Operation and maintenance instructions
CPU ETHERNET-IP Series CX04 module
Operation and maintenance instructions CPU ETHERNET-IP Series CX04 fieldbus
The products are designed and manufactured in conformity with the following directives:
-
2004/108/CE
They also comply partially or totally with regard to the applicable parts of the following standards:
-
CEI EN 61131-2
The website www.camozzi.it contains a section to download the relative CE Declarations of
Conformity
node
19
5000005119
Versione 01
Made in Italy
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Camozzi CPU ETHERNET-IP CX04
Summary of Contents for Camozzi CPU ETHERNET-IP CX04
- Page 1 The products are designed and manufactured in conformity with the following directives: 2004/108/CE They also comply partially or totally with regard to the applicable parts of the following standards: CEI EN 61131-2 The website www.camozzi.it contains a section to download the relative CE Declarations of Conformity...
-
Page 2: Product Identification
5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 1. Product identification... -
Page 3: General Recommendations
For all situations not contemplated in this manual and in situations in which there is the risk of potential damage to objects, or injury to persons or animals, contact Camozzi for advice. Never make unauthorized modifications to the product. In this case, any damage or injury to objects, persons or animals will be the responsibility of the user. - Page 4 The product may only be used in observance of the specifications provided; if these requirements are not met, the product may only be used on authorisation by Camozzi. Avoid covering the equipment with paint or other substances that may reduce heat...
- Page 5 5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 3. General characteristics and conditions of use General characteristics and conditions of use Assembly position Overall dimensions L = 122,6 mm; W = 90,7 mm; H = 48,9 mm Weight 425 gr approximately Ambient temperature...
-
Page 6: Electrical Circuit
In addition a number of modules that allow you to remotely locate the modules above. For more details refer to the "Operation and maintenance - Bus System Internal Camozzi" manual. -
Page 7: Installation And Start-Up
5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 POWER LEDS BUS OUT BUS IN 7. Installation and start-up During unpacking, take great care not to damage the product. Check whether there are any fault caused by product transport or storage. ... - Page 8 5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 Envisage the installation of dehumidifiers to avoid the formation of humidity or condensation on internal components. If the device is used to activate an actuator on which any accidental movement can generate a hazard, envisage suitable locking devices on the mobile section of the actuator.
- Page 9 5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 This illustrates the pins of the M12 connector located on the upper section CPU module: POWER Connector M12A 5 poles male Signal Description 24Vdc power supply (logic, digital input, analog I/O): connect to the L24V positive pole of the 24Vdc power supply (ref.
- Page 10 5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 Use only power able to ensure a reliable electrical isolation of the supply voltage according to IEC 742 / EN 60742 / VDE 0551 with a minimum strength of 4 kV isolation Protected Extra Low Voltage, PELV.
- Page 11 5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 o Il = Logic currente + SPI input current o Ip = Power current (loads) o Rc1 + Rc2 = Cable resistance o Rc0 = Common cable resistance o L = Cable length In order to calculate the cable length use this formula: Where:...
- Page 12 For configuration of the CPU module and the connected modules, download the set-up file of the software CX-Configurator from the web site http://www.camozzi.com and proceed with installation according to the instructions on screen displayed during the process. For more details, please refer to the "Operating and Maintenance Instructions - CX...
- Page 13 Versione 01 input / physical output) are contained in the manual "Operating and Maintenance Instructions - Bus System Internal Camozzi". Furthermore, the CX-Configurator software calculates automatically the size of the data used by the CX04 node and by the modules connected to it. For more details on using the configurator and in particular of this feature, refer to the manual "Operating and...
- Page 14 The product may only be used in observance of the specifications provided; if these requirements are not met, the product may only be used on authorization by Camozzi. Observe the specifications on the identification data plate.
- Page 15 Ethernet frame frame Blinking 10. Limitations on use Never exceed the technical specifications stated in the paragraph "General characteristics" and the Camozzi general catalogue. Do not install the product in environments where the air itself may generate hazards.
-
Page 16: Maintenance
Always wear the correct personal protective equipment as envisaged by local authorities and in compliance with current legislation. In the event of maintenance, replacement of worn parts, use exclusively the original Camozzi kits and ensure that operations are only performed by specialized and authorized personnel. -
Page 17: Product Certification
5000005119 Operation and maintenance instructions CPU ETHERNET-IP Series CX04 module Versione 01 13. Contacts Camozzi spa Società Unipersonale Via Eritrea, 20/I 25126 Brescia - Italy Tel. +39 030 37921 Fax +39 030 2400464 info@camozzi.com www.camozzi.com Product Certification National and International Directives, Regulations and Standards productcertification@camozzi.com...
