transmission •...
Page 26: Plo
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE The PLO (Phase Locked Oscillator) equipped on the MP card is responsible to synchronize the system and to the clock signals from the another ofﬁce. When the PBX is a clock receiver ofﬁce, the PLO generates the clock signals according to the source clocks received from the source ofﬁce within the network.
Page 27: No. 7 Ccis
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE No. 7 CCIS The PBX can provide No. 7 CCIS via either a digital network or an analog network. Regardless of the digital network or analog network, CCH (Common Channel Handler) to control the com- mon signaling channel is required.
Page 28: Analog Network
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE Analog Network When No. 7 CCIS is provided via an analog network, the CCH is connected to the Common Sig- naling Channel Controller in the distant ofﬁce via MODEMs, directly. Voice signals are transmit- ted/received through analog trunks (LDT/ODT).
Page 29: Centralized Billing
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE Centralized Billing Centralized Billing is a function that transmits billing information at each ofﬁce to the center ofﬁce within the same network through the common signaling channels of No. 7 CCIS. To transmit the own billing information of the local ofﬁce to the center ofﬁce, or transfer the billing information from other local ofﬁces to the center ofﬁce, an AP (Application Processor) or Built-in SMDR of MP card is required for each ofﬁce.
Page 30: Service Conditions For Centralized Billing
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE Service Conditions for Centralized Billing If all the PBXs within the network are the 2000 IVS , the PBX can be a center billing ofﬁce. In that case, there are the following conditions: For Center Ofﬁce; MP Built-in SMDR can not be used.
Page 31 CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE For Local Ofﬁce using AP00; The AP00 can not be used when MP Built-in SMDR is provided in the own ofﬁce • (CM08>800: 0). A billing information of own ofﬁce can be sent to the SMDR of the own ofﬁce. •...
Page 32: Inter-Office Digital Data Transmission Through No. 7 Ccis
CHAPTER 1 GENERAL INFORMATION SYSTEM OUTLINE Inter-Ofﬁce Digital Data Transmission through No. 7 CCIS The PBX can provide Inter-Ofﬁce Digital Data Transmission through No. 7 CCIS. When the PBX is an end ofﬁce in the Inter-Ofﬁce Digital Data Transmission through No. 7 CCIS with Digital Interface, the digital signal is transmitted directly.
Page 33: Card Name And Function
CHAPTER 1 GENERAL INFORMATION CARD NAME AND FUNCTION CARD NAME AND FUNCTION This table shows the circuit card name and function for No. 7 CCIS. Card Name and Function EQUIPMENT FUNCTIONAL FUNCTION NAME NAME PN-AP00-B AP00 Application Processor Card Provides four RS-232C ports, and is used for SMDR, Hotel Printer, CIS, PMS, MCI, CS report functions.
Page 34 CHAPTER 1 GENERAL INFORMATION CARD NAME AND FUNCTION Card Name and Function EQUIPMENT FUNCTIONAL FUNCTION NAME NAME PN-2LDTA 2-line Loop Dial Trunk Card [For Austra- Line resistance: Max. 2500 ohms (including internal resis- lia/Other tance of the distant ofﬁce equipment) Countries] Equipped with –48V DC-DC on-board power supply.
Page 35 CHAPTER 1 GENERAL INFORMATION CARD NAME AND FUNCTION Card Name and Function EQUIPMENT FUNCTIONAL FUNCTION NAME NAME PZ-M537 EXPMEM Memory Expansion Card for AP00 Card The number of SMDR call record is expanded when mounted on PN-AP00-B (AP00) card. System Capacity No EXPMEM With EXPMEM SMDR call record...
Page 36: System Capacity
CHAPTER 1 GENERAL INFORMATION SYSTEM CAPACITY SYSTEM CAPACITY CCIS with Digital Interface System Capacity for CCIS with Digital Interface CAPACITY DESCRIPTION 30DTI 24DTI 24CCT 30CCT 30DTC-A 30DTC-C DTI Card — — CCH Card — — AP00 Card (for Centralized Billing) Trunks for DTI —...
Page 37: Time Slot Assignment Condition
CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION TIME SLOT ASSIGNMENT CONDITION As shown below, the 30DTI (30DTC-A)/CCH cards use the time slots on the basic highway 4. Therefore, the total number of time slots for all 30DTI (30DTC-A)/CCH cards must be 128 time slots or less including all other application processor (AP) cards, which use the highway 4.
Page 38: Time Slot Allocation For Dti Card
CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION Time Slot Allocation for DTI Card On each DTI card, the system recognizes the lowest and highest channel numbers to which trunk numbers are assigned, and allocates time slots to all the channels between them. If trunk num- bers are assigned to nonconsecutive channels, the system also allocates time slots to channels not assigned.
Page 39: Number Of Time Slots Required For Dti/Cch Card
CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION Number of Time Slots Required for DTI/CCH Card (1) When the system is serving as a Lower Hierarchy Ofﬁce within the network, 1 time slot is allocated for setting up a ﬁxed path between the DTI/ODT and the CCH as the common signaling channel.
Page 40 CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION Following ﬁgures show the CCH time slot assignment for CCIS with Digital Interface. CCH Time Slot Assignment (for No. 7 CCIS with Digital Interface) • Network Configuration: : Main Office : Local Office (High Hierarchy Office) A, B, C: Local Office (Low Hierarchy Office) •...
Page 41 CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION Following ﬁgures show the CCH time slot assignment for No. 7 CCIS with Analog Interface. CCH Time Slot Assignment (for No. 7 CCIS with Analog Interface) • Network Configuration: : Main Office : Local Office (High Hierarchy Office) A, B, C: Local Office (Low Hierarchy Office) •...
Page 42 CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION This table shows the number of time slots for each of the cards required for No. 7 CCIS with Dig- ital Interface and next page shows the number of time slots for each of the cards required for No. 7 CCIS with Analog Interface.
Page 43 CHAPTER 1 GENERAL INFORMATION TIME SLOT ASSIGNMENT CONDITION Number of Time Slots Required per CCH/AP00 Card (for No. 7 CCIS with Analog Interface) NUMBER OF TIME CARD REMARKS SLOTS PER CARD PN-SC00 • For a distant Main Ofﬁce – Common Signaling Channel: 1 time slot •...
Page 44: Dti Specifications
CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS DTI SPECIFICATIONS Transmission Characteristics Transmission Characteristics CHARACTERISTICS 24-CHANNEL 30-CHANNEL (1) Output Line Rate 1.544 Mbps ±50 ppm 2.048 Mbps ±50 ppm • Line Code AMI with ZCS/B8ZS* HDB3 (High Density Bipolar 3) • Line Impedance 100 ohms 75 ohms •...
Page 45: Frame Configuration Of 24Dti
CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS Frame Conﬁguration of 24DTI According to the AT&T Speciﬁcations for 24-channel transmission, there are two types of frame conﬁgurations: 12-Multi Frame (D4) and 24-Multi Frame (ESF). (1) 12-Multi Frame (D4) The frame has 12-Multi Frames, and each Multi frame has a 24-channel PCM signal (8 bits/ channel) and an S bit (Super Frame Bit).
Page 46 CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS 12-Multi Frame Bit Assignment S BIT FRAME TERMINAL SIGNAL SYNCHRONIZATION SYNCHRONIZATION (FT) (FS) * The S-bit is the ﬁrst bit in each frame. * Frames are repeated in the order shown above. – 26 – Rev.1.1 97024-11...
Page 47 CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS (2) 24-Multi Frame (Extended Super Frame <ESF>) This frame has 24-Multi Frames and each Multi frame has a 24-Channel PCM signal (8 bits/ channel) and an S bit (Super Frame Bit). This ﬁgure shows the frame conﬁguration, and table on next page shows frame bit assignment.
Page 48 CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS 24-Multi Frame Bit Assignment S BIT FRAME FRAME 4 Kbps SYNCHRONI- DATA ZATION LINK – 28 – Rev.1.1 97024-11...
Page 49 CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS * The S-bit is the ﬁrst bit in each frame. * Frames are repeated in the order shown above. * “m” in the “4 Kbps Data Link” column means that the frame is usually assigned to 1. –...
Page 50: Frame Configuration Of 30Dti
CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS Frame Conﬁguration of 30DTI Based on 30-channel transmission method of ITU-T Speciﬁcation, the frame conﬁguration con- sists of 16-multi frame, each frame having 32 time slots. This ﬁgure shows the frame conﬁguration, and table on next page shows the details of time slot assignment.
Page 51: Modem Specifications
CHAPTER 1 GENERAL INFORMATION DTI SPECIFICATIONS Time Slot Assignment of 30DTI TIME SLOT EVEN No. FRAME ODD No. FRAME Frame Alignment Signal (FAS) REMOTE ALARM CRC BIT 0: NORMAL CRC BIT 1: FRAME LOSS TS1-TS15 Voice Channel CH1-CH15 TS16 No. 7 CCIS: •...
Page 52: Service Features
CHAPTER 1 GENERAL INFORMATION SERVICE FEATURES SERVICE FEATURES List of No. 7 CCIS Service Features SERVICE FEATURES REMARKS Attendant Camp-On with Tone Indication-CCIS Attendant Controlled Conference-CCIS NOTE 1 Brokerage-Hot Line-CCIS Busy Veriﬁcation-CCIS Call Back-CCIS NOTE 2 Call Forwarding-All Calls-CCIS Call Forwarding-Busy Line-CCIS Call Forwarding-Don’t Answer-CCIS Call Forwarding-Intercept-CCIS Call Forwarding-Override-CCIS...
Page 53 CHAPTER 1 GENERAL INFORMATION SERVICE FEATURES List of No. 7 CCIS Service Features SERVICE FEATURES REMARKS Elapsed Time Display-CCIS Flexible Numbering of Stations-CCIS Hands-Free Answer back-CCIS Hot Line-CCIS House Phone-CCIS Incoming Call Identiﬁcation-CCIS Individual Attendant Access-CCIS NOTE 4 LDN Night Connection-CCIS Link Alarm Display-CCIS Message Waiting Lamp Setting-Attendant-CCIS NOTE 3...
Page 54 CHAPTER 1 GENERAL INFORMATION SERVICE FEATURES List of No. 7 CCIS Service Features SERVICE FEATURES REMARKS Toll Restriction-3/6 Digits-CCIS Trunk Answer from Any Station (TAS)-CCIS Trunk to Trunk Restriction-CCIS Uniform Numbering Plan-CCIS Voice Call-CCIS Voice Mail Integration-CCIS NOTE 1: An attendant/extension of the IMX must be a conference leader. NOTE 2: This service is available by the closed numbering plan.
Page 55: Network Structure Considerations
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS NETWORK STRUCTURE CONSIDERATIONS Determining System Conﬁguration The conﬁguration of the network and the number of lines (channels) should be determined, and is dependent on the trafﬁc between each ofﬁce (PBX). For example, when the trafﬁc between Of- ﬁce A and Ofﬁce C is high (as shown in the network of the following ﬁgure), Ofﬁce A and Ofﬁce C should be connected by No.
Page 56: Determining Which Pbx Should Be Main Office
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Determining Which PBX Should Be Main Ofﬁce When using No. 7 CCIS, the following features require establishing a clear relationship between the Main and Satellite ofﬁces: Centralized Attendant Service (CAS) • – Attendant Camp-On with Tone Indication-CCIS –...
Page 57: Determining Point Code
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS For Centralized Fault Message, the PBX cannot generate its own fault message. It can only relay a fault message from one ofﬁce to another ofﬁce. OFFICE A OFFICE B OFFICE C PRINTER FOR FAULT MESSAGE NO.
Page 58 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Data Assignment of Ofﬁce A • Command Code 1st Data 2nd Data Remarks CMA7 Y=01 00001 Assign the Originating Point Code and the   CMA7 Y=02 00002 Destination Point Code for CCH0. CMA7 Y=01 00001 Assign the Originating Point Code and the...
Page 59: Determining Cch Link To Send Messages
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Determining CCH Link to Send Messages Each system MP must be programmed with the proper information indicating to which CCH (in its own system) every other ofﬁce in the network is connected. This is required for providing inter- ofﬁce services such as Attendant Camp-On, Call Back, and Busy Veriﬁcation when using CCIS.
Page 60 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Data Assignment of Ofﬁce C • Command Code 1st Data 2nd Data Remarks CMA8 00001 Assign the data to make a CCH link with  00002 Office D via CCH0, and make a CCH link ...
Page 61: Determining Numbering Plan
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Data Assignment of Ofﬁce B • Command Code 1st Data 2nd Data Remarks CMA8 00001 Assign the data to make a CCH link with  00003 Office A via CCH0 make a CCH link with ...
Page 62 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Example of Station Number (Closed Numbering) Station Numbering (Closed Numbering): 53 × × 53 × × 52 × × 54 × × 52 × × 54 × × • When originating a call from Office A to Office C 54 ×...
Page 63 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Limitations on developing the Uniform Numbering Plan are as follows: (1) Station Number (Closed Numbering) The dialing number must be formed as follows: • XXXXXXXX Station Number (Max. 8 digits) Office Location Number (Max.
Page 64 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS LCR Groups 0-3 (CM20>A126-A129) can be used for assigning an LCR access code. • When providing a pseudo dial tone to alter the dialing access code, LCR Groups 0-2 • (CM20>A126-A128) must be used. Example 1: Station Number (Closed Numbering) When the ofﬁce location number is distinguished by the 1st or 2nd digit of the dialed station •...
Page 65 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS When the ofﬁce location number is distinguished by the 3rd digit of the dialed station num- • ber: 512 × 513 × NO. 7 CCIS Data Assignment of Ofﬁce A • Command Code 1st Data 2nd Data Remarks...
Page 66 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Example 2: Ofﬁce Code and Station Number (Open Numbering) 31 ×× 21 ×× 34 ×× Access Code: 8 Office Code : 20 (Office A) 21 (Office B) 22 (Office C) Data Assignment of Ofﬁce A •...
Page 67 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Pattern 2 (Used when not receiving pseudo dial tone.) Command Code 1st Data 2nd Data Remarks CM20 Y=0 A129 LCR Group 3 CM8A Y=A000 4005 Area Code Development Pattern No. 5 CM8A Y=4005 8000 Intra Office Termination CM8A Y=4005...
Page 68: Determining Route Advance
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Determining Route Advance In a No.7 CCIS network, the system can automatically route outgoing calls over an alternate fa- cility. Example 1: When the number of tie line routes is two or more: 21 ××...
Page 69 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Example 2: When route advance to C.O. is required because the desired tie lines are all busy: C.O. DID (LDN: 516753-××××) 21 ×× 31 ×× NO. 7 CCIS CONDITIONS: Ofﬁce Code and Station Number (Open Numbering) •...
