SERVICE MANUAL
Boomer
45 Cab - From PIN LSM0B45Cxx0010001 to LSM0B45CAH0010031
™
Boomer
45 ROPS - From PIN LSM0B45Rxx0010001 to LSM0B45RJH0010062
™
Boomer
50 Cab - From PIN LSM0B50Cxx0010001 to LSM0B50CEH0010080
™
Boomer
50 ROPS - From PIN LSM0B50Rxx0010001 to LSM0B50REH0010097
™
Boomer
55 Cab - From PIN LSM0B55Cxx0010001 to LSM0B55CCH0010090
™
Boomer
55 ROPS - From PIN LSM0B55Rxx0010001 to LSM0B55RCH0010120
™
Part number 48144020
1
edition English
st
June 2017
Boomer
Boomer
Boomer
Tier 4B (final)
Compact Tractor
45
™
50
™
55
™
Advertisement
Related Manuals for New Holland Boomer 45 Tier 4B
Summary of Contents for New Holland Boomer 45 Tier 4B
- Page 1 SERVICE MANUAL Boomer ™ Boomer ™ Boomer ™ Tier 4B (final) Compact Tractor Boomer 45 Cab - From PIN LSM0B45Cxx0010001 to LSM0B45CAH0010031 ™ Boomer 45 ROPS - From PIN LSM0B45Rxx0010001 to LSM0B45RJH0010062 ™ Boomer 50 Cab - From PIN LSM0B50Cxx0010001 to LSM0B50CEH0010080 ™...
- Page 2 SERVICE MANUAL Boomer™ 45 Tier 4B (final), Cab [LSM0B45Cxx0010001 - LSM0B45CAH0010031], Boomer™ 45 Tier 4B (final), ROPS [LSM0B45Rxx0010001 - LSM0B45RJH0010062], Boomer™ 50 Tier 4B (final), Cab [LSM0B50Cxx0010001 - LSM0B50CEH0010080], Boomer™ 50 Tier 4B (final), ROPS [LSM0B50Rxx0010001 - LSM0B50REH0010097], Boomer™ 55 Tier 4B (final), Cab [LSM0B55Cxx0010001 - LSM0B55CCH0010090], Boomer™...
- Page 3 Link Product / Engine Product Market Product Engine North America Boomer™ 45 Tier 4B (final), L3C19-T3 ROPS [LSM0B45Rxx0010001 - LSM0B45RJH0010062] North America Boomer™ 45 Tier 4B (final), L3C19-T3 Cab [LSM0B45Cxx0010001 - LSM0B45CAH0010031] Boomer™ 50 Tier 4B (final), North America L3C19-T2 ROPS [LSM0B50Rxx0010001 - LSM0B50REH0010097] Boomer™...
- Page 4 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.216] Fuel tanks .
- Page 5 [25.102] Front bevel gear set and differential ..........25.2 [25.108] Final drive hub, steering knuckles, and shafts .
- Page 6 Hitches, drawbars, and implement couplings........37 [37.100] Drawbars and towing hitches ............37.1 [37.108] Rear three-point hitch external controls .
- Page 7 [55.989] Exhaust Gas Recirculation (EGR) electrical system ....... 55.9 [55.640] Electronic modules ............. . . 55.10 [55.031] Parking brake electrical system .
- Page 8 INTRODUCTION 48144020 23/06/2017...
-
Page 9: Table Of Contents
Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Foreword . -
Page 10: Foreword - Important Notice Regarding Equipment Servicing
Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your NEW HOLLAND Sales and Service Networks. 48144020 23/06/2017... -
Page 11: Foreword
40 and 50 tractors. Use this manual in conjunction with the operator's manual for complete operation, adjustment, and maintenance information On NEW HOLLAND equipment, left and right are determined by standing behind the unit, looking in the direction of travel. -
Page 12: Safety Rules
INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions. -
Page 13: Safety Rules
INTRODUCTION Safety rules BT09A213 48144020 23/06/2017... -
Page 14: Safety Rules - Ecology And The Environment
Improper disposal of batteries can contaminate the soil, groundwater, and waterways. NEW HOLLAND strongly recommends that you return all used batteries to a NEW HOLLAND dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement. -
Page 15: Safety Rules Service Precautionary Statements Climate Control
INTRODUCTION Safety rules Service precautionary statements climate control Boomer™ 45 Tier 4B (final), Cab [LSM0B45Cxx0010001 - LSM0B45CAH0010031] Boomer™ 50 Tier 4B (final), Cab [LSM0B50Cxx0010001 - LSM0B50CEH0010080] Boomer™ 55 Tier 4B (final), Cab [LSM0B55Cxx0010001 - LSM0B55CCH0010090] SERVICE PRECAUTIONARY STATEMENTS Leak Testing Recharging an air conditioning system that leaks simply allows more refrigerant to escape into the atmosphere and ultimately leaves the system non-functioning and in need of additional charging. - Page 16 INTRODUCTION CONTAMINANTS General No mobile air conditioning system can operate for long without picking up some contaminants in the refrigerant. The flexible hoses, for example, allow moisture and air to migrate into the refrigerant from the outside atmosphere. Mois- ture and non-condensable gases (air) are the most common contaminants found in mobile air conditioning systems. NOTICE: Contaminating R134 with R12 or CFC will lead to copper plating of steel components and major compres- sor failure.
- Page 17 INTRODUCTION Recycling equipment meeting SAE standards J1990 and J2210 is designed to extract and recycle refrigerants that have been in mobile air conditioning systems only. R134 refrigerant that also is used in non-mobile systems may introduce contaminants to the refrigerant that equipment meeting SAE J1990 and J2210 cannot remove. This equip- ment is not intended for use on non-mobile systems.
- Page 18 INTRODUCTION CONTAINMENT OF AIR CONDITIONING REFRIGERANTS The following procedure is a guide to servicing mobile air conditioning systems in a way that minimizes the potential for losing refrigerant to the atmosphere. Following the procedures in this section will help ensure compliance with SAE J2211 for R134 systems.
- Page 19 INTRODUCTION 10. Determine the amount of lubricant removed from the air conditioning system during the refrigerant extraction process. Replenish the air conditioning system with an equal volume of new, correct lubricant. 11. The system is now ready for service or repair. Flushing Flushing needs to be performed when the compressor is replaced due to internal parts failure, or when a desiccant bag deteriorates and desiccant travels throughout the system.
- Page 20 INTRODUCTION Recharging/Refilling Recharge the system only with the proper virgin refrigerant or recycled refrigerant purified to meet SAE purity standard (J2099 for R134 ). Use the weight method to determine the proper amount of refrigerant. The Boomer 45/50/55 cab tractors use 1.0 kg (2.2 lb) of R134a refrigerant. 48144020 23/06/2017...
- Page 21 INTRODUCTION Using a Manifold Gauge Set When using a manifold gauge set to diagnose, recharge, or service the tractor air conditioning system: 1. Be sure that all equipment hose lines are fitted with shutoff valves or check valves within 30 cm (12 in) of their ends and that the valves are closed.
- Page 22 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
