September 23, 2021
WBUR56 PRODUCT SPECIFICATION
WBUR56
IEEE 802.11 a/b/g/n/ac 2x2 + BT5 Combo Module
Product Specification 1.0
Approved:
Approved:
Prepared by:
________________________
_________________________
_________________________
Zeke Wu
Ben Ho
Wayne Chang
Manager
Supervisor
Engineer
FOXCONN CONFIDENTIAL
1
This preliminary specification is subject to change without notice.
Copyright © 2017 Hon Hai Precision Ind Co., Ltd. All rights reserved
Advertisement
Table of Contents
Related Manuals for Foxconn WBUR56
Summary of Contents for Foxconn WBUR56
- Page 1 September 23, 2021 WBUR56 PRODUCT SPECIFICATION WBUR56 IEEE 802.11 a/b/g/n/ac 2x2 + BT5 Combo Module Product Specification 1.0 Approved: Approved: Prepared by: ________________________ _________________________ _________________________ Zeke Wu Ben Ho Wayne Chang Manager Supervisor Engineer FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice.
-
Page 2: Revision History
Initial Released RESTRICTED AND CONFIDENTIAL INFORMATION STATEMENT All information contained in this document is the exclusive property of Foxconn Technology Inc. and its development partners. Any reproduction or disclosure of all or part of this document without the expressed written consent of Foxconn Technology Inc. is strictly prohibited. -
Page 3: Chapter 1. Module Overview
Multi-user MIMO with WLAN USB2.0 network interface controller. It combines a WLAN MAC, a 2T2R capable WLAN baseband, and RF in a single module. The WBUR56 provides a complete solution for a high-performance integrated wireless and Bluetooth device. -
Page 4: Pin Definition
September 23, 2021 WBUR56 PRODUCT SPECIFICATION Pin definition 12……10 Figure 1 Pin Definitions (Module Top View) Table 1 Pin Definitions FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice. Copyright © 2017 Hon Hai Precision Ind Co., Ltd. All rights reserved... -
Page 5: Power Consumption
September 23, 2021 WBUR56 PRODUCT SPECIFICATION CHAPTER 2. ELECTRICAL AND RF SPECIFICAITON Recommended Operation Rating Table 2 Operation Rating Parameter Condition Typ. Max. Unit 3.3V 3.3V 3.6V RF Interface Power Consumption Power consumption is measured using current probe loop on the Power rails of the USB interface (Pins). - Page 6 September 23, 2021 WBUR56 PRODUCT SPECIFICATION WiFi RF Specification – TX Table 4 IEEE 802.11 b/g/n TX Average Maximum Output Power North America(NA), Asia-Pacific(AP) Band@2.4GHz Data Rate(Mbps) Modulation WLAN 0[dBm] WLAN 1[dBm] WLAN 0+1[dBm] DBPSK DQPSK 802.11b 13.5 13.5 16.5...
- Page 7 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Table 5 IEEE 802.11 a/n/ac TX Average Maximum Output Power North America(NA), Asia-Pacific(AP) Band@5GHz Data Rate(Mbps) Modulation WLAN 0[dBm] WLAN 1[dBm] WLAN 0+1[dBm] OFDM OFDM OFDM 802.11a OFDM 10.5 10.5 13.5 (5150-5725MHz) 10(NA), 4(AP)
- Page 8 September 23, 2021 WBUR56 PRODUCT SPECIFICATION WiFi RF Specification – RX Table 6 IEEE 802.11 b/g/a/n/ac RX Sensitivity (WLAN0&WLAN1) Rx Sensitivity Rx Sensitivity Data Rate Data Rate Modulation (dBm) Modulation (dBm) (Mbps) (Mbps) Max. Typ. Max. Typ. DBPSK HT20-7.22 BPSK DQPSK HT20-14.44...
- Page 9 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Bluetooth RF Specification Parameter Condition Min. Typ. Max. Unit Basic Data Rate – Transmit Performance RF Transmit Power (TRM01) Power Density (TRM02) Per 100kHz ≤20 Power Control (TRM03) 2≤ step size ≤ 8 TX Output Spectrum –...
