Delta Electronics Network Device VFD-S User Manual

Compact low-cost easy-to-use general-purpose ac motor drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Network Device VFD-S and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Electronics Network Device VFD-S

Summary of Contents for Delta Electronics Network Device VFD-S

  • Page 4: Preface

    Thank you for choosing DELTA’s high-performance VFD-S Series. The VFD-S Series is manufactured with high-quality components and materials and incorporate the latest microprocessor technology available. This manual is to be used for the installation, parameter setting, troubleshooting, and daily maintenance of the AC motor drive. To guarantee safe operation of the equipment, read the following safety guidelines before connecting power to the AC motor drive.
  • Page 5 WARNING! DO NOT use Hi-pot test for internal components. The semi-conductor used in the AC motor drive is easily damaged by high-pressure. There are highly sensitive MOS components on the printed circuit boards. These components are especially sensitive to static electricity. To prevent damage to these components, do not touch these components or the circuit boards with metal objects or your bare hands.

  • Page 6: Table Of Contents

    Preface ...i Table of Contents ...iii Chapter 1 Introduction ...1-1 1.1 Receiving and Inspection... 1-1 1.1.1 Nameplate Information... 1-1 1.1.2 Model Explanation ... 1-1 1.1.3 Series Number Explanation ... 1-2 1.1.4 Drive Frames ... 1-2 1.2 Appearances... 1-2 1.3 Installation Steps ... 1-3 1.4 Storage ...
  • Page 7 3.1 Preparations before Start-up... 3-1 3.2 Operation Method ... 3-2 3.3 Trial Run ... 3-2 Chapter 4 Digital Keypad Operation ...4-1 4.1 Description of the Digital Keypad... 4-1 4.2 Explanation of LED Indicators... 4-1 4.3 Explanations of Display Messages ... 4-1 4.4 How to Operate the Digital Keypad...
  • Page 8 Group 3: Output Function Parameters ... 5-31 Group 4: Input Function Parameters... 5-35 Group 5: Multi-step Speeds and PLC Parameters... 5-47 Group 6: Protection Parameters ... 5-52 Group 7: Motor Parameters ... 5-57 Group 8: Special Parameters... 5-58 Group 9: Communication Parameters... 5-62 Group A: PID Control ...
  • Page 9 7.15 Affecting Other Machines ... 7-10 Chapter 8 Maintenance and Inspections ...8-1 Appendix A Specifications ... A-1 Appendix B Accessories ... B-1 B.1 All Brake Resistors & Brake Units Used in AC Motor Drives ... B-1 B.1.1 Dimensions and Weights for Brake resistors ... B-3 B.2 EMI Filters ...

  • Page 10: Chapter 1 Introduction

    MODEL : VFD007S23A INPUT : 3PH 200-240V 50/60Hz 5.1A OUTPUT : 3PH 0-240V 4.2A 1.6kVA 0.75kW/1HP Frequency Range : 1-400Hz 007S23A0T7010001 DELTA ELECTRONICS INC. Version Type Input Voltage 11:Single phase 115V 21:Single phase 230V 23:Three phase 230V 43:Three phase 460V...

  • Page 11: Chapter 1 Introduction|Vfd-S Series

    Chapter 1 Introduction|VFD-S Series 1.1.3 Series Number Explanation 007S23A 230V 3-phase 1HP(0.75kW) If the nameplate information does not correspond to your purchase order or if there are any problems, please contact your distributor. 1.1.4 Drive Frames Frame Power range 0.25-2hp (0.2-1.5kW) 1-5hp (0.75-3.7kW)

  • Page 12: Installation Steps

    1.3 Installation Steps KNOB CASE HEAT SINK DIVISION PLATE SCREW Revision August 2008, SE09, SW V2.61 COVER SCREW Installation Steps Remove front cover screw and open. Remove Division Plate. If using optional conduit bracket, please refer to next page. Connect AC Input Power and motor leads. Never connect the AC drive output terminals U/T1, V/T2, W/T3 to main AC Input power.

  • Page 13: Storage

    Chapter 1 Introduction|VFD-S Series DIVISION PLATE SCREW 1.4 Storage The AC motor drive should be kept in the shipping carton or crate before installation. In order to retain the warranty coverage, the AC motor drive should be stored properly when it is not to be used for an extended period of time.
  • Page 14 If the AC motor drive is stored for more than 3 months, the temperature should not be higher than 30 °C. Storage longer than one year is not recommended, it could result in the degradation of the electrolytic capacitors. When the AC motor drive is not used for a long time after installation on building sites or places with humidity and dust, it’s best to move the AC motor drive to an environment as stated above.
  • Page 15 Chapter 1 Introduction|VFD-S Series This page intentionally left blank. Revision August 2008, SE09, SW V2.61...

  • Page 16: Chapter 2 Installation And Wiring

    2.1 Ambient Conditions Install the AC motor drive in an environment with the following conditions: Operation Air Temperature: Relative Humidity: Atmosphere pressure: Installation Site Altitude: Vibration: Storage Temperature: Transportation Relative Humidity: Atmosphere pressure: Vibration: Pollution Degree 2: good for a factory type environment. CAUTION! Operating, storing or transporting the AC motor drive outside these conditions may cause damage to the AC motor drive.
  • Page 17 Chapter 2 Installation and Wiring|VFD-S Series When installing multiple AC motor drives in the same cabinet, they should be adjacent in a row with enough space. When installing one AC motor drive below another one, use a metal separation barrier between the AC motor drives to prevent mutual heating. Refer to figure below for details.

  • Page 18: Dimensions

    Chapter 2 Installation and Wiring|VFD-S Series 2.3 Dimensions (Dimensions are in millimeter and [inch]) Frame S1: VFD002S11A, VFD002S21A, VFD002S23A 85.0 [3.35] 5.8 [0.23] 88.0 [3.47] 13.0 [0.51] 74.0 [2.92] 5.0 [0.20] 5.0 [0.20] Revision August 2008, SE09, SW V2.61...
  • Page 19 Chapter 2 Installation and Wiring|VFD-S Series Frame S1: VFD002S11B, VFD002S21B 8 5 .0 [3 .3 5] 5 . 8 [0. 23 ] 88 .0 [3 .4 7 ] 74 .0 [2 .9 2] 1 3 .0 [0 .5 1] 73 .0 [2 .8 8 ] 67 .8 [2 .6 7] 13 .0 [0 .5 1] 5 .
  • Page 20 Frame S1: VFD004S11A, VFD004S21A, VFD004S23A 8 5 .0 [3 .3 5] 7 4 .0 [2 .9 2] Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series 5. 8 [0 . 23 ] 5 . 0 [0. 2 0 ] 5.
  • Page 21 Chapter 2 Installation and Wiring|VFD-S Series Frame S1: VFD004S11B, VFD004S21B 85 .0 [3 .3 5] 74 .0 [2 .9 2] 74 .0 [2 .9 2] 73 .0 [2 .8 8 ] 5. 8 [0. 23 ] 10 2. 0 [ 4. 02 ] 67 .8 [2 .6 7] 5.
  • Page 22 Chapter 2 Installation and Wiring|VFD-S Series Frame S1: VFD007S21A, VFD007S23A 85 .0 [3 .3 5] 5. 8 [0. 23 ] 12 4. 0 [ 4. 89] 74 .0 [2 .9 2] 2. 8 [0. 11 ] 5. 0 [0. 20 ] 5.
  • Page 23 Chapter 2 Installation and Wiring|VFD-S Series Frame S1: VFD007S21B 85 .0 [3 .3 5] 74 .0 [2 .9 2] 74 .0 [2 .9 2] 73 .0 [2 .8 8] 5. 8 [0. 23 ] 67 .8 [2 .6 7] 5. 0 [0. 20 ] 5.
  • Page 24 Frame S1: VFD004S43A, VFD004S43E, VFD007S43A, VFD007S43E 85 .0 [3 .3 5] 74 .0 [2 .9 2] Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series 5. 8 [0. 23 ] 5. 0 [0. 20 ] 5. 0 [0. 20 ] 12 6.
  • Page 25 Chapter 2 Installation and Wiring|VFD-S Series Frame S1: VFD004S43B, VFD007S43B 85 .0 [3 .3 5] 74 .0 [2 .9 2] 73 .0 [2 .8 8] 2-10 5. 8 [0. 23 ] 67 .8 [2 .6 7] 5. 0 [0 . 20 ] 5 .
  • Page 26 Frame S1: VFD002S21E, VFD004S21E, VFD007S21E, VFD015S23D 85 .0 [3 .3 5] 74 .0 [2 .9 2] Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series 5. 8 [ 0. 23 ] 12 7. 0 [ 5. 00] 5.
  • Page 27 Chapter 2 Installation and Wiring|VFD-S Series Frame S2: VFD007S11A 10 0. 0 [ 3. 94] 86 .5 [3 .4 1] 5. 4 [0. 21 ] 12 9. 0 [ 5. 08] 5. 5 [0. 22 ] 5. 5 [0. 22 ] 2-12 Revision August 2008, SE09, SW V2.61...
  • Page 28 Frame S2: VFD007S11B 10 0. 0 [ 3. 94] 86 .5 [3 .4 1] 73 .0 [2 .8 8] Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series 5. 4 [0. 21 ] 67 .8 [2 .6 7] 5.
  • Page 29 Chapter 2 Installation and Wiring|VFD-S Series Frame S2: VFD015S21D, VFD015S21E, VFD015S43D, VFD015S43E, VFD022S21D, VFD022S21E, VFD022S23D, VFD022S43D, VFD022S43E 10 0 . 0 [ 3. 94 ] 5 . 4 [0. 2 1 ] 12 9. 3 [ 5. 09] 86 .5 [3 .4 1] 8.
  • Page 30 Chapter 2 Installation and Wiring|VFD-S Series Frame S2: VFD015S21U, VFD015S43U, VFD022S21U, VFD022S43U 5.4 [0.21] 129.3 [5.09] 100.0 [3.94] 86.5 [3.41] 8.5 [0.33] 67.8 [2.67] 53.9 [2.12] 73.0 [2.88] 5.5 [0.22] 5.5 [0.22] Revision August 2008, SE09, SW V2.61 2-15...

