  • Page 1 WBU063-VZ WBU063-VZ 802.11a/b/g/n/ac WLAN 2T2R + BT v5.1 Combo Module Product Specification 3.0 Approved: Approved: Prepared by: ________________________ _________________________ _________________________ Zeke Wu Ben Ho Kevin Manager Supervisor Engineer...
  • Page 2: Revision History

    Updated page 18~22 Regulatory statement RESTRICTED AND CONFIDENTIAL INFORMATION STATEMENT All information contained in this document is the exclusive property of Foxconn Technology Inc. and its development partners. Any reproduction or disclosure of all or part of this document without the expressed written consent of Foxconn Technology Inc. is strictly prohibited.
  • Page 3: Chapter1: Module Overview

    WBU063-VZ CHAPTER1: MODULE OVERVIEW The Foxconn WBU063-VZ is a highly integrated module which features a low power 2x2 The Wi-Fi subsystem 11a/b/g/n/ac dual-band Wi-Fi subsystem and a Bluetooth subsystem. contains the 802.11a/b/g/n/ac radio, baseband, and MAC that are designed to meet both the low power and high throughput application.
  • Page 4: Pin Definition

    WBU063-VZ 1-3 Pin Definition 12……10 Figure 1 Pin Definitions (Module Top View) Table 1 Pin Definitions Pin number Symbol name Type Pin description VBUS Power DC 5V VBUS Power DC 5V WoBLE BT_wake on Ground Ground USB data - USB data +...
  • Page 5: Chapter2: Electrical And Rf Specificaiton

    WBU063-VZ CHAPTER2: ELECTRICAL AND RF SPECIFICAITON 2-1 Recommended Operation Rating Table 2 Operation Rating Condition Typ. Max. Unit RF Interface 2-2 Power Consumption Table 3 Power Consumption Description Typical Unit IDLE 2G/2T- N mode HT 40MHz MCS 7 2G/2T- N mode HT 20MHz MCS 7...
  • Page 6 WBU063-VZ 2-3 WiFi RF Specification – TX Table 4 IEEE 802.11 b/g/n TX Average Maximum Output Power Band@2.4GHz Data Rate(Mbps) Modulation WLAN 0[dBm] WLAN 1[dBm] WLAN 0+1[dBm] DBPSK DQPSK 802.11b 13.5 13.5 16.5 OFDM OFDM OFDM OFDM 802.11g OFDM OFDM...
  • Page 7 WBU063-VZ Table 5 IEEE 802.11 a/n/ac TX Average Maximum Output Power Band@5GHz Data Rate(Mbps) Modulation WLAN 0[dBm] WLAN 1[dBm] WLAN 0+1[dBm] OFDM OFDM OFDM OFDM 802.11a OFDM OFDM OFDM OFDM MCS0 BPSK MCS1 BPSK MCS2 QPSK MCS3 QPSK 802.11n-HT20 11.5 11.5...
  • Page 8 WBU063-VZ 2-4 WiFi RF Specification – RX Table 6 IEEE 802.11 b/g/n RX Sensitivity (WLAN0&WLAN1) Rx Sensitivity Rx Sensitivity Data Rate Data Rate (dBm) (dBm) Modulation Modulation (Mbps) (Mbps) Typ. Typ. DBPSK HT20-MCS0 BPSK -94.5 DQPSK -95.5 HT20-MCS1 QPSK -91.5 -93.5...
  • Page 9 WBU063-VZ Table 7 IEEE 802.11 a/n/ac RX Sensitivity (WLAN0&WLAN1) Rx Sensitivity Data Rate Data Rate Sensitivity Modulation (dBm) Modulation (Mbps) (Mbps) (dBm) Typ. Typ. OFDM HT40-MCS0 BPSK OFDM HT40-MCS1 QPSK -86.5 OFDM HT40-MCS2 QPSK -84.5 OFDM HT40-MCS3 16-QAM -81.5 OFDM...
  • Page 10 WBU063-VZ Bluetooth RF Specification Parameter Condition Min. Typ. Max. Unit Basic Data Rate – Transmit Performance RF Transmit Power (TRM01) Power Density (TRM02) Per 100kHz ≤20 Power Control (TRM03) 2≤ step size ≤ 8 TX Output Spectrum – F(low)- CH0 >...
  • Page 11 WBU063-VZ In-band Spurious Emission (TRM13) ∣f-f ∣= 1MHz ≤ -26 ∣f-f ∣= 2MHz ≤ -20 ∣f-f ∣≥ 3MHz ≤ -40 TX Output Spectrum – 30MHz – 1GHz ≤ -36 Out of Band Spurious Emission 1GHz -12.75GHz ≤ -30 5.15GHz -5.35GHz ≤...
  • Page 12 WBU063-VZ Enhanced Data Rate – Receiver Performance Sensitivity at 0.1% BER (RCV07) π/4 DQPSK ≤ -94 8DPSK ≤ -88 EDR BER Floor Performance at ≤ 0.0007% BER (RCV08) C/I Co-Channel interference (RCV09) π/4 DQPSK ≤ +13 8DPSK ≤ +21 C/I Adjacent Channel C/I ∣f-f π/4 DQPSK...
  • Page 13 WBU063-VZ Bluetooth Low Energy RF Specification Parameter Condition Min. Typ. Max. Unit Transmit Performance RF Transmit Power (TRM-LE01,02) In-Band Emission (TRM-LE03,04) ∣= 2MHz ≤ -20 ∣f-f ∣≥ 3MHz ≤ -30 ∣f-f TX Output Spectrum – 30MHz – 1GHz ≤ -36 Out of Band Spurious Emission 1GHz -12.75GHz...
  • Page 14: Environment Specifications

    WBU063-VZ 2-7 Environment Specifications Operating Conditions (preliminary) Operation Temperature : 0 ~ 60℃ Storage Conditions (preliminary) Non-Operation Temperature : -10 ~ 60℃ (Typ. 25℃)
  • Page 15: Chapter3: Mechanical Specification

    WBU063-VZ CHAPTER3: MECHANICAL SPECIFICATION 3-1 Module Assembly Dimension Figure 2 Mechanical Drawing 3-2 Label Specification Figure 3 Label Drawing...
  • Page 16: Module Photo

    WBU063-VZ 3-3 Module Photo Figure 4 Module Photo(top) Figure 5 Module Photo(bottom)
  • Page 17: Chapter4: Wireless Module Installation Procedure

    WBU063-VZ CHAPTER4: WIRELESS MODULE INSTALLATION PROCEDURE 1, Prepare wireless module and open connector as red part 2, Prepare a FFC(Flexible Flat Cable) to connect with wireless module connector and press 3, Another FFC site to connect with host main board and press...
  • Page 18: Chapter5: Regulatory Statement

    WBU063-VZ CHAPTER5: REGULATORY STATEMENT FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 WBU063-VZ IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for reevaluating the end product (including the transmitter) and obtaining a separate FCC authorization.
  • Page 20 WBU063-VZ Part 15 Subpart B disclaimer This transmitter module is tested as a subsystem and its certification does not cover the FCC Part 15 Subpart B rule requirement applicable to the final host. The final host will still need to be reassessed for compliance to this portion of rule requirements if applicable.
  • Page 21 WBU063-VZ ISED Statement: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:...
  • Page 22 WBU063-VZ IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate Canada authorization.
  • Page 23 WBU063-VZ Antennas The following antennas have been certified for use with this module; antennas of the same type with equal or lower gain may also be used with this module. The antenna must be installed such that 20 cm can be maintained between the antenna and users.
