After the wireless network is running, observe the WLAP ID from the WLAP RF Statistics screen.
Display this screen by pressing
WLAP Manual BSS ID
Intel recommends that you set the WLAP Manual BSS ID to its own MAC address. An example is
shown in Figure 1-3. This causes the access point to go directly to the Functional state and therefore
reduces the time required to begin the wireless connection. The Functional state is described in
section 3.3.1: Functional State.
Access Point A
.DTIM Interval
.BC/MC Q Max
.Max Retries (d)
.Max Retries (v)
.Multicast Mask (d) 09000E00
.Multicast Mask (v) 01005E00
.Beacon Interval
.Accept Broadcast ESSID
.MU Inactivity Timeout
.Rate Control
11 Mb/s
5.5 Mb/s
2 Mb/s
1 Mb/s
.RTS Threshold
Extended Range
OK-[CR]
Use the space bar to enable/disable/set link required WLAP operation.
Figure 1-3: Example Settings for the Root Access Point
Configuring Access Point Bridging and Repeating (WLAP Mode)
from the RF Statistics screen.
F3
RF Configuration
10
10
15
5
hex
hex
100 K-us
Disabled
60 min.
Optional
Optional
Required
Required
2347 bytes
0 mi.
Save-[F1] Save All APs-[F2]
WLAP Mode Enabled
WLAP Priority 7000 hex
WLAP Manual BSS ID 00:A0:F8:93:C5:B5
WLAP Hello Time 20
WLAP Max Age 100
WLAP Forward Delay
WLAP MU Table Aging Time
.WEP (Privacy) Disabled
.WEP Algorithm 40 bit shared key
.Encryption Key ID 1
Encryption Key Maintenance
.Short RF Preamble Disabled
Tx Power Control Full
Cancel-[ESC]
5
240 min.
3
