This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the grill owner for future reference.
Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com
3197188
Napoleon Appliance Corp.,
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278
Serial No.
XXXXXX000000
MODEL NO.
PTSS165
WARNING
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flammable
liquids or vapors in the vicinity of this or any
other appliance. An L.P. cylinder not connected
for use must not be stored in the vicinity of
this or any other appliance. If the information
in these instructions is not followed exactly, a
fire or explosion may result, causing property
damage, personal injury or death.
APPLY SERIAL NUMBER LABEL FROM CARTON
N415-0225 APR 12/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTSS165 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Napoleon PTSS165

  • Page 1 Notice to Installer: Leave these instructions with the grill owner for future reference. Napoleon Appliance Corp., 214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: (705)726-4278 Fax: (705)725-2564 email: wecare@napoleonproducts.com web site: www.napoleongrills.com...
  • Page 2: Conditions And Limitations

    NAPOLEON will not be responsible for the installation, labor or any other costs or expenses related to the re-installation of a warranted part, and such expenses are not covered by this warranty.
  • Page 3: Safe Operating Practices

    WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the required leak tests before operating the grill.
  • Page 4: Handle With Care

    Optional R.V. Kit Instructions: An optional kit is available from your Napoleon Dealer that allows the grill to be connected to a R.V. If installed on a recreational vehicle the grill shall be connected to the vehicles...
  • Page 5: Leak Testing Instructions

    Table Top Use The PTSS165 has been designed with mobility in mind. With collapsible legs, the PTSS165 can be set up on most table tops. The legs fold out and lock into place, folding back into a locked position when on the go. To use on a table top, unfold the (4) legs located in each corner of your grill.
  • Page 6: Lighting Instructions

    Lighting Instructions Igniter Burner Control Lighting Hole WARNING! Open lid Main Burner Lighting 1. Open grill lid. 2. Turn regulator control to the high position. 3. Press and hold the igniter until burner lights or light by match. 4. If ignition is not immediate, turn regulator control to off. Wait 5 minutes.
  • Page 7: Cooking Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.
  • Page 8: Maintenance Instructions

    Maintenance Instructions We recommend this gas grill be thoroughly inspected and serviced annually by a qualified service person. WARNING! Always wear protective gloves and safety glasses when cleaning your grill. WARNING! Turn off the gas at the source and disconnect the unit before servicing. To avoid the possibility of burns, maintenance should be done only when the grill is cool.
  • Page 9 WARNING! Hose (optional): Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer. www.napoleongrills.com...
  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Causes Solution Low heat / Low flame when Blockage of gas. Check for spider webs in the burner or valve turned to high. orifice. Improper preheating. Preheat grill with main burners on high for 5 to 10 minutes. Cylinder freezing up.
  • Page 11 Problem Possible Causes Solution “Paint” appears to be peeling Grease build-up on inside This is not a defect. The lid and hood are inside lid or hood. surfaces. stainless steel, and will not peel. The peeling is caused by hardened grease, which dries into paint-like shards that flake off.
  • Page 12: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 13 To install the regulator, screw it into the threaded hole on the right side of the grill. The burner may have to be pushed upwards slightly from underneath to ensure that the orifice is aligned with the opening in the burner. Pour installer le régulateur, vissez-le dans le trou fileté...
  • Page 14 Place the cooking grid into the grill. Insert the rod protruding from the back of the grid into the two holes located in the base of the grill as illustrated. Placez la grille de cuisson dans le gril. Insérez la tige située à l’arrière de la grille dans les deux trous situés à la base du gril comme illustré.
  • Page 15 Parts List / Liste Des Pièces Item Part # Description n010-0666 stainless steel lid assembly / couvercle en acier inoxydable n570-0095 lid pivot screw / vis du pivot n450-0025 locking nut 1/4-20 / écrou de blocage 1/4-20 n305-0075 cooking grid / grille de cuisson n570-0017 1/4-20 x 1/2”screw / vis 1/4-20 x 1/2”...
  • Page 16 PARTS DIAGRAM / DIAGRAMME DE PIÈCES PARTS DIAGRAM ACCESSORY R.V. KIT / DIAGRAMME DE PIÈCES ACCESSOIRE R.V.KIT www.napoleongrills.com...
  • Page 17 FAX TO: 705 727 4282 ACCESSORIES & PARTS ORDER FORM PLEASE PRINT CLEARLY CONTACT NAME:______________________________________________________________________ SHIP TO :_____________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ TEL :_________________________________ FAX :______________________________ EMAIL: __________________________________________________________________ VISA OR MASTERCARD # :_______________________________________ EXPIRY DATE: _____________ SIGNATURE:_____________________________________________________________________________ QUANTITY PART NUMBER DESCRIPTION TAXES MAY APPLY SHIPPING EXTRA IF CONFIRMATION IS REQUIRED PLEASE INCLUDE A FAX NUMBER OR EMAIL ADDRESS...
  • Page 19: Ordering Replacement Parts

    KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY. Ordering Replacement Parts Warranty Information MODEL: DATE OF PURCHASE: SERIAL NUMBER: (Record information here for easy reference) Before contacting the Customer Care Department, check the NAC Website for more extensive cleaning, maintenance, troubleshooting and parts replacement instructions at www.napoleongrills.com.
