Chapter 5 Parameters|VFD-S Series
Setting
d10 PLC Program Running
d11 PLC Program Step
Completed
d12 PLC Program Completed
d13 PLC Operation Paused
Terminal Count Value
d14
Attained
Preliminary Counter Value
d15
Attained
d16 AC Motor Drive Ready
d17 FWD Command Indication
d18 REV Command Indication
5-34
Function
the output will be activated when the PLC program is
running.
the output will be activated for 0.5 sec. when each multi-
step speed is attained.
the output will be activated for 0.5 sec. when the PLC
program cycle has completed.
the output will be activated when PLC operation is
paused.
counter reaches Terminal Count Value.
counter reaches Preliminary Count Value.
When AC drive receives the command of forward
running, it will output immediately no matter AC drive is
in the state of run or stop.
When AC drive receives the command of reverse
running, it will output immediately no matter AC drive is
in the state of run or stop.
Description
Revision August 2008, SE09, SW V2.61
