  • Page 1 Installation Guide Blind Spot Detection / ACABSDLP...
  • Page 2: Table Of Contents

    Kit Contents Item QTY. Image BSD Sensor Plate Frame Control Module w/ Speaker Main Harness Surface LED Flush LED Sensor Extension Cable LED Extension Cable User Guide Installation Guide 3M Tape...
  • Page 3: Control Module

    System Layout Control Module Left LED Right LED Left Signal Right Signal BSD Sensor...
  • Page 4 System Layout (Cont) GPS LED RED - Accessory BLACK - Ground Ext. Cable ORANGE - A Trigger Input Ext. Cable PINK - B Trigger Input Ext.Cable GREEN - Reverse Trigger Input B - LED A - LED...
  • Page 5: Sensor Installation

    Installation 1. Sensor Installation The Blind Spot License Plate Frame can be installed onto the vehicle’s license plate with the sensor located at the top or bottom. Labels are located on the back of the BSD sensor. Each side is marked with an “A“or “B”. Please note which side each label is located on before securing the plate frame to the vehicle.
  • Page 6: Installation

    Installation 2. “A” Trigger Input Locate the vehicle’s right tail light assembly. Using a digital multi-meter, test each wire to identify the right turn signal trigger wire. This wire will pulse 12-Volt (+) when the turn signal is activated. Using the sensor labels as a guide, connect the “A” trigger input wire to the vehicle’s right turn signal trigger wire.
  • Page 7: Mounting The Control Box

    Installation 5. Accessory / Ground Input Locate the vehicle’s Accessory wire. This wire will rest at Ground (-) and change to 12-Volt (+) when the key is in the Accessory and Ignition positions. Connect the Red Accessory input to vehicle’s Accessory wire. Identify a secure location for the BLACK Ground input.
  • Page 8: Test Drive

    Testing Test Drive Pre-Check The sensor control module is equipped with a Green LED. This LED is used to check the status of the GPS receiver. When GPS is available the system will use this information to activate or deactivate the BSD detection. This is done to prevent any false warnings while driving at slow speeds in traffic or parking lots.
  • Page 9: Troubleshooting

    Audible warning is provided without Check all trigger input wires activating the vehicle turn signal. Audible Warning is provided when Check GPS Status vehicle is not in motion. Technical Support Please contact Voxx Electronics for technical support at 1-800-225-6074 visit www.voxxuniversity.com. NOTES:...
  • Page 10 Notes...
  • Page 11 Notes...
  • Page 12 © 2018 Voxx Electronics Corp., 180 Marcus Blvd. Hauppauge, NY 11788...
