Arrow WH1014-C Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Table of Contents

Owner's Manual & Assembly Instructions
ST01
Model No.
712780403
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 14' 121" x 160 1/4"
3,0m x 4,0m 307cm x 407cm
WH1014-C
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
129
852
123 1/4"
12,0m
2
24,1m
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
162 3/4"
87 7/8"
313cm
413cm
223cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
118 1/4" 157 1/2" 86 5/8"
300cm
400cm
Door
Opening
Height Width Height
55 1/2"
60"
220cm
141cm 152cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WH1014-C and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow WH1014-C

Summary of Contents for Arrow WH1014-C

  • Page 1 Owner's Manual & Assembly Instructions ST01 Model No. WH1014-C CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 712780403 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 A foundation is also necessary as a base in order to construct a square and level building. Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Foundation Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct the foundation and anchoring system of your choice.

  • Page 3: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 ATTIC KIT / WORKBENCH KIT FLOOR FOUNDATION KITS Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They install quickly and easily to help organize space and create more useable space as an attic or workbench.
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FOUNDATION KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
  • Page 11 65109 67468 66646 #8-32 Acorn Nut (14) Peak Cap (6) 66045 Washer (400) Handle (2) (Packed with Screws) (Arrow Logo) (10 sheets of 40) 66183 65020 66242 66382 Roof Trim Cap 1/4" Door Washer (14) Door Slide (4) Lower Door Guide (4) (2 right &...

  • Page 12: Parts List

    Parts List ST12 Parts in Carton One Assembly Part Part Quantity Check Key No. Number Description in Carton List 5291 Front Siding (3 board) 5305 Side Siding (3 board) 5307 Rear Siding (3 board) 6114 Small Right Gable 6115 Small Left Gable 7667 Horizontal Door Brace 7858...
  • Page 13 Assembly by Key No. ST13...
  • Page 14 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Step 1 8936 Rear Floor Frame (2) Floor Frame Assemblies 10387 Side Floor Frame (4) SO14 The front floor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.

  • Page 15: Frame Assemblies

    5986 Rear Wall Angle (2) 10391 Side Wall Angle (4) Parts Needed For 10398 Right Side Wall Channel (2) Step 2 10399 Left Side Wall Channel (2) Frame Assemblies 9006 Right Rear Wall Channel (1) 9007 Left Rear Wall Channel (1) ST15 The main frame pieces reinforce the 9006...
  • Page 16 Parts Needed For Step 3 10386 Roof Beam (12) Roof Beam Assemblies SS16 The roof beams join the two gables 10386 and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the cen- 10386 ter.
  • Page 17 Parts Needed For 6403 Door Track Splice (1) Step 4 Door Track Assembly 9366 Door Track (2) SO17 NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
  • Page 18 Front Floor Assembly (1) Parts Needed For Step 5 Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) SO18 RIGHT REAR 10387 STEP Place the floor frame pieces that 8936 you assembled earlier on the foun- dation. Assemble the four corners of the floor frame using two screws at each corner as shown.

  • Page 19: Top View

    8716 Right Corner Post (2) Parts Needed For 8715 Left Corner Post (2) Step 6 Door Track Assembly (1) Posts/Top Frames Rear Wall Angle Assembly (1) Side Wall Angle Assemblies (2) ST19 NOTE The remainder of the building assembly requires many hours and more than one person.

  • Page 20: Splice Post

    Parts Needed For Step 7 8718 Rear Splice Post (1) 8734 Side Splice Post (2) Splice Post ST20 STEP The splice posts support the walls. 8718 Position a rear splice post at the center of the rear wall and fasten using 2 nuts and bolts into rear wall angle and 2 screws into rear floor frame.
  • Page 21 Parts Needed For Step 8 8717 Door Jamb (2) Door Jamb ST21 The door jambs reinforce the door opening and provide an attractive trim. Fasten the top of the door jambs to the door track with two screws. Do the same for the bottom into frame. Notched edge faces toward center of building.
  • Page 22 Side Wall Channel Assemblies (2) Parts Needed For Rear Wall Channel Assembly (1) Step 9 9003 Stud (10) Mid Frames/Studs 9365 Front Wall Channel (2) ST22 Wearing gloves, bend the tabs on each mid wall channel down. STEP Fasten side wall channel assem- blies to the sides of building at the splice and corner posts using screws.
  • Page 23 9193 Side Siding (5 board) (8) 5305 Side Siding (3 board) (4) Parts Needed For 8736 Rear Siding (5 board) (4) Step 10 5307 Rear Siding (3 board) (2) Side/Rear/Front Siding 8737 Front Siding (5 board) (4) 5291 Front Siding (3 board) (2) ST23 Each screw in the wall requires a washer.
  • Page 24 7858 Large Right Gable (2) 7859 Large Left Gable (2) Parts Needed For 6114 Small Right Gable (2) Step 11 6115 Small Left Gable (2) Gable Assemblies 6085 Roof Beam Bracket (4) 7860 Mid Gable Brace (4) ST24 67521 Edge Trim The gables go on top of the front and (Plastic Piece) rear walls to support the roof beams.
  • Page 25 Left Gable Assemblies (2) Parts Needed For Right Gable Assemblies (2) Step 12 Single Roof Beam Assemblies (4) Gables/Roof Beams 6636 Gable Brace (2) ST25 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
  • Page 26 Parts Needed For Step 13 Main Roof Beam Assembly (1) Roof Beam/Braces 6227 Roof Beam Brace (2) SS26 Fasten the track supports to the front gable assembly only, as shown. STEP Wrap the weather stripping along the mating edge of the large left and right gables as shown.
  • Page 27 Parts Needed For Step 14 7862 Right Roof Panel (1) Right Roof Panel ST27 Installing the roof panels is best done 7863 7862 with a step ladder. Begin installing roof panels at the back right corner of the building. Each screw and bolt in 7861 7861 the roof requires a washer.

  • Page 28: Roof Assembly

    Parts Needed For 7863 Left Roof Panel (1) Step 15 7861 Roof Panel (2) Roof Assembly 6797 Ridge Cap (3) ST28 Install a left roof panel at the left Screws To rear corner of the roof. Roof Beam Install two roof panels in the se- quence shown on previous page.
  • Page 29 Parts Needed For 7861 Roof Panel (4) Step 16 Roof Assembly 6869 Ridge Cap (3) ST29 Install four roof panels as you unroll the weather stripping tape, and press it down, install the second ridge caps 6869 overlapping the first ridge caps.
  • Page 30 7861 Roof Panel (2) Parts Needed For 7863 Left Roof Panel (1) Step 17 Roof Assembly 6797 Ridge Cap (3) 7862 Right Roof Panel (1) ST30 Install two roof panels, left roof panel, three ridge caps 6797 and right roof panel on the front of the roof as before.
  • Page 31 Parts Needed For 6893 Left Side Roof Trim (2) Step 18 6892 Right Side Roof Trim (2) Roof Trim 6015 Side Roof Trim (2) ST31 Attach the right and left side roof trim to the lower end of the roof pan- els on each side of the building using screws at each panel overlap.

  • Page 32: Door Assembly

    67730 Foam Board (2) Parts Needed For 9930 Right Door (1) Step 19 9931 Left Door (1) Door Assembly 7667 Horizontal Door Brace (4) 8109 Vertical Door Brace (2) ST32 The steps on this page tell how to assemble the left door. You will per- form exactly the same procedures for the right door.
  • Page 33 Parts Needed For Right Door Assembly (1) Step 20 Door Installation & Adjustment Left Door Assembly (1) ST33 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
  • Page 34 SOME FACTS ABOUT RUST SO34 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
