ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
Important: This Document is customer property and is to remain with this unit. Please return to service information
pack upon completion of work.
Important: These instructions do not cover all variations
in systems nor provide for every possible contingency to
be met in connection with the installation. Should further
information be desired or should particular problems
arise which are not covered sufficiently for the pur-
chaser's purposes, the matter should be referred to your
installing dealer or local distributor.
Note: The manufacturer recommends installing ONLY
A.H.R.I. approved, matched indoor and outdoor systems.
Some of the benefits of installing approved matched
indoor and outdoor split systems are maximum efficien-
cy, optimum performance, and the best overall system
reliability.
Note: Condensation may occur on the surface of the air
handler when installed in an unconditioned space. When
units are installed in unconditioned spaces, verify that
all electrical and refrigerant line penetrations on the air
handler are sealed completely.
Important: The GAM5A0C60M51SA air handler applied
in downflow or horizontal configurations should not ex-
ceed 2000 CFM. Airflow above 2000 CFM could result
in water blow-off. For verification, see airflow table.
Important: The GAM5 air handlers will only use the fol-
lowing internal electric heaters:
BAYEAAC05BK1AA
BAYEAAC05LG1AA
BAYEAAC08BK1AA
BAYEAAC08LG1AA
BAYEAAC10BK1AA
BAYEAAC10LG1AA
BAYEAAC10LG3AA
BAYEABC15BK1AA
BAYEABC15LG3AA
BAYEABC20BK1AA
BAYEACC25BK1AA
Installer's Guide
Convertible Air Handlers
1-1/2 – 5 Ton
GAM5A0A18M11SA
GAM5A0A24M21SA
GAM5A0B30M21SA
GAM5A0B36M31SA
18-GJ04D1-6
GAM5A0C42M31SA
GAM5A0C48M41SA
GAM5A0C60M51SA
