Summary of Contents for Napoleon PT600RB

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Napoleon PT600RB Owner's Manual Shop genuine replacement parts for Napoleon PT600RB Find Your Napoleon Grill Parts - Select From 278 Models -------- Manual continues below part list --------...
  • Page 2 Available Replacement Parts for Napoleon PT600RB N240-0016 ELECTRODE FOR MAIN BURNER N350-0054 COLLECTOR BOX FOR ELECTRODE N510-0002 Black Silicone Lid Bumper- Standard Unit S91003 TEMPERATURE GAUGE - STANDARD UNIT N570-0015 Lid Pivot Screw- Standard Unit. S81006 SCREEN, MAIN BURNER - STANDARD UNIT...
  • Page 3 N725-0010 MAIN BURNER VALVE, NG S85001 1-Outlet Regulator/Hose Assy. - Propane N350-0033 Rear Burner Housing - Right N010-0498 INFRARED BURNER...
  • Page 4 Notice to Installer: Leave these instructions with the grill owner for future reference. Manufactured by: Napoleon Appliance Corp., 214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278 Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com...
  • Page 5: Conditions And Limitations

    NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.
  • Page 6: Safe Operating Practices

    WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the re- quired leak tests before operating the grill.
  • Page 7: General Information

    General Information This Gas Barbecue Is Certified Under Canadian And American National Standards, CAN/CGA-1.6-M95 AND ANSI Z21.58 -1995 respectively for Outdoor Gas Grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN1-B149.2 Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States.
  • Page 8: Leak Testing Instructions

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommend- ed by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
  • Page 9: Lighting Instructions

    Lighting Instructions Lighting Hole Igniter Center Tube Main Infrared Left Tube Rear Burner Right Tube Burner Burner Burner Burner Off Position WARNING! Open lid WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. Main Tube Burner Rear Burner Main Infrared Burner...
  • Page 10: Cooking Instructions

    Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Infrared Main Burner Use: Follow the Infrared Burner Ignition procedures and operate on high for 5 minutes with the lid closed or until the ceramic burners glow red.
  • Page 11 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports –...
  • Page 12: Cleaning Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stain- less steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.
  • Page 13: Maintenance Instructions

    Maintenance Instructions We recommend this gas grill be thoroughly inspected and serviced annually by a qualified service person. WARNING! Always wear protective gloves and safety glasses when cleaning your grill. WARNING! Turn off the gas at the source and disconnect the unit before servicing. To avoid the pos- sibility of burns, maintenance should be done only when the grill is cool.
  • Page 14 WARNING! Hose: Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.
  • Page 15: Troubleshooting

    Troubleshooting Problem Possible Causes Solution Low heat / Low flame For propane - improper lighting Ensure lighting procedure is followed carefully. when valve turned to procedure. All gas grill valves must be in the off position high. when the tank valve is turned on. Turn tank on slowly to allow pressure to equalize.
  • Page 16 Allow burner to cool and inspect very closely Cracked ceramic tile. for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Contact your authorized Napoleon dealer for Leaking gasket surrounding the ceramic...
  • Page 17: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 18 2 X N570-0026 (#14 x 1/2”) 3/8”(10mm) If necessary the center panel can be tapped down with a rubber mallet. Si nécessaire, le panneau central peut être enfoncé avec un maillet en caoutchouc. 4 X N570-0026 (#14 X1/2”) 3/8”(10mm) www.napoleongrills.com...
  • Page 19 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) If necessary the cross beam can be tapped down with a rubber mallet. Si nécessaire, le barre de traverse peut être enfoncé avec un maillet en caoutchouc. 4 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement...
  • Page 20 4 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Two people are required for this step. Deux personnnes son nécessaires pour cette étappe. www.napoleongrills.com...
  • Page 21 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) Propane Only Propane Seulement disposable grease tray jetable du récipient à graisse www.napoleongrills.com...
  • Page 22 2 x N570-0026 (#14 x 1/2”) 3/8”(10mm) 4 x N570-0029 (1/4-20 X 3/8”) 4 x N735-0002 (1/4”) www.napoleongrills.com...
  • Page 23 10 x N570-0076 (#8 X1/2”) 3/8”(10mm) 4 x N570-0026 (#14 X1/2”) Twist tab to lock in place. Tournez la patte pour verrouiller. www.napoleongrills.com...
  • Page 24 N305-0027 Ensure holes in sear plates are postitoned to the front of the grill. Assurez-vous que les trous dans les plaques de brûleur soient placés à l’avant du gril. N520-0019 N305-0026 www.napoleongrills.com...
  • Page 25 Rotisserie Kit Assembly Instruction (included with most rear burner units) Assemble rotisserie kit components as shown. Instructions D’assemblage De L’ensemble De Rôtissoire (inclus avec la plupart des appareils avec brûleur arrière) Assemblez les composantes de la rôtissoire tel qu’illustré. Ensure stop bushing is tightened on the inside of hood casting.
  • Page 26 Propane Only – Proper Hose Connection Propane Seulement - Branchement Adéquat Du Boyau WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. AVERTISSEMENT! Assurez-vous que le boyau ne touche à aucune surface à haute température sinon il risque de fondre, de provoquer une fuite et causer un feu.
  • Page 27 Natural Gas Only – Proper Hose Connection Gaz Naturel Seulement - Branchement Adéquat Du Boyau WARNING! The installation must be performed by a licensed gas fitter, and all connections must be leak tested before operating the grill. AVERTISSEMENT! L’installation doit être effectuée par un installateur certifié pour le gaz et tous les raccordements doivent être testés pour des fuites avant de faire fonctionner le gril.
  • Page 28 WARNING – FIRE HAZARD ATTENTION - RISQUE D’INCENDIE WARNING! Do not route hose underneath drip pan. AVERTISSEMENT! Ne pas passer le tuyau d’alimentation sous le tiroir d’égouttement afin de garder. WARNING! Hose must be routed through right side panel only. Do not route hose through left side panel and underneath drip pan.
  • Page 29 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.
  • Page 30 Description PT600RBI n135-0020g left side lid casting / moulage gauche du couvercle n385-0129 NAPOLEON logo / logo NAPOLEON w450-0005 logo spring clips / écrous à ressort pour logo n510-0002 black silicone lid bumper / pare-chocs du couvercle (silicone noir) n685-0004 temperature gauge / jauge de température...
  • Page 31 Parts List / Liste Des Pièces Item Part # Description PT600RBI n720-0045 rear burner supply tube / tuyau d’alimenation brûleur arriére n010-0188 rear burner orifice assembly / ensemble des orifices brûleur arriére n010-0189 rear burner orifice assembly / ensemble des orifices brûleur arriére n725-0009 main burner valve / soupape brûleur principal n725-0010...
  • Page 32 www.napoleongrills.com...
