Summary of Contents for TBB power RiiO Sun Series

  • Page 2 RiiO Sun User Manual...
  • Page 3 RiiO Sun User Manual WARNING: HIGH VOLTAGE INSIDE CAUTION: THE DC FUSE MUST HAVE BEENTURNED OFF BEFORE SERVICING MADE IN CHINA...
  • Page 4 RiiO Sun User Manual Disclaimer Unless specially agreed in writing, TBB Power Co.,Ltd Take no warranty as to the accuracy, sufficiency and suitability of any technical or other  information provided in this manual or other documentation. Assumes no responsibility or liability for loss or damage, whether direct, indirect, ...

  • Page 5: Table Of Contents

    RiiO Sun User Manual Contents General Safety Instruction......................1 Safety Instruction.....................1 General precaution....................1 Precaution regarding battery operation............... 1 Instruction............................2 Brief Instruction......................2 1.1.1 General Description..................2 1.1.2 Naming Rules....................2 Structure........................3 1.2.1 Front........................3 1.2.2 Control panel....................4 1.2.3 Connection compartment................4 1.2.4 Dimension......................

  • Page 6: General Safety Instruction

    RiiO Sun User Manual 1. General Safety Instruction Safety Instruction As the dangerous voltage and the high temperature exist within the RiiO Sun All in One Solar Inverter, only the qualified and authorized maintenance personnel is permitted to open and repair it.

  • Page 7: Instruction

    RiiO Sun User Manual 2. Instruction Brief Instruction 2.1.1 General Description RiiO Sun is a new generation of all in one solar inverter designed for various type of off grid system including DC Couple system and generator hybrid system. It can provide UPS class switching speed.

  • Page 8: Structure

    RiiO Sun User Manual Structure 2.2.1 Front RiiO Sun 2KVA-M, RiiO Sun 2KVA-S, RiiO Sun 3KVA-M, RiiO Sun 3KVA-S, RiiO Sun 4KVA-S RiiO Sun 3KVA-M-LV, RiiO Sun 3KVA-S-LV RiiO Sun 5KVA-S, RiiO Sun 6KVA-S Figure 2-1 Front View of the All in One Solar Inverter Structure...

  • Page 9: Control Panel

    RiiO Sun User Manual 2.2.2 Control panel Figure 2-2 All in One Solar Inverter Control Buttons 2.2.3 Connection compartment RiiO Sun 2KVA-M, RiiO Sun 2KVA-S, RiiO Sun 3KVA-M, RiiO Sun 3KVA-S, RiiO Sun 4KVA-S RiiO Sun 3KVA-M-LV, RiiO Sun 3KVA-S-LV RiiO Sun 5KVA-S, RiiO Sun 6KVA-S Figure 2-3 Signal Terminals...
  • Page 10 RiiO Sun User Manual Table 2-1 Signal Terminals Introduction Silk-screen Definition BAT Sample Battery temperature and voltage sample. ① Remote Dry contact input control, remote ON/OFF control. ② RS485 port for external monitor such as MCK, SNMP, Kinergy, ComMON ③ etc.

  • Page 11: Dimension

    RiiO Sun User Manual 2.2.4 Dimension RiiO Sun 2KVA-M, RiiO Sun 2KVA-S, RiiO Sun 3KVA-M, RiiO Sun 3KVA-S, RiiO Sun 4KVA-S RiiO Sun 3KVA-M-LV, RiiO Sun 3KVA-S-LV RiiO Sun 5KVA-S, RiiO Sun 6KVA-S Figure 2-5 Dimension of the All in One Solar Inverter...

  • Page 12: Function

    RiiO Sun User Manual Function 2.3.1 Power Control and Power Assist RiiO Sun offers a unique feature of power control & power assist, which is very useful when you have a limited grid supply or working with the generator. RiiO Sun will take control of energy flow automatically, using extra power to charge the battery or inverting as the supplement to the grid or generator.
  • Page 13 RiiO Sun User Manual Float charging and recycle charging program guarantee your battery getting proper maintenance in case of long time connected and less aging in case of long time connected with no use. Multi Chemical Batteries Available RiiO Sun offers premium charging algorithm for the common chemical acid batteries including AGM, GEL, Flooded, lead-carbon and Lithium battery.