Page 70 CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Example 3: When route advance to one’s own ofﬁce C.O. is required and the tie line route of the tandem ofﬁce connected through CCIS are all busy: C.O. DID (LDN: 516753-××××) NO. 7 CCIS NO.
Page 71: Network Construction With Imx
CHAPTER 1 GENERAL INFORMATION NETWORK STRUCTURE CONSIDERATIONS Network Construction with IMX The Tenant Number and the Trunk Restriction Class are different between the 2000 IVS and the IMX as indicated below. 2000 IVS Tenant No. 00-63 01-255 • (CM12 Y=04, CM30 Y=01) Trunk Restriction class 1-15 •...
Page 72 THIS PAGE LEFT BLANK INTENTIONALLY. – 52 – 97044-10...
Page 73: Installation
CHAPTER 2 INSTALLATION CHAPTER 2 INSTALLATION This chapter explains the required equipment and the hardware instal- lation procedure to provide CCIS system. PRECAUTIONS ................. REQUIRED EQUIPMENT ............INSTALLATION PROCEDURE FOR DIGITAL CCIS ....INSTALLATION PROCEDURE FOR ANALOG CCIS ....– 53 – Rev.1.1 97053-11...
Page 74: Precautions
CHAPTER 2 INSTALLATION PRECAUTIONS PRECAUTIONS Static Electricity Guard You must wear a grounded wrist strap to protect circuit cards from static electricity. Static Electricity Guard • WHEN PLUGGING/UNPLUGGING A CIRCUIT CARD FRAME GROUND SCREW WRIST STRAP • WHEN HOLDING A CIRCUIT CARD NEVER TOUCH THE COMPONENTS OR SOLDERED SURFACE WITH BARE HANDS.
Page 75 CHAPTER 2 INSTALLATION PRECAUTIONS Static Electricity Guard • WHEN MAKING A SWITCH SETTING ON A CIRCUIT CARD CIRCUIT CARD WEAR A WRIST STRAP AND PERFORM THE WORK ON A GROUNDED CONDUCTIVE WORK SURFACE. • WHEN CARRYING A CIRCUIT CARD CONDUCTIVE CIRCUIT POLYETHYLENE CARD...
Page 76 CHAPTER 2 INSTALLATION PRECAUTIONS CAUTION You must hold the edge of a circuit card when plugging or unplugging the circuit card. If you touch another area, you may be exposed to hazard voltages. NEVER TOUCH THE COMPO- NENTS OR SOLDERED SUR- FACE WITH BARE HANDS.
Page 77: Required Equipment
CHAPTER 2 INSTALLATION REQUIRED EQUIPMENT REQUIRED EQUIPMENT This table shows the equipment required when providing No. 7 CCIS with digital interface to the system. Required Equipment for Digital CCIS EQUIPMENT DESCRIPTION QUANTITY REMARKS PN-24DTA-C 24-channel DTI Card (24DTI) PN-30DTC-A 30-channel DTI Card (30DTI) PN-30DTC-C 30-channel DTI Card...
Page 78 CHAPTER 2 INSTALLATION REQUIRED EQUIPMENT This table shows the equipment and cables required when providing No. 7 CCIS with analog in- terface. Required Equipment for Analog CCIS EQUIPMENT DESCRIPTION QUANTITY REMARKS PN-2LDT (LDT) or Loop Dial Trunk or 1-128 PN-2ODT (ODT) 2-wire E&M/4-wire E&M Trunk PN-SC00 (CCH) Common Channel Handler Card...
Page 79: Installation Procedure For Digital Ccis
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS INSTALLATION PROCEDURE FOR DIGITAL CCIS Install the equipment according to the procedures shown below. For installation of the PBX, refer to the Installation Procedure Manual. Installation Procedure for Digital CCIS START page 60 Mounting DTI Card page 61-1 Mounting CCT Card...
Page 80: Mounting Dti Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting DTI Card (1) Before mounting the DTI (PN-24DTA-C/PN-30DTC-A/PN-30DTC-C) card, set the MB switch to UP position, and set the other switches to ATTENTION appropriate position. Contents Static Sensitive See CHAPTER 4. page 257 Handling Precautions Required...
Page 81: Mounting Cch Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting CCH Card (1) Before mounting the CCH (PN-SC00) card, set the MB switch to UP position, and set the other switches to appropriate position. ATTENTION See CHAPTER 4. page 257 Contents Static Sensitive Handling Precautions Required...
Page 82: Mounting Cct Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting CCT Card (1) Before mounting the CCT (PN-24CCTA/PN-30CCTA) card, set the MB switch to UP position, and set the other switches to appropriate position. ATTENTION See CHAPTER 4. page 257 Contents Static Sensitive Handling Precautions Required...
Page 83 THIS PAGE LEFT BLANK INTENTIONALLY. – 61-2 – Rev.1.1 97059-11...
Page 84: Mounting Expmem Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting EXPMEM Card When billing information of more than 1600 calls is needed, install the EXP- MEM (PZ-M537) card on the AP00 (PN-AP00-B) card as below. ATTENTION Contents Static Sensitive (1) Conﬁrm the correct switch setting of the EXPMEM card. Handling Precautions Required See CHAPTER 4.
Page 85: Mounting Ap00 Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting AP00 Card When Centralized Billing is required, install the AP00 (PN-AP00-B) card in center ofﬁce as below. ATTENTION When billing information of more than 1600 calls is needed, install the AP00 Contents Static Sensitive card as below.
Page 86: Mounting Conn Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting CONN Card When providing the CONN (PZ-M542/PZ-M557) card to connect a coaxial ca- ble for 30DTI card, do the following installation. ATTENTION Contents Static Sensitive (1) Conﬁrm the correct switch settings of the CONN card. Handling Precautions Required See CHAPTER 4.
Page 87 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS STEP2: Connect the LT connector on the PZ-M542/PZ-M557 card to the LTC connector on BWB in PIM. NOTE: Two PZ-M542/PZ-M557 cards can not be mounted on the adjoining LTC connectors. LTC0 and LTC2, or LTC0 and LTC3, or LTC1 and LTC3 are mountable. Mounting of PZ-M542/PZ-M557 Card LTC CONNECTOR L T C...
Page 88 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS STEP3: Secure the PZ-M542/PZ-M557 card to the PIM CARD STOPPER with one screw. NOTE1: Screw is attached to the PZ-M542/PZ-M557 card. NOTE2: Before securing the PZ-M542/PZ-M557 card to the PIM CARD STOPPER, all the cards should be mounted on the card slots and the PIM CARD STOPPER should be secured with screws.
Page 89: Mounting M10 Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Mounting M10 Card (1) Conﬁrm the correct switch settings of the M10 (PN-M10) card. See CHAPTER 4. page 257 ATTENTION Contents Static Sensitive (2) Mount the M10 card in the following LT slots on PIM0 through PIM7. Handling Precautions Required PIM0-7: LT00-LT11...
Page 90: Selection Of Plo In Mp Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Selection of PLO in MP Card (1) Conﬁrm the correct switch settings of MP (PN-CP14/PN-CP20) card. See CHAPTER 4. page 257 ATTENTION Contents Static Sensitive (2) Mount the MP card in the following MP slot of PIM0. Handling Precautions Required PN-CP14: MP12...
Page 91: Cable Connection Via Mdf
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Cable Connection via MDF When using a twisted-pair cable, connect the cable to a CSU via the MDF as shown below. • Location of AP Slots and LTC Connectors for DTI/CCT page 68 •...
Page 92 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Location of AP Slots and LTC Connectors for DTI/CCT LTC0 LTC1 LTC2 LTC3 AP09 SLOT AP03 AP00 AP06 SLOT SLOT SLOT AP10 SLOT AP04 AP07 AP01 SLOT SLOT SLOT AP08 AP11 SLOT SLOT AP05 AP02...
Page 93 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Example of MDF Cross Connection for DTI/CCT PIM 0 LTC1 DTI/CCT RECEIVE AP05 TO CSU TRANSFER LTC1 (J) LTC1 (P) – 69 – Rev.1.1 97067-11...
Page 94: Cable Connection Via Conn Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Cable Connection via CONN Card When using a coaxial cable, connect the cable to a CSU via the CONN (PZ-M542/PZ-M557) card as shown below. The ﬁgure in next page shows an example of the cable connection when the DTI/CCT card is mounted in the AP05 slot of PIM0.
Page 95 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Example of Coaxial Cable Connection PIM 0 LTC1 CONN CARD RECEIVE AP05 TO CSU SEND LTC1 CONNECTOR COAXIAL CONNECTOR LTC1 (J) LTC1 (P) – 71 – Rev.1.1 97067-11...
Page 96: Optical Fiber Connection
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Optical Fiber Connection The optical ﬁber interface card (PN-M10) is available for DTI to DTI connection or CCT to CCT connection between the 2000 IVS s/Retro system of them. (1) Connect the ﬁbers each other to the CN1 connector of the M10 cards. Fiber Requirement Size of ﬁber: Any size of Single Mode ﬁber Kind of ﬁber optic connector: SC connector...
Page 97 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Example of MDF Cross Connection for M10 Card PIM 0 LTC3 DTI/CCT RECEIVE AP09 TRANSFER LTC3 DTI/CCT RECEIVE AP10 TRANSFER LTC1 RECEIVE No. 1 TRANSFER LT05 RECEIVE No. 0 TRANSFER TRANSFER TO UPSIDE OF CN1 CONNECTOR OF M10 CARD IN OPPOSITE OFFICE RECEIVE TO DOWNSIDE OF CN1 CONNECTOR OF M10 CARD IN OPPOSITE OFFICE Continued on next page...
Page 98 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR DIGITAL CCIS Example of MDF Cross Connection for M10 Card 1 LTC3 CONNECTOR LTC (J) 2 LTC3 CONNECTOR LTC (J) 3 LTC1 CONNECTOR LTC (J) – 74 – Rev.1.1 97072-11...
Page 99: Installation Procedure For Analog Ccis
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS INSTALLATION PROCEDURE FOR ANALOG CCIS Install the equipment according to the procedure shown below. For installation of the PBX, refer to the Installation Procedure Manual. Installation Procedure for Analog CCIS START page 76 Mounting LDT/ODT Card page 61 Mounting CCH Card...
Page 100: Mounting Ldt/Odt Card
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS Mounting LDT/ODT Card Mount the LDT (PN-2LDTA) card or the ODT (PN-2ODTA/PN-2ODTB) card in the following LT slots on PIM0 through PIM7. ATTENTION PIM0-7: LT00-LT11 Contents Static Sensitive PIM0 (for Backup CPU): LT00-LT10 Handling Precautions Required The LT11 or LT10 slot on PIM0 is available only when the FP card is not...
Page 101: Cable Connection Of Cch And Modem
CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS Cable Connection of CCH and MODEM • When providing the Common Signaling Data Link via MODEM: (1) Connect the RS NORM-4 CA-A/RS NORM-4S CA-A to the CCH card and the MODEM (PBX side) as shown below. Cable Connection for Common Signaling Data Link via MODEM PSTN: Public Switched Telephone Network...
Page 102 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS • When providing the Common Signaling Data Link via LDT/ODT: (1) Connect the RS NORM-4 CA-A/RS NORM-4S CA-A to the CCH card and the MODEM (PBX side) as shown below. Cable Connection for Common Signaling Data Link via LDT/ODT RS NORM-4 CA-A/RS NORM-4S CA-A (4 m/13.1 ft.) MODEM...
Page 103 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS Location of AP Slots and LTC Connectors for CCH LTC0 LTC1 LTC2 LTC3 RCVR RCVT RCVR RCVT RCVR RCVT RCVR RCVT AP09 SLOT AP03 AP00 AP06 SLOT SLOT SLOT RCVR RCVT RCVR RCVT RCVR RCVT...
Page 104 CHAPTER 2 INSTALLATION INSTALLATION PROCEDURE FOR ANALOG CCIS Example of LINE Cable and MDF Cross Connection for CCH PIM 0 LTC1 (TX Ring) TX R (TX Tip) TX T (RCV Ring) RCV R (RCV Tip) RCV T AP05 [LT05] Not Used MODEM LINE MODULAR...
Page 105: System Data Programming
CHAPTER 3 SYSTEM DATA PROGRAMMING CHAPTER 3 SYSTEM DATA PROGRAMMING This chapter explains the programming procedure for providing CCIS system, and also explains the general description, programming pro- cedure, operating procedure, and hardware requirement of each ser- vice feature. HOW TO READ THIS CHAPTER ..........DIGITAL CCIS PROGRAMMING ..........
Page 106: How To Read This Chapter
CHAPTER 3 SYSTEM DATA PROGRAMMING HOW TO READ THIS CHAPTER HOW TO READ THIS CHAPTER This chapter explains the feature programming for each service feature about the following Ab- breviations. (1) : 1st data (2) : 2nd data : Initial data; With the system data clear command (CM00, CM01), the data with this marking is automatically set for each command.
Page 107: Digital Ccis Programming
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DIGITAL CCIS PROGRAMMING Program the system data according to the procedures shown below. Programming Procedure for Digital CCIS START Digital Trunk Data page 84 Assignment page 89 CCH Assignment Numbering Plan page 91 Assignment Inter-Tenant Connection page 95...
Page 108: Digital Trunk Data Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Digital Trunk Data Assignment DESCRIPTION DATA START CM05 Assign an AP number to each DTI/CCT • card. The AP number must match the 04-15, 20-31: AP No. switch settings on the DTI/CCT card. 09: DTI card 11: CCT card INITIAL...
Page 109 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA Assign the necessary functions to each Y=00 Data Mode • CMAA 24DTI/24CCT cards. 04-15, 20-31: AP No. assigned by CM05 Y=0 DTI INITIAL 0: Based on AT&T Speciﬁcations After entering the data, set the MB switch Y=01 Frame Conﬁguration •...
Page 110 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA Assign a trunk route number to each DTI/ Y=00 CM30 • CCT. 000-255: Trunk No. assigned by CM07 Y=01 NOTE 1: The trunk routes used for a com- 00-63: Trunk Route No. mon signaling channel must be different from the trunk routes used for voice channels.
Page 111 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA Specify the DTI/CCT PAD Patterns on the Y=19 CM35 • voice channel route. 00-63: Trunk Route No. : Programmable PAD (See CM42. page 87 : Fixed PAD (See the following tables.) CM35 Y=19 DTI/CCT PAD [Australia/New Zealand] [North America/Other Countries]...
Page 112 THIS PAGE LEFT BLANK INTENTIONALLY. – 86-2 – Rev.1.1 97083-11...
Page 113 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA When using the programmable PAD 50-65: See tables below. CM42 (CM35 Y=19, 2nd Data=0-3), assign the 00-15: See tables below. PAD data for the DTI/CCT. PATTERNS PAD DATA PATTERNS CONNECTING PATTERNS (A-B) CM35 Y=19 CM35 Y=19...
