- Page 1 Instruction Manual so f t ware releas e 0 7 1 8 0 68 0 0 F I R S T P R I N T IN G : F E B R UA RY 2 0 0 1 2010/2 0 1 1 RD A D U A L / Q U A D A E S / E B U R E C L O C K I N G D A...
- Page 2 Grass Valley Group. Grass Valley Group assumes no re- sponsibility or liability for any errors or inaccuracies that may appear in this publication.
-
Page 3: Table Of Contents
Cabling ............. 2010RDA COAX PRM Passive Rear Module...... - Page 4 Contents 2010/2011RDA Instruction Manual...
-
Page 5: Preface
Preface About This Manual This manual describes the features of a specific module of the 2000 Series Modular Products family. As part of this module family, it is subject to Safety and Regulatory Compliance described in the 2000 Series frame and power supply documentation (see the 2000 Frames Instruction Manual). - Page 6 Preface 2010/2011RDA Instruction Manual...
-
Page 7: 2010/2011Rda Dual/Quad Aes/Ebu Reclocking Da
The 2010RDA is a Dual AES/EBU Reclocking Distribution Amplifier pro- viding two independent digital audio streams. The module can be config- ured for single or dual operation. The following 2010RDA models are available: 2010RDA with 75 Ω (unbalanced) BNC connector passive rear module... -
Page 8: Installation
2010/2011RDA Dual/Quad AES/EBU Reclocking DA Installation Installation of the 2010/2011RDA module is a process of: Placing the passive rear module in a rear frame slot, Placing the media module in the corresponding front slot, and Cabling and terminating signal ports. The 2010/2011RDA module can be plugged in and removed from a 2000 Series frame with power on. - Page 9 Installation 2. Insert the passive rear module into the vacant rear slot of the frame as illustrated in Figure 2 (2000PRM-D shown here). Figure 2. Installing Passive Rear Module 2000 frame (rear view) Board edge guides (both sides) Alignment post and receptacle Screw lock (both sides)
- Page 10 2010/2011RDA Dual/Quad AES/EBU Reclocking DA 6. With the component side up, insert the front media module in the corresponding front slot (see Figure 7. Verify that the module connector seats properly against the midplane and rear module connector. 8. Press firmly on both ejector tabs to seat the module. Figure 4.
-
Page 11: Cabling
All cabling to the modules is done on the corresponding passive rear module at the back of the 2000 frame. There are two versions of passive rear modules available for the 2010RDA, the COAX PRM with 75 Ω BNC I/O 5) and the 2000PRM-D with 110 Ω D-connector I/O... -
Page 12: 2000Prm-D Passive Rear Module
The 2000PRM-D passive rear module with 110 Ω D-connectors (Figure provides a single 15-pin input D-connector and two 25-pin output D-con- nectors for single, dual (2010RDA-110 or 2011RDA-110) or quad (2011RDA- 110 only) operation. The module must be jumpered during configuration for the correct mode of operation. - Page 13 Refer to Table 2 below for a guide to 2000PRM-D passive rear module cabling in single, dual (2010RDA-110 or 2011RDA-110) or quad (2011RDA-110 only) mode. Note that pins numbers are given in G (ground), – and + sequence. Table 2. 2000PRM-D Cabling...
-
Page 14: Power Up
2010/2011RDA Dual/Quad AES/EBU Reclocking DA Power Up The front LED indicators and configuration jumper are illustrated in Figure 8. Upon power-up, the green PWR LED should light and the yellow CONF LED should illuminate for the duration of module initialization. Operation Indicator LEDs With valid input signals connected, the green PWR LED and the green LOCK LED 1–4 should be on for each channel. - Page 15 Power Up A red FAULT LED indicates an error situation and, with the other LEDs, can indicate the operational conditions presented in Table 3. The table describes signal output and LED indications for various input/reference combinations and user settings. Table 3. Indicator LEDs and Conditions Indicated Indication Condition Normal operation.
-
Page 16: Configuration And Monitoring
Local Onboard Module Configuration The 2010/2011RDA module is configured locally using the jumper shown Figure 9. The CONF LED indicates status of the configuration process. Figure 9. Module Configuration Switches and LEDs 2010RDA DUAL AES/EBU RECLOCKING DA 2011RDA QUAD Configuration LED SINGLE DUAL... -
Page 17: Remote Configuration And Monitoring
Remote Configuration and Monitoring Remote Configuration and Monitoring Monitoring of the 2010/2011RDA can be performed remotely using the 2000NET interface (see Figure 10). This section describes the GUI access to the module configuration functions. Refer to the 2000NET Network Inter- face Module Instruction Manual for information on setting up and oper- ating the 2000 frame network. -
Page 18: Module Configuration Displays
Figure 11. 2010/2011RDADisplay Links Software Update Display The Software Update display allows you to download new software ver- sions for the module. Refer to the 2000NET manual and the Grass Valley Group web site at http://www.grassvalleygroup.com for complete details and new software versions. - Page 19 PRM ( ) passive rear module is installed. (Refer to 2000PRM-D PRM-COAX Passive Rear Module on page 6 or 2010RDA COAX PRM Passive Rear Module on page 5 indicates the input impedance of the passive rear INPUT IMPEDANCE module installed as (COAX PRM) or (2000PRM-D).
-
Page 20: Specifications
2010/2011RDA Dual/Quad AES/EBU Reclocking DA Specifications Table 4. 2010/2011RDA Specifications Parameter Value AES/EBU Inputs (2010RDA COAX PRM) Signal type AES3id – 1992 Number of inputs 2 (jumper selectable for single or dual) 75 Ω BNC (COAX PRM passive rear module) - Page 21 Specifications Table 4. 2010/2011RDA Specifications - (continued) Parameter Value DC offset <±1 mV Electrical length (delay) 560 ns 5 kV (330 Ω, 150 pF) any input or output Static withstand Environmental Frame temperature range 0 to 40° C Operating humidity range 0 to 90% non-condensing Non-operating temperature -10 to 70°...
-
Page 22: Service
LED indications. If the module is still not operating correctly, replace it with a known good spare and return the faulty module to a designated Grass Valley repair depot. Call your Grass Valley representative for depot location. Refer to the... -
Page 23: Functional Description
2000PRM-D 110 Ω passive rear module. The 2010/2011RDA modules reclock and distribute AES/EBU digital audio. The 2010RDA has two independent streams of video and the 2011RDA-110 has four independent streams. The modules are configured with jumpers to operate in single, dual or quad (2011RDA-110 only) mode. -
Page 24: Aes Receivers
(PLL). Each AES Receiver controls the LOCK LEDs which indicate when the receiver IC is locked to an incoming data stream. The reclocked signal is then fed to the FPGA for routing and control. Figure 15. 2010RDA-110/2011RDA-110 with 2000PRM-D Midplane 2000PRM–D... -
Page 25: Routing And Control Fpga
Functional Description Routing and Control FPGA The signals from the AES receiver ICs are applied to the Routing and Control FPGA. The signal routing is determined by the setting of the on- board configuration jumper at the front of the module. After processing, the signals are embedded into an AES stream and applied to the Output Drivers. - Page 26 2010/2011RDA Dual/Quad AES/EBU Reclocking DA 2010/2011RDA Instruction Manual...
-
Page 27: Index
Index Numerics 2000NET module LOCK LEDs 2000PRM-D passive rear module cabling 2010RDA media module features installation specifications midplane 2011RDA features specifications network COAX PRM passive rear module cabling COMM LED operational conditions LED indications CONF (configuring) LED configuration on-board remote... - Page 28 Index-2 2010/2011RDA Instruction Manual...