- Page 10 September 23, 2021 WBUR56 PRODUCT SPECIFICATION TX Output Spectrum – 30MHz – 1GHz ≤ -36 Out of Band Spurious Emission 1GHz -12.75GHz ≤ -30 5.15GHz -5.35GHz ≤ -47 5.725GHz-5.825GHz ≤ -47 Enhanced power control (TRM14) Step Size 2 ≤ Step Size ≤ 8 Difference.
- Page 11 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Bluetooth Low Energy RF Specification Parameter Condition Min. Typ. Max. Unit Transmit Performance RF Transmit Power (TRM-LE01,02) In-Band Emission (TRM-LE03,04) ∣f-f ∣= 2MHz ≤ -20 ∣f-f ∣≥ 3MHz ≤ -30 TX Output Spectrum –...
- Page 12 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Power On Sequence Figure 2 Power On Sequence FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice. Copyright © 2017 Hon Hai Precision Ind Co., Ltd. All rights reserved...
- Page 13 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Antenna Specification Requirement Nominal antenna port impedance specification is 50 ohms for the Foxconn WBUR56 hardware. For regulatory requirements, it is assumed that the antenna gain are: WLAN Type : PCB, Internal BT Type : PIFA, External FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice.
-
Page 14: Mechanical Specification
September 23, 2021 WBUR56 PRODUCT SPECIFICATION CHAPTER 3. MECHANICAL SPECIFICATION Module Assembly Dimension Top View Side View FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice. Bottom View Copyright © 2017 Hon Hai Precision Ind Co., Ltd. All rights reserved... -
Page 15: Label Specification
September 23, 2021 WBUR56 PRODUCT SPECIFICATION Figure 3 Mechanical Drawing Label Specification Figure 4 Label Drawing FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice. Copyright © 2017 Hon Hai Precision Ind Co., Ltd. All rights reserved... -
Page 16: Additional Information
September 23, 2021 WBUR56 PRODUCT SPECIFICATION CHAPTER 4. ADDITIONAL INFORMATION EEPROM Information Table 7 USB PID/VID Setting WLAN Type Mode Realtek RTL8822CU Wireless LAN 802.11ac C82C 0BDA USB 2.0 Mass Production Network Adapter Module Photo Figure 5 Top Side Photo... -
Page 17: Environment Specification
September 23, 2021 WBUR56 PRODUCT SPECIFICATION Environment Specification Operation Operation Temperature : 0~55 degree Relevant Humidity: 5 ~ 90% (non-condensing) Storage Operation Temperature : 0~55 degree Relevant Humidity: 5 ~ 90% (non-condensing) FOXCONN CONFIDENTIAL This preliminary specification is subject to change without notice. - Page 18 September 23, 2021 WBUR56 PRODUCT SPECIFICATION CHAPTER5: WIRELESS MODULE INSTALLATION PROCEDURE 1, Prepare wireless module and open connector as red part 2, Prepare a FFC(Flexible Flat Cable) to connect with wireless module connector and press 3, Another FFC site to connect with host main board and press...
-
Page 19: Chapter6: Regulatory Statement
September 23, 2021 WBUR56 PRODUCT SPECIFICATION CHAPTER6: REGULATORY STATEMENT FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 20 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: RX3-WBUR56”. The grantee's FCC ID can be used only when all FCC compliance requirements are met.
- Page 21 September 23, 2021 WBUR56 PRODUCT SPECIFICATION Part 15 Subpart B disclaimer This transmitter module is tested as a subsystem and its certification does not cover the FCC Part 15 Subpart B rule requirement applicable to the final host. The final host will still need to be reassessed for compliance to this portion of rule requirements if applicable.
- Page 22 September 23, 2021 WBUR56 PRODUCT SPECIFICATION ISED Statement: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject...
- Page 23 Ce module émetteur est autorisé uniquement pour une utilisation dans un appareil où l’antenne peut être installée et utilisée à plus de 20 cm entre l’antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 2878F-WBUR56 ". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this...
- Page 24 The antenna must be installed such that 20 cm can be maintained between the antenna and users. This radio transmitter [2878F-WBUR56] has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