Page 114 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA [North America/Other Countries (µ-law)] [Other Countries (A-law)] CM42 PATTERNS PAD DATA OF PATTERNS PAD DATA OF B TRUNK B TRUNK DTI/CCT (T/R) DTI/CCT (T/R) 2ND DATA [dB] 2ND DATA [dB] –2/–2 –2/–2 –3/–3...
Page 115: Cch Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING CCH Assignment DESCRIPTION DATA START Assign an AP number to the CCH or CCT CM05 • card. The AP number must match the 04-15, 20-31: AP No. switch settings on the CCH or CCT card. 11: CCH/CCT card INITIAL Assign a CCH number to each CCH or...
Page 116 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA Assign a Destination Point Code (DPC) to Y=02 CMA7 • each CCH number. 0-7: CCH No. 00001-16367: DPC NOTE: The Destination Point Code is used to designate a terminating ofﬁce in the No. 7 CCIS network. Usually a different DPC is as- signed to each CCH number in the same system.
Page 117: Numbering Plan Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Numbering Plan Assignment • For open numbering system DESCRIPTION DATA START CM20 Assign the access code for LCR Group 0- • Y=0-3 Numbering Plan Group 0-3 X-XXXX: Access Code A126: LCR Group 0 A127: LCR Group 1 A128: LCR Group 2 A129: LCR Group 3...
Page 118 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA For area code delection, designate the Y=5000-5255 CM8A • digits to be deleted. LCR Pattern No. 000-255 153: Designation of digit to be deleted : No digit deletion 01-10: Leading 1-10 digits deletion CCC : No digit deletion For area code addition, designate the dig- •...
Page 119 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING • For closed numbering system DESCRIPTION DATA START CM20 Assign the access code for LCR Group 3. Y=0-3 Numbering Plan Group 0-3 • X-XXXX: Access Code A129: LCR Group 3 When providing Centralized MAT or Num- Y=0-3 Numbering Plan Group 0-3 •...
Page 120 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING DESCRIPTION DATA For area code deletion, designate the dig- Y=5000-5255 CM8A • its to be deleted. LCR Pattern No. 000-255 153: Designation of digit to be deleted : No digit deletion 01-10: Leading 1-8 digits deletion CCC : No digit deletion For area code addition, designate the dig- •...
Page 121: Inter-Tenant Connection Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Inter-Tenant Connection Assignment DESCRIPTION DATA START CM12 Assign the tenant number to each station. • Y=04 X-XXXXXXXX: Station No. NOTE: When linking with the IMX, the 00-63: Tenant No. 00-63 tenant number for the 2000 IVS : Tenant No.
Page 122 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Example 1: Inter-Tenant Connection for Station-to-Station Calling STA. A TRUNK A STA. B TRUNK B NO. 7 CCIS OFFICE OFFICE TENANT NO. TENANT NO. OF STA. A: 01 OF STA. B: 02 For the inter-tenant connection between Station A and Station B, the data assignment at Ofﬁce B is as follows.
Page 123 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Example 2: Inter-Tenant Connection for Incoming Call Termination STA. B TRUNK C TRUNK A TRUNK B NO. 7 CCIS OFFICE OFFICE TENANT NO. TENANT NO. OF TRUNK C: 01 OF STA. B: 02 For the inter-tenant connection between Trunk C (Ofﬁce A) and Station B (Ofﬁce B), the data as- signment at Ofﬁce B is as follows.
Page 124: Sample Data Programming For Open Numbering System
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Sample Data Programming for Open Numbering System EXAMPLE OFFICE A PC: 00001 OFFICE B PC: 00010 OFFICE NO.: 820 OFFICE NO.: 822 DTI0 RT10 TRK000 CIC=1 CIC=1 31xx 32xx TRK001 CIC=2 CIC=2 RT11 21xx TRK002...
Page 125 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING For ofﬁce A, the following programming is required: (1) Assign the DTI card. Command Code 1st Data 2nd Data 05 Y=0 : DTI0 : DTI1 05 Y=1 : Basic Highway channel : Basic Highway channel (2) Assign a trunk number to the required DTI channels.
Page 126 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (5) Assign the trunk route data. Command Code 1st Data 2nd Data 35 Y=00 Tie Line route assignment 35 Y=01 Dialing signal type 35 Y=04 Answer Signal 35 Y=05 Release Signal 35 Y=09 Incoming connection signal 35 Y=19 DTI PAD Pattern assignment...
Page 127 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (7) Assign the CCH number to each CCH. Command Code 1st Data 2nd Data 06 Y=07 : CCH 0 : CCH 1 (8) Assign the CCH number to each route. Command Code 1st Data 2nd Data 35 Y=91...
Page 128 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (11) Assign the route access data. Command Code 1st Data 2nd Data 20 Y=0 A126 : Access Code=8 8A Y=A000 4005 : Area Code Development Pattern No. 5 8A Y=4005 0000 : Route Pattern 000 0001 : Route Pattern 001 8A Y=0000...
Page 129: Sample Data Programming For Closed Numbering System
CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING Sample Data Programming for Closed Numbering System EXAMPLE OFFICE A PC: 00001 OFFICE B PC: 00010 OFFICE NO.: 21 OFFICE NO.: 22 DTI0 RT10 TRK000 CIC=1 CIC=1 22xx TRK001 CIC=2 CIC=2 RT11 TRK002 21xx CCH0...
Page 130 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING For ofﬁce A, the following programming is required: (1) Assign the DTI card. Command Code 1st Data 2nd Data 05 Y=0 : DTI0 : DTI1 05 Y=1 : Basic Highway channel : Basic Highway channel (2) Assign a trunk number to the required DTI channels.
Page 131 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (5) Assign the trunk route data. Command Code 1st Data 2nd Data 35 Y=00 Tie Line route assignment 35 Y=01 Dialing signal type 35 Y=04 Answer Signal 35 Y=05 Release Signal 35 Y=09 Incoming connection signal 35 Y=19 DTI PAD Pattern assignment...
Page 132 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (7) Assign the CCH number to each CCH. Command Code 1st Data 2nd Data 06 Y=07 : CCH 0 : CCH 1 (8) Assign the CCH number to each route. Command Code 1st Data 2nd Data 35 Y=91...
Page 133 CHAPTER 3 SYSTEM DATA PROGRAMMING DIGITAL CCIS PROGRAMMING (11) Assign the route access data. Command Code 1st Data 2nd Data 20 Y=0 A129 : Access Code=22 20 Y=0 A129 : Access Code=25 8A Y=A000 4007 : Area Code Development Pattern No. 5 8A Y=4007 0000 : Route Pattern 000 (22XX)
Page 134 THIS PAGE LEFT BLANK INTENTIONALLY. – 106-2 – Rev.1.1 97103-11...
Page 135: Analog Ccis Programming
CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING ANALOG CCIS PROGRAMMING Program the system data according to the procedures shown below. Programming Procedure for Analog CCIS START page 108 LDT/ODT Assignment page 113 CCH Assignment Numbering Plan page 113 Assignment Inter-Tenant Connection page 113 Assignment...
Page 136: Ldt/Odt Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING LDT/ODT Assignment DESCRIPTION DATA START CM10 Assign a trunk number to each LDT/ODT 000-763: LEN card. D000-D255: Trunk No. Any trunk number already assigned by NOTE: The Trunk number must be as- CM07 cannot be used.
Page 137 CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING DESCRIPTION DATA CM35 Specify the PAD Patterns on the voice Y=19 • channel route. 00-63: Trunk Route No. 0-3 : Programmable PAD [Australia/New Zealand] (See CM42. page 111 4-7 : Fixed PAD PAD DATA OF B TRUNK [dB] (See left column.) CONNECTION...
Page 138 CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING DESCRIPTION DATA [North America/Other Countries] CM35 PAD DATA OF B TRUNK [dB] CONNECTION PATTERNS (A-B) DATA DATA DATA DATA =4 (T/R) =5 (T/R) =6 (T/R) =7 (T/R) Station- –3/–3 –3/–3 ODT (4W E&M) Tone- ODT (4W E&M) COT/DID/LDT/IPT-...
Page 139 CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING DESCRIPTION DATA When using the programmable PAD 50-65: See tables below. CM42 (CM35 Y=19, 2nd Data=0-3), assign the 00-15: See tables below. PAD data. PATTERNS PAD DATA PATTERNS CONNECTING PATTERNS (A-B) CM35 Y=19 CM35 Y=19 CM35 Y=19 CM35 Y=19...
Page 140 CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING DESCRIPTION DATA CM42 [North America/Other Countries (µ-law)] PATTERNS PAD DATA OF B TRUNK (T/R) [dB] ODT (4W E&M) ODT (2W E&M) 2ND DATA –2/–2 –3/–3 –3/–3 –3/–3 –12/–11 –6/–6 –6/–6 –16/–11 0/+5 –6/–6 +3/+3 Not Used...
Page 141: Cch Assignment
CHAPTER 3 SYSTEM DATA PROGRAMMING ANALOG CCIS PROGRAMMING CCH Assignment Follow the same programming procedure as shown in “CCH Assignment” in DIGITAL CCIS PROGRAMMING. page 89 Note that the assignment of trunk number by CMA7 Y=00 is not required when the CCH is con- nected with a dedicated line.
Page 142: Ccis Feature Programming
CHAPTER 3 SYSTEM DATA PROGRAMMING CCIS FEATURE PROGRAMMING CCIS FEATURE PROGRAMMING This section explains the feature programming of each CCIS service feature. The following features require no programming. • Elapsed Time Display-CCIS • Hands-Free Answer Back-CCIS • Individual Attendant Access-CCIS •...
Page 143: Attendant Camp-On With Tone Indication-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING ATTENDANT CAMP-ON WITH TONE INDICATION-CCIS ATTENDANT CAMP-ON WITH TONE INDICATION-CCIS General Description This feature permits the Attendant, when the desired station at another switching ofﬁce is busy, to hold an incoming call in a special waiting mode. A distinctive Camp-On tone is sent to the busy station when the Attendant sets Camp-On.
Page 144: Operating Procedure
CHAPTER 3 SYSTEM DATA PROGRAMMING ATTENDANT CAMP-ON WITH TONE INDICATION-CCIS To reenter a Camped-On trunk from an Attendant before Automatic Recall: DESCRIPTION DATA START CM20 Assign the access code for Call Pickup- Y=0-3 Numbering Plan Group 0-3 • Direct. X-XXXX: Access Code A021: Call Pickup-Direct To display the busy station number and name on an Attendant Console when reentering a Camped-On trunk by pressing the loop key:...
Page 145: Brokerage-Hot Line-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING BROKERAGE-HOT LINE-CCIS BROKERAGE-HOT LINE-CCIS General Description term This feature provides a ringdown connection between two stations, each using a D , in differ- ent ofﬁces in the CCIS network. Programming DESCRIPTION DATA START Assign the Virtual Line station number to 000-255: Virtual LEN CM11 the required Virtual LEN.
Page 146 CHAPTER 3 SYSTEM DATA PROGRAMMING BROKERAGE-HOT LINE-CCIS DESCRIPTION DATA CM72 • 000-299: Memory Slot No. XXX...X: Station Name Character by MAT/CAT (Max. 16 charac- ters) CM52 Assign the Hot Line pairs. • Y=00-99 Hot Line pair No. Bidirectional Hot Line should be assigned 0: Calling Station as follows: 1: Called Station...
Page 147: Busy Verification-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING BUSY VERIFICATION-CCIS BUSY VERIFICATION-CCIS General Description This service feature permits the operator, via the Attendant Console on the IMX or the 2000 IVS to interrupt a busy station’s call at another switching ofﬁce connected through CCIS. Programming DESCRIPTION DATA...
Page 148 CHAPTER 3 SYSTEM DATA PROGRAMMING BUSY VERIFICATION-CCIS Operating Procedure To activate Busy Veriﬁcation-CCIS: 1. Press an idle LOOP key. 2. Dial the desired station number; receive busy tone. 3. Press the BV key. 4. Two-burst tones are sent to connected parties. 5.
Page 149: Call Back-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL BACK-CCIS CALL BACK-CCIS General Description This feature provides inter-ofﬁce Call Back-CCIS service. A station user who has dialed a busy station at another ofﬁce can set Call Back-CCIS by dialing a feature access code. When this ser- vice has been set, the calling station will be rung as soon as the busy station becomes available.
Page 150 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL BACK-CCIS Operating Procedure Single-Line Telephone: To set Call Back-CCIS from a Single-Line Telephone: 1. Dial desired station number; receive busy tone. 2. Press hookswitch for feature dial tone. 3. Dial Call Back-CCIS feature access code; receive service set tone. 4.
Page 151 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL BACK-CCIS 5. When calling station answers, the called station will ring. 6. The originaly called Station’s LCD displays: term term 65 Series 75 Series XXXX XXXX (TIME DISPLAY) (TIME DISPLAY) Called station number term To cancel Call Back-CCIS from a D 1.
Page 152: Call Forwarding-All Calls-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS General Description This service feature permits all calls destined for a particular station to be routed to another sta- tion, or to an Attendant Console, in another ofﬁce in the CCIS network regardless of the status (busy or idle) of the called station.
Page 153 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS DESCRIPTION DATA CM35 To apply this feature to incoming calls, as- Y=05 sign trunk route combinations for Tandem 00-63: Trunk Route No. connection. 1 : Release Signal arrives CM36 •...
Page 154 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS DESCRIPTION DATA Allow or restrict Multiple Call Forwarding- Y=29 CMA7 • All Calls/Busy Line/Don’t Answer-CCIS for 0-7: CCH No. each CCH number. 0 : Allowed [Series 2100 software (R2.2 software) 1 : Restricted (Only once) required] Specify the number of times of Multiple...
Page 155 THIS PAGE LEFT BLANK INTENTIONALLY. – 125-2– Rev.1.1 97124-11...
Page 156 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS When a call is forwarded through CCIS by Call Forwarding-All Calls/-Busy Line/-Don’t Answer, the kind of Call Forwarding and the station number which is setting the service can be indicated term on the LCD of the forwarding destination D PBX-B...
Page 157 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS Operating Procedure Single Line Telephone To set Call Forwarding-All Calls-CCIS from a Single Line Telephone: 1. Lift the handset; receive dial tone. 2. Dial the Call Forwarding-All Calls-CCIS access code; receive feature dial tone. 3.
Page 158 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-ALL CALLS-CCIS MULTIPLE CALL FORWARDING-ALL CALLS-CCIS term To set Call Forwarding-All Calls-CCIS from a My Line: 1. Lift handset or press SPEAKER key; receive dial tone. 2. Press the Call Forwarding-All Calls-CCIS feature access key; receive feature dial tone. 3.
Page 159: Call Forwarding-Busy Line-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS General Description This service feature provides inter-ofﬁce Call Forwarding-Busy Line-CCIS, which permits a call to a busy station to be immediately forwarded to a pre-designated station or to an Attendant Con- sole in another ofﬁce in the CCIS network.
