- Page 1 No.2, 2nd Dong Huan Road, 10th YouSong lndustrial District, Longhua Town, Baoan, ShenZhen User Manual WiFi+ BT Module Project Name WiFi+ BT Module Approval Sheet Rev. Foxconn Part No. J20H064 Prepared by Reviewed by Approved by Shu-yu Li Xue-dong Jiang...
- Page 2 CONTENTS PRODUCT INTRODUCTION .............. 3 ..............3 PPLICATION SCOPE MODULE HARDWARE OVERVIEW ............4 ................ 4 LOCK IAGRAM ................4 EATURES .............. 4 NTERFACE AND ONNECTOR ELECTRICAL SPECIFICATION ............6 ............... 6 BSOLUTE MAXIMUM RATING ............6 ECOMMENDED OPERATING RATING ..............
-
Page 3: Product Introduction
1 Product Introduction J20H064 802.11b/g/n+Bluetooth4.0 module provides wireless modem functionality utilizing direct sequence spread spectrum and OFDM/CCK technology. This module is based on Marvell 88W8766P solution which is integrated 2.4GHz IEEE802.11 b/g/n (MAC/baseband/radio), Bluetooth 4.0 + High speed and power amplifiers (PA). -
Page 4: Block Diagram
2 Module Hardware Overview 2.1 Block Diagram The general HW architecture is shown below Figure: Module Block Diagram 2.2 Features ♦ IEEE802.11b/g/n (1X1) and Bluetooth 4.0 based on Marvell 88W8766P solution. ♦ USB 2.0 Interface, High and Full Speeds supported. ♦... - Page 5 Pin Number Symbol Name Status Pin definition Ground USB positive data USB negative data USB +5V power input Ground Ground Ground...
-
Page 6: Electrical Specification
3 Electrical Specification Absolute maximum rating Element Symbol Unit DC supply voltage Recommended operating rating Element Symbol Unit DC supply voltage DC Characteristics Symbol Parameter Unit Supply voltage Tx Current(1M/15dBm) (mA) Tx Current(11M/15dBm) (mA) Tx Current(6M/15dBm) (mA) Tx Current(54M/15dBm) (mA) Tx Current(MCS0/15Bm/HT20) (mA) Tx Current(MCS7/15dBm/HT20) - Page 7 4 RF Specification IEEE802.11b Items Contents Specification IEEE802.11b Mode DSSS / CCK Channel CH1 to CH13 Data rate 1, 2, 5.5, 11Mbps TX Characteristics Min. Typ. Max. Unit 1. Power Levels (Calibrated) 1) Target Power@1Mbps 13.5 16.5 2) Target Power@2Mbps 13.5 16.5 3) Target Power@5.5Mbps...
- Page 8 IEEE802.11g Items Contents Specification IEEE802.11g Mode OFDM Channel CH1 to CH13 Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps TX Characteristics Min. Typ. Max. Unit 1. Power Levels (Calibrated) 1) Target Power@6Mbps 13.5 16.5 2) Target Power@9Mbps 13.5 16.5 3) Target Power@12Mbps 13.5...
- Page 9 802.11n HT20 Items Contents Specification IEEE802.11n HT20 Mode OFDM Channel CH1 to CH13 Data rate (MCS index) MCS0/1/2/3/4/5/6/7 TX Characteristics Min. Typ. Max. Unit 1. Power Levels (Calibrated) 13.5 16.5 1) Target Power@MCS0 13.5 16.5 2) Target Power@ MCS1 13.5 16.5 3) Target Power@ MCS2 13.5...
- Page 10 5 Operation SOP 1: Install normal driver under Linux PC 2: search WiFi AP and double click to make connection 3: If connection setup is ok, PC can communicate with network through wireless AP.
- Page 11 Items Contents Specification BT4.0+EDR Frequency range 2.4GHz~2.4835GHz Data rate 1Mbps, 2Mbps, 3Mbps Min. Typ. Max. Unit - TX Characteristics - 1. Power Levels BT Output Power 2. Initial Carrier Frequency Tolerance Average Offset 3. Carrier Drift Drift Rate kHz/50us kHz/50us kHz/50us Average Drift 4.
- Page 12 Items Contents Specification BT4.0+EDR Frequency range 2.4GHz~2.4835GHz Data rate 1Mbps, 2Mbps, 3Mbps - RX Characteristics - Min. Typ. Max. Unit 1. Minimum Input Level Sensitivity GFSK (1Mbps) π/4 DQPSK (2Mbps) 8DPSK (3Mbps) 2. Maximum Input Level GFSK (1Mbps) π/4 DQPSK (2Mbps) 8DPSK (3Mbps) 3.
-
Page 13: Mechanical Specifications
6 Mechanical Specifications Shielding Cover Dimension Dimension (LxWxH): 20.32mm x 18.28mm x 2.4mm Thickness: 0.2mm... -
Page 14: Industry Canada Statement
PCB Assembly Dimension Dimension (W x Lx H ): 51.8mmx20mmx0.9mm PCB: 2 layer HF-FR4 design Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 15 être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 2878D- J20H064". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which...
-
Page 16: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 17 This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: MCLJ20H064”.