  • Page 14: Transfer

    RiiO Sun User Manual Important: Equalization may damage your batteries if it is not performed properly. Always check battery  fluid before and after equalization. Fill the batteries only with the distilled water. Always check the equalization switch is set back to OFF after each time’s equalization. ...

  • Page 15: Communication

    RiiO Sun User Manual 2.3.6 Communication Dry Contact Input RiiO Sun is equipped with a dry contact input for remote on/off control. Note: When the setting item 64 Main switch selection is set as Mobile Only mode, the touch switch needs to be changed to a rocker switch. RS485 Equipped with two RS485 interfaces.

  • Page 16: Installation And Wiring

    RiiO Sun User Manual 3. Installation and Wiring Please refer to "Installation & operation guide for RiiO Sun 2KVA-4KVA " and "Installation & operation guide for RiiO Sun 5KVA-6KVA". Keep away from the fire, avoid direct sunlight and rain; do not store flammable, explosive or corrosive gases or liquids in the working environment.

  • Page 17: Configuration

    RiiO Sun User Manual 4. Configuration Check before Operation Please check before Operation according to the following.  The inverter is installed correctly and steady.  Reasonable cable layout to meet customer requirements.  Make sure the grounding is reliable. ...

  • Page 18: Operation

    RiiO Sun User Manual 5. Operation Operation and Display Panel The operation and display includes four buttons and a LCD display, indicating the operating status and input/output power information. Button Function To exit the setting mode or confirm the fault code. ...

  • Page 19: Lcd Display Icons

    RiiO Sun User Manual LED Indicator Function Solid on Inverting mode Invert Green Flashing Power Assist mode Solid on The battery is Charging. Charge Green Flashing The battery is fully Charged. Solid on Fault occurs Fault Flashing Warning occurs LCD Display Icons Icon Function description Input Source Information...
  • Page 20 RiiO Sun User Manual Indicates input voltage, input frequency, PV voltage, charge current, charge power, battery voltage. Configuration Program and Fault Information Indicates the setting programs Warning: flashing every 2 seconds. Press <ESC> button to view the warning code. Fault: flashing every 1 second. Press <ESC> button to view the warning code.
  • Page 21 RiiO Sun User Manual Indicates the inverter working in a charging mode Indicates the inverter working in a inverting mode Indicates the inverter connecting to the mains or generators. Indicates the inverter connecting to the PV panel.

  • Page 22: Lcd Setting

    RiiO Sun User Manual LCD Setting After press and holding the <ENTER> button for 3 seconds, the inverter will enter the setting mode. Press <UP> or <DOWN> button to select setting programs. Then press the <ENTER> button to confirm the selection of the setting programs, or press the <ESC> button to exit the setting mode.
  • Page 23 RiiO Sun User Manual AC in source priority Note: ACin First: The system will work in AC input first mode (default) When there is an AC input, the load will firstly be powered by the AC input. When the solar panel is sufficient to charge the battery independently and there are still some surplus solar power, it will also supply power to the AC load together with the AC...
  • Page 24 RiiO Sun User Manual When the battery type is TBB SUPER-L, the SOC Ctrl will be displayed, and the ACin First power supply can be turned on/off according to the battery SOC. The SOC value should be set in the TBB LINK user control interface.
  • Page 25 RiiO Sun User Manual 0-Normal AC wave harmonic adaption 1-Weak AC Input Default:0 20~990s AC in connect delay Step:10s Default:20s 0-Display Low AC in alarm control 1-Shield Default:1 0~Max(Rate charge Maximum ACin charging current) current in the ACin backup mode under the low Step:1A battery voltage condition Default: Max...
  • Page 26 RiiO Sun User Manual 24V: default 27.2V 48V: default 54.4V Floating charging voltage Step:0.1V (C.F voltage) Default:13.6V/(12V/cell) (≤Bulk charging voltage ) 24V:20.0~26.0V, default 22.0V 48V:40.0~52.0V, default 44.0V Low battery alarm voltage Step:0.1V Default:11.0V/(12V/cell) (≥Low battery protect voltage) 24V:19.0~24.0V, default 21.0V 48V:38.0~48.0V, default 42.0V Step:0.1V Low battery protection voltage...
  • Page 27 RiiO Sun User Manual Low SOC alarm threshold 15~90% Note: Step:1% Only applicable to the compatible lithium battery, Default:15% such as Super-L, Pylontech lithium battery and other lithium batteries compatible with CAN communication (≥Low SOC protect threshold) protocol. Low SOC protect threshold 3~50% Note: Step:1%...
  • Page 28 RiiO Sun User Manual ACin stop charging SOC in the ACin backup mode 30~99% Select ACin First mode in the setting item 12 Step:1% AC in source priority, then when the lithium Default:80% battery reaches the set SOC threshold, the AC ( ≥...
  • Page 29 RiiO Sun User Manual For48V： 0-N/A 1-BGK-12 For24V： BGK_Module 0-N/A Select the type of the BGK module 1-BGK-Balancer Step:1 Default:0 (Not lithium-ion batteries for 24V and 48V system) 1 (Press <ENTER> to trigger BGK_RESTART the effect once) One-key reset of the BGK module Default:0 Remote control enable 0-Disable...
  • Page 30 RiiO Sun User Manual 0~ The last day of this month Default: N/A 0~23 Hour Default: N/A 0~59 Minute Default: N/A...