Page 160 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS DESCRIPTION DATA CM35 To apply this feature to incoming calls, as- • Y=05 sign trunk route combinations for Tandem 00-63: Trunk Route No. connection. 1 : Release Signal arrives CM36 •...
Page 161 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS DESCRIPTION DATA Allow or restrict Multiple Call Forwarding- Y=29 • CMA7 All Calls/Busy Line/Don’t Answer-CCIS for 0-7: CCH No. each CCH number. 0 : Allowed [Series 2100 software (R2.2 software) 1 : Restricted (Only once) required] Specify the number of times of Multiple...
Page 162 THIS PAGE LEFT BLANK INTENTIONALLY. – 130-2 – Rev.1.1 97129-11...
Page 163 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS When a call is forwarded through CCIS by Call Forwarding-All Calls/-Busy Line/-Don’t Answer, the kind of Call Forwarding and the station number which is setting the service can be indicated term on the LCD of the forwarding destination D PBX-B...
Page 164 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS Operating Procedure Single Line Telephone To set Call Forwarding-Busy Line-CCIS from a Single Line Telephone: 1. Lift the handset; receive dial tone. 2. Dial the speciﬁc Call Forwarding-Busy Line-CCIS access code; receive feature dial tone. 3.
Page 165 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-BUSY LINE-CCIS MULTIPLE CALL FORWARDING-BUSY LINE-CCIS term term To set Call Forwarding-Busy Line-CCIS from a D 1. Lift handset or press SPEAKER key; receive dial tone. 2. Press the Call Forwarding-Busy Line-CCIS feature access key; receive feature dial tone. 3.
Page 166: Call Forwarding-Don't Answer-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS General Description This service feature provides interofﬁce Call Forwarding-Don’t Answer-CCIS, which permits a call to an unanswered station to be forwarded to a pre-designated station or to an Attendant Con- sole in another ofﬁce, when the called station does not answer after a predetermined time inter- val.
Page 167 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS DESCRIPTION DATA CM35 To apply this feature to incoming calls, set • Y=05 the trunk route combinations for Tandem 00-63: Trunk Route No. connection. 1 : Release Signal arrives CM36 •...
Page 168 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS DESCRIPTION DATA Allow or restrict Multiple Call Forwarding- Y=29 CMA7 • All Calls/Busy Line/Don’t Answer-CCIS for 0-7: CCH No. each CCH number. 0 : Allowed [Series 2100 software (R2.2 software) 1 : Restricted (Only once) required] Specify the number of times of Multiple...
Page 169 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS When a call is forwarded through CCIS by Call Forwarding-All Calls/-Busy Line/-Don’t Answer, the kind of Call Forwarding and the station number which is setting the service can be indicated term on the LCD of the forwarding destination D PBX-B...
Page 170 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS Operating Procedure Single-Line Telephone To set Call Forwarding-Don’t Answer-CCIS from a Single-Line Telephone: 1. Lift the handset; receive dial tone. 2. Dial the Call Forwarding-Don’t Answer-CCIS access code; receive feature dial tone. 3.
Page 171 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-DON’T ANSWER-CCIS MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS term term To set Call Forwarding-Don’t Answer-CCIS from a D 1. Lift the handset or press the SPEAKER Key; receive dial tone. 2. Press the Call Forwarding-Don’t Answer-CCIS feature access key; receive feature dial tone.
Page 172: Call Forwarding-Intercept-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-INTERCEPT-CCIS CALL FORWARDING-INTERCEPT-CCIS General Description This feature allows calls to an inoperative number, through a CCIS trunk, to be intercepted and automatically routed to a recorded announcement informing the caller that an inoperative num- ber was dialed, and giving the Listed Directory Number for information.
Page 173 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-INTERCEPT-CCIS Programming DESCRIPTION DATA START CM10 Assign the Digital Announcement Trunk 000-763: LEN card number to the required LEN. EB002-EB127: Digital Announcement (For Intercept Announcement only.) Trunk Card No. For PIM0/PIM1: EB002-EB031 NOTE: The Digital Announcement Trunk For PIM2/PIM3: EB032-EB063 card number must be assigned For PIM4/PIM5: EB064-EB095...
Page 174 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-INTERCEPT-CCIS DESCRIPTION DATA CM20 To record, replay, or delete a massage, as- Y=0-3 Numbering Plan Group 0-3 • sign the appropriate Digital Announce- X-XXXX: Access Code ment Trunk Card access codes. A100: Digital Announcement Trunk ac- (For Intercept Announcement only.) cess (Record) A101: Digital Announcement Trunk ac-...
Page 175: Call Forwarding-Override-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL FORWARDING-OVERRIDE-CCIS CALL FORWARDING-OVERRIDE-CCIS General Description This feature allows a target station user (Station A) to call the station (Station B) which set Call Forwarding-All Calls-CCIS to it through CCIS. Programming DESCRIPTION DATA START Assign Call Forwarding-Override-CCIS. CM08 0 : Not available (BT connection) 1 : Available...
Page 176: Call Transfer-All Calls-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL TRANSFER-ALL CALLS-CCIS CALL TRANSFER-ALL CALLS-CCIS General Description This feature allows a station user to transfer incoming or outgoing Central Ofﬁce calls, intra-ofﬁce and inter-ofﬁce calls to another station in the CCIS network, without Attendant assistance. Programming DESCRIPTION DATA...
Page 177 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL TRANSFER-ALL CALLS-CCIS NOTE: See also the programming for “Trunk to Trunk Connection” in the “Feature Program- ming Manual”, when no release signal arrives from the incoming trunk route. Operating Procedure To transfer a call in progress from a Single-Line Telephone: 1.
Page 178: Call Transfer-Attendant-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALL TRANSFER-ATTENDANT-CCIS CALL TRANSFER-ATTENDANT-CCIS General Description This service feature permits a station user, while connected to a CCIS network call, to transfer a call to an Attendant Console located in the main ofﬁce via the CCIS network. Programming DESCRIPTION DATA...
Page 179 CHAPTER 3 SYSTEM DATA PROGRAMMING CALL TRANSFER-ATTENDANT-CCIS NOTE 1: In the Inter-Tenant Connection Assignment, the Tenant number should be assigned as 01-63. 00 should not be used if connecting to a PBX. NOTE 2: Refer to Numbering Plan Assignment and assign a dial code to call the attendant by the LCR feature.
Page 180: Calling Name Display-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NAME DISPLAY-CCIS CALLING NAME DISPLAY-CCIS General Description This feature provides a display indicating the calling/called party’s name, at another switching of- term ﬁce, on the LCD of a D or an Attendant Console. Programming DESCRIPTION DATA START...
Page 181 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NAME DISPLAY-CCIS DESCRIPTION DATA CM77 Enter the desired user’s name to each sta- • Y=0 By Character Code tion number with Character Codes or char- X-XXXXXXXX: Station No. acters. 20-7F: Character Code Max. 32 digits (See CM77 in the Command Manual) Y=1 By character •...
Page 182: Calling Number Display-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS CALLING NUMBER DISPLAY-CCIS General Description This feature permits the number of a calling or called party at another switching ofﬁce to be dis- term played either on a D or an Attedant Console/Smart Console. To transfer the calling party number received from the network (ISDN CPN/Caller-ID/MFC or T1- ANI) transparently between the ofﬁces on the CCIS network, assign the following data.
Page 183 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS DESCRIPTION DATA CM15 Specify the number of digits on the LCD of Y=95 • term the D for Ofﬁce B. 00-15: Service Restriction Class C 0 : 24 digits term NOTE: For the D 70/75 (Elite Termi- 1 : 16 digits term...
Page 184 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS When the Station 200 on the Ofﬁce A answers the call from the network, and transfers the call to the Station 300 on the Ofﬁce B, the calling party number will be displayed on the Station 300. [Series 2100 software (R2.2 software) required ] Office A Office B...
Page 185 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS To transmit a calling party number to the ISDN route over CCIS tandem connection: [Series 2100 software (R2.2 software) required] Office B Office A Calling Party Number CCIS Network Transparent ISDN Route (Tandem) •...
Page 186 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS DESCRIPTION DATA CM20 Assign the LCR data for CCIS calls. See “Least Cost Routing-3/6 digit” in the Feature Programming Manual. CM81 This feature is available only when the call- ing party calls to CCIS route by the LCR. CM8A CM85 CM35...
Page 187 CHAPTER 3 SYSTEM DATA PROGRAMMING CALLING NUMBER DISPLAY-CCIS • For Tandem Ofﬁce (Ofﬁce B) DESCRIPTION DATA START CM08 Provide the system with Caller ID Display feature for CCIS calls. 0: To provide Provide each CCH number with Name Y=26 • CMA7 Display-CCIS feature.
Page 188 THIS PAGE LEFT BLANK INTENTIONALLY. – 152-4 – Rev.1.1 97140-11...
Page 189: Centralized Billing-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS CENTRALIZED BILLING-CCIS General Description This feature is used to collect billing information from each ofﬁce within the network and to direct it to the associated center ofﬁce. Billing information is then forwarded to the SMDR of center of- ﬁce.
Page 190 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS AP Initialization This section explains the data assignment to make the AP active. If the system already applied the AP related feature, you can skip the data assignment explained on this section. The AP should have already activated if one of the following feature applied;...
Page 191 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMD003 Allow the maximum number of Call Record for SMDR which is set to “5” by 0 : No limitation CMD001>80/100/120/140. 1-27000: 1-27000 calls NOTE: When the data is set to 1-27000, external alarm of memory over- ﬂow is available, if CM44, 2nd data=3002 is assigned.
Page 192 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMD102 Initialize the billing memory. 0000 AP OFFLINE On the AP00 card, set the SW1 switch as shown below: SW1-4 should be set as follows; ON : The AP No. is 04-15 OFF: The AP No.
Page 193 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS SMDR with AP00 Programming (1) When sending a billing information from local ofﬁces to SMDR of Center Ofﬁce, do the following programming. When sending a billing information from both Center Ofﬁce and Local Ofﬁce to SMDR of Center Ofﬁce, do the following programming in addition to the basic programming of SMDR with AP00.
Page 194 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CM08 Not provide the system with Built-in SMDR of MP card. 1 : Not provided (AP00 is effective) Provide the system with Centralized Bill- ing-CCIS for Center Ofﬁce. 0: To provide INITIAL Not provide the system with Centralized Billing-CCIS for Local Ofﬁce.
Page 195 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMD001 Assign the attribute data, depending on See the following table. the port (Port 0-3) connected to the SMDR See the following table. terminal. (For the details of commands, re- fer to the Command Manual.) AP00 INITIAL FIRST DATA (1) SECOND...
Page 196 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMD016 Invalidate the data setting of Centralized XX31: Sending of billing information of Billing used for Local Ofﬁce. C.O. outgoing calls through CCIS : 00-15 (Station Class No. as- signed by CMD015) 0 : Not sent XX32: Sending of billing information of Tie Line outgoing calls through...
Page 197 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Built-in SMDR Programming For Local Ofﬁce or Tandem Ofﬁce, in addition to the basic programming of Built-in SMDR, do the following programming. For details of the Built-in SMDR, refer to Feature Programming Manual. NOTE 1: When the system provides an AP00 card (CM05 Y=0 second data=04 is assigned), the Built-in SMDR cannot be provided.
Page 198 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMA7 Assign the data as follows. Y=03 • 1st Data 2nd Data 0-7: CCIS channel No. CCIS channel No. 0 : Distant end is Center Ofﬁce (0-7) for 1 : Distant end is Local Ofﬁce Center Ofﬁce See Example 3: Data Assignment of page 175...
Page 199 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS SMDR with AP00 Programming (2) For Local Ofﬁce or Tandem Ofﬁce, in addition to the basic programming of SMDR with AP00, do the following programming. For details of the SMDR with AP00, refer to Feature Programming Manual.
Page 200 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA Assign the data as follows. Y=03 CMA7 • • For Local Ofﬁce: 0-7: CCIS channel No. 0 : Distant end is Center Ofﬁce 1st Data 2nd Data 1 : Distant end is Local Ofﬁce CCIS channel No.
Page 201 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS DESCRIPTION DATA CMD015 Assign a Station Class number to the re- X-XXXX: Station No. quired station number. 00 -15: Station Class No. CMD016 Assign the data for sending the detail call XX31 information for C.O. outgoing calls through XX: 00-15 (Station Class No.
Page 202 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Example 1: Data Assignment of SMDR output for Center Ofﬁce In a Centralized Billing Ofﬁce, the following four patterns of SMDR output can be selected. (1) To SMDR 0: Sending of billing information from both a Center Ofﬁce and Local Ofﬁces. (2) To SMDR 1: Sending of billing information from both a Center Ofﬁce and Local Ofﬁces.
Page 203 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Centralized Billing Programming Steps for Pattern 1 Local Ofﬁce A, B uses AP00. CENTER OFFICE LOCAL OFFICE A/B CM05 Y=0>XX : 04 (AP00) 04 (AP00) CMD101>0000 : CCC (Data All Clear) CMD001>179 : 1 (Center Ofﬁce) 0 (Local Ofﬁce) CMD003>24 : 0 (Not record)
Page 204 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Centralized Billing Programming Steps for Pattern 2 SMDR 1 Using Port 0 Local Ofﬁce A, B uses AP00. CENTER OFFICE LOCAL OFFICE A/B CM05 Y=0>XX : 04 (AP00) 04 (AP00) CMD101>0000 : CCC (Data All Clear) CMD001>179 : 1 (Center Ofﬁce) 0 (Local Ofﬁce)
Page 205 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Centralized Billing Programming Steps for Pattern 3 To SMDR 0: Setting of billing information from Local Ofﬁces. To SMDR 1: Setting of billing information from Center Ofﬁce. Use two SMDR terminals, one for Port 0 and one for Port 1. LOCAL OFFICE A/B CENTER OFFICE CM05 Y=0>XX...
Page 206 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS LOCAL OFFICE A/B CENTER OFFICE CMD001>104 : 1 (Free Wheel) (Port 1) Default >105 : 48 (SA) (Port 1) Default >106 : 33 (UA) (Port 1) Default CMD015>XXXX : XX (Station Class No.) XX (Station Class No.) CMD016>XX31 : 0 (C.O.
Page 207 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Centralized Billing Programming Steps for Pattern 4 To SMDR 0: Setting of billing information from Local Ofﬁces. To SMDR 1: Setting of billing information from Center Ofﬁce. Use two SMDR terminals, one for Port 0 and one for Port 1. CENTER OFFICE LOCAL OFFICE A/B CM05 Y=0>XX...
Page 208 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS LOCAL OFFICE A/B CENTER OFFICE CMD001>104 : 1 (Free Wheel) (Port 1) Default >105 : 48 (SA) (Port 1) Default >106 : 33 (UA) (Port 1) Default CMD015>XXXX : XX (Station Class No.) XX (Station Class No.) CMD016>XX31 : 0 (C.O.