  • Page 31: Wiring

    Chapter 2 Installation and Wiring|VFD-S Series 2.4 Wiring After removing the front cover, check if the power and control terminals are clear of debris. Be sure to observe the following precautions when wiring. General Wiring Information Applicable Codes All VFD-S series are Underwriters Laboratories, Inc. (UL) and Canadian Underwriters Laboratories (cUL) listed, and therefore comply with the requirements of the National Electrical Code (NEC) and the Canadian Electrical Code (CEC).

  • Page 32: Basic Wiring

    2.4.1 Basic Wiring Make sure that power is only applied to the R/L1, S/L2, T/L3 terminals. Failure to comply may result in damage to the equipment. The voltage and current should lie within the range as indicated on the nameplate. Check the following items after completing the wiring: Are all connections correct? No loose wires?
  • Page 33 Chapter 2 Installation and Wiring|VFD-S Series For VFDXXXSXXA/B/D/U Main Circuit Power R/L1 S/L2 T/L3 Recommended Circuit when power supply is turned OFF by a fault output Factory setting Forward/Stop Reverse/Stop Reset Multi-step 1 Multi-step 2 Multi-step 3 Common signal Analog voltage 0~10VDC Potentiometer 3K~5KΩ...
  • Page 34 For VFDXXXSXXE NPN (sink mode) Main Circuit Power R/L1 S/L2 T/L3 Recommended Circuit when power supply is turned OFF by a fault output Factory setting Forward/Stop Reverse/Stop Reset Multi-step 1 Multi-step 2 Multi-step 3 Comm. signal (sink) Analog voltage 0 10VDC ～...
  • Page 35 Chapter 2 Installation and Wiring|VFD-S Series Two/Three wire control The wiring for Pr.4-04=d1 The wiring for Pr.4-04=d2 The wiring for Pr.4-04=d3 2-20 Forward/Stop Reverse/Stop Reset Multi-step 1 Multi-step 2 Multi-step 3 Common Signal Run/Stop Forward/Reverse Reset Multi-step 1 Multi-step 2 Multi-step 3 Comm on Signal Stop...
  • Page 36 For VFDXXXSXXE NPN Mode NPN mode without external power Forward/Stop Reverse/Stop Reset Multi-step 1 Multi-step 2 Multi-step 3 Common Signal NOTE Don't apply the mains voltage directly to above terminals. PNP Mode PNP mode without external power Forward/Stop Reverse/Stop Reset Multi-step 1 Multi-step 2 Multi-step 3...

  • Page 37: External Wiring

    Chapter 2 Installation and Wiring|VFD-S Series 2.4.2 External Wiring Power Supply FUSE/NFB Magnetic contactor Input AC Line Reactor EMI Filter R/L1 S/L2 T/L3 +2/B1 U/T1 V/T2 W/T3 Output AC Line Reactor Motor 2-22 Items Power supply Fuse/NFB (Optional) Magnetic contactor (Optional) Zero-phase Reactor...

  • Page 38: Main Terminals Connections

    2.4.3 Main Terminals Connections Terminal Symbol R/L1, S/L2, T/L3 L/L1, N/L2 U/T1, V/T2, W/T3 +1, +2/B1 +2/B1, B2 Mains power terminals (R/L1, S/L2, T/L3 and L/L1, N/L2) Connect these terminals via a non-fuse breaker or earth leakage breaker to 3-phase AC power (some models to 1-phase AC power) for circuit protection.
  • Page 39 Chapter 2 Installation and Wiring|VFD-S Series DO NOT connect phase-compensation capacitors or surge absorbers at the output terminals of AC motor drives. With long motor cables, high capacitive switching current peaks can cause over-current, high leakage current or lower current readout accuracy. To prevent this, the motor cable should be less than 20m for 3.7kW models and below.

  • Page 40: Control Terminals

    2.4.4 Control Terminals Control Terminal Wiring (Factory Setting) A. XXXSXXA/B/D/U AFM M0 Operation freq. setting potentiometer VR : 3K~5K Corrector potentiometer VR : 1K~5K Freq. meter Reverse/Stop 0~10 VDC Forward/Stop Full scale voltmeter B. XXXSXXE Wire Gauge: 24-16 AWG Wire Type: Copper Only Torque: 2 kgf-cm (1.7 in-lbf) Terminal symbols and functions Terminal...
  • Page 41 Chapter 2 Installation and Wiring|VFD-S Series Terminal Terminal Function Symbol Analog output meter Multi-function Relay output (N.O.) a Multi-function Relay output (N.C.) b Multi-function Relay common Multi-function Output 1 (Photocoupler) Multi-function output common Max. 48Vdc 50mA +10V Potentiometer power supply Analog voltage Input (AVI/ACI) Control signal wiring size: 18 AWG (0.75 mm...
  • Page 42 Analog input terminals (AVI, GND) Analog input signals are easily affected by external noise. Use shielded wiring and keep it as short as possible (<20m) with proper grounding. If the noise is inductive, connecting the shield to terminal GND can bring improvement. If the analog input signals are affected by noise from the AC motor drive, please connect μ...

  • Page 43: Main Circuit Terminals

    Chapter 2 Installation and Wiring|VFD-S Series 2.4.5 Main Circuit Terminals VFD002S11A/11B, VFD004S11A/11B Power Terminal: Torque: 12 kgf-cm (10 lbf-in) Wire Gauge: 14-20 AWG (2.1-0.5mm Wire Type: Copper only, 75 2-28 Power terminal AC Input Line Motor Ter minal Conne ction Groun d Br ak e Res is tor Revision August 2008, SE09, SW V2.61...
  • Page 44 VFD002S21B/23A, VFD004S21B/23A/43A/43B/43E, VFD007S21B/23A/43A/43B/43E, VFD015S23D Power Terminal: Torque: 12 kgf-cm (10 lbf-in) Wire Gauge: 14-20 AWG (2.1-0.5mm Wire Type: Copper only, 75 Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series Power terminal AC Input Line Motor Ter minal Conne ction G roun d Br ak e...
  • Page 45 Chapter 2 Installation and Wiring|VFD-S Series VFD002S21A/E, VFD004S21A/E, VFD007S21A/E Power Terminal: Torque: 12 kgf-cm (10 lbf-in) Wire Gauge: 14-20 AWG (2.1-0.5mm Wire Type: Copper only, 75 2-30 Power terminal AC Input Line Terminal Motor Conne ction Groun d DC Reactor Brak e Res istor Revision August 2008, SE09, SW V2.61...
  • Page 46 VFD007S11A/B Power Terminal: Torque: 20 kgf-cm (17.4 lbf-in) Wire Gauge: 10-18 AWG (5.3-0.8mm Wire Type: stranded copper only, 75 Revision August 2008, SE09, SW V2.61 Chapter 2 Installation and Wiring|VFD-S Series Power terminal AC Input Line Terminal G roun d Motor Conne ction Brak e Res is tor...
  • Page 47 Chapter 2 Installation and Wiring|VFD-S Series VFD015S21U/43D/43E/43U, VFD022S21U/23D/43D/43E/43U Power Terminal: Torque: 20 kgf-cm (17.4 lbf-in) Wire Gauge: 10-18 AWG (5.3-0.8mm Wire Type: stranded copper only, 75 2-32 Power terminal AC Input Line Terminal Groun d Revision August 2008, SE09, SW V2.61 Motor Conne ction Br ak e...
  • Page 48 Chapter 2 Installation and Wiring|VFD-S Series VFD015S21D/E, VFD022S21D/E Power terminal AC Input Line Motor Ter minal Conne ction Groun d Br ak e DC Reacto r Res istor Power Terminal: Torque: 20 kgf-cm (17.4 lbf-in) Wire Gauge: 10-18 AWG (5.3-0.8mm Wire Type: stranded copper only, 75 Revision August 2008, SE09, SW V2.61 2-33...
  • Page 49 Chapter 2 Installation and Wiring|VFD-S Series This page intentionally left blank 2-34 Revision August 2008, SE09, SW V2.61...

