- Page 1 Eclipse RESIDENTIAL ELEVATOR (with Micro-6 Controller) MAINTENANCE AND TROUBLESHOOTING GUIDE Part No. 000858 22-m11-2021...
-
Page 2: Electrical Shock Hazard
Failure to comply could result in death or serious injury. Savaria is not responsible for any modifications of the the installation instructions agrees to indemnify, save, and hold harmless the manufacturer from any and all loss, product made by the user. -
Page 3: Table Of Contents
Step Page original Savaria design. No person or company is authorized to change the design of this product without written Wiring harnesses authorization by Savaria. -
Page 4: Wiring Harnesses
Bottom landing switch harness 326006 220 Vac 110 Vac Travelling cable harness 326010-XX 220 Vac (goes to either rail mounted or 110 Vac remote controller) Hoistway disconnects (if required) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) -
Page 5: Main Controller Board Connections
Step 2 Main controller board connections Purpose To verify the Eclipse main controller board connections. Procedure The layout of the Micro-6 geared controller box is shown below. Use the drawings on the next pages to check all connections to the main controller board. - Page 6 Figure 2 Main controller board (772390) connections Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021)
- Page 7 Figure 3 Main controller board (772401) connections Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
-
Page 8: Main Controller Board Leds And Switches
Step 3 Main controller board LEDs and switches Purpose To identify the main controller board LEDs and switches. Figure 4 Main controller board (772390) LEDs and switches Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 9 Figure 5 Main controller board (772401) LEDs and switches Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
- Page 10 Normal limit up input indicator Normal limit down input indicator Gates closed input indicator Main safety chain input indicator LPS1 Low pressure switch input indicator Drive enable indicator Levelling indicator High speed indicator Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021)
-
Page 11: Car Top Board Connections
IN SERIES WITH 1N5404 DIODE AT T16. (010) # REMOVE JUMPER FROM T19 IF REAR GATE OPERATOR IS REQUIRED N GND POWER SUPPLY NOTE: PI SERVICE INDICATOR CIRCUIT (SVC RELAY) REMOVED. Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide... -
Page 12: Car Top Board Leds
LED6 Selector DZ (door zone) input indicator LED7 SELECTOR POWER (+24V) indicator Car top for a lift with a power gate includes a power supply that plugs into T20. Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) -
Page 13: Selector Board Connections
Solderer board connections COP board connections TO T12 ON CAR TOP PCB TO T6 ON CAR TOP PCB TO T13 ON TO T11 ON CAR TOP PCB CAR TOP PCB Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide... -
Page 14: Power And Motor Connections
Make sure the building ground is connected to the controller ground bus before turning the disconnect on. Improper or no ground can result in shocking hazard and unsafe operation. Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 15 Figure 10 Controller box power and motor connections Light power H and N Main power L1 and L2 Motor T1, T2, T3 CONTROLLER CONNECTIONS CONTROLLER CONNECTIONS Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
-
Page 16: Sling Disassembly
'' lock washer -- - '' lock washer -- - '' nut '' nut -- - -- - '' x 2 '' bolt ----- - -- - Allen key ----- - Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 17 Figure 14 Lifting bracket - 13 x 1 '' carriage bolts -- - -- - '' lock washer -- - '' nut -- - Remove counterweights travelling assembly, if required. Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
-
Page 18: Sling Assembly
227564 allows you to use it at any point on the U-channels where holes are available. Figure 16 Bottom shoring bracket Bottom shoring bracket insert Assembly no. 227564 Insertion points Insertion points Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) -
Page 19: Guide Shoe Replacement
FALLING DANGER Figure 19 Three guide shoes can support the elevator. Two guide Guide shoe above view shoes cannot. Replace only one guide shoe at a time. Guide shoe Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide... -
Page 20: Slack Chain Test For Maintenance
Repeat the steps for the guide shoe on the opposite rail. Bell crank Repeat the steps for the bottom guide shoes. Work from the bottom with the lower two guide shoes. Brake Brake Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 21 File and clean the marks from the rails. Oil the brakes, if necessary. There are two holes on either side of the sling that allow access to oil the brake wheel. Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
-
Page 22: Motor Wiring
Remove the retaining clip and remove the fan from the shaft. Figure 29 Refer to the Installation Guide for information on wiring Remove motor brake fan the motor to the power source. Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 23 12 Secure the cap head bolts with Loctite 270 (type thermoplastic liquid). NOTE Check and re-adjust the air gap if necessary after 3 months or at the first maintenance visit. Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide...
-
Page 24: Rail Lubrication
To upgrade the variable frequency drive (VFD). Considerations Procedure From time to time, Savaria may provide a copy tool to upgrade the software on the variable frequency drive (VFD) Periodically, check the cab for a smooth ride. in the controller box. -
Page 25: Chain Maintenance
DO NOT use heavy oil, low-grade oil, impure oil or grease, or used oil. These types will reduce chain life or cause chain damage or breakage. Part No. 000858 (22-m11-2021) Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide... -
Page 26: Appendix A Diagnostic Beep Codes
• 1 long and 2 short beeps - possible problems are re- level shutdown or low pressure switch activated. • 1 long and 3 short beeps - possible problems are selector fault, selector encoding or position error. Eclipse (Micro-6 Controller) Maintenance and Troubleshooting Guide Part No. 000858 (22-m11-2021) - Page 27 THIS PAGE WAS LEFT INTENTIONALLY BLANK...
- Page 28 Eclipse Residential Eleva- (with Micro-6 Controller) MAINTENANCE AND TROUBLESHOOTING GUIDE Part No. 000858 © Copyright 2021 www.savaria.com Support 2 Walker Drive Brampton, Ontario, L6T 5E1, Canada Toll free (800) 791-7999 Fax: (905) 791-2222...
