Owner's Manual & Assembly Instructions
ST01
Model No.
714890108
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 14' 121" x 160 1/4"
3,0m x 4,0m 307cm x 407cm
WH1014-D1
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
Width
129
852
123 1/4"
2
3
12,0m
24,1m
313cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Depth
Height
162 3/4"
87 7/8"
413cm
223cm
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4" 157 1/2" 86 5/8"
300cm
400cm
220cm
Door
Opening
55 1/2"
60"
141cm 152cm
Advertisement
Related Manuals for Arrow WH1014-D1
Summary of Contents for Arrow WH1014-D1
- Page 1 Owner's Manual & Assembly Instructions ST01 Model No. WH1014-D1 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 714890108 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
- Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.
- Page 3 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
- Page 6 For buildings ATTIC KIT / WORKBENCH KIT larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FRAME KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
- Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
- Page 11 #8Ax5/16" Screw (460) 65109 67468 66646 66045 #8-32 Acorn Nut (14) Peak Cap (6) Washer (400) (Packed with Screws) (Arrow Logo) Handle (2) (10 sheets of 40) 66183 65020 66382 Roof Trim Cap 66769 1/4" Door Washer (14) Lower Door Guide (4) (2 right &...
- Page 12 Parts List ST12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 5291 Front Siding (3 board) 5305 Side Siding (3 board) 5307 Rear Siding (3 board) 6114 Small Right Gable 6115 Small Left Gable 10501 Horizontal Door Brace 7858 Large Right Gable 7859...
- Page 13 Assembly by Key No. ST13...
- Page 14 ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9367 Front Floor Frame (2) Step 1 ● ● ● ● ● 8936 Rear Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 10387 Side Floor Frame (4) SO14 The front floor frame is made up of three pieces.
- Page 15 ● ● ● ● ● 5986 Rear Wall Angle (2) ● ● ● ● ● 10391 Side Wall Angle (4) ● Parts Needed For ● ● ● ● ● ● 10398 Right Side Wall Channel (2) Step 2 ● ● ● ● ● 10399 Left Side Wall Channel (2) Frame Assemblies ●...
- Page 16 ● Parts Needed For ● ● ● ● ● ● 10386 Roof Beam (12) Step 3 Roof Beam Assemblies SS16 The roof beams join the two gables 10386 and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the cen- 10386 ter.
- Page 17 ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
- Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) SO18 RIGHT REAR 10387 STEP Place the floor frame pieces that 8936...
- Page 19 ● ● ● ● ● 8716 Right Corner Post (2) ● Parts Needed For ● ● ● ● ● ● 8715 Left Corner Post (2) Step 6 ● ● ● ● ● Door Track Assembly (1) Posts/Top Frames ● ● ● ● ● Rear Wall Angle Assembly (1) ●...
- Page 20 ● Parts Needed For ● ● ● ● ● ● 8718 Rear Splice Post (1) Step 7 ● ● ● ● ● 8734 Side Splice Post (2) Splice Post ST20 STEP The splice posts support the walls. 8718 Position a rear splice post at the center of the rear wall and fasten using 2 nuts and bolts into rear wall angle and 2 screws into rear floor...
- Page 21 ● Parts Needed For ● Step 8 ● ● ● ● ● 8717 Door Jamb (2) Door Jamb ST21 The door jambs reinforce the door opening and provide an attractive trim. Fasten the top of the door jambs to the door track with two screws. Do the same for the bottom into frame.
- Page 22 ● ● ● ● ● Side Wall Channel Assemblies (2) ● Parts Needed For ● ● ● ● ● ● Rear Wall Channel Assembly (1) Step 9 ● ● ● ● ● 9003 Stud (10) Mid Frames/Studs ● ● ● ● ● 9365 Front Wall Channel (2) ST22 Wearing gloves, bend the tabs on each mid wall channel down.
- Page 23 ● ● ● ● ● 9193 Side Siding (5 board) (8) ● ● ● ● ● 5305 Side Siding (3 board) (4) ● Parts Needed For ● Step 10 ● ● ● ● ● 8736 Rear Siding (5 board) (4) ●...
- Page 24 ● ● ● ● ● 7858 Large Right Gable (2) ● ● ● ● ● 7859 Large Left Gable (2) ● Parts Needed For ● ● ● ● ● ● 6114 Small Right Gable (2) Step 11 ● ● ● ● ● 6115 Small Left Gable (2) Gable Assemblies ●...
- Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● ● ● ● ● ● Right Gable Assemblies (2) Step 12 ● ● ● ● ● Single Roof Beam Assemblies (4) Gables/Roof Beams ● ● ● ● ● 6636 Gable Brace (2) ST25 Lift and fasten a right and left gable, under angle at corner, to the...
- Page 26 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam Assembly (1) Step 13 ● ● ● ● ● 6227 Roof Beam Brace (2) Roof Beam/Braces SS26 Fasten the track supports to the front gable assembly only, as shown. STEP Wrap the weather stripping along the mating edge of the large left and...
- Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 7862 Right Roof Panel (1) Right Roof Panel ST27 Installing the roof panels is best done 7863 7862 with a step ladder. Begin installing roof panels at the back right corner of the building.
- Page 28 ● Parts Needed For ● ● ● ● ● ● 7863 Left Roof Panel (1) Step 15 ● ● ● ● ● 7861 Roof Panel (2) Roof Assembly ● ● ● ● ● 6797 Ridge Cap (3) ST28 Install a left roof panel at the left Screws To rear corner of the roof.
- Page 29 ● Parts Needed For ● ● ● ● ● ● 7861 Roof Panel (4) Step 16 ● ● ● ● ● 6869 Ridge Cap (3) Roof Assembly ST29 Install four roof panels as you unroll the weather stripping tape, and press it down, install the second ridge caps 6869 overlapping the first ridge caps.
- Page 30 ● ● ● ● ● 7861 Roof Panel (2) ● Parts Needed For ● ● ● ● ● ● 7863 Left Roof Panel (1) Step 17 ● ● ● ● ● 6797 Ridge Cap (3) Roof Assembly ● ● ● ● ● 7862 Right Roof Panel (1) ST30 Install two roof panels, left roof panel, three ridge caps 6797 and...
- Page 31 ● Parts Needed For ● ● ● ● ● ● 6893 Left Side Roof Trim (2) Step 18 ● ● ● ● ● 6892 Right Side Roof Trim (2) Roof Trim ● ● ● ● ● 6015 Side Roof Trim (2) ST31 Attach the right and left side roof trim to the lower end of the roof pan-...
- Page 32 ● ● ● ● ● 67730 Foam Board (2) ● Parts Needed For ● ● ● ● ● ● 10509 Right and Left Doors (2) Step 19 Door Assembly ● ● ● ● ● 10501 Horizontal Door Brace (4) ● ● ● ● ● 8109 Vertical Door Brace (2) ST32 The steps on this page tell how to assemble the left door.
- Page 33 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 20 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment ST33 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
- Page 34 SOME FACTS ABOUT RUST SO34 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
- Page 35 WH1014-D1 ST36 714890108...