  • Page 50: Chapter 3 Start Up

    3.1 Preparations before Start-up Carefully check the following items before proceeding. Make sure that the wiring is correct. In particular, check that the output terminals U/T1, V/T2, W/T3 are NOT connected to power and that the drive is well grounded. Verify that there are no short-circuits between terminals and from terminals to ground or mains power.

  • Page 51: Operation Method

    Chapter 3 Start Up| VFD-S Series 3.2 Operation Method Refer to 4.2 How to operate the digital keypad and chapter 5 parameters for setting. Please choose a suitable method depending on application and operation rule. The operation is usually done as shown in the following table.
  • Page 52 NOTE 1. Stop running immediately if any fault occurs and refer to the troubleshooting guide for solving the problem. 2. Do NOT touch output terminals U/T1, V/T2, W/T3 when power is still applied to R/L1, S/L2, T/L3 even when the AC motor drive has stopped. The DC-link capacitors may still be charged to hazardous voltage levels, even if the power has been turned off.
  • Page 53 Chapter 3 Start Up| VFD-S Series This page intentionally left blank Revision August 2008, SE09, SW V2.61...

  • Page 54: Chapter 4 Digital Keypad Operation

    4.1 Description of the Digital Keypad LED indication Light during RUN, STOP, FWD and REV operation. Potentiometer for frequency setting. Could be the Master Frequency input by setting Pr.2-00. MIN. MAX. Mode Key Change between different display modes. 4.2 Explanation of LED Indicators 4.3 Explanations of Display Messages Display Message Displays the AC drive Master Frequency.

  • Page 55: Chapter 4 Digital Keypad Operation|Vfd-S Series

    Chapter 4 Digital Keypad Operation|VFD-S Series Display Message The internal PLC process step currently being performed. Displays the DC-BUS voltage Displays the output voltage Displays the AC motor drive forward run status. Displays the AC motor drive reverse run status. The counter value (C).

  • Page 56: How To Operate The Digital Keypad

    4.4 How to Operate the Digital Keypad Setting Mode START Note： In the selection mode, press Setting parameters NOTE： In the parameter setting mode, you can press To shift data START (When operation source is digital keypad) Setting direction Revision August 2008, SE09, SW V2.61 Chapter 4 Digital Keypad Operation|VFD-S Series to set the parameters.
  • Page 57 Chapter 4 Digital Keypad Operation|VFD-S Series This page intentionally left blank Revision August 2008, SE09, SW V2.61...

  • Page 58: Chapter 5 Parameters

    The VFD-S parameters are divided into 11 groups by property for easy setting. In most applications, the user can finish all parameter settings before start-up without the need for re-adjustment during operation. The 11 groups are as follows: Group 0: User Parameters Group 1: Basic Parameters...

  • Page 59: Summary Of Parameter Settings

    Chapter 5 Parameters|VFD-S Series 5.1 Summary of Parameter Settings : The parameter can be set during operation. Group 0 User Parameters Explanation 0-00 Identity Code of the AC Motor Drive 0-01 Rated Current Display of the AC Motor Drive 0-02 Parameter Reset 0-03 Start-up Display Selection 0-04 Content of Multi-Function Display...

  • Page 60: Group 2 Operation Method Parameters

    Explanation 1-04 Mid-Point Voltage (Vmid) 1-05 Minimum Output Frequency (Fmin) 1-06 Minimum Output Voltage (Vmin) 1-07 Output Frequency Upper Limit 1-08 Output Frequency Lower Limit 1-09 Accel Time 1 1-10 Decel Time 1 1-11 Accel Time 2 1-12 Decel Time 2 1-13 Jog Acceleration / Deceleration Time 1-14 Jog Frequency Auto acceleration / deceleration (refer...
  • Page 61 Chapter 5 Parameters|VFD-S Series Explanation Source of Master Frequency 2-00 Command Source of Operation 2-01 Command 2-02 Stop Method 2-03 PWM Carrier Frequency Selections 2-04 Motor Direction Control 2-05 Loss of ACI Signal 2-06 Analog Auxiliary Frequency Operation Settings d3: Master Frequency determined by Potentiometer on the digital keypad.

  • Page 62: Group 3 Output Function Parameters

    Group 3 Output Function Parameters Explanation 3-00 Analog Output Signal 3-01 Analog Output Gain 3-02 Desired Frequency Attained 3-03 Terminal Count Value 3-04 Preliminary Count Value Multi-Function Output Terminal 1 3-05 (Photocoupler Output) Multi-Function Output Terminal 2 3-06 (Relay Output) Group 4 Input Function Parameters Explanation 4-00 Potentiometer Bias Frequency...
  • Page 63 Chapter 5 Parameters|VFD-S Series Explanation Multi-Function Input Terminal 1 (M0, 4-04 4-05 Multi-Function Input Terminal 2 (M2) 4-06 Multi-Function Input Terminal 3 (M3) 4-07 Multi-Function Input Terminal 4 (M4) 4-08 Multi-Function Input Terminal 5 (M5) 4-09 Line Start Lockout 4-10 Up/Down Mode Accel/Decel Rate of Change of 4-11...

  • Page 64: Group 5 Multi-Step Speed And Plc Parameters

    Group 5 Multi-Step Speed and PLC Parameters Explanation 5-00 1st Step Speed Freq. 5-01 2nd Step Speed Freq. 5-02 3rd Step Speed Freq. 5-03 4th Step Speed Freq. 5-04 5th Step Speed Freq. 5-05 6th Step Speed Freq. 5-06 7th Step Speed Freq. 5-07 PLC Mode 5-08...
  • Page 65 Chapter 5 Parameters|VFD-S Series Explanation 6-04 Over-Torque Detection Level 6-05 Over-Torque Detection Time Electronic Thermal Overload Relay 6-06 Selection Electronic Thermal 6-07 Characteristic 6-08 Present Fault Record 6-09 Second Most Recent Fault Record 6-10 Third Most Recent Fault Record Settings d4: Enabled during running.

  • Page 66: Group 7 Motor Parameters

    Explanation Group 7 Motor Parameters Explanation 7-00 Motor Rated Current 7-01 Motor No-Load Current 7-02 Torque Compensation 7-03 Slip Compensation Group 8 Special Parameters Explanation 8-00 DC Brake Voltage Level 8-01 DC Brake Time during Start-Up 8-02 DC Brake time during Stopping 8-03 Start-Point for DC Brake Momentary Power Loss Operation...

  • Page 67: Group 9 Communication Parameters

    Chapter 5 Parameters|VFD-S Series Group 9 Communication Parameters Explanation Communication 9-00 Address 9-01 Transmission Speed Transmission Fault 9-02 Treatment 9-03 Time-out Detection Communication 9-04 Protocol Group A PID Parameters Explanation A-00 Input terminal for PID Feedback A-01 Gain over PID Detection value A-02 Proportional Gain (P) A-03...
  • Page 68 Explanation Treatment of the Erroneous A-09 Feedback Signals A-10 Sleep Frequency A-11 Wakeup Frequency A-12 Sleep Period A-13 PID User Defined Revision August 2008, SE09, SW V2.61 Chapter 5 Parameters|VFD-S Series Settings d0: warn and RAMP to stop d1: warn and COAST to stop d0.0 to d400Hz d0.0 to d400Hz d0.0 to d650 seconds...