Page 209 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Example 2: Data Assignment of SMDR Call Record on a Tandem Call through CCIS To provide one SMDR call record showing the ofﬁce number and the station that made the call in Ofﬁce A. Office B Office A 2000IVS...
Page 210 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS To provide Tandem Centralized Billing without AP00 in the Local Ofﬁce Office B Office A 2000IVS 2000IVS /IMX C.O. SMDR Terminal Data Assignment of Ofﬁce A CM08>040: 0 (Provides SMDR service for tandem calls) CM08>377: 0 (Provides ofﬁce number and station number from the tandem ofﬁce) CM35 Y=14>C.O.
Page 211 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Example 3: Data Assignment of CMA7 Y=03, 04 CCH0 CCH0 CCH1 SMDR OFFICE OFFICE OFFICE PC: 00001 PC: 00002 PC: 00003 OFFICE NO.: 821 OFFICE NO.: 822 OFFICE NO.: 823 PC : Point Code CCH: Common Channel Handler •...
Page 212 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Example 4: Data Assignment of CMA7 Y=06 and CMD004>55 CCH0 CCH0 CCH1 SMDR OFFICE OFFICE OFFICE PC: 00001 PC: 00002 PC: 00003 OFFICE NO.: 821 OFFICE NO.: 822 OFFICE NO.: 823 PC : Point Code CCH: Common Channel Handler •...
Page 213 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED BILLING-CCIS Example 5: Data Assignment of CMD004>56 Sta. Billing Information CCH0 SMDR OFFICE of Office B OFFICE PC: 00003 CCH1 CCH0 PC: 00001 OFFICE NO.: 823 OFFICE NO.: 821 OFFICE PSTN PC: 00002 OFFICE NO.: 822 PC : Point Code CCH: Common Channel Handler To specify the billing ofﬁce (Ofﬁce B) in center ofﬁce (Ofﬁce C) when a station of Ofﬁce A make...
Page 214: Centralized Day/Night Mode Change-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED DAY/NIGHT MODE CHANGE-CCIS CENTRALIZED DAY/NIGHT MODE CHANGE-CCIS General Description This service feature switches the Day/Night Mode of a remote ofﬁce, linked to the main ofﬁce IMX via CCIS, in accordance with the Day/Night Mode switching on the Attendant Console at the main ofﬁce.
Page 215: Hardware Required
CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED DAY/NIGHT MODE CHANGE-CCIS To provide an indication on external equipment when Day/Night Mode status is changed by the Attendant Console at the Main Ofﬁce, do the following programming. DESCRIPTION DATA START CM10 Assign the DK card to the required LEN. 000-763: LEN E800-E831: DK Card No.
Page 216: Centralized E911-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED E911-CCIS CENTRALIZED E911-CCIS [Series 2100 software (R2.2 software) required] [North America Only] General Description This feature allows the system to transmit a calling party number to the 911 Emergency system over CCIS tandem connection. Office B Office A Calling Party Number...
Page 217 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED E911-CCIS DESCRIPTION DATA CM20 Assign the LCR data for CCIS calls. See “Least Cost Routing-3/6 digit” in the Feature Programming Manual. CM81 This feature is available only when the call- ing party calls to CCIS route by the LCR. CM8A CM85 CM35...
Page 218 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED E911-CCIS • For Tandem Ofﬁce (Ofﬁce B) DESCRIPTION DATA START CM08 Provide the system with Caller ID Display feature for CCIS calls. 0: To provide Send ANI signal to the network on 474: Enhanced 911 Enhanced 911 calls.
Page 219 THIS PAGE LEFT BLANK INTENTIONALLY. – 179-4 – Rev.1.1 97178-11...
Page 220: Centralized Mat-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED MAT-CCIS CENTRALIZED MAT-CCIS General Description All ofﬁces in the plural IMX and 2000 IVS to be connected through CCIS link can be maintained from the Centralized MAT installed in IMX. When the fault occurs at the 2000 IVS , the alarm information (ofﬁce name, alarm kind) is dis- played on the Centralized MAT.
Page 221 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED MAT-CCIS Programming DESCRIPTION DATA START CMEA Assign fault kind information and its exter- • nal alarm kind. Fault Kind No.: See left column External Alarm Kind Fault Kind number: 0: Fault Memory/No out put of External 01 : System Initialization Alarm 04 : MP-FP/AP communication failure...
Page 222 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED MAT-CCIS DESCRIPTION DATA Specify the external alarm kind which is CMEA • automatically sent. 00-02: External Alarm Kind set by CMEA Y=2 0 : Send 1 : Not sent Specify the contents which is sent to the •...
Page 223 CHAPTER 3 SYSTEM DATA PROGRAMMING CENTRALIZED MAT-CCIS NOTE: When a fault occurs, the external alarm kind registered in the 2000 IVS in the CCIS network is displayed on Centralized MAT on the IMX office as follows: DFTD 99/08/30 14:57 xxxxxxxxxxxxxxx SYSTEM MESSAGE 15-0 IVS MESSAGE...
Page 224: Consultation Hold-All Calls-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING CONSULTATION HOLD-ALL CALL-CCIS CONSULTATION HOLD-ALL CALLS-CCIS General Description This feature permits a station user within the CCIS network to hold any incoming/outgoing public network or Tie Line call while originating a call to another station within the CCIS network. Programming DESCRIPTION DATA...
Page 225 CHAPTER 3 SYSTEM DATA PROGRAMMING CONSULTATION HOLD-ALL CALL-CCIS To return to the original call from a Single-Line Telephone: 1. Under any of the following conditions, the calling station can return to the original call by pressing the switch hook: a. The second station called is busy. b.
Page 226: Data Line Security-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DATA LINE SECURITY-CCIS DATA LINE SECURITY-CCIS General Description This feature allows line circuits which are used for data transmission to be protected from follow- ing interruptions: • Attendant Camp-On with Tone Indication (Attendant Camp-On) • Attendant Camp-On with Tone Indication-CCIS •...
Page 227: Deluxe Traveling Class Mark-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DELUXE TRAVELING CLASS MARK-CCIS DELUXE TRAVELING CLASS MARK-CCIS General Description This feature provides outgoing call restrictions within the CCIS network. The following three types of restrictions are allowed: • Deluxe Traveling Class Mark Restriction • Route Restriction •...
Page 228 CHAPTER 3 SYSTEM DATA PROGRAMMING DELUXE TRAVELING CLASS MARK-CCIS DESCRIPTION DATA CM35 Specify to outgoing/incoming call capabili- Y=51 (RCA) • ty on each Route Restriction Class (RCA- Y=52 (RCB) • RCH) assigned by CM12 Y=01 to each Y=53 (RCC) • route.
Page 229 CHAPTER 3 SYSTEM DATA PROGRAMMING DELUXE TRAVELING CLASS MARK-CCIS When changing the initial setting (see NOTE ), or when receiving the IMX Trunk Restriction Class (9-15) as a Deluxe Traveling Class Mark, execute the following programming. DESCRIPTION DATA START Assign the IMX Trunk Restriction Class to 20: TRK Restriction Class 1 (RCA) CM42 each PBX Trunk Restriction Class for the...
Page 230 CHAPTER 3 SYSTEM DATA PROGRAMMING DELUXE TRAVELING CLASS MARK-CCIS NOTE: If no data is set, the default setting is shown below. (1) PBX to IMX: 1ST DATA 2ND DATA 20: TRK Restriction Class 1 (RCA) 01: TRK Restriction Class 1 21: TRK Restriction Class 2 (RCB) 02: TRK Restriction Class 2 22: TRK Restriction Class 3 (RCC)
Page 231: Dial Access To Attendant-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DIAL ACCESS TO ATTENDANT-CCIS DIAL ACCESS TO ATTENDANT-CCIS General Description This feature allows a station user to call an Attendant Console by dialing an operator call code through the CCIS network. Programming DESCRIPTION DATA START CM62 Specify the tenants to be handled by each •...
Page 232 CHAPTER 3 SYSTEM DATA PROGRAMMING DIAL ACCESS TO ATTENDANT-CCIS Operating Procedure To call an Attendant Console: 1. The station user dials the operator call code, then receives ringback tone. 2. The ATND lamp for Incoming Call Identiﬁcation ﬂashes on the Attendant Console. The At- tendant answers the call.
Page 233: Direct-In Termination-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DIRECT-IN TERMINATION-CCIS DIRECT-IN TERMINATION-CCIS General Description This feature automatically routes incoming exchange calls through CCIS to a predesignated sta- tion in the network without Attendant assistance. Programming • When a release signal arrives on the incoming (IC) trunk DESCRIPTION DATA START...
Page 234 CHAPTER 3 SYSTEM DATA PROGRAMMING DIRECT-IN TERMINATION-CCIS DESCRIPTION DATA Specify the combination of trunk routes al- CM36 • lowing the Tandem connection. XX ZZ XX: 00-63 (Incoming Trunk Route) ZZ: 00-63 (Outgoing Trunk Route for CCIS) 0: Allow CM71 Assign the System Speed Dialing memory 66: Exclusively for DIT-Outside area used exclusively for DIT-Outside.
Page 235 CHAPTER 3 SYSTEM DATA PROGRAMMING DIRECT-IN TERMINATION-CCIS • When no release signal arrives on the IC trunk. DESCRIPTION DATA START CM08 Provide the DIT-Outside feature. (In case 324: DIT-Outside of no release signal on IC trunk.) 0: Allow (When both answer and release signal appear on the OG trunk) Assign the data for terminating system in Y=02 Day Mode...
Page 236 CHAPTER 3 SYSTEM DATA PROGRAMMING DIRECT-IN TERMINATION-CCIS DESCRIPTION DATA Assign Trunk Route data to the trunk route Y=04 CM35 • number (for OG route). Answer Signal from Distant Ofﬁce 00-63: Trunk Route No. 2: Arrive • Y=05 Release Signal from Distant Ofﬁce 00-63: Trunk Route No.
Page 237: Distinctive Ringing-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DISTINCTIVE RINGING-CCIS DISTINCTIVE RINGING-CCIS General Description This feature provides distinctive station ringing patterns for terminated calls through the CCIS network so that a station user can distinguish between incoming internal and external calls. Programming RINGING The ringing pattern should be selected in PBX A (equipped with incoming COT).
Page 238: Do Not Disturb-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DO NOT DISTURB-CCIS DO NOT DISTURB-CCIS General Description This feature allows a station user to establish the Do Not Disturb (DND) status on a temporary basis, during which time access to the station from incoming CCIS calls will be denied. Programming DESCRIPTION DATA...
Page 239 CHAPTER 3 SYSTEM DATA PROGRAMMING DO NOT DISTURB-CCIS DESCRIPTION DATA CM90 If the Attendant Console is assigned as Y=00 • the destination by CM51, assign a Call My Line No. + + Key No. Forwarding-Intercept (ICPT) key to the F6065: Call Forwarding-Intercept Key console.
Page 240 CHAPTER 3 SYSTEM DATA PROGRAMMING DO NOT DISTURB-CCIS Operating Procedure term Single-Line Telephone/D term To set Do Not Disturb from a Single-Line Telephone or D 1. Lift the handset; receive dial tone. 2. Dial Do Not Disturb-CCIS feature access code; receive service set tone. 3.
Page 241: Dual Hold-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING DUAL HOLD-CCIS DUAL HOLD-CCIS General Description term This feature allows two connected D s to simultaneously be placed on hold over the CCIS link. This enables the held parties to answer or originate a call from a secondary-line appearance or the idle prime extension.
Page 242: Flexible Numbering Of Stations-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING FLEXIBLE NUMBERING OF STATIONS-CCIS FLEXIBLE NUMBERING OF STATIONS-CCIS General Description This feature allows voice and data station numbers to be assigned to any instrument in the CCIS network, based solely upon numbering plan limitations. PUBLIC SATELLITE OFFICE NETWORK MAIN OFFICE...
Page 243 CHAPTER 3 SYSTEM DATA PROGRAMMING FLEXIBLE NUMBERING OF STATIONS-CCIS Programming DESCRIPTION DATA START CM29 Assign a Numbering Plan Group to each 00-63: Tenant No. Tenant. 710-713: Numbering Plan Group 0-3 Specify the number of digits for station Y=0-3 Numbering Plan Group 0-3 •...
Page 244: Hot Line-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING HOT LINE-CCIS HOT LINE-CCIS General Description This feature allows two stations at different nodes in the CCIS network to be mutually associated on an automatic ring down basis through the CCIS network. Programming Use the Hot Line-Outside feature. DESCRIPTION DATA START...
Page 245 CHAPTER 3 SYSTEM DATA PROGRAMMING HOT LINE-CCIS DESCRIPTION DATA Specify the result of Switch Hook Flash on CM08 Hot Line station. 0 : Special Dial Tone To allow Hot Line stations to transfer a call 1 : Attendant Recall or access a feature, set the data to”0”. Operating Procedure To place a Hot Line-CCIS call: 1.
Page 246: House Phone-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING HOUSE-PHONE-CCIS HOUSE PHONE-CCIS General Description This feature allows selected stations to call an Attendant Console through the CCIS network, simply by going off hook. Programming Use the Hot Line-Outside feature. DESCRIPTION DATA START Assign a Hot Line (House-phone) to the Y=03 CM12 •...
Page 247 CHAPTER 3 SYSTEM DATA PROGRAMMING HOUSE-PHONE-CCIS Operating Procedure To call an Attendant in another ofﬁce: 1. House Phone-CCIS user lifts the handset. 2. The Attendant in another ofﬁce is automatically called. ATND lamps on Attendant Console ﬂash and console buzzer sounds. –...
Page 248: Incoming Call Identification-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING INCOMING CALL IDENTIFICATION-CCIS INCOMING CALL IDENTIFICATION-CCIS General Description This feature allows an attendant to visually identify the type of service and/or trunk group which is arriving or waiting to be answered at the Attendant Console through the CCIS network. Programming DESCRIPTION DATA...
Page 249 CHAPTER 3 SYSTEM DATA PROGRAMMING INCOMING CALL IDENTIFICATION-CCIS DESCRIPTION DATA (01) (02) (03) (04) Night Busy ATND NANS Recall PAGE (13) (14) (15) (16) (17) (18) (92) (19) (20) (21) TRKSL Call Park Start Mute Position Busy (22) (23) (24) Cancel L6 (12) Volume...
Page 250: Ldn Night Connection-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING LDN NIGHT CONNECTION-CCIS LDN NIGHT CONNECTION-CCIS General Description This feature routes Listed Directory Number (LDN) calls to a predesignated station in the CCIS network when the Night Mode has been entered. Programming DESCRIPTION DATA START CM08 Provide the system with Diversion Display.
