•CONTENTS AND RATINGS

Ratings and specifications are subject to change without prior notice.
Model
Transmitter
Receiver
Servos
Switch
Nicd battery
Accessories
Transmitter FP-T8SGAP
Operating system : Two-stick, 8 channels for
F3A pattern
Transmitting : 50/53MHz BANDS
frequency 72/75MHz BANDS
53MHz <-> 72MHz
Frequency change to any of
above bands is possible by
merely changing RF module.
Modulation
: PCM, FM
Power requirement : 9.6V
Nicd battery
Current drain
: 250mA
Servo FP-S130
Control system +pulse width control, 1520
uS.N
Operating angle One side 45° or greater (in-
cluding trim)
Power requirement 4.8V (shared with receiver)
Current drain 5mA (at idle)
55.6oz.in (4kg-cm)
Output torque
Operating speed
0.24 sec/60°
Dimensions 1.52x0.77 x 1.36 in
(38.5 x 19.5x34.5mm)
Weight 1.47oz (42g)
Battery Charger FBC-8B(2)
: 120 VAC, 50/60 Hz
Input voltage
: TX side
Output
RX side
Battery charger, landing gear adaptor, DSC cord, CHG adaptor, DSC-CHG
cord, servo tray, frequency flag, spare horn, neck strap, screws
Chosen
band
8/500mAH internal
9.6V/45mA
4.8V/45mA
FP-8SGAP
FP-T8SGAP x 1 with module FP-TF-FM
FP-R118GPx 1
FP-S130x4
SWH-5x 1 (R4-SWJx 1)
NR-4J x 1
Receiver FP-R118GP
Receiving frequency
Intermediate
frequency
Power requirement
Current drain
Dimensions
Weight
Receiving range
Landing Gear Servo FP-S130G (Option)
Control system
Operating angle
Power requirement
Current drain
Output torque
Operating speed
Dimensions
Weight
Receiver Servo Nicd Battery NR-4J
Voltage
Dimensions
Weight
50/53MHz BANDS
Chosen
band
72/75MHz BANDS
455kHz
4.8V Nicd battery (shared
with servo)
42mA (4.8V reception)
2.23 x 1.65x0.94 in
(57 x 52 x 24mm)
1.85oz (53g)
500m on the ground
1000m in the air
When FP-T8SGAP used.
(At the best radio wave con-
dition of environment)
+pulse width control
Rotary approx 160°
4.8V (shared with receiver)
8mA (at idle)
65.3oz.in (4.7kg-cm)
0.34 sec/60°
1.52 x 0.77 x 1.36 in
(38.5 x 19.5 x 34.5mm)
1.48oz (42g)
: 4.8V, 4/500mAH
: 2.01 x 2.28 x 0.59 in
(51 x 58 x 15mm)
: 3.35oz (95g)