  • Page 69: Parameter Settings For Applications

    Chapter 5 Parameters|VFD-S Series 5.2 Parameter Settings for Applications Speed Search Applications Windmill, winding Restart free- machine, fan and all running motor inertia loads DC Brake before Running Applications When e.g. windmills, Keep the free- fans and pumps rotate running motor at freely by wind or flow standstill.
  • Page 70 Two-wire/three-wire Applications To run, stop, forward and General application reverse by external terminals Frequency Hold Applications Acceleration/ General application deceleration pause Auto Restart after Fault Applications For continuous and Air conditioners, reliable operation remote pumps without operator intervention Emergency Stop by DC Brake Applications Emergency stop High-speed rotors...
  • Page 71 Chapter 5 Parameters|VFD-S Series Over-torque Setting Applications To protect Pumps, fans and machines and to extruders have continuous/ reliable operation Upper/Lower Limit Frequency Applications Control the motor Pump and fan speed within upper/lower limit Skip Frequency Setting Applications To prevent Pumps and fans machine vibrations Carrier Frequency Setting...
  • Page 72 Output Signal during Running Applications Provide a signal for General application running status Output Signal in Zero Speed Applications Provide a signal for General application running status Output Signal at Desired Frequency Applications Provide a signal for General application running status Over-torque Detection Applications To protect...
  • Page 73 Chapter 5 Parameters|VFD-S Series Output Signal when Frequency Attained Applications Provide a signal for General application running status Output Signal for Base Block Applications Provide a signal for General application running status Overheat Warning for Heat Sink Applications General application For safety Multi-function Analog Output Applications...

  • Page 74: Description Of Parameter Settings

    5.3 Description of Parameter Settings Group 0: User Parameters 0-00 Identity Code of the AC Motor Drive Settings Read Only 0-01 Rated Current Display of the AC motor drive Settings Read Only Pr. 0-00 displays the identity code of the AC motor drive. The capacity, rated current, rated voltage and the max.
  • Page 75 Chapter 5 Parameters|VFD-S Series Multifunction display, see Pr.0-04 Display output current (LED A) Display forward/reverse command (Frd/rEv) 0-04 Content of Multi-function Display Settings d0 Display the user-defined unit (u) Display the counter value (C) Display the content of PLC time (1.tt) Display the DC BUS voltage (U) Display the output voltage (E) Display frequency commands of PID (P)
  • Page 76 0-06 Software Version Settings Read Only Display d #.# 0-07 Password Input Settings d0 to d999 Pr.0-07 and Pr.0-08 work together to provide data security for the AC drive. When Pr.0-08 is set to a value other than 0, a password must be entered to alter the values of parameters. The password is the number set in Pr.0-08, which ranges from 1 to 999.
  • Page 77 Chapter 5 Parameters|VFD-S Series Password Decode Flow Chart 0-08 Displays 0 when entering correct password into Pr.0-07. Memory Mode Selections 0-09 Settings d0 to d63 This parameter is determined to save frequency, operation direction and parameter setting after power off or not. Setting method: input to this parameter after converting binary 6-bit to decimal.
  • Page 78 bit 5 bit4 When Pr. 0-09 is set to b5=0, Pr. 0-09 setting will be saved after power on again. When Pr. 0-02 is set to d10, all parameters (includes Pr.0-09) will be set to factory setting. Revision August 2008, SE09, SW V2.61 Bit 3 bit 1 Setting for Pr.

  • Page 79: Group 1: Basic Parameters

    Chapter 5 Parameters|VFD-S Series Group 1: Basic Parameters Maximum Output Frequency (Fmax) 1-00 Settings d50.0 to d400 Hz This parameter determines the AC motor drive’s Maximum Output Frequency. All the AC motor drive frequency command sources (analog inputs 0 to +10V and 4 to 20mA) are scaled to correspond to the output frequency range.
  • Page 80 This parameter sets the Mid-Point Voltage of any V/f curve. With this setting, the V/f ratio between Minimum Frequency and Mid-Point Frequency can be determined. This parameter must be equal to or greater than Minimum Output Voltage (Pr.1-06) and equal to or less than Maximum Output Voltage (Pr.1-02).
  • Page 81 Chapter 5 Parameters|VFD-S Series If the Upper Limit of Output Frequency is 50Hz and the Maximum Output Frequency is 60Hz, the Maximum Output Frequency will be limited to 50Hz. If the Lower Limit of Output Frequency is 10Hz, and the Minimum Output Frequency (Pr.1-05) is set at 1.0Hz, then any Command Frequency between 1-10Hz will generate a 10Hz output from the drive.
  • Page 82 The JOG function can be selected using Multi-function Input terminals (Pr.4-04 to Pr.4-08) if programmed for Jog (d10). When the Jog terminal is “closed”, the AC drive will accelerate from Minimum Output Frequency (Pr.1-05) to Jog Frequency (Pr.1-14). When the Jog terminal “open”, the AC drive will decelerate from Jog Frequency to zero.
  • Page 83 Chapter 5 Parameters|VFD-S Series 1-16 Acceleration S-Curve 1-17 Deceleration S-Curve Settings d0 to d7 These two parameters allow you to configure whether the acceleration and/or deceleration ramps are linear or S-shaped. The S-curve is enabled when set at d1-d7. Setting d1 offers the quickest S-curve and d7 offers the longest and smoothest S-curve.

  • Page 84: Group 2: Operation Method Parameters

    Group 2: Operation Method Parameters 2-00 Source of Master Frequency Command Settings This parameter sets the Frequency Command Source of the AC drive. If the Frequency Command Source is external (DC 0 to +10V or 4 to 20mA), please make sure the (AVI) terminal jumper is in the proper position as shown below.
  • Page 85 Chapter 5 Parameters|VFD-S Series 2-01 Source of Operation Command Settings When the AC drive is controlled by an external source, please refer to parameter group 4 for detailed explanations on related parameter settings. 2-02 Stop Method Settings The parameter determines how the motor is stopped when the AC motor drive receives a valid stop command or detects External Fault.
  • Page 86 Frequency output frequency motor speed operation command 2-03 PWM Carrier Frequency Selections Power Setting Range Factory Setting This parameter determines the PWM carrier frequency of the AC motor drive. Carrier Acoustic Frequency Noise Significant 3kHz 10kHz Minimal From the table, we see that the PWM carrier frequency has a significant influence on the electromagnetic noise, AC motor drive heat dissipation, and motor acoustic noise.
  • Page 87 Chapter 5 Parameters|VFD-S Series 2-05 Loss of ACI Signal (4-20mA) Settings This parameter is only effective when the Source of Frequency is commanded by a 4 to 20mA signal. The ACI input is considered lost when the ACI signal falls below 2mA. 2-06 Analog Auxiliary Frequency Operation Settings...

  • Page 88: Group 3: Output Function Parameters

    Group 3: Output Function Parameters 3-00 Analog Output Signal (AFM) Settings This parameter sets the function of the AFM output 0~+10VDC (ACM is common). The voltage output type for this analog signal is PWM. It needs to read value by the movable coil meter and is not suitable for A/D signal conversion.
  • Page 89 Chapter 5 Parameters|VFD-S Series For example: When using the meter with full scale of 5 volts, adjust Pr.3-01 to 50%. 3-02 Desired Frequency Attained Settings d1.0 to d400 Hz If a multi-function output terminal is set to function as Desired Frequency Attained (Pr.3-05 or 3-06=d9), then the output will be activated when the programmed frequency is attained.
  • Page 90 Display (Pr.0-04=d1) Counter Trigger Signal Multi-function Input Terminal Preliminary Counter Value Attained Output (Pr. 3-04=d3) (Pr. 3-05 to Pr. 3-06=d15) Terminal Count Value Attained Output (Pr.3-03=d5) (Pr.3-05 to Pr.3-06=d14) 3-05 Multi-function Output Terminal 1 (Photocoupler output) 3-06 Multi-function Output Terminal 2 (relay output) Settings d0 to d18 Setting Function...
  • Page 91 Chapter 5 Parameters|VFD-S Series Setting Function PLC Program Running PLC Program Step Completed PLC Program Completed PLC Operation Paused Terminal Count Value Attained Preliminary Counter Value Attained AC Motor Drive Ready FWD Command Indication REV Command Indication 5-34 Description the output will be activated when the PLC program is running.