Page 251 CHAPTER 3 SYSTEM DATA PROGRAMMING LDN NIGHT CONNECTION-CCIS To provide the LDN Diversion feature, the following programming is also required. DESCRIPTION DATA START CM08 Provide the system with the LDN Diversion feature. 0: To provide Assign the data for LDN Diversion to each Y=00 Tenant No.
Page 252 CHAPTER 3 SYSTEM DATA PROGRAMMING LDN NIGHT CONNECTION-CCIS DESCRIPTION DATA Y=05 Night Mode Diversion for busy CM58 • destination station Same as CM58 Y=00 Same as CM58 Y=04 • Y=06 Day Mode Diversion for non-an- swering destination station Same as CM58 Y=00 00: To ATTCON (NANS key) 08: To TAS Y=07 Night Mode Diversion for non-an-...
Page 253 CHAPTER 3 SYSTEM DATA PROGRAMMING LDN NIGHT CONNECTION-CCIS DESCRIPTION DATA If the 2nd data (CXX) is designated by CM36 • CM58 Y=08, 09, specify the combination XX ZZ of trunk routes allowing the Tandem con- XX: 00-63 (Incoming Trunk Route) nection.
Page 254: Link Alarm Display-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING LINK ALARM DISPLAY-CCIS LINK ALARM DISPLAY-CCIS General Description This feature provides an indication on external equipment when the CCIS link is connected/dis- connected, when the system is initialized or when the CCH is in make busy. Programming DESCRIPTION DATA...
Page 255: Message Waiting Lamp Setting-Attendant-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING MESSAGE WAITING LAMP SETTING-ATTENDANT-CCIS MESSAGE WAITING LAMP SETTING-ATTENDANT-CCIS General Description This feature allows an attendant, in the IMX system, to set or cancel a Message Waiting lamp indication, through the CCIS network on a station in a PBX system. Programming DESCRIPTION DATA...
Page 256: Message Waiting Lamp Setting-Station-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING MESSAGE WAITING LAMP SETTING-STATION-CCIS MESSAGE WAITING LAMP SETTING-STATION-CCIS General Description This feature allows a station user in the IMX system to set or cancel a Message Waiting lamp indication, through the CCIS network, to a station in the PBX system with this feature. Programming DESCRIPTION DATA...
Page 257: Miscellaneous Trunk Access-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING MISCELLANEOUS TRUNK ACCESS-CCIS MISCELLANEOUS TRUNK ACCESS-CCIS General Description This feature provides access to all types of external and customer-provided equipment/facilities, such as tie lines and exchange networks, along with Dictation, Paging Access-CCIS and Code Calling through the CCIS network. Programming Refer to Numbering Plan Assignment and assign the trunk access code using the LCR feature.
Page 258: Miscellaneous Trunk Restriction-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING MISCELLANEOUS TRUNK RESTRICTION-CCIS MISCELLANEOUS TRUNK RESTRICTION-CCIS General Description This feature denies certain stations and dial-repeating tie trunks access to particular trunk groups, such as tie lines, exchange networks, Dictation or Paging Access-CCIS through the CCIS network. Programming Assign “1”...
Page 259: Night Connection-Fixed-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING NIGHT CONNECTION-FIXED-CCIS NIGHT CONNECTION-FIXED-CCIS General Description When the Night Mode has been entered, this service feature routes calls normally directed to the Attendant Console to a preselected station in another ofﬁce, through the CCIS network. Programming page 193 Refer to Direct-In Termination-CCIS...
Page 260: Night Connection-Flexible-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING NIGHT CONNECTION-FLEXIBLE-CCIS NIGHT CONNECTION-FLEXIBLE-CCIS General Description This feature provides an inter-ofﬁce Night Connection service, via the CCIS network, when the calling station and the Night station belong to different ofﬁces. Programming page 193 Refer to Direct-In Termination-CCIS. Operating Procedure To set the Night Connection-Flexible-CCIS: 1.
Page 261: Number Portability-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING NUMBER PORTABILITY-CCIS NUMBER PORTABILITY-CCIS General Description When the 2000 IVS is connected to an IMX via CCIS link, Network Station Number can be moved to other ofﬁce within the network by a simple command operation from the Centralized MAT in the IMX.
Page 262 CHAPTER 3 SYSTEM DATA PROGRAMMING NUMBER PORTABILITY-CCIS Programming DESCRIPTION DATA START CM10 Assign a network station number to the re- 000-763: LEN quired LEN. X-XXXXXXXX: Network station No. Assign the Access Code for the number of Y=0-3: Numbering Plan Group 0-3 CM20 •...
Page 263 CHAPTER 3 SYSTEM DATA PROGRAMMING NUMBER PORTABILITY-CCIS Example for Data Assignment: term • Network station number for a D on the 2000IVS ofﬁce: 60000 term • Network station number for a D on the IMX ofﬁce: 60001 • Area Code Development Pattern number: 0 •...
Page 264: Outgoing Trunk Queuing-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING OUTGOING TRUNK QUEUING-CCIS OUTGOING TRUNK QUEUING-CCIS General Description This feature allows a CCIS network station, upon encountering an all trunks busy signal, to dial a speciﬁed access code and enter a ﬁrst-in, ﬁrst-out queue. As soon as a CCIS trunk becomes available, stations in the queue will be called back on a ﬁrst-come, ﬁrst-served basis.
Page 265 CHAPTER 3 SYSTEM DATA PROGRAMMING OUTGOING TRUNK QUEUING-CCIS Operating Procedure To activate Outgoing Trunk Queuing-CCIS: 1. Dial the trunk access code; receive dial tone. 2. Dial the desired number; receive busy tone. 3. Press the hookswitch momentarily; receive feature dial tone. 4.
Page 266: Paging Access-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING PAGING ACCESS-CCIS PAGING ACCESS-CCIS General Description This feature provides dial access to paging equipment from an Attendant Console or station through the CCIS network. Programming DESCRIPTION DATA START CM10 Assign the Paging Trunk (COT card and 000-763: LEN DK card) to the required LEN.
Page 267: Hardware Required
CHAPTER 3 SYSTEM DATA PROGRAMMING PAGING ACCESS-CCIS DESCRIPTION DATA Assign paging trunk route to the trunk Y=00 Trunk Route Allocation CM30 • number assigned by CM10. 000-255: Trunk No. 00-63: Trunk Route No. Assign Paging Answer Zone and Kind of •...
Page 268: Restriction From Outgoing Calls-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING RESTRICTION FROM OUTGOING CALLS-CCIS RESTRICTION FROM OUTGOING CALLS-CCIS General Description This feature automatically restricts users of preselected stations from placing outgoing calls and/ or certain miscellaneous trunk calls through CCIS without Attendant assistance. Programming page 187 Refer to Deluxe Traveling Class Mark-CCIS.
Page 269: Single-Digit Station Calling-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING SINGLE-DIGIT STATION CALLING-CCIS SINGLE-DIGIT STATION CALLING-CCIS General Description This feature allows the assignment of single digit station numbers. Programming SATELLITE OFFICE MAIN OFFICE STATION NO. X DIAL.X NO. 7 CCIS IMX/PBX – 229 – 97229-10...
Page 270 CHAPTER 3 SYSTEM DATA PROGRAMMING SINGLE-DIGIT STATION CALLING-CCIS • For Satellite Ofﬁce DESCRIPTION DATA START Assign the single-digit station number to Y=0-3 Number Plan Group 0-3 CM20 • LCR Group 3 (A129). X-XXXX: Access Code A129: LCR Group 3 CM8A Assign an area code table to be used to •...
Page 271: Station-To-Station Calling-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING STATION-TO-STATION CALLING-CCIS STATION-TO-STATION CALLING-CCIS General Description This feature permits any station user to dial another station directly through CCIS without oper- ator assistance. Programming In addition to the programming of ﬂexible station numbering, perform the following programming: DESCRIPTION DATA START...
Page 272: Toll Restriction-3/6 Digits-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING TOLL RESTRICTION-3/6 DIGITS-CCIS TOLL RESTRICTION-3/6 DIGITS-CCIS General Description This feature allows the PBX to be programmed to restrict outgoing calls through CCIS according to speciﬁc areas and/or Central Ofﬁce codes. This restriction is determined on the basis of a three-digit Area Code or six-digit area and Ofﬁce Code numbering plan.
Page 273 CHAPTER 3 SYSTEM DATA PROGRAMMING TOLL RESTRICTION-3/6 DIGITS-CCIS DESCRIPTION DATA Provide the Toll Restriction feature to the Y=11 CM35 • required trunk routes. 00-63: Trunk Route No. 0: To provide Specify the route access capability for • Y=51-55 each restriction class. 00-63: Trunk Route No.
Page 274 CHAPTER 3 SYSTEM DATA PROGRAMMING TOLL RESTRICTION-3/6 DIGITS-CCIS DESCRIPTION DATA Specify the maximum number of digits di- Y=0-4 CM85 • aled by the calling party. The maximum Area Code Development Pattern No. 0- number of digits including the area codes 4 assigned by CM8A Y=A000 should be assigned to each area code.
Page 275 CHAPTER 3 SYSTEM DATA PROGRAMMING TOLL RESTRICTION-3/6 DIGITS-CCIS DESCRIPTION DATA To add the Tenant Pattern: CM8A STEP 1 Assign the area code to be re- Y=4000-4004 • stricted and a Tenant Pattern Area Code Development Pattern No. number to the Area Code De- velopment Pattern number as- X-X...X: Area Code (Max.
Page 276 CHAPTER 3 SYSTEM DATA PROGRAMMING TOLL RESTRICTION-3/6 DIGITS-CCIS DESCRIPTION DATA STEP 3 Assign the starting time for the Y=2000-2007 Time Pattern No. 0-7 CM8A • Toll Restriction and Route Pat- XX ZZ (Starting Time) tern number to the Time Pattern XX: 00-23 (Hours) number assigned by Step 2.
Page 277: Trunk Answer From Any Station-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS TRUNK ANSWER FROM ANY STATION-CCIS General Description This feature allows any station, not restricted from incoming calls, to answer incoming calls when the network is in Night Mode. When this feature is activated, incoming exchange network calls will activate a common alert Trunk Answer From Any Station (TAS) signal at the customer premises.
Page 278 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS • For the Satellite Ofﬁce Use the LDN Diversion feature. DESCRIPTION DATA START CM12 Assign a Trunk Restriction Class to each • Y=01 station. X-XXXXXXXX: Station No. Z: 1-8: Trunk Restriction Class in Night Mode 1: Unrestricted (RCA) 2: Non-Restricted 1 (RCB)
Page 279 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS DESCRIPTION DATA CM58 Assign the data for LDN Diversion to each Y=00 Tenant No. of the LDN • indialed number assigned by CM50 Y=02. 01-08: TIE 0-7 assigned by CM50 Y=02 00-63: Tenant No.
Page 280 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS DESCRIPTION DATA Specify the tenants allowing TAS Answer • CM63 between them. XX ZZ XX: 00-63 (Tenant No. of TAS Answer station) ZZ: 00-63 (Tenant No. of Trunk) 0 : Allow 1 : Restricted –...
Page 281 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS To provide an External TAS Indicator via the DK card: DESCRIPTION DATA START Assign the card number of the to required 000-763: LEN CM10 LEN. E800-E831: DK Card No. For PIM0/1: EB800-EB807 NOTE: The DK card number must be as- For PIM2/3: EB808-EB815...
Page 282 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS To provide the telephone set for TAS Indication: DESCRIPTION DATA START Assign the TAS Buzzer number (telephone 000-763: LEN CM10 set for TAS Indication) to the required LEN. E600-E663: TAS Buzzer No. The TAS Buzzer number must correspond with the TAS Group number assigned by CM30 Y=17.
Page 283 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS • For Main Ofﬁce COT: When using a COT interface between the Central Ofﬁce and a Main Ofﬁce, set up pro- gramming to the Main Ofﬁce by using the DIT-CCIS feature, and send the dial code as an LDN to the Satellite Ofﬁce.
Page 284 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS DESCRIPTION DATA CM58 Y=03 Night Mode Destination • Same as CM58 Y=02 09: LDN Diversion-Outside (Assigned by CM58 Y=09) Assign the Abbreviated Code for System Y=08 Day Mode • Speed Dialing to terminate the Satellite Y=09 Night Mode •...
Page 285 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK ANSWER FROM ANY STATION-CCIS Hardware Required To provide the External TAS Indicator: - DK card (Four Indicators per card can be equipped) - Indicator Requirement to External Indicator Control Method : Loop/Ground/Battery (-27 V) (Max. 125 mA) Type : Visual and/or Audible type with volume control For cross connection of the TAS indicator, refer to the Installation Procedure Manual.
Page 286: Trunk To Trunk Restriction-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS TRUNK TO TRUNK RESTRICTION-CCIS General Description This feature allows trunk to trunk tandem restriction by caller’s information (e.g., caller is a trunk) through the CCIS network. Case 1: A tandem connection at the following ofﬁce can be restricted by Trunk Restriction Class of Trunk A and Outgoing Connection Restriction data of Trunk B.
Page 287 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS Programming DESCRIPTION DATA START CM35 Assign the Trunk Restriction Class to the Y=97 • required trunk route. 00-63: Route No. X: 1-8: Day Class Z: 1-8: Night Class 1: Unrestricted (RCA) 2: Non-Restricted 1 (RCB) 3: Non-Restricted 2 (RCC) 4: Semi-Restricted 1 (RCE)
Page 288 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS DESCRIPTION DATA Assign the Toll Restriction Patterns with Y=01-13 CM81 • eight kinds of Trunk Restriction Classes Toll Restriction Pattern No. 01-13 assigned by CM35 Y=97. Toll Restriction 1-8: Trunk Restriction Class Pattern 00-15 have already been pro- 0: Restricted grammed as shown below.
Page 289 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS DESCRIPTION DATA Assign the area code to be restricted and Y=4000-4004 CM8A • the Toll Restriction Pattern number as- Area Code Development No. 0-4 signed by CM81 to the Area Code Devel- X-X...X: Area Code (Max.
Page 290 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS DESCRIPTION DATA To add the Tenant Pattern: CM8A STEP 1 Assign the area code to be re- Y=4000-4004 • stricted and the Tenant Pattern Area Code Development Pattern No. number to the Area Code De- X-X...X: Area Code (Max.
Page 291 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS DESCRIPTION DATA CM8A STEP 3 Assign the starting time for the Y=2000-2007 Time Pattern No. 00-07 • Toll Restriction and Route Pat- XX ZZ (Starting Time) tern number to the Time Pattern XX: 00-23 (Hours) number assigned by Step 2.
