Approval Sheet Rev.
Foxconn Part No.
Sony Part No.
Prepared by
J20H084ac
User Manual
802.11ac/a/b/g/n+BT4.0/BT3.0/BT2.1/EDR
Reviewed by
1
WLAN Module
1.0
J20H084ac
Approved by

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J20H084ac and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Foxconn J20H084ac

  • Page 1 J20H084ac User Manual Technology 802.11ac/a/b/g/n+BT4.0/BT3.0/BT2.1/EDR WLAN Module Approval Sheet Rev. Foxconn Part No. J20H084ac Sony Part No. Prepared by Reviewed by Approved by...
  • Page 2: Table Of Contents

    CONTENTS REVISION HISTORY ............... 3 PRODUCT OVERVIEW ............... 4 ................ 4 PPLICATION SCOPE MODULE HARDWARE OVERVIEW ..............5 ................5 LOCK IAGRAM ................5 EATURES ..............5 NTERFACE AND ONNECTOR PCB A ..............7 SSEMBLY IMENSION REGULATORY ................8...
  • Page 3: Revision History

    1 Revision History Change Description Date Document revision Initial release 2014/05/27...
  • Page 4: Product Overview

    2 Product Overview The J20H084.00 802.11a/b/g/n/ac 2X2 and BT4.0+LE module provides wireless modem functionality utilizing direct sequence spread spectrum and OFDM/CCK technology. This module is based on MTK MT7662U solution .It fully complies with IEEE 802.11n,IEEE 802.11 a/b/g and ,IEEE 802.11 ac standards, Bluetooth v2.1+EDR, V4.0 standard, offering feature-rich wireless connectivity at high standards, and delivering reliable, cost-effective throughput from an extended distance.
  • Page 5: Module Hardware Overview

    3 Module Hardware Overview 3.1 Block Diagram The general HW architecture is shown below Figure: Module Block Diagram 3.2 Features ♦ IEEE802.11a/b/g/n/ac (2X2) based on MTK MT7662U solution. ♦ Support BT4.0+LE ♦ USB 2.0 Interface, High and Full Speeds supported. ♦...
  • Page 6 Pin Number Symbol Name Status Pin definition UART_RX Input UART_RX for BT UART_TX Output UART_TX for BT Ground RST_L Input “L”-drive reset signal input from Host. WOW_H Output Wake on WLAN signal output. “H”-drive is hoped when awake Host. WOBT_H Output Wake on Bluetooth signal output.
  • Page 7: Pcb Assembly Dimension

    3.4 PCB Assembly Dimension Dimension (W x Lx H ): 80mmx25mmx1.0mm PCB: 4 layer FR4 design...
  • Page 8: Regulatory

    4 Regulatory Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 9 End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains IC: 2878DJ20H064”.
  • Page 10 minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna.
  • Page 11 EN 301 489‐1 V1.8.1: 2008 Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements EN 301 489‐17 V2.1.1 2009 Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;...