  • Page 92: Group 4: Input Function Parameters

    Group 4: Input Function Parameters 4-00 Potentiometer Bias Frequency Settings d0.0 to d100.0% 4-01 Potentiometer Bias Polarity Settings 4-02 Potentiometer Frequency Gain Settings d1 to d200% 4-03 Potentiometer Reverse Motion Enable Settings Pr.4-00 to Pr.4-03 are used when the source of frequency command is the analog signal (0 to +10V DC or 4 to 20 mA DC).
  • Page 93 Chapter 5 Parameters|VFD-S Series Example 3: The example also shows the popular method. The whole scale of the potentiometer can be used as desired. In addition to signals of 0 to 10V and4 to 20mA, the popular voltage signals also include signals of 0 to 5V, 20 to 4mA or that under 10V.
  • Page 94 Example 6: In this example, a negative bias is used to provide a noise margin. Also a potentiometer frequency gain is used to allow the Maximum Output Frequency to be reached. Max. Pr.1-00 Output Freq. 60Hz Negative bias 6Hz Example 7: In this example, the potentiometer is programmed to run a motor is both forward and reverse direction.
  • Page 95 Chapter 5 Parameters|VFD-S Series Max. Pr.1-00 Output Freq. 60Hz anti-slope 4-04 Multi-function Input Terminal (M0, M1) Settings d0 to d29 (Only M1 can be set to d0~d29) 4-05 Multi-function Input Terminal (M2) 4-06 Multi-function Input Terminal (M3) 4-07 Multi-function Input Terminal (M4) 4-08 Multi-function Input Terminal (M5) Parameters &...
  • Page 96 Explanations: d0 Parameter Disable: Enter value (d0) to disable any Multi-Function Input Terminal: M1 (Pr.4-04), M2 (Pr.4-05), M3 (Pr.4- 06), M4 (Pr.4-07) or M5 (Pr.4-08). NOTE The purpose of this function is to provide isolation for unused Multi-Function Input Terminals. Any unused terminals should be programmed to d0 to insure they have no effect on drive operation.
  • Page 97 Chapter 5 Parameters|VFD-S Series NOTE When value d3 is selected for Pr. 4-04, this will over ride any value entered in Pr.4-05, since Pr.4-05 must be used for three wire control as shown above. d4, d5 External Faults: Parameter values d4, d5 programs Multi-Function Input Terminals: M1 (Pr. 4-04), M2 (Pr. 4-05), M3 (Pr.
  • Page 98 D7 Multi-step 1 D8 Multi-step 2 D9 Multi-step 3 These three inputs select the multi-step speeds defined by Pr.5-00 to Pr.5-06 as shown in the following diagram. Pr.5-07 to Pr.5-16 can also control output speed by programming the AC drive’s internal PLC function.
  • Page 99 Chapter 5 Parameters|VFD-S Series Frequency Acceleration inhibit Mx-GND Operation command d12 First or Second Acceleration/Deceleration Time Selection: Parameter value d12 programs a Multi-Function Input Terminal: M1 (Pr.4-04), M2 (Pr.4-05), M3 (Pr.4-06), M4 (Pr.4-07) or M5 (Pr.4-08) to control selection of First or Second Acceleration/deceleration time.
  • Page 100 setting by d13 setting by d14 NOTE When a Base-Block signal is received, the AC drive will stop all output and the motor will free run. When base block control is deactivated, the AC drive will start its speed search function and synchronize with the motor speed, and then accelerate to Master Frequency.
  • Page 101 Chapter 5 Parameters|VFD-S Series PLC operation setting by d17 setting by d18 NOTE Pr.5-00 to Pr.5-16 define the PLC program. d19 Counter Trigger: Parameter value d19 programs Multi-Function Input Terminal: M1 (Pr.4-04), M2 (Pr.4-05), M3 (Pr.4- 06), M4 (Pr.4-07) or M5 (Pr.4-08) to increase the AC drive’s internal counter. When an input is received, the counter is increased by 1.
  • Page 102 d20 Counter Reset: Parameter value d20 programs Multi-Function Input Terminal: M1 (Pr.4-04), M2 (Pr. 4-05), M3 (Pr.4- 06), M4 (Pr.4-07) or M5 (Pr.4-08) to reset the counter. Reset counter d20 reset the counter value. d21 Select ACI / Deselect AVI: Parameter value d21 allows the user to select the input type ACI or AVI via an external switch.
  • Page 103 Chapter 5 Parameters|VFD-S Series d29 M0: 0: RUN 1: STOP, M1: no function, Direction is controlled by keypad 4-09 Line Start Lockout Settings When enabled, the AC drive will not start when powered up with run commands applied. To start in Line Start Lockout mode, the AC drive must see the run command go from stop to run after power up.

  • Page 104: Group 5: Multi-Step Speeds And Plc Parameters

    Group 5: Multi-step Speeds and PLC (Process Logic Control) Parameters 5-00 1st Step Speed Frequency 5-01 2nd Step Speed Frequency 5-02 3rd Step Speed Frequency 5-03 4th Step Speed Frequency 5-04 5th Step Speed Frequency 5-05 6th Step Speed Frequency 5-06 7th Step Speed Frequency Settings...
  • Page 105 Chapter 5 Parameters|VFD-S Series Frequency 60Hz 50Hz 40Hz 30Hz 20Hz 15Hz Master 10Hz Freq. 5-09 Program operation command Program operation output indication Program step complete Program operation completed NOTE The above diagram shows one complete PLC cycle. To restart the cycle, turn the PLC program off and then back on.
  • Page 106 Example 3 (Pr. 5-07 = d3) Execute one cycle step by step: The example shows how the PLC can perform one cycle at a time, within a complete cycle. Each step will use the acceleration/deceleration times in Pr.1-09 to Pr.1-12. It should be noticed that the time each step spends at its intended frequency is diminished, due to the time spent during acceleration/deceleration.
  • Page 107 Chapter 5 Parameters|VFD-S Series Example 5 (Pr. 5-07 = d1 Execute one cycle of the PLC program): In this example, the PLC program runs continuously. It should be noted that the times of reserve motion may be shorter than expected, due to the acceleration/deceleration times. Frequency 60Hz 50Hz...
  • Page 108 Weights Direction The setting value = bit7 x 2 +bit6 x 2 = 0 x 2 +1 x 2 +0 x 2 = 0+64+0+0+0+4+0+0 = 68 Setting Pr.5-08 as d68. 5-09 Time Duration of Master Speed 5-10 Time Duration of 1st Step Speed 5-11 Time Duration of 2nd Step Speed 5-12...

  • Page 109: Group 6: Protection Parameters

    Chapter 5 Parameters|VFD-S Series Group 6: Protection Parameters 6-00 Over-Voltage Stall Prevention Settings d0 During deceleration, the motor DC bus voltage may exceed its Maximum Allowable Value due to motor regeneration. When this function is enabled, the AC drive will stop decelerating. Maintaining a constant output frequency when it happens.
  • Page 110 DC bus voltage Over-voltage detection level Pr.6-01 Output Freq. 6-02 Over-Current Stall Prevention Level Settings d20 to d150% A setting of 100% is equal to the Rated Output Current of the drive. During acceleration and steady-state operation, the AC drive output current may increase abruptly to exceed the value specified by Pr.6-02 due to rapid acceleration or excessive load on the motor.
  • Page 111 Chapter 5 Parameters|VFD-S Series 6-03 Over-Torque Detection Mode (OL2) Settings 6-04 Over-Torque Detection Level Settings d30 to d200% This setting is proportional to the Rated Output Current of the drive. 6-05 Over-Torque Detection Time Settings d0.1 to d10.0 sec If a Multi-Function Output Terminal is set as Over-Torque Detection Indication and the output current exceeds the Over-Torque Detection Level (Pr.6-04, Factory Setting: 150%), the Over- Torque Detection Time (Pr.6-05, Factory setting: 0.1) and the setting of multi-function terminal is Over-Torque Detection Indication, the contact will be “close”.
  • Page 112 Operation time(min) 20 40 60 80 100 120 140 160 180 200 6-08 Present Fault Record 6-09 Second Most Recent Fault Record 6-10 Third Most Recent Fault Record Readings Revision August 2008, SE09, SW V2.61 60Hz or more 50Hz 10Hz No fault Over-current (oc) Over-voltage (ov)
  • Page 113 Chapter 5 Parameters|VFD-S Series Pr.6-08 to 6-10 store records of the three most recent faults that had occurred. Use the reset key to reset the drive when the fault no longer exits. 5-56 Software protection enable (codE) Reserved CPU failure (cF3.1) CPU failure (cF3.2) CPU failure (cF3.3) CPU failure (cF3.4)

  • Page 114: Group 7: Motor Parameters

    Group 7: Motor Parameters 7-00 Motor Rated Current Settings d30 to d120% This parameter will limit the AC drive output current in order to prevent the motor from overheating. Motor No-load Current 7-01 Settings d0 to d90% The rated current of the AC drive is regarded as 100%. Motor setting of no-load current will effect the slip compensation.

