FUTABA FP-5NLH Instruction Manual

Futaba
DIGITAL PROPORTIONAL
RADIO CONTROL

INSTRUCTION MANUAL

Thank you for purchasing a Futaba digital proportional
radio control set.
Please read this manual carefully before using your set.

FEATURES OF FP-5NLH

The FP-5NLH for helicopters is an FM proportional radio con-
trol set for helicopters with an ergonomic case crested as a
result of the exhaustive pursuit of easier operation. Newly de-
signed sticks for smooth and positive operation, servo revers-
ing switches for a l l channels, aileron and elevator AST (Ad-
justable Servo Throw), pitch control trim, idle up, and other
innovations based on the opinions of many RC modelers.

TRANSMITTER

FP-T5NLH
• Reliability substantially improved by using industrial robots to as-
semble the PC board.
• Servo reversing switch for each channel. Servos are reversed by using
this switch
• Aileron and elevator AST (Adjustable Servo Throw). Servo throw can
be set as desired.
• Easy-to-adjust two knob type revolution mixing. Throttle pitch con-
trol rudder mixing.
• Pitch control trimmer. Approximately 30% of the pitch control servo
throw can be trimmed, this allows optimum pitch control of the
model.
• Throttle hold switch and trimmer for auto rotation.
• This allows the Rotor r.p.m. to maintained at an effective control
speed, even when the pitch is reduced, allowing maneuvers which
were impossible in the past to be performed.
• Newly designed open gimbal sticks operate smoothly and reliably.
Spring tension mechanism allows adjustment of the operating feel of
the stick lever.
• Nonslip adjustable lever head allows adjustment of the stick length as
desired.
• Throttle ATL. Adjustable throttle limiter type throttle trim. As the
high side does not change even when the trim is altered, it is very
convenient when connecting the linkage, etc.
• RF PC board module system.
• Functional case, created as a result of the exhaustive pursuit of easier
operation, has evolved a thick case which fits into the palm of the
hand.
• Square level meter at the transmitter indicates the power supply
voltage.
• Excellent radiation efficiency, strong 8-stage telescoping antenna.
• Neck strap bracket provided as standard. Operation is easier if the
transmitter is hung from your neck by using the optional neck strap.
• Built-in NiCad battery.
RECEIVER FP-R107N
• Compact, high performance FM 7-channel receiver with PC board
space reduced to a minimum.
•Special IF amp for radio communications improves the effective
receiving range stability.
• Narrow band ceramic filter improves rejection of adjacent channel
interference.
• Futaba original squelch circuit reduces erroneous operation by weak
signals (when passing a dead point, etc.) and erroneous operation by
natural noise when no signals are being received.
• Large capacitor copes with voltage changes when a battery is used.
• Vibration-resistant pin connectors.
• Fiberglass epoxy PC board with thru-the-hole plating is vibration and
shock resistant.
FM
D60400
SERVO FP-S130

SMALL, RUGGED, HIGH NEUTRAL SERVO

• Small, double ball bearing, water-tight & dusttight servo. High output
torque 55.6 oz-in (4kg-cm), high-speed 0.24sec/60°
• New indirect drive potentiometer improves vibration and shock resist-
ance and neutral accuracy.
• Futaba low-power custom 1C provides extremely high torque, narrow
dead band, and superior tracking.
• Fiberglass reinforced
molded servo case is mechanically strong and invulnerable to glow
fuel.
• Strong polyacetal resin ultra-precision servo gear features smooth
operation, positive neutral, and very little backlash.
• Fiberglass reinforced epoxy resin PC board with thru-the-hole plating
improves servo amp vibration and shock resistance.
• Three pin connector eliminates faulty contact and improves reliability
against vibration and shock. Housing has a reverse insertion preven-
tion mechanism.
• Special grommet simplifies mounting of the servo and has an excel-
lent cushioning effect.
• Six special adjustable splined horns.

SET CONTENTS AND RATINGS

(Specifications are subject to change without prior notice.)
Transmitter
Receiver
Servo
NiCad battery
Switch
Others
TRANSMITTER
Operating system
Transmitting frequency
Modulation system
Power requirement
Current drain
RECEIVER FP-R107N
Receiving frequency
Intermediate frequency
Power requirement
Current drain
Dimensions
Weight
Receiving range
SERVO FP-S130
Control system
Operating angle
Power requirement
Current drain (IDLE)
Output torque
Operating speed
Dimensions
Weight
PBT (polybutylene terephthalate)
FP-5NLH
PCM
FP-T5NLH x 1
FP-R107N x 1
FP-S130 x 4
NR-4J x 1
SSW-J
Charger, Ribbon, Spare horn. Mounting screw.
FP-T5NLH
2 stick, 5 channels w/servo reverse, aileron
and elevator AST, helicopter mechanism
72MHz band.53MHz band
FM (Frequency modulation)
9.6 volts NiCad battery (NT-8LP)
170mA (at 12V)
72MHz band .53MHz band
455kHz
4.8V, NiCad battery (common use with servo)
13.5mA (4.8V reception)
1.38 x 2.42 x 0.8 in (35.2 x 61.7 x 20.3mm)
1.55oz (43g)
550 yards (500m) on the ground, 1,100 yard
(1000m) in the air. [FP-T5NLH]
(at the best conditions)
+pulse width control
One side 45° or more (at idle)
4.8V (Shared with receiver)
5.0V, 8mA
55.6 oz.in (4kg-cm)
0.24sec/60°
1.52 x 0.77 x 1.36 in (38.5 x 19.5 x 34.5mm)
1.47oz (42g)
injection
