- Page 1 Version Record： Date Version Remark Author 2023/05/17 V1.0 First version Yago Shen...
-
Page 2: Table Of Contents
Content 1 . G e ne r a l i ns t r u c t i o n ......................2 1.1 Tools .............................................. -
Page 3: General Instruction
This document was applied for the following model of Kinergier Pro Kinergier Pro M/ Kinergier Pro S 1. General instruction 1.1 Tools Cross screw driver, sharp-nose pliers, socket spanner, multi-meters, instructions. 1.2 General Safety 1 Only authorized and professional electrician can carry out the maintenance. -
Page 4: Inverter Cleaning
4. Check if the system grounding works well regularly. 5. Check regularly if the system current and voltage are right and stable. 6. Check if the temperature and humidity of the installation site meet the demand of system working. 1.5 Inverter Cleaning Notes: ①... -
Page 5: Structure
1.6 Structure Upper Cover Inverter Chassis Inverter Power Board Middle Steel Panel Inverter Fan Inverter Main Board... -
Page 6: Removal And Installation Of Upper Cover
Parts Notes Bear the components of transformer Inverter Chassis and inverter Upper Cover The cover for installation Inverter Power Board Circuit board integrating inverter and rectification Middle Steel Panel Isolate Power Board and Main Board to avoid circuit interference Inverter Main Board Main Board that controls the operation of the circuit Inverter Fan... -
Page 7: Main Board Replacement
3. Main Board Replacement 3.1 Remove Main Board Step1 As shown in Figure2, unscrew all screws fixing Main Board. Figure 2 Step2 As shown in Figure 3, disconnect ①transformer sampling line, ② two sampling lines of the Main Board and Power Board, and ③ fan sensing line. -
Page 8: Step3
Step3 As shown in Figure 4, disconnect L (marked CN5) and N (marked CN4) in the HV side of the transformer. Figure 4 Step4 As shown in Figure 5, remove the Main Board. Figure 5... -
Page 9: Main Board Installation
3.2 Main Board Installation Step1 As shown in Figure 6, restore Main Board to the right position and screw all fixing screws. Figure 6 Step2 As shown in Figure 7, connect ①transformer sampling line, ② two sampling lines of the Main Board and Power Board, and ③ fan sensing line. -
Page 10: Step3
Step3 As shown in Figure 8, connect L (marked CN5) and N (marked CN4) in the HV side of the transformer. Figure 8 Step4 As shown in Figure 9, finish the installation of the Main Board. Figure 9... -
Page 11: Po W E R B O A R D Re P L A Ce M E N
4. Power Board Replacement Notes: Main Board should be removed (as shown in Part3) before replacing Power Board. 4.1 Remove Power Board Step1 As shown in Figure 10, remove the yellow panel. Figure 10 Step2 As shown in Figure 11, unscrew two screws and remove the yellow panel. Figure 11... -
Page 12: Step3
Step3 As shown in Figure 12, unscrew the screws fixing middle steel panel (2 on the left and 2 on the right, 4 in total) and remove the steel panel. Figure 12 Step4 As shown in Figure 13, unscrew the screws fixing the power lines of the LV side of transformer. -
Page 13: Step5
Figure 13 Step5 As shown in Figure 14, unscrew all screws fixing Power Board. Figure 14 Step6 As shown in Figure 15, finish the removal of the Power Board. Figure 15... -
Page 14: Power Board Installation
4.2 Power Board Installation Step1 As shown in Figure 16, restore Power Board to the right position and screw all fixing screws. Figure 16 Step2 As shown in Figure 17, screw the screws fixing the power lines of the LV side of transformer(P1,P2,P3,P4). Figure 17... -
Page 15: Step3
Step3 As shown in Figure 18, after finishing the installation of the steel panel, connect the 2 communication lines between Power Board and Main Board to the mainboard. Figure 18 Step4 As shown in Figure 19, place the steel panel in the right position and screw the 4 screws. Figure 19... -
Page 16: Step5
Step5 As shown in Figure 20, install the yellow panel and screw the screws. Figure 20 Step6 As shown in Figure 21, install the yellow panel according to the screw holes and finish the installation of Power Board. Figure... -
Page 17: F A N R E Pl A C E M En
5. Fan Replacement Notes: As the fan is installed on the steel panel (as shown in Part4-Step3), Main Board should be removed before replacing fan. 5.1 Remove the Fan Step1 As shown in Figure 22, disconnect the sensing line of fan and remove Main Board (Part3-3.1). Step1 Figure 22 Step2... -
Page 18: Step3
Step3 As shown in Figure 24, unscrew the screws and finish the removal of the fan. Figure 24 5.2 Fan Installation Step1 As shown in Figure 25, install the fan on the steel panel and screw the screws. Figure 25... -
Page 19: Step2
Step2 As shown in Figure 26, install the steel panel with fan by screwing all screws. Figure 26 Step3 As shown in Figure 27, install Main Board first and connect fan sensing lines to it. Finish the installation of the fan. Figure 27... -
Page 20: L C D P A N E L R E Pl A C E M E N
6. LCD Panel Replacement 6.1 Remove LCD Panel Step1 As shown in Figure 28, remove Upper Cover of the inverter and unscrew all screws fixing LCD Panel. Figure 28 Step2 As shown in Figure 29, finish the removal by removing LCD Panel. Figure 29... -
Page 21: Lcd Panel Installation
6.2 LCD Panel Installation Step1 As shown in Figure 30, place LCD Panel in the right position and finish the installation by screwing all screws. Figure 30...
