Thank you for purchasing this quality product. Be sure to check all packing materials carefully for
small parts, which may have come loose inside the carton during shipment. Identify and count all
items and compare with the PARTS LIST and/or HARDWARE LIST shown below.
CAUTION: Read the instructions carefully before assembly.
1. We recommend that you assemble this product with the assistance of another person to eliminate
damage to the product during assembly.
2. When you want to reposition the product, please always "LIFT & MOVE".
PARTS LIST
NO.
DESCRIPTION
A
SEAT FRAME
LEFT SIDE
B
FACING (LSF)
ARM
RIGHT SIDE
C
FACING (RSF)
ARM
D
BACKREST
SEAT
E
CUSHION
F
LEG
Created date: 10/10/2023
Revised date: 12/16/2023
ASSEMBLY INSTRUCTIONS
CONSTANTINE COLLECTION
U532T-20 CONSTANTINE LOVESEAT
Q'TY
SKETCH
(PCS)
HARDWARE LIST
NO.
DESCRIPTION
FLAT WASHER
1
1
Ø5/16 x 3/4''
WASHER
1
2
Ø5/16 x 1/2''
BOLT
1
3
Ø5/16 x 2''
ALLEN KEY
4
Ø5/16 x 3¼''
1
BOLT
5
Ø5/16 x 3¼''
THREAD
6
BOLT
2
Ø5/16 x 3¼''
HEX NUT
7
2
Ø5/16 x 1/2''
WRENCH
8
1/2'' x 3½''
SCREWS
9
D4 x 2¾''
Q'TY
SKETCH
(PCS)
16
16
4
1
10
2
2
1
4
PAGE 1/6
Advertisement
Related Manuals for New Classic Furniture ROYAL CLASSICS CONSTANTINE LOVESEAT U532T-20
Summary of Contents for New Classic Furniture ROYAL CLASSICS CONSTANTINE LOVESEAT U532T-20
- Page 1 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS LIST and/or HARDWARE LIST shown below. CAUTION: Read the instructions carefully before assembly.
- Page 2 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT STEP 1: Place the seat frame (A) upside down. Assemble the legs (F) to both left and right back side of the seat frame (A) by using the Allen Key (4) with hardware 1, 2, and 3. STEP 2: Lay the seat frame (A) on its backside to reach the holes to secure the bolts for the arms.
- Page 3 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT STEP 3: Assemble and secure the front legs of the LSF arm (B) and RSF arm (C) to the seat frame (A) by using a screwdriver with hardware 9. STEP 4: Place the backrest (D) on its backside. Install the thread bolt (6) into the hole on the bottom of the backrest (D) by using your hands to rotate the bolt about 25 mm into the backrest (D).
- Page 4 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT STEP 5: Place the frame up right and install the backrest (D) to the LSF arm (B) and RSF arm (C) by sliding the brackets all the way until it is secured. STEP 6: Open the Velcro cover on the RSF arm (B) and LSF arm (C) to reach the holes to secure the bolts for the backrest.
- Page 5 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT STEP 7: Place the chair on its back on a clean and soft surface to reach the thread bolt (6). Secure the backrest (D) to the seat frame (A) by using the Wrench (8) with hardware 1,2, and 7. STEP 8: Place the loveseat up right and install the seat cushion (E) to the seat frame (A).
- Page 6 ASSEMBLY INSTRUCTIONS CONSTANTINE COLLECTION U532T-20 CONSTANTINE LOVESEAT FINISH Created date: 10/10/2023 PAGE 6/6 Revised date: 12/16/2023...