  • Page 115: Group 8: Special Parameters

    Chapter 5 Parameters|VFD-S Series Group 8: Special Parameters 8-00 DC Brake Current Level Settings d0 to d30% This parameter determines the level of DC Brake Voltage Level output to the motor during start-up and stopping. When setting DC Brake Voltage, the Maximum Output Voltage (Pr.1- 02) is regarded as 100%.
  • Page 116 DC Brake during Start-up is used for loads that may move before AC drive starts, such as fans and pumps. These loads may also be moving in the wrong direction. Under such circumstances, DC Brake can be executed to hold the load in position before applying a forward motion.
  • Page 117 Chapter 5 Parameters|VFD-S Series Following a power failure, the AC drive will start its speed search operation, only if the output current is greater than the value determined by Pr.8-07. When the output current is less than that of Pr.8-07, the AC drive output frequency is at a “speed synchronization point”. The drive will start to accelerate or decelerate back to the operating frequency at which it was running prior to the power failure.
  • Page 118 8-15 Automatic Voltage Regulation (AVR) Settings AVR function automatically regulates the AC drive output voltage to the Maximum Output Voltage (Pr.1-02). For instance, if Pr.1-02 is set at 200 VAC and the input voltage is at 200V to 264VAC, then the Maximum Output Voltage will automatically be reduced to a maximum of 200 VAC.

  • Page 119: Group 9: Communication Parameters

    Chapter 5 Parameters|VFD-S Series Group 9: Communication Parameters 9-00 Communication Address Settings d1 to d254 If the AC drive is controlled by RS-485 serial communication, the communication address must be set via this parameter. Computer 9-01 Transmission Speed Settings Users can set parameters and control the operation of the AC drive via the RS-485 serial interface of a personal computer.
  • Page 120 9-03 Time-out Detection Settings d1~d20 If this function is enabled, the timer will start counting once the first valid Modbus communication signal is received after power-up or reset. The timer will reset to 0 after each valid Modbus communication message is received. If the watchdog timer reaches the value set in Pr.
  • Page 121 Chapter 5 Parameters|VFD-S Series Code Description: ASCII mode: Each 8-bit data is the combination of two ASCII characters. For example, a 1-byte data: 64 Hex, shown as ‘64’ in ASCII, consists of ‘6’ (36Hex) and ‘4’ (34Hex). Character ASCII code Character ASCII code RTU mode:...
  • Page 122 2.2 11-bit character frame (For 8-bit character): ( 8.N.2 ) Start ( 8.E.1 ) Start ( 8.O.1 ) Start 3. Communication Protocol 3.1 Communication Data Frame: ASCII mode: Start character ‘:’ (3AH) ADR 1 Communication address: 8-bit address consists of 2 ASCII codes ADR 0 CMD1 Command code:...
  • Page 123 Chapter 5 Parameters|VFD-S Series 3.2 ADR (Communication Address) Valid communication addresses are in the range of 0 to 254. A communication address equal to 0, means broadcast to all AC drives (AMD). In this case, the AMD will not reply any message to the master device.
  • Page 124 RTU mode: Command message: Starting data address Number of data (count by word) CRC CHK Low CRC CHK High (2) 06H: single write, write single data to register. Example: writing data 6000(1770H) to register 0100H. AMD address is 01H. ASCII mode: Command message: ADR 1 ADR 0...
  • Page 125 Chapter 5 Parameters|VFD-S Series (3) Command code: 10H, write n word, n<=12 For example, writing 6000(1770H) to Pr 5-00 (address 0500H) and1000(03E8H) to Pr 5- 01 (address 0501H) with slave address 01H. ASCII Mode: Command message: ADR 1 ADR 0 CMD1 CMD0 Starting Data address...
  • Page 126 3.4 Check sum ASCII mode: LRC (Longitudinal Redundancy Check) is calculated by summing up, module 256, the values of the bytes from ADR1 to last data character then calculating the hexadecimal representation of the 2’s-complement negation of the sum. For example, reading 1 word from address 0401H of the AC drive with address 01H Starting data address Number of data LRC CHK 1...
  • Page 127 Chapter 5 Parameters|VFD-S Series Step 5: Repeat step 3 and 4 until eight shifts have been performed. When this is done, a complete 8-bit byte will have been processed. Step 6: Repeat step 2 to 5 for the next 8-bit byte of the command message. Continue doing this until all bytes have been processed.
  • Page 128 Content Address Command 2000H 2001H 2002H Status 2100H monitor Read only Revision August 2008, SE09, SW V2.61 Functions Bit 0-1 00: No function 01: Stop 10: Run 11: Jog + Run Bit 2-3 Not used 00: No function 01: FWD Bit 4-5 10: REV 11: Change direction...
  • Page 129 Chapter 5 Parameters|VFD-S Series Content Address 2101H 2102H 2103H 2104H 2105H 2106H 2107H 2108H 2109H 210AH 3.6 Exception response: The AC motor drive is expected to return a normal response after receiving command messages from the master device. The following depicts the conditions when no normal response is replied to the master device.
  • Page 130 Example of an exception response of command code 06H and exception code 02H: ASCII mode: ADR 1 ADR 0 CMD1 CMD0 Exception code LRC CHK 1 LRC CHK 0 END1 END0 The explanation of exception codes: Exception code Illegal command code: The command code received in the command message is not available for the AC drive.
  • Page 131 Chapter 5 Parameters|VFD-S Series 3.7 Communication program of PC: The following is a simple example of how to write a communication program for Modbus ASCII mode on a PC in C language. #include<stdio.h> #include<dos.h> #include<conio.h> #include<process.h> #define PORT 0x03F8 /* the address of COM1 */ /* the address offset value relative to COM1 */ #define THR 0x0000 #define RDR 0x0000...

  • Page 132: Group A: Pid Control

    Group A: PID Control A-00 Input Terminal for PID Feedback Settings Select an input terminal to serve as the PID feedback location. Please verify the feedback location is different from the Frequency Set Point location and J1 for selecting ACI or AVI must be in the correct position.
  • Page 133 Chapter 5 Parameters|VFD-S Series When this parameter is set to gain =1, PID output is Derivative time. At this time, error value – error value of the preceding item= additional respond speed and it is easy to have over compensation situation. A-05 Upper Bound for Integral Control Settings...
  • Page 134 This parameter selects the operation of the drive upon a loss of PID feedback signal. Sleep Frequency A-10 Settings d0.0 to d400Hz A-11 Wakeup Frequency Settings d0.0 to d400Hz A-12 Sleep Period Settings d0.0 to d650 seconds These parameters determine sleep functions of the AC drive. If the command frequency falls below the sleep frequency, for the specified time in Pr.
  • Page 135 Chapter 5 Parameters|VFD-S Series the setting frequency of parameters, such as Max. operation frequency, 1 they are still needed to set with actual value. Target Value A-02 If the input range of sensor is 0~SI_max, output range is SO_min~SO_max and then Input Per output SO_max-SO_min...

  • Page 136: Chapter 6 Fault Code Information

    The AC motor drive has a comprehensive fault diagnostic system that includes several different alarms and fault messages. Once a fault is detected, the corresponding protective functions will be activated. The following faults are displayed as shown on the AC motor drive digital keypad display. The three most recent faults can be read from the digital keypad or communication.
  • Page 137 Chapter 6 Fault Code Information|VFD-S Series Fault Fault Descriptions Name Overheating Heat sink temperature too high Low voltage The AC motor drive detects that the DC bus voltage has fallen below its minimum value. Overload The AC motor drive detects excessive drive output current.
  • Page 138 Fault Fault Descriptions Name Over-current during constant speed operation External Fault Internal EEPROM can not be programmed. Internal EEPROM can not be programmed. OH error OV error LV error Drive’s internal circuitry abnormal. Ground fault External Base Block. (Refer to Pr. 8-06) Auto accel/decel failure Communication Error Revision August 2008, SE09, SW V2.61...

