Page 2
CARRIER (TC), FOUR-WHEEL DRIVE (4WD), B110C STAGE IV, STRAIGHT LOADER ARM (SLA), FOUR-WHEEL DRIVE (4WD), B110C TC STAGE IV, TOOL CARRIER (TC), FOUR-WHEEL DRIVE (4WD), B115C TC STAGE IV, CENTER PIVOT (CP), B115C TC STAGE IV, SIDE SHIFT (SS) 48126557 24/02/2017...
Page 3
Link Product / Engine Product Market Product Engine Europe B100C STAGE IV, STRAIGHT F5BFL413A*B009 LOADER ARM (SLA), FOUR-WHEEL DRIVE (4WD), MARBLE CUTTING B100C STAGE IV, STRAIGHT Australia New Zealand F5BFL413A*B009 LOADER ARM (SLA), FOUR-WHEEL DRIVE (4WD) B100C STAGE IV, STRAIGHT Europe F5BFL413A*B009 LOADER ARM (SLA),...
Page 4
B115C TC STAGE IV, CENTER Europe F5BFL413A*C004 PIVOT (CP) B115C TC STAGE IV, CENTER Middle East Africa F5BFL413A*C004 PIVOT (CP) B115C TC STAGE IV, SIDE SHIFT Europe F5BFL413A*C004 (SS) B115C TC STAGE IV, SIDE SHIFT Asia Pacific F5BFL413A*C004 (SS) B115C TC STAGE IV, SIDE SHIFT...
Page 12
Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your NEW HOLLAND CONSTRUCTION Sales and Service Networks. 48126557 24/02/2017...
B100C TC B100C B110C TC B110C B115C TC Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury.
INTRODUCTION Safety rules General safety rules Use caution when you operate the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces.
Page 15
INTRODUCTION Operate controls only when seated in the operator’s seat, except for those controls expressly intended for use from other locations. From the operator's platform, install the backhoe swing lock pin when the backhoe is not in use and before all other operation.
INTRODUCTION 3. Move the operator’s seat to the backhoe operating position and choose one of the following backhoe positions: ○ Move the backhoe into the stowed position and from the operator's seat install the backhoe swing lock pin. See Swing tower - Basic instructions () . ○...
INTRODUCTION Wheels and tires Make sure that tires are correctly inflated. Do not exceed any recommended load or pressure. Follow the instructions in the manual for proper tire inflation. Tires are heavy. Handling tires without proper equipment could cause death or serious injury. Never weld on a wheel with a tire installed.
INTRODUCTION At least once each day and at the end of the day, remove all trash and debris from the machine especially around hot components such as the engine, transmission, exhaust, battery, etc. More frequent cleaning of your machine may be necessary depending on the operating environment and conditions.
INTRODUCTION Seat belts Seat belts must be worn at all times. Seat belt inspection and maintenance: • Keep seat belts in good condition. • Keep sharp edges and items than can cause damage away from the belts. • Periodically check belts, buckles, retractors, tethers, slack take-up system, and mounting bolts for damage and wear.
INTRODUCTION Operator protective structure Your machine is equipped with an operator protective structure, such as: a Roll Over Protective Structure (ROPS), Falling Objects Protective Structure (FOPS), or a cab with a ROPS. A ROPS may be a can frame or a two-posted or four-posted structure used for the protection of the operator to minimize the possibility of serious injury.
INTRODUCTION Do Not Operate tag Before you start servicing the machine, attach a ‘Do Not Operate’ warning tag to the machine in an area that will be visible. RH99E029 Hazardous chemicals If you are exposed to or come in contact with hazardous chemicals you can be seriously injured. The fluids, lubricants, paints, adhesives, coolant, etc.
INTRODUCTION • Apply the parking brake, stop the engine, and remove the key. • Check if you can safely leave the cab or your actual position without contact with electrical wires. If not, stay in your position and call for help. If you can leave your position without touching lines, jump clear of the machine to make sure that you do not make contact with the ground and the machine at the same time.
INTRODUCTION Do not leave equipment in raised position while parked or during service, unless securely supported. Hydraulic cylin- ders must be mechanically locked or supported if they are left in a raised position for service or access. Loader buckets, forks, etc. or other lifting, handling, or digging equipment and its load will change the center of gravity of the machine.
Page 25
INTRODUCTION Safety rules - Specific precautions to this machine • From the operator's platform, install the backhoe swing lock pin when the backhoe is not in use and before all other operation. • When traveling on the road or working with the front loader keep the backhoe in the stowed position. •...
Page 26
INTRODUCTION Safety rules - Ductile iron DANGER Altering cast ductile iron can cause it to weaken or break. Before you weld, cut, or drill holes on any part of this machine, make sure that the part is not cast ductile iron. Failure to comply will result in death or serious injury.
Page 27
NEW HOLLAND CONSTRUCTION strongly recommends that you return all used batteries to a NEW HOLLAND CONSTRUCTION dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement.
Page 28
INTRODUCTION Basic instructions - Support strut for loader lift arm WARNING Crushing hazard! If you service the machine with the loader lift arms raised, always use the support strut. Remove the retaining pin and place the support strut onto the cylinder rod. Install the retaining pin into the support strut.
Page 29
INTRODUCTION 4. Remove the strut (3) from the attachment and install the pin (1) and the split pin (2) back into the holes in the strut. 5. Start the engine and lower the loader attachment. MOLI12LBB0263AB 48126557 24/02/2017...
Page 30
INTRODUCTION Machines with the Tool Carrier (TC) option Engage the loader arm support strut: 1. Remove the split pins (1) and the safety strut (2) from the storage position on the loader arm. Put the split pins back in place. 2.
