Savaria CONCORD INFINITY Installation And Service Manual

Residential elevator w/ plc controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The following details and provided documents replace or augment
the published manuals and schematics. The most recent engineering
changes and enhancements are reflected in the notes below.
Technical Documentation Modifications and Additions
Infinity w/PLC Residential Elevator Installation and Service Manual (PN 000582 rev. 01-06-1)
Note: Modifications between revisions are marked M, additions between revisions are marked A.
Section
3.6 Bumpers and Buffers
10.2 Controller Installation and Wiring
Appendix C Virginia PLC Controller
Appendix E Hands-Free Telephone Installation
IMPORTANT
Fig. 35 Torsion Bar Mounting, if pit is less than 8
inches and buffer is required
Fig. 81 and Fig. 82 modified to include additional
connectors between motor overload and pump motor
Program updates for TSSA (Ontario, Canada only)
Modified to include field installation of telephone
Details
©Savaria Concord Lifts Inc.
A
M
M
M
1 of 1