  • Page 31: Faq

    RiiO Sun User Manual 6. FAQ Fault code When inverter fault occurs, press the ESC button to view the fault code. The digital tube in the middle of LCD displays the fault code, and the digital tube on the left side of LCD displays the "Err".

  • Page 32: Mppt Fault

    RiiO Sun User Manual 6.1.2 MPPT Fault Fault Code Description Solution The DC bus is over voltage Check the PV input voltage. The battery is under voltage Check the battery voltage. Hardware protection against DC bus over Check the battery voltage and the voltage charger output voltage Check if there is a short circuit at...

  • Page 33: Mppt Warning

    RiiO Sun User Manual internal NTC connection. Contact the Transformer NTC fail installer if the fault still exists. Check battery sensor connection; The battery temperature is too high Check battery temperature; Check battery connection 1.Check whether the fan is blocked. 2.Open the case, check the fan Abnormal Fan connection.

  • Page 34: Bms Warning

    RiiO Sun User Manual 6.2.3 BMS Warning Warning Code Description The lithium module is over voltage protection. The lithium module is under voltage protection. The lithium module's temperature is too high. The lithium module's temperature is too low. The lithium module's discharging current is over normal value. The lithium module's charging current is over normal value.

  • Page 35: Bgk Warning

    RiiO Sun User Manual 6.2.4 BGK Warning Warning Code Description Battery over voltage alarm. Battery under voltage alarm. The single battery voltage is lower than the average voltage. The single battery voltage is higher than the average voltage. The battery temperature is too high. NTC fail The Battery Cell voltage does not match.

  • Page 36: Specification

    RiiO Sun User Manual 7. Specification Series RiiO Sun Model 2KVA-M 3KVA-M 2KVA-S 3KVA-S 4KVA-S 5KVA-S 6KVA-S Product Topology Transformer based Power Assist AC inputs Input voltage range:175~265 VAC, Input frequency:45~65Hz AC input Current (transfer switch) Inverter Nominal battery voltage 24VDC 48VDC Input voltage range...
  • Page 37 RiiO Sun User Manual Series RiiO Sun Model 3KVA-M-LV 3KVA-S-LV Product Topology Transformer based Power Assist AC inputs Input voltage range:85~140 VAC, Input frequency:45~65Hz AC input Current (transfer switch) Inverter Nominal battery voltage 24VDC 48VDC Input voltage range 21~34VDC 42~68VDC Output Voltage: 110/115/120 VAC ±...
  • Page 38 RiiO Sun User Manual...
  • Page 39 RiiO Sun User Manual...
  • Page 40 RiiO Sun User Manual...