Page 292 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS When changing the initial setting (See NOTE on next page.), or when receiving the IMX Trunk Restriction Class (0-15), execute the following programming. DESCRIPTION DATA START CM42 Assign the IMX Trunk Restriction Class to 20: TRK Restriction Class 1 (RCA) each PBX Trunk Restriction Class for the 21: TRK Restriction Class 2 (RCB)
Page 293 CHAPTER 3 SYSTEM DATA PROGRAMMING TRUNK TO TRUNK RESTRICTION-CCIS NOTE: If no data is set, the initial setting is shown below. (1) PBX to IMX 1ST DATA 2ND DATA 20: TRK Restriction Class 1 (RCA) 01: TRK Restriction Class 1 21: TRK Restriction Class 2 (RCB) 02: TRK Restriction Class 2 22: TRK Restriction Class 3 (RCC)
Page 294: Uniform Numbering Plan-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING UNIFORM NUMBERING PLAN-CCIS UNIFORM NUMBERING PLAN-CCIS General Description In a CCIS network, a Uniform Numbering Plan enables a station user to call any other station in the network. Two alternative numbering plans are provided. In the ﬁrst plan, the station user dials any digits station number from three to eight.
Page 295: Voice Call-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING VOICE CALL-CCIS VOICE CALL-CCIS General Description term This feature provides a voice path, through the CCIS network, between a D in one ofﬁce and term in another ofﬁce. This path is established from the calling party to the called party’s built- in speaker.
Page 296: Voice Mail Integration-Ccis
CHAPTER 3 SYSTEM DATA PROGRAMMING VOICE MAIL INTEGRATION-CCIS VOICE MAIL INTEGRATION-CCIS General Description This feature allows any station user in the CCIS network to utilize the Voice Mail System (VMS) with the Message Center Interface (MCI). Programming Refer to Feature Programming Manual. –...
Page 297: Circuit Card Information
CHAPTER 4 CIRCUIT CARD INFORMATION CHAPTER 4 CIRCUIT CARD INFORMATION This chapter explains the mounting location, the meaning of lamp in- dications, and the method of switch settings of each circuit card for CCIS system. HOW TO READ THIS CHAPTER ..........MOUNTING LOCATION OF CIRCUIT CARD ......
Page 298: How To Read This Chapter
CHAPTER 4 CIRCUIT CARD INFORMATION HOW TO READ THIS CHAPTER HOW TO READ THIS CHAPTER This chapter explains each circuit card used in this system about the following items. Explana- tions are given in alphabetical order of the circuit card names within each circuit card category (Control, Application Processor, and Line/Trunk).
Page 299: Mounting Location Of Circuit Card
CHAPTER 4 CIRCUIT CARD INFORMATION MOUNTING LOCATION OF CIRCUIT CARD MOUNTING LOCATION OF CIRCUIT CARD This section explains the location for mounting circuit cards for the CCIS system. Regular PIM The ﬁgure below shows circuit card mounting slots allocated in the regular PIM. Mounting Location of Circuit Card (Regular PIM) AC/DC LTC1...
Page 300: Pim For Backup Cpu System
CHAPTER 4 CIRCUIT CARD INFORMATION MOUNTING LOCATION OF CIRCUIT CARD PIM for Backup CPU System The ﬁgure below shows circuit card mounting slots allocated in the PIM0 for Backup CPU Sys- tem. Mounting Location of Circuit Card (Backup CPU) AC/DC PIM0 (For Backup CPU)
Page 301 THIS PAGE LEFT BLANK INTENTIONALLY. – 259-2 – Rev.1.1 97258-11...
Page 302: List Of Required Card
CHAPTER 4 CIRCUIT CARD INFORMATION LIST OF REQUIRED CARD LIST OF REQUIRED CARD The table below shows the required cards to be explained in this section. List of Required Cards EXTRACTION/ INSERTION WITH LAMP SWITCH POWER ON NAME X: PROVIDED X: PROVIDED REFERENCE X: ALLOWED...
Page 303: Pn-Cp14 (Mp)
PN-CP14 (MP) PN-CP14 (MP) Locations of Lamps, Switches, and Connectors CONN JACK CONN: To CONNR connector on PZ-M537 (EXPMEM) Lamp Indications LAMP COLOR FUNCTION NAME Green Flash (120 IPM) : On Line Flash (slowly) : Off Line OFF or ON : This card is not operating.
Page 304 PN-CP14 (MP) Switch Settings CAUTION When the operating power is being supplied to this circuit card, do not plug/unplug this circuit card into/from its mounting slot. SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW3 (Rotary SW) On Line (Call processing is in progress) Off Line (Call processing is stopped) •...
Page 305 PN-CP14 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW1 (Push SW) For initializing CPU A-law (Australia) (Piano Key SW) µ-law (North America) Selection of PLO0 input (Phase Locked Oscillator) • For clock receiver ofﬁce: SW2-2 SW2-3 FUNCTION 1.5MHz clock [For PN-24DTA/PN-24CCT/ PN-24PRT] 192kHz clock...
Page 306 PN-CP14 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW4 (Dip SW) Not used Not used 1 2 3 4 Selection of PLO1 input (Phase Locked Oscillator) • For clock receiver ofﬁce: SW4-3 SW4-4 FUNCTION 1.5MHz clock [For PN-24DTA/PN-24CCT/ PN-24PRT] 192kHz clock 3, 4...
Page 307 PN-CP14 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION JP0 (Jumper pin) Not used (Memory backup OFF) For normal operation DOWN Front (Memory backup ON) JP1 (Jumper pin) For using internal tone source DOWN For using external tone source Front The ﬁgure in the SWITCH NAME column and the position in in the SETTING POSITION...
Page 308: Pn-Cp20 (Mp)
PN-CP20 (MP) PN-CP20 (MP) Locations of Lamps, Switches, and Connectors CONN JACK CLK IN STBY CONN: To CONNR connector on PZ-M537 (EXPMEM) Lamp Indications LAMP COLOR FUNCTION NAME Green Flash (120 IPM) : On Line Flash (slowly) : Off Line OFF or ON : This card is not operating.
Page 309 PN-CP20 (MP) Switch Settings CAUTION When the operating power is being supplied to this circuit card, do not plug/unplug this circuit card into/from its mounting slot. SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW3 (Rotary SW) On Line (Call processing is in progress) Off Line (Call processing is stopped) •...
Page 310 PN-CP20 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW1 (Push SW) For initializing CPU A-law (Australia) (Piano Key SW) µ-law (North America) Selection of PLO0 input (Phase Locked Oscillator) • For clock receiver ofﬁce: SW2-2 SW2-3 FUNCTION 1.5MHz clock [For PN-24DTA/PN-24CCT/ PN-24PRT] 192kHz clock...
Page 311 PN-CP20 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW4 (Dip SW) Always set to OFF Not used 1 2 3 4 Selection of PLO1 input (Phase Locked Oscillator) • For clock receiver ofﬁce: SW4-3 SW4-4 FUNCTION 1.5MHz clock [For PN-24DTA/PN-24CCT/ PN-24PRT] 192kHz clock...
Page 312 PN-CP20 (MP) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION JP0 (Jumper pin) Not used (Memory backup OFF) For normal operation DOWN Front (Memory backup ON) JP1 (Jumper pin) For using internal tone source DOWN For using external tone source Front The ﬁgure in the SWITCH NAME column and the position in in the SETTING POSITION...
Page 313 THIS PAGE LEFT BLANK INTENTIONALLY. – 267-4 – Rev.1.1 97261-11...
Page 314: Pn-Ap00-B (Ap00)
PN-AP00-B (AP00) PN-AP00-B (AP00) Locations of Lamps, Switches, and Connectors CONN SENSE CONN: To CONNR connector on PZ-M537 (EXPMEM) – 268 – 97261-10...
Page 315 PN-AP00-B (AP00) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. L0-L3 Green Second data setting value for CMD001 > 250 1 (port0)-3 (port2) Indication of transmitting Indication of CTS signal status on status of port0 port0-2 Indication of transmitting...
Page 316 PN-AP00-B (AP00) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW0 (Dip SW) Not used 1 2 3 4 5 6 7 8 For normal operation For normal operation 4, 5 Not used Sets No. 0 Port forcibly in a state which DSR signal is always pro- vided.
Page 317 PN-AP00-B (AP00) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW2 (Dip SW) Sets No. 3 Port forcibly in a state which DSR signal is always pro- 1 2 3 4 5 6 7 8 vided. NOTE3 Receives DSR signal from the DCE on No.
Page 318 PN-AP00-B (AP00) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW2 (Dip SW) • Uses internal clock as the receive clock when No. 1 Port is synchro- 1 2 3 4 5 6 7 8 nous. • When No. 1 Port is asynchronous. NOTE4 Enables receive clock from the DCE (Modem) when No.
Page 319 PN-AP00-B (AP00) NOTE4: The use of the external clock (from the distant end) or the internal clock is determined by the following table: CLOCK External Internal – 273 – 97261-10...
Page 320: Pn-24Ccta (Cct)
PN-24CCTA (CCT) PN-24CCTA (CCT) Locations of Lamps, Switches and Connectors SENSE AISS JPR0 JRR1 – 273-1 – Rev.1.1 97273-11...
Page 321 PN-24CCTA (CCT) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. Green Remains lit when communications are normally ongoing with the common signaling channel data links connected. Green Remains lit when a loop-back test is in progress. Remains lit when detecting Cyclic Redundancy Checking (CRC) errors.
Page 322 PN-24CCTA (CCT) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION MB (Toggle SW) For make-busy For normal operation DOWN NOTE2 Source clock signal from network is (Piano Key SW) sent to the PLO 0 input on MP card. NOTE3 Source clock signal from network is NOTE4 not sent to the PLO 0 input on MP card.
Page 323 PN-24CCTA (CCT) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION Not used (Piano Key SW) Not used Not used AP No. 04-15 AP No. 20-31 SW2 (Dip SW) • Common channel signaling data transmission speed (For Digital Interface) 8 7 6 5 4 3 2 1 TRANSMISSION SPEED 48kbps...
Page 324 PN-24CCTA (CCT) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION JPR0 (Jumper pin) Neutral grounding on the receiving line is provided. Neutral grounding on the receiving DOWN line is not provided. JPR1 (Jumper pin) Line impedance: 100 ohms RIGHT LEFT Line impedance: 110 ohms JPS (Jumper pin) Neutral grounding on the transmit-...
Page 325 PN-24CCTA (CCT) NOTE2: When the power is on, flip the MB switch to ON (UP position) before plugging/unplug- ging the circuit card. NOTE3: Set SW0-1 and SW0-2 as follows: CCT0 CCT1 CCT2 • • • • • CCT7 CONDITIONS REMARKS MP card will receive the When one CCT ON OFF –...
Page 326: Pn-30Ccta (Cct)
PN-30CCTA (CCT) PN-30CCTA (CCT) Locations of Lamps, Switches and Connectors SENSE MFRM MRMT – 273-7 – Rev.1.1 97273A11...
Page 327 PN-30CCTA (CCT) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM when this card is normally operating. Green Remains lit when communications are normally ongoing with the common signaling channel data links connected. Green Remains lit when a loop-back test is in progress. Remains lit when detecting PCM signal loss.
Page 328 PN-30CCTA (CCT) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SENSE Set the switch to match the AP Number (04-31) to (Rotary SW) be set by CM05. SW-8: ON 04 05 06 07 08 09 10 11 12 13 14 15 AP No.
Page 329 PN-30CCTA (CCT) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Source clock signal from network is (Piano Key SW) sent to the PLO 0 input on MP card. NOTE3 Source clock signal from network is NOTE4 not sent to the PLO 0 input on MP card.
Page 330 PN-30CCTA (CCT) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW1(Dip SW) • Common channel signaling data transmission speed (For Digital Interface) 8 7 6 5 4 3 2 1 TRANSMISSION SPEED 48kbps NOTE5 OFF OFF 48kbps NOTE5 56kbps 64kbps Not used (Always set to OFF) Not used (Always set to OFF) Not used (Always set to OFF)
Page 331 PN-30CCTA (CCT) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Balanced transmission RIGHT (Jumper pin) (For twisted-pair cable) TA is grounded on the transmission LEFT line (For coaxial cable) Balanced transmission (Jumper pin) (For twisted-pair cable) RA is grounded on the transmission DOWN line (For coaxial cable) Line impedance: 75 ohms...
Page 332 PN-30CCTA (CCT) NOTE3: Set SW-1 and SW-2 as follows: • • • • • CCT0 CCT1 CCT2 CCT7 CONDITIONS REMARKS MP card will receive the When one CCT is ON OFF – – – – – – – – clock signal from CCT0 provided.
Page 333 THIS PAGE LEFT BLANK INTENTIONALLY. – 273-14 – Rev.1.1 97273A11...
Page 334: Pn-24Dta-C (Dti)
PN-24DTA-C (DTI) PN-24DTA-C (DTI) Locations of Lamps, Switches and Connectors SENSE AISS JPR0 JRR1 – 274 – Rev.1.1 97274-11...
Page 335 PN-24DTA-C (DTI) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. Remains lit when detecting Cyclic Redundancy Checking (CRC) errors. Remains lit when detecting PCM signal loss. Remains lit when detecting Frame Alignment signal loss. Remains lit when receiving Frame Alignment signal loss alarm from a distant ofﬁce.
Page 336 PN-24DTA-C (DTI) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SENSE Not used (Rotary SW) Set the switch to match the AP Number (04-31) to be set by CM05. SW1-4: ON 04 05 06 07 08 09 10 11 12 13 14 15 AP No.
Page 337 PN-24DTA-C (DTI) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION Source clock signal from network is (Piano Key SW) sent to the PLO 0 input on MP card. NOTE 3 Source clock signal from network is NOTE 4 not sent to the PLO 0 input on MP card.
Page 338 PN-24DTA-C (DTI) SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION Not used (Piano Key SW) Not used Not used AP No. 04-15 AP No. 20-31 NOTE4 JPR0 (Jumper pin) Neutral grounding on the receiving line is provided. Neutral grounding on the receiving DOWN line is not provided.
Page 339 PN-24DTA-C (DTI) The ﬁgure in the SWITCH NAME column and the position in in the SETTING POSITION column indicate the standard setting of the switch. When the switch is not set as shown by the ﬁgure and , the setting of the switch varies with the system concerned. NOTE1: Set the groove on the switch to the desired position.
Page 340: Pn-30Dtc-A (Dti)
PN-30DTC-A (DTI) PN-30DTC-A (DTI) Locations of Lamps, Switches and Connectors SENS MFRM MRMT – 280 – 97280-10...
Page 341 PN-30DTC-A (DTI) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM when this card is normally operating. Remains lit when detecting PCM signal loss. Remains lit when detecting Frame Alignment signal loss. MFRM Remains lit when detecting Multi-Frame Alignment signal loss on time slot 16.
Page 342 PN-30DTC-A (DTI) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SENS Set the switch to match the AP Number (04-31) to (Rotary SW) be set by CM05. SW-8: ON 04 05 06 07 08 09 10 11 12 13 14 15 AP No.
