LA
vehicle
land & air
INSTRUCTIONS FOR USE
H4810
FORBIDDEN:
Special design for indoor & outdoor, please keep it away from obstacle.
This product is suitable for indoor (the wind grade should be not more than 4),
please choose a place without obstacle, and keep distance from crowd and
pets, don't play it under unsafety, for instance, heat source, wire or electronic
power source in order not to be damaged by collision landing, entanglement
and lead to a fore, electric shock and cause losses of lives and property.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LA VEHICLE H4810 and is the answer not in the manual?

Questions and answers

Related Manuals for Wowitoys LA VEHICLE H4810

Summary of Contents for Wowitoys LA VEHICLE H4810

  • Page 1 vehicle land & air INSTRUCTIONS FOR USE H4810 FORBIDDEN: Special design for indoor & outdoor, please keep it away from obstacle. This product is suitable for indoor (the wind grade should be not more than 4), please choose a place without obstacle, and keep distance from crowd and pets, don’t play it under unsafety, for instance, heat source, wire or electronic power source in order not to be damaged by collision landing, entanglement and lead to a fore, electric shock and cause losses of lives and property.

  • Page 2: Table Of Contents

    CONTENT 1.0 Disclaimer & Warnings 2.0 Safety Guidelines 3.0 Packing list 4.0 Drone’s Details 5.0 Transmitter Functions 6.0 Joystick Mode 7.0 Installation 8.0 Charging 9.0 Operation Guide 9.1 Pairing 9.2 Calibrating the Gyro 9.3 Taking-Off / Landing Method 10.0 Function Details 10.1 Emergency Stop 10.2 Trimming 10.3 Headless Mode...

  • Page 3: Disclaimer & Warnings

    1.0 DISCLAIMER & WARNINGS 1. Please read this disclaimer, warnings and safety guidelines carefully before using our product. This product is not recommended for people under the age of 14. By using this product, you hereby agree to this disclaimer and signify that you have read it fully.

  • Page 4: Safety Guidelines

    2.0 SAFETY GUIDELINES 2.1 Check Before Use (1). This product is not a toy, but a high precision drone that integrates various electronic stability and control mechanisms. Please be sure to set up this drone carefully and correctly to ensure safe, accident-free operation. (2).
  • Page 5 2.3 Use of Battery (1) Please ensure the batteries are fitted in the correct orientation as shown in the instruction manual. (2) Avoid short circuits by fitting the batteries incorrectly, and do not crush the batteries as this may cause the risk of an explosion. (3) Do not mix new and old batteries as this can lead to a poor performance of the product.

  • Page 6: Maintenance

    2.4 Maintenance 1. Clean the product after each use with a clean, soft cloth. 2. Avoid prolonged exposure to direct sunlight and avoid the buildup of heat on the drone or batteries. 3. This device is not waterproof and must not be submerged or subjected to water under any circumstance.

  • Page 7: Drone's Details

    4.0 DRONE’S DETAILS Propeller A Propeller B Propeller B Propeller A It is crucial that all the propellers are installed in the correct position (Pay attention to the letter A or B printed underneath each propeller). WARNING Power Switch...

  • Page 8: Transmitter Functions

    5.0 TRANSMITTER FUNCTIONS Indicator Light Speed Switch Flip Right Joystick Left Joystick Trim Headless (Short Press down) (Short Press down) One Key Take-off Calibrating the Gyro One Key Land (Short Press) (Short Press) LED ON/OFF Emergency Stop (Long Press) Power Switch (Long Press) 6.0 JOYSTICK MODE Left Joystick...

  • Page 9: Installation

    7.0 INSTALLATION 7.1 Drone Battery Installation: Push down to open the battery compartment, align the battery plug with the drone plug and connect them. Pay attention to the positive and negative directions of the battery plug when connecting the battery. The plug in the wrong direction cannot be WARNING connected.
  • Page 10 7.2 Propellers HEAD Installation: As shown above, connect each propeller to its corresponding motor shaft, either position "A/B", then lock the propeller to the motor shaft. To remove the blades: insert the blade driver diagonally into the bottom of the blade with downward pressure.

  • Page 11: Transmitter Battery

    7.3 Transmitter Battery Battery Cover 3 x AAA batteries (not included) Always use alkaline batteries, never mix old and new batteries. WARNING 1. Unscrew the battery cover, press and slide the battery cover out, and insert 3 x AAA batteries(not included), make sure to insert them following the correct polarity as shown.

  • Page 12: Operation Guide

    1. Plug the USB charging cable into a USB charging port on the computer, power bank or USB adapter (5V @ 0.5 to 2.0A ). 2. Connect the wire of battery with USB charging cable. 3. Charging time: about 60-70 minutes. 4.

  • Page 13: Calibrating The Gyro

    HEAD (3). Place the drone on a flat and level surface with the head forward and the tail facing towards the operator. (4). Slowly push the left joystick of the transmitter up to the top and transmitter will beep once and then pull down to the bottom and transmitter will beep once again.

  • Page 14: Taking-Off / Landing Method

    9.3 Taking-Off / Landing Method 1.2m Short Press One Key Take-Off One Key Land Method 1: Short press the one key take-off/land button “ ”, the drone will automatically take off and hover at an altitude about 1.2 meter. Short press the one key take-off/land button “ ”...

  • Page 15: Trimming

    10.2 Trimming F/B Sideward Fly Trim If the drone drifts forward, short press down the right joystick while pushing the direction joystick down to balance the drone; If the drone drifts backwards, short press down the right joystick while pushing the direction joystick up to balance the drone.Short press down the right joystick again to exit trim.

  • Page 16: Headless Mode

    10.3 Headless Mode Short press down the left joystick Short press down the left joystick, the remote control will beep once, and at the same time all the LED lights of the drone body will flash twice simultaneously then break for 0.5 seconds, then flash twice and then break for 0.5 seconds, thus the drone has entered headless flight mode.Short press down the left joystick again to exit headless mode.

  • Page 17: Speed Switch

    Under Headless Mode, the forward direction is the direction that the head of drone faces when the drone takes off. In order to make sure the pilot can tell drone's direction, we recommend that pilots to stay in the same orientation as the drone head faces when the drone takes off.

  • Page 18: 360 Flips

    10.5 360 Flips Short Press Perform 360 flips by pressing the "flip" button and immediately operate the right joystick in the desired direction. 10 Feet When you get familiar with all the functions of the drone, you can try this amazing flip mode.

  • Page 19: Led On/Off

    10.6 LED ON/OFF Long Press Long press the LED button to turn off/on the LED lights of the drone 10.7 Race On Land Mode Forward 1. When the drone is flying in the air, after landing the drone to the level ground, push the right joystick forward, and the drone will drive forward.
  • Page 20 www.facebook.com/WOWITEC...
