- Page 1 Installation Guide FR1500S Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Installation
Installation Dimensions (mm) 38.0 49.0 77.3 Note: Not all the devices have the fingerprint cover. The real product prevails. Procedure to be followed before installation STEP 1 Remove both the screws... - Page 3 Installation STEP 2 Take out the front panel as shown below Method 1: Mounting on the standard Single gang junction box Lay the cables from the desired hole in single gang junction box and fix the machine part to the box part. The single gang junction box's size recommendations: Location column: 83.3mm...
- Page 4 Method 2: Mounting inside the wall Place the mounting sticker Drill fixing holes and dig mounting STEP 1 STEP 2 to the place where the device groove deep of 36mm needs to be installed wall Fixing Hole The depth of the installation groove is 36mm Instruction for the Mounting Paper Before the device is fastened, please...
-
Page 5: Wiring Terminals
Wiring Terminals This reader is an innovative Silk ID reader. It needs to be connected to a host machine so that fingerprint information can be transferred through RS485. Reader wires nomenclature and Dip Switch Dip Switch BLACK GND YELLOW 485+ PURPLE 485- BLACK 1. -
Page 6: Working Principle
Working Principle > Dip Switch setting with control panel Switch Setting Switch Setting Address Address Terminal Resistance 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 Number 1, 2, 3, 4 of the dip switch are used to set the address of RS485, 5 is the... - Page 7 2. Connection with a Standalone Access Controller +12V +12V 485+ 485A 485- 4 85B When using the reader with Standalone access controller device, please move the dial code “1” to the ON position as shown above.
-
Page 8: Safety Precautions
Verification Proccess Connection with the controller: Unsuccessful: LED flashes blue light twice every one second. Successfully: LED flashes blue light once every one second. When verifying the fingerprint or punching the card: Successful Verification: Green LED lights, short BEEP Authentication error: Red LED lights, two short and a long BEEP Data Error: Red LED lights, one short and a long BEEP... - Page 9 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2021 ZKTECO CO., LTD. All Rights Reserved.