  • Page 139: Reset

    Chapter 6 Fault Code Information|VFD-S Series Fault Fault Descriptions Name Software protection failure Password is locked. Analog feedback error or ACI open circuit Phase Loss PID feedback error 6.2 Reset There are three methods to reset the AC motor drive after solving the fault: STOP/RESET Press key on keypad.

  • Page 140: Chapter 7 Troubleshooting

    7.1 Over Current (OC) Remove short circuit or ground fault Reduce the load or increase the power of AC motor drive No Reduce torque compensation Reduce torque compensation Maybe AC motor drive has malfunction or error due to noise. Please contact with DELTA.

  • Page 141: Chapter 7 Troubleshooting |Vfd-S Series

    Chapter 7 Troubleshooting |VFD-S Series 7.2 Ground Fault Ground fault 7.3 Over Voltage (OV) Reduce voltage to be within spec. Maybe AC motor drive has malfunction or misoperation due to noise. Please contact with DELTA. Reduce moment of inertia Need to check control method. Please contact DELTA. Is output circuit(cable or motor) of AC motor drive grounded?

  • Page 142: Low Voltage (Lv)

    7.4 Low Voltage (Lv) Low voltage Is input power correct? Or power cut, including momentary power loss Check if there is any malfunction component or disconnection power supply circuit Check if voltage is within specification Check if there is heavy load with high start current in the same power system Check if Lv occurs when...

  • Page 143: Over Heat (Oh)

    Chapter 7 Troubleshooting |VFD-S Series 7.5 Over Heat (OH) AC motor drive overheats Heat sink overheats Check if temperature of heat sink is greater than 90 Is load too large If cooling fan functions normally Check if cooling fan is jammed Check if surrounding temperature is within specification Adjust surrounding temperature...

  • Page 144: Keypad Display Is Abnormal

    7.7 Keypad Display is Abnormal Abnormal display or no display Cycle power to AC motor drive Display normal? AC motor drive works normally 7.8 Phase Loss (PHL) Check wiring at R, S and T terminals Check if the screws of terminals are tightened Check if the input voltage of R, S, T is unbalanced Maybe AC motor drive has malfunction or misoperation due to noise.

  • Page 145: Motor Cannot Run

    Chapter 7 Troubleshooting |VFD-S Series 7.9 Motor cannot Run Motor cannot run Reset after clearing fault and then RUN It can run when no faults occur Press RUN key to check if it can run Press UP key to set frequency Check if input FWD or REV command Press UP to...

  • Page 146: Motor Speed Cannot Be Changed

    7.10 Motor Speed cannot be Changed Modify the setting If the setting of Pr.5-09 to Pr.5-16 is too high If finished with executing Pr.5-07 If the setting of Pr.5-00 to Pr.5-06 are the same Revision August 2008, SE09, SW V2.61 Motor can run but cannot change speed Check if the setting of the...

  • Page 147: Motor Stalls During Acceleration

    Chapter 7 Troubleshooting |VFD-S Series 7.11 Motor Stalls during Acceleration Motor stalls during acceleration Thicken or shorten the wiring between the motor or AC motor drive Reduce load or increase the capacity of AC motor drive 7.12 The Motor does not Run as Expected Motor does not run as expected Run in low speed continuously...

  • Page 148: Electromagnetic/Induction Noise

    7.13 Electromagnetic/Induction Noise Many sources of noise surround AC motor drives and penetrate it by radiation or conduction. It may cause malfunctioning of the control circuits and even damage the AC motor drive. Of course, there are solutions to increase the noise tolerance of an AC motor drive. But this has its limits. Therefore, solving it from the outside as follows will be the best.

  • Page 149: Affecting Other Machines

    Chapter 7 Troubleshooting |VFD-S Series Store within a relative humidity range of 0% to 90% and non-condensing environment. Use an air conditioner and/or exsiccator. 7.15 Affecting Other Machines An AC motor drive may affect the operation of other machines due to many reasons. Some solutions are: High Harmonics at Power Side High harmonics at power side during running can be improved by:...

  • Page 150: Chapter 8 Maintenance And Inspections

    Chapter 8 Maintenance and Inspections Modern AC motor drives are based on solid-state electronics technology. Preventive maintenance is required to keep the AC motor drive in its optimal condition, and to ensure a long life. It is recommended to have a qualified technician perform a check-up of the AC motor drive regularly. Daily Inspection: Basic check-up items to detect if there were any abnormalities during operation are: Whether the motors are operating as expected.

  • Page 151: Chapter 8 Maintenance And Inspections|Vfd-S Series

    Chapter 8 Maintenance and Inspections|VFD-S Series Periodical Maintenance Ambient environment Check Items Check the ambient temperature, humidity, vibration and see if there is any dust, gas, oil or water drops Check for any dangerous objects near drive and motor Voltage Check Items Check if the voltage of main circuit and control circuit is...
  • Page 152 Check Items Check partsfor deformity or damaged If there is any color change caused by overheating Check for dust and dirt Main circuit Check Items If there are any loose or missing screws If machine or insulator is deformed, cracked, damaged or with changed color change due to overheating or ageing Check for dust and dirt...
  • Page 153 Chapter 8 Maintenance and Inspections|VFD-S Series DC capacity of main circuit Check Items If there is any leakage of liquid, change of color, cracks or deformation Measure static capacity when required Resistor of main circuit Check Items If there is any peculiar smell or insulator cracks due to overheating If there is any disconnection...
  • Page 154 Printed circuit board and connector of main circuit Check Items If there are any loose screws and connectors If there is any peculiar smell and color change If there is any crack, damage, deformation or corrosion If there is any leaked liquid or deformation in capacitors Cooling fan of cooling system Check Items...
  • Page 155 Chapter 8 Maintenance and Inspections|VFD-S Series This page intentionally left blank Revision August 2008, SE09, SW V2.61...

  • Page 156: Appendix A Specifications

    Voltage Class Model Number VFD-_ _ _S Max. Applicable Motor Output (kW) Max. Applicable Motor Output (HP) Rated Output Capacity (KVA) Rated Output Current (A) Maximum Output Voltage (V) Output Frequency (Hz) Carrier Frequency (kHz) Rated Input Current (A) Rated Voltage/Frequency Voltage Tolerance Freqency Tolerance Cooling Method...
  • Page 157 Appendix A Specifications|VFD-S Series Voltage Class Model Number VFD-_ _ _S Max. Applicable Motor Output (kW) Max. Applicable Motor Output (HP) Rated Output Capacity (KVA) Rated Output Current (A) Maximum Output Voltage (V) Output Frequency (Hz) Carrier Frequency (kHz) Rated Input Current (A) Rated Voltage/Frequency Voltage Tolerance Freqency Tolerance...

  • Page 158: Appendix B Accessories

    B.1 All Brake Resistors & Brake Units Used in AC Motor Drives Note: Please only use DELTA resistors and recommended values. Other resistors and values will void Delta’s warranty. Please contact your nearest Delta representative for use of special resistors. The brake unit should be at least 10 cm away from AC motor drive to avoid possible interference.
  • Page 159 Appendix B Accessories|VFD-S Series Please read the wiring information in the user manual of the brake unit thoroughly prior to installation and operation. In applications with brake resistor or brake unit, Pr.6-00 (Over-voltage stall prevention) must be disabled. And Pr.8-15 (AVR function) shall not be used. Definition for Brake Usage ED% Explanation: The definition of the barke usage ED(%) is for assurance of enough time for the brake unit and brake resistor to dissipate away heat generated by braking.

  • Page 160: Dimensions And Weights For Brake Resistors

    B.1.1 Dimensions and Weights for Brake resistors (Dimensions are in millimeter) Order P/N: BR080W200, BR080W750, BR300W70, BR300W100, BR300W250, BR300W400, BR400W150, BR400W040 Model no. BR080W200 BR080W750 BR300W70 BR300W100 BR300W250 BR300W400 BR400W150 BR400W040 Revision August 2008, SE09, SW V2.61 Appendix B Accessories|VFD-S Series Max.