Page 343 PN-30DTC-A (DTI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Source clock signal from network is (Piano Key SW) sent to the PLO 0 input on MP card. NOTE3 Source clock signal from network is NOTE4 not sent to the PLO 0 input on MP card.
Page 344 PN-30DTC-A (DTI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Balanced transmission (Jumper pin) (For twisted-pair cable) TA is grounded on the transmission DOWN line (For coaxial cable) Balanced transmission (Jumper pin) (For twisted-pair cable) RA is grounded on the transmission DOWN line (For coaxial cable) Line impedance: 75 ohms...
Page 345 PN-30DTC-A (DTI) NOTE3: Set the SW-1 and SW-2 as follows: DTI0 DTI1 DTI2 DTI3 CONDITIONS REMARKS MP card will receive the clock When one DTI is ON OFF – – – – – – signal from DTI0 at its PLO0 provided.
Page 346: Pn-30Dtc-C (Dti)
PN-30DTC-C (DTI) PN-30DTC-C (DTI) Locations of Lamps, Switches and Connectors SENSE MFRM MRMT – 285-1 – Rev.1.1 97285-11...
Page 347 PN-30DTC-C (DTI) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM when this card is normally operating. Remains lit when detecting PCM signal loss. Remains lit when detecting Frame Alignment signal loss. MFRM Remains lit when detecting Multi-Frame Alignment signal loss on time slot 16.
Page 348 PN-30DTC-C (DTI) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SENSE Set the switch to match the AP Number (04-31) to (Rotary SW) be set by CM05. SW-8: ON 04 05 06 07 08 09 10 11 12 13 14 15 AP No.
Page 349 PN-30DTC-C (DTI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Source clock signal from network is (Piano Key SW) sent to the PLO 0 input on MP card. NOTE3 Source clock signal from network is NOTE4 not sent to the PLO 0 input on MP card.
Page 350 PN-30DTC-C (DTI) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION Balanced transmission RIGHT (Jumper pin) (For twisted-pair cable) TA is grounded on the transmission LEFT line (For coaxial cable) Balanced transmission (Jumper pin) (For twisted-pair cable) RA is grounded on the transmission DOWN line (For coaxial cable) Line impedance: 75 ohms...
Page 351 PN-30DTC-C (DTI) NOTE3: Set the SW-1 and SW-2 as follows: • • • • • DTI0 DTI1 DTI2 DTI7 CONDITIONS REMARKS MP card will receive the When one DTI is ON OFF – – – – – – – – clock signal from DTI0 at provided.
Page 352: Pn-Sc00 (Cch)
PN-SC00 (CCH) PN-SC00 (CCH) Locations of Lamps, Switches and Connectors SENS TO MODEM ( FOR ANALOG INTERFACE) Lamp Indications LAMP COLOR FUNCTION NAME Green Flashes at 120 IPM while this card is operating normally. Green Remains lit when communications are normally ongoing with the common signalling channel data links connected.
Page 353 PN-SC00 (CCH) Switch Settings SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SENS Set the switch to match the AP Number (04-31) to (Rotary SW) be set by CM05. SW0-4: ON 04 05 06 07 08 09 10 11 12 13 14 15 AP No.
Page 354 PN-SC00 (CCH) SWITCH SWITCH SETTING FUNCTION CHECK NAME NUMBER POSITION SW1 (Dip SW) • Common channel signaling data transmission speed (For Digital 1 2 3 4 5 6 7 8 Interface) TRANSMISSION SPEED 48kbps NOTE4 OFF OFF 48kbps NOTE4 56kbps 64kbps •...
Page 355: Pz-M537 (Expmem)
PZ-M537 (EXPMEM) PZ-M537 (EXPMEM) Locations of Lamps, Switches and Connectors FACE REAR CONNR CONNR: To CONN connector on PN-CP14/PN-CP20 (MP) or PN-AP00-B (AP00) – 289 – Rev.1.1 97286-11...
Page 356 PZ-M537 (EXPMEM) Lamp Indications This card has no lamps. Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION SW (Dip SW) For normal operation (Memory backup ON) 1 2 3 4 Not used (Memory backup OFF) Not used Not used Not used The ﬁgure in the SWITCH NAME column and the position in in the SETTING POSITION...
Page 357 PZ-M537 (EXPMEM) Mounting PZ-M537 Card When mounting the EXPMEM card on the AP00/MP card, do the following procedure. STEP1: Take off three screws from the rear side of EXPMEM support. NOTE: Supports and screws are attached to the EXPMEM card. STEP2: Connect the CONNR connector on the EXPMEM card and the CONN connector on the AP00/MP card.
Page 358: Pz-M542 (Conn)
PZ-M542 (CONN) PZ-M542 (CONN) Locations of Lamps, Switches and Connectors TRS21 RCV21 No.2 CIRCUIT TRS11 RCV11 TO CHAMP TO LTC CONNECTOR No.1 CONNECTOR (MDF) ON BWB IN PIM CIRCUIT RCV01 TRS01 No.0 CIRCUIT COAXIAL CONNECTOR Lamp Indications This card has no lamps. –...
Page 359 PZ-M542 (CONN) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION For coaxial connectors RIGHT (No.0 circuit) For champ connector LEFT (LT connector) (No.0 circuit) For coaxial connectors RIGHT (No.1 circuit) For champ connector LEFT (LT connector) (No.1 circuit) For coaxial connectors RIGHT (No.2 circuit)
Page 360: Pz-M557 (Conn)
PZ-M557 (CONN) PZ-M557 (CONN) Locations of Lamps, Switches and Connectors TRS20 RCV20 No.2 CIRCUIT TRS10 RCV10 TO CHAMP TO LTC CONNECTOR No.1 CONNECTOR (MDF) ON BWB IN PIM CIRCUIT RCV00 TRS00 No.0 CIRCUIT COAXIAL CONNECTOR Lamp Indications This card has no lamps. –...
Page 361 PZ-M557 (CONN) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION For coaxial connectors RIGHT (No.0 circuit) For champ connector LEFT (LT connector) (No.0 circuit) For coaxial connectors RIGHT (No.1 circuit) For champ connector LEFT (LT connector) (No.1 circuit) For coaxial connectors RIGHT (No.2 circuit)
Page 362: Pn-2Ldta (Ldt)
PN-2LDTA (LDT) PN-2LDTA (LDT) Locations of Lamps, Switches and Connectors Lamp Indications LAMP COLOR FUNCTION NAME BL0, 1 • Remains lit when the corresponding circuit is in use. • Flashes at 60 IPM when the corresponding circuit is in make- busy state or the system data for this card is not assigned.
Page 363: Pn-M10 (M10)
PN-M10 (M10) PN-M10 (M10) Location of Lamps, Switches and Connectors TALM RALM CN1 TO OPTICAL CABLE Lamp Indications LAMP COLOR FUNCTION NAME Green Remains lit when a Digital Trunk Interface is connected to No. 0 circuit on this card. Green Remains lit when a Digital Trunk Interface is connected to No.
Page 364 PN-M10 (M10) Switch Settings SWITCH SETTING SWITCH NAME FUNCTION CHECK NUMBER POSITION JP0, 1 When connected to E1 (2M) Digital (Jumper pin) Trunk Interface When connected to T1 (1.5M) Digi- DOWN tal Trunk Interface JP2 (Jumper pin) Line code: B8ZS* is provided (For T1 interface) RIGHT *B8ZS: Bipolar Eight Zero Substitu-...
Page 365: Pn-2Odta (Odt)
PN-2ODTA (ODT) PN-2ODTA (ODT) Locations of Lamps, Switches and Connectors Lamp Indications LAMP COLOR FUNCTION NAME BL0, 1 • Remains lit when the corresponding circuit is in use. • Flashes at 60 IPM when the corresponding circuit is in make- busy state or the system data for this card is not assigned.
Page 366: Pn-2Odtb (Odt)
PN-2ODTB (ODT) PN-2ODTB (ODT) Locations of Lamps, Switches and Connectors Lamp Indications LAMP COLOR FUNCTION NAME BL0, 1 • Remains lit when the corresponding circuit is in use. • Flashes at 60 IPM when the corresponding circuit is in make- busy state or the system data for this card is not assigned.
Page 367: Chapter 5 Operation Test
CHAPTER 5 OPERATION TEST CHAPTER 5 OPERATION TEST This chapter explains inter-ofﬁce test procedure for basic DTI/CCT functions. LOOP-BACK TEST ..............INTEROFFICE TRANSMISSION LINE TEST ......PLO OPERATION TEST ............– 301 – Rev.1.1 97301-11...
Page 368: Loop-Back Test
CHAPTER 5 OPERATION TEST LOOP-BACK TEST LOOP-BACK TEST A loop-back test is performed on the DTI/CCT card. At least two DTI/CCT cards are necessary. Operational tests are performed by the clock within the MP. STEP 1: Assign the system data for a performance test as follows. Loop-Back Test TDSW DP/PB TEL...
Page 369 CHAPTER 5 OPERATION TEST LOOP-BACK TEST STEP 2: Connect the cable for loop-back test. (1) When using a twisted-pair cable: This ﬁgure shows an example of the cable connection when the DTI/CCT cards are mounted in the AP05 and AP06 slot of PIM0. Loop-Back Test Connection for Twisted-Pair Cable PIM0 LTC1...
Page 370 CHAPTER 5 OPERATION TEST LOOP-BACK TEST (2) When using a coaxial cable: This ﬁgure shows an example of the cable connection when the 30DTI/30CCT cards are mounted in the AP07 and AP08 slot of PIM0. Loop-Back Test Connection for Coaxial Cable PIM0 LTC2 CONN CARD...
Page 371 CHAPTER 5 OPERATION TEST LOOP-BACK TEST STEP 3: Turn on the operating power. Conﬁrm the state of the lamps on the two 24DTI/24CCT cards or 30DTI/30CCT cards. See following tables. page 306 • Alarm Indications on 24DTI page 307 • Alarm Indications on 30DTI page 308-1 •...
Page 372 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 24DTI Card LED INDICATION FAULT NORMAL FAULT CAUSE ACTION Flash On or Off Abnormal opera- Conﬁrm the programming data: (120 IPM) tion of DTI card CM05 Y=0/Y=1, CM07 Y=01. Check to see if the SENSE switch is set as per the AP number (04-15, 20-31) assigned by CM05 Y=0.
Page 373 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 30DTI Card LED INDICATION FAULT NORMAL FAULT CAUSE ACTION Flash On or Off Abnormal opera- Conﬁrm the programming data: (120 IPM) tion of DTI card CM05 Y=0/Y=1, CM07 Y=01. Check to see if the SENSE switch is set as per the AP number (04-15, 20-31) assigned by CM05 Y=0.
Page 374 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 30DTI Card LED INDICATION FAULT NORMAL FAULT CAUSE ACTION MRMT Multi Frame Conﬁrm the switch setting on Alignment sig- the DTI card indicating an nals can not be alarm. sent to the Replace the DTI card not indi- remote PBX cating an alarm, with a spare.
Page 375 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 24CCT LED INDICATION FAULT NORMAL FAULT CAUSE ACTION Flash On or Off Abnormal opera- Conﬁrm the programming data: (120 IPM) tion of CCT card CM05 Y=0/Y=1, CM07 Y=01. Check to see if the SENSE switch is set as per the AP number (04-15, 20-31) assigned by CM05 Y=0.
Page 376 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 24CCT LED INDICATION FAULT NORMAL FAULT CAUSE ACTION Frame Alignment Check the transmission line signals can not and external equipment. be sent to the Replace the CCT card. remote PBX Remote PBX is in Check the switch settings of the the local loop- remote CCT card.
Page 377 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 30CCT LED INDICATION FAULT NORMAL FAULT CAUSE ACTION Flash On or Off Abnormal opera- Conﬁrm the programming data: tion of CCT card CM05 Y=0/Y=1, CM07 Y=01. (120 IPM) Check to see if the SENSE switch is set as per the AP number (04-15, 20-31) assigned by CM05 Y=0.
Page 378 CHAPTER 5 OPERATION TEST LOOP-BACK TEST Alarm Indications on 30CCT LED INDICATION FAULT NORMAL FAULT CAUSE ACTION MRMT Multi Frame Conﬁrm the switch setting on Alignment sig- the CCT card indicating an nals can not be alarm. sent to the Replace the CCT card not indi- remote PBX cating an alarm, with a spare.
Page 379: Interoffice Transmission Line Test
CHAPTER 5 OPERATION TEST INTEROFFICE TRANSMISSION LINE TEST INTEROFFICE TRANSMISSION LINE TEST To conﬁrm inter-ofﬁce synchronization and speech quality using “In-Service” transmission lines, do the following steps. STEP 1: Connect the transmission line to the MDF or CONN card. STEP 2: Make busy the channels except the channel tested by CME5. STEP 3: Conﬁrm indication lamps on the DTI/CCT card, as per the following table.
Page 380 THIS PAGE LEFT BLANK INTENTIONALLY. – 310 – Rev.1.1 97302-11...
Page 381: Plo Operation Test
CHAPTER 5 OPERATION TEST PLO OPERATION TEST PLO OPERATION TEST To conﬁrm the PLO operation, do the following tests. • Clock Signal Generation Test • Clock Signal Synchronization Test To be tested when the PBX is a clock receiver ofﬁce. •...
Page 382: Clock Signal Synchronization Test
CHAPTER 5 OPERATION TEST PLO OPERATION TEST Clock Signal Synchronization Test This test checks to see if the PLO keeps synchronizing with the external clock signals, when the external clock signals from network have input again after they have stopped once. Do the fol- lowing steps using “In Service”...
Page 383 CHAPTER 5 OPERATION TEST PLO OPERATION TEST (2) When providing two clock supply routes STEP 1: On the DTI/CCT cards extracting clock signals, set the switches as follows to change the clock supply route from 0 to 1. • 30DTI0/30CCT0 card: SW-1 to OFF, SW-2 to OFF •...
Page 384: Interoffice Synchronization Test
CHAPTER 5 OPERATION TEST PLO OPERATION TEST STEP 9: Repeat the procedure shown in STEP 2 and STEP 3. NOTE: If noise periodically occurs, replace the MP card after checking the switch settings on the MP card, and do the above test again. Interofﬁce Synchronization Test This test checks to see if noise occurs while calling with the opposite ofﬁce, by difference of the clock signal frequency between the ofﬁces.
Page 385 CHAPTER 5 OPERATION TEST PLO OPERATION TEST STEP 3: Conﬁrm indication lamps on the MP card. NOTE: When the CLK lamp lights on the MP card, the clock signal is not generated from the MP card. Check the switch settings on the DTI/CCT and MP card. page 257 For details of the lamp indications, refer to the CHAPTER 4.

This manual is also suitable for:

Neax 7400 ics m100mx
