Digital Watchdog Blackjack Ai DW-BJAiHDX51 T Series Quick Start Manual

Hide thumbs Also See for Blackjack Ai DW-BJAiHDX51 T Series:

Advertisement

State of the art hyper-optimized video management platform designed for ease, speed and efficiency.
Default Login Information for DW Spectrum®
Username: admin
Blackjack Ai HDX™
server
Quick start guide
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/support-download/.
2. Search your product by entering the part number in the 'Search by Product' search bar. Results for applicable part
numbers will populate automatically based on the part number you enter.
3. Click 'Search'. All supported materials, including manuals, Quick start guides (QSG), software and firmware will appear in
the results.
Attention: This document is intended to serve as a quick reference for initial setup.
See the DW Spectrum® full manual for more information on features and functionality.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
Blackjack Ai HDX slim desktop servers — Up to 480Mbps
DW-BJAiHDX51xxT
Password: admin12345
WHAT'S IN THE BOX
1
1
DW-BJAiHDX71xxT
Default login information for the server's OS
Username: dwuser
Keyboard and mouse
Power cable
Quick Start Guide
Password: Dw5pectrum
1 set
1
digital-watchdog.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blackjack Ai DW-BJAiHDX51 T Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Watchdog Blackjack Ai DW-BJAiHDX51 T Series

  • Page 1 Quick Start Guide State of the art hyper-optimized video management platform designed for ease, speed and efficiency. Blackjack Ai HDX slim desktop servers — Up to 480Mbps DW-BJAiHDX51xxT DW-BJAiHDX71xxT Default Login Information for DW Spectrum® Default login information for the server’s OS Username: admin Password: admin12345 Username: dwuser...
  • Page 2: Hardware Overview

    HARDWARE OVERVIEW Power Button/Power LED Mic in (3.5mm) Audio out (3.5mm) 2x USB 3.0 ports 2x USB 2.0 ports HDD Activity LED Power port Antenna ports (not used) Microphone (pink) Line in (light blue) Front speaker (lime) USB 3.2 Gen2 Type-A port USB 3.2 Gen2x2 Type-C port USB 2.0 port USB 3.2 Gen2 port...
  • Page 3: Setting Up The Server

    Quick Start Guide SETTING UP THE SERVER STEP 1: Connect external devices, power and network. Connect a monitor, USB keyboard, mouse, and network cable to Ethernet port B13 (1G LAN) on the rear panel diagram. Configure SETTING UP THE E-RACK the camera network first, then the server’s STEP 1: Connect Peripherals, power and network...
  • Page 4 STEP 3: Configure network Please have the following information ready before starting the network configuration. Camera network Local network (LAN) IP address Subnet mask / Netmask Default gateway / Gateway DNS servers * Camera network and local network cannot be on the same network. NOTE The Blackjack server’s network settings are set to DHCP by default.
  • Page 5 Quick Start Guide Local Network 6. Click OK to close then click Close to go back to Network Connections. Right-click on the Ethernet (Network cable unplugged) and click Properties. Local Network Select Internet Protocol Version 4 (TCP/IPv4) and click Properties. 7.
  • Page 6 STEP 1: Login from the Blackjack server ® Open the DW Spectrum client. Click on the pre-configured server. If it does not log in automatically, enter the default password and click Connect. STEP 2: To rename the server Right-click on the server name in the resource list on the left side and click Server Settings… Enter the new server name in the name field and click OK.
  • Page 7: Activate Licenses

    Quick Start Guide Click OK when the update is complete. STEP 4: Activate licenses NOTE: An active Internet connection is required. Click the main menu icon in the upper-left corner of the DW Spectrum window, and click System Administration… Click the Licenses tab. Enter the license key and click Activate License. * Click Activate Free License to use a free, four-channel license for 30 days.
  • Page 8 Click OK when the necessary recording schedule is set. A red circle will appear next to the camera in the resource list. NOTE: A Recording License is required to allow a camera to record to the archive. STEP 6: Backup database Click the main menu icon in the upper-left corner of the DW Spectrum window, and click System Administration…...
  • Page 9 Quick Start Guide NOTE: If connecting the DW Ai Server Configuration Tool to the DW Spectrum Server is hindered by the message “Unauthorized. Please check the access credentials and try again,” after changing the user password, enable the Digest Authentication setting of the user profile in the DW Spectrum Client. Once logged in and connected to the DW Ai Server through the DW Ai Server Configuration Tool, a list will show all added 2) v panel.
  • Page 10 STEP 2: DW Ai Server Licenses A license is required to use the analytic features of a DW Ai Server. Licenses can be managed through the DW Ai Server Configuration Tool program. Select “Licenses” from the Main Menu in the DW Ai Server Configuration Tool to view the licenses. Active Licenses The Active Licenses list shows all licenses of the DW Ai Server and how the licenses are currently allocated.
  • Page 11 Quick Start Guide STEP 3: Enable Tab – DW Ai Server Plugin To set up analytics on the DW Ai Server, select a camera from the left-side panel. The Enable tab shows the status of the plug-in for the selected camera. From here, you can check your license status and select the preferred deep-learning feature. •...
  • Page 12: Troubleshooting Tips

    Important: OS not listed will be not be supported by DW® Tech Support. Tel: +1 (866) 446-3595 www.digital-watchdog.com Fax: (813) 888-9262 sales@digital-watchdog.com Copyright © Digital Watchdog. All rights reserved. Rev: 05/25 Specifications and pricing are subject to change without notice.