  • Page 161: Emi Filters

    Appendix B Accessories|VFD-S Series B.2 EMI Filters The DELTA VFD-S Series 0.25-3HP, 115V, 230V, 460V AC drive uses DELTA EMI Filter. Use the table below to find the appropriate filter for your DELTA VFD-S drive. Model of AC Motor Drive VFD002S21A/B, VFD004S21A/B, VFD007S21A/B VFD015S21D/U, VFD022S21D/U VFD004S43A/B, VFD007S43A/B...
  • Page 162 Use the cable with shielding (double shielding is the best). The shielding on both ends of the motor cable should be grounded with the minimum length and maximum contact area. Remove any paint on metal saddle for good ground contact with the plate and shielding. Remove any paint on metal saddle for good ground contact with the plate and shielding.
  • Page 163 Appendix B Accessories|VFD-S Series The length of motor cable When motor is driven by an AC motor drive of PWM type, the motor terminals will experience surge voltages easily due to components conversion of AC motor drive and cable capacitance. When the motor cable is very long (especially for the 460V series), surge voltages may reduce insulation quality.

  • Page 164: Dimensions

    If the length is too long, the stray capacitance between cables will increase and may cause leakage current. It will activate the protection of over current, increase leakage current or not insure the correction of current display. The worst case is that AC motor drive may damage.
  • Page 165 Appendix B Accessories|VFD-S Series Order P/N: RF022S21BA (1.97) (1.06) (0.59) (8.98) (0.94) (3.94) (2.91) (9.49) (8.98) (0.22) Revision August 2008, SE09, SW V2.61...
  • Page 166 Appendix B Accessories|VFD-S Series Order P/N: 12DKT1W3S Order P/N: 08TDT1W4S Revision August 2008, SE09, SW V2.61...
  • Page 167 Appendix B Accessories|VFD-S Series Order P/N: 22DRT1W3S Order P/N: 35DRT1W3C B-10 Revision August 2008, SE09, SW V2.61...

  • Page 168: Ac Reactor

    B.3 AC Reactor B.3.1 AC Input Reactor Recommended Value 230V, 50/60Hz, 1-Phase 0.75 460V, 50/60Hz, 3-Phase Fundamental 0.75 B.3.2 AC Output Reactor Recommended Value 115V/230V, 50/60Hz, 3-Phase Fundamental 0.75 460V, 50/60Hz, 3-Phase Fundamental Amps 0.75 Revision August 2008, SE09, SW V2.61 Fundamental Max.

  • Page 169: Applications For Ac Reactor

    Appendix B Accessories|VFD-S Series B.3.3 Applications for AC Reactor Connected in input circuit Application 1 When more than one AC motor drive is connected to the same mains power, and one of them is ON during operation. Correct wiring Application 2 Silicon rectifier and AC motor drive are connected to the same power.
  • Page 170 Application 3 Used to improve the input power factor, to reduce harmonics and provide protection from AC line disturbances (surges, switching spikes, short interruptions, etc.). The AC line reactor should be installed when the power supply capacity is 500kVA or more and exceeds 6 times the inverter capacity, or the mains wiring distance Correct wiring...

  • Page 171: Dc Choke Recommended Values

    Appendix B Accessories|VFD-S Series B.4 DC Choke Recommended Values 230V DC Choke Input voltage 230Vac 50/60Hz 0.75 3-Phase 230Vac 50/60Hz 0.75 1-Phase 460V DC Choke Input voltage 460Vac 0.75 50/60Hz 3-Phase B-14 DC Amps Inductance (mh) DC Amps Inductance (mh) MTE CAT.

  • Page 172: Zero Phase Reactor (Rf220X00A

    B.5 Zero Phase Reactor (RF220X00A) Dimensions are in millimeter and (inch) Wiring Method Please wind each wire 4 times around the core. The reactor must be put at inverter output as close as possible. Power Supply Revision August 2008, SE09, SW V2.61 Motor Qty.

  • Page 173: Din Rail-Dr01

    Appendix B Accessories|VFD-S Series B.6 Din Rail-DR01 (Dimensions are in millimeter) Models Screw Size VFD002S11A/B M4*22 VFD002S21A/B/E M4*22 VFD002S23A/B M4*22 VFD004S11A/B M4*12 VFD004S21A/B/E M4*12 VFD004S23A/B M4*12 VFD004S43A/B/E M4*12 VFD007S21A/B/E M4*12 VFD007S23A/B M4*12 VFD007S43A/B/E M4*12 VFD015S23D M4*12 B-16 To install the Din Rail Adapter use the specified screws for different models.

  • Page 174: Remote Controller

    B.7 Remote Controller RC-01 (Dimensions are in millimeter) AFM GND VFD-S Programming Pr. 2-00 set to d01 Pr. 2-01 set to d01 Pr. 4-04 set to d02 (M0, M1 set at RUN/STOP and FWD/REV) Pr. 4-05 set to d06 (M2 set for reset) Pr.

  • Page 175: Conduit Bracket (Bk-S

    Appendix B Accessories|VFD-S Series B.8 Conduit Bracket (BK-S) (Dimensions are in millimeter) 73.0(2.87) B-18 Revision August 2008, SE09, SW V2.61...

  • Page 176: Non-Fuse Circuit Breaker Chart

    B.9 Non-fuse Circuit Breaker Chart The fuse should comply with UL248 and the breaker should comply with UL489. The current rating of the breaker shall be within 2~4 times maximum input current rating. (Refer to Appendix A for rated input/output current) 1-phase Recommended Model...
  • Page 177 Appendix B Accessories|VFD-S Series This page intentionally left blank B-20 Revision August 2008, SE09, SW V2.61...

  • Page 178: Appendix C How To Select The Right Ac Motor Drive

    Appendix C How to Select the Right AC Motor Drive The choice of the right AC motor drive for the application is very important and has great influence on its lifetime and the performance. If the capacity of AC motor drive is too large, it cannot offer complete protection to the motor and it may be damaged.

  • Page 179: Capacity Formulas

    |VFD-S Series C.1 Capacity Formulas 1. When one AC motor drive operates one motor The starting capacity should be less than 1.5x rated capacity of AC motor drive The starting capacity is ⎛ × ⎜ ⎜ η ϕ × × ⎝...
  • Page 180 2.3 When it is running continuously The requirement of load capacity should be less than the capacity of the AC motor drive(kVA) The requirement of load capacity is × η × The motor capacity should be less than the capacity of AC motor drive ×...

  • Page 181: General Precautions

    |VFD-S Series C.2 General Precautions Selection Note When the AC Motor Drive is connected directly to a large-capacity power transformer (600kVA or above) or when phase lead capacitors are switched, excess peak currents may occur in the power input circuit and the rectifier section might be damaged. To avoid this, use an AC input reactor (optional) before AC Motor Drive mains input to reduce the current and improve the input power efficiency.

  • Page 182: How To Choose A Suitable Motor

    If the stall prevention function is activated, the accel./decel. time is automatically extended to a length that the AC Motor Drive can handle. If the motor needs to decelerate within a certain time with high load inertia that can’t be handled by the AC Motor Drive in the required time, either use an external brake resistor and/or brake unit, depending on the model, (to shorten deceleration time only) or increase the capacity for both the motor and the AC Motor Drive.
  • Page 183 |VFD-S Series Motor dynamic balance and rotor endurance should be considered if the operating speed exceeds the rated speed (60Hz) of a standard motor. Motor torque characteristics vary when an AC Motor Drive instead of commercial power supply drives the motor. Check the load torque characteristics of the machine to be connected.
  • Page 184 Gear reduction motor: The lubricating method of reduction gearbox and speed range for continuous operation will be different and depending on brand. The lubricating function for operating long time at low speed and for high-speed operation needs to be considered carefully. Synchronous motor: The rated current and starting current are higher than for standard motors.
  • Page 185 |VFD-S Series AC motor drive 60 seconds 60 seconds 0 3 20 Frequency (Hz) Base freq.: 60Hz V/F for 220V/60Hz 60 seconds 0 3 20 Frequency (Hz) Base freq.: 50Hz V/F for 220V/50Hz Motor 60 seconds 0 3 20 Frequency (Hz) Base freq.: 60Hz V/F for 220V/60Hz 60 seconds...

Table of Contents

Save PDF
