- Page 1 SIP Contemporary Series S2100-X SIP Contemporary 1-line Corded Lobby Hotel Telephone User‘s Guide...
-
Page 2: Important Safety Instructions
Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. This product should be installed by a premises, consult your dealer or local qualified technician. - Page 3 instructions. Improper adjustment of plugged into a ceiling, under-the-table other controls may result in damage or cabinet outlet. and often requires extensive work by 19. Use only the power cord indicated in this an authorised technician to restore the manual. product to normal operation.
-
Page 4: Table Of Contents
Parts check list ....................5 Telephone layout ....................6 Installation......................7 Telephone settings....................10 Telephone operation................... 11 Appendix......................12 Troubleshooting..........................12 VTech Hospitality Limited Warranty Program ................14 Important note........................... 16 Maintenance........................... Environmental notes......................... Disclaimer and Limitation of Liability..................... European Directives.......................... Declaration of Conformity....................... -
Page 5: Parts Check List
Parts check list Items contained in the corded telephone package: Parts included Model Model name number Telephone base Ethernet with faceplate Corded handset Mounting bracket cable and overlay SIP 1-line Corded Lobby S2100-X Hotel Telephone EN - 5... -
Page 6: Telephone Layout
Telephone layout RJ-45 LAN port DATA port Switch hook Wall mount clip RINGER VOL VOLUME + VOLUME -... -
Page 7: Installation
Installation SIP Contemporary 1-line Corded Lobby Hotel Telephone - S2100-X Telephone base installation Installation option - desktop position 1. Turn the telephone base over with the bottom side facing up. Connect the coiled handset cord to the telephone base. Coiled handset cord jack 2. - Page 8 4. Once installed, the system administrator will begin an initialization and system registration process. CAUTION: • Use only the supplied Cat-5 network cable. Cat-5 network cable is not designed for use in any other IT devices. Misuse of Cat-5 network cable on your other IT devices shall be prohibited. •...
- Page 9 SIP Contemporary 1-line Corded Lobby Hotel Telephone - S2100-X Telephone base installation Installation option - wall mount position To mount the telephone base on the wall 1. Unplug the Cat-5 network cable from the network wall jack. 2. Remove the corded handset from the telephone base if it is cradled in the telephone base. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).
-
Page 10: Telephone Settings
Telephone settings SIP Contemporary 1-line Corded Lobby Hotel Telephone - S2100-X All telephone settings are programmed through the administrative web portal. Please refer to the SIP Phone Configuration Guide for details. EN - 10... -
Page 11: Telephone Operation
Telephone operation SIP Contemporary 1-line Corded Lobby Hotel Telephone - S2100-X Receive a call The telephone rings when there is an incoming call. Lift the corded handset from the telephone base to answer. Place a call Lift the corded handset and it automatically connects to the operator. Refer to the SIP Phone Configuration Guide for automatic dialing. -
Page 12: Appendix
Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. +44 (0)1706 694 070 or email ukca@trustdistribution.com For customer service, call For corded telephone Question Suggestions • Make sure a Cat-5 network cable is plugged into the LAN port of the telephone base and the network wall jack with Power over Ethernet (PoE). - Page 13 Question Suggestions • Make sure your network is providing Power over Ethernet (PoE). 4. The telephone cannot register to the network server. • Make sure the initialization and system registration process completes. • Make sure the Cat-5 network cable is plugged into the LAN port of the telephone base and the network wall jack with Power over Ethernet (PoE).
-
Page 14: Vtech Hospitality Limited Warranty Program
Product of the shipping the Product, or for installation or same or similar design. Repair or replacement set up, adjustment of customer controls, and of Product, at VTech’s option, is the exclusive installation or repair of systems outside the remedy. unit. -
Page 15: Other Limitations
VTech’s liability to end user hereunder shall not warranty. exceed the purchase price of the Product. In no event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the product,... -
Page 16: Important Note
Appendix Environmental notes • Do not expose to direct sunlight. Important note • Do not place your product on carpets or This equipment is not designed for making other surfaces which generate fibres, or emergency telephone call when the power place in locations where proper ventilation fails. -
Page 17: Disclaimer And Limitation Of Liability
VTech Telecommunications Limited and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product. VTech Telecommunications Limited and its suppliers assume no responsibility for any damage or loss caused by deletion of data as a result of malfunction, or repairs. -
Page 18: Disposal Of Batteries And Product
Disposal of batteries and product Product disposal instructions for business users ( ‚) These symbols on the products, packaging, and/or accompanying documents If you wish to discard electrical and electronic mean that used electrical and electronic equipment, please contact your dealer or products and batteries must not be mixed with supplier for further information. -
Page 19: Technical Specifications
Telephone base: 204 x 152 x 96 mm (8.03 x 5.98 x 3.78 inches) Corded handset: 213 x 47 x 40 mm (8.39 x 1.85 x 1.58 inches) Manufacturer VTech Telecommunications Limited Address: 23/F Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong... - Page 20 Specifications are subject to change without notice. Copyright © 2022 VTech Telecommunications Limited All rights reserved. 09/22. S2100-X_UG_V1_CEC_EU-UK_2022.09.05...
