  • Page 1 USER'S MANUAL Model No. WLEL1946.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY.

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. .Back Cover WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical exerciser. 1. Read all instructions in this manual and all 8. Wear appropriate exercise clothes while warnings on the elliptical exerciser before using the elliptical exerciser.

  • Page 4: Before You Begin

    635 elliptical exerciser. The WESLO Momentum 635 tacting us. The model number is WLEL1946.0. The is an incredibly smooth exerciser that moves your feet serial number can be found on a decal attached to the in a natural elliptical path, minimizing the impact on elliptical exerciser (see the front cover of this manual).

  • Page 5: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call toll-free 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a phillips screwdriver , an adjustable wrench...
  • Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Attach the Rear Stabilizer (35) to the Frame (1) with two M10 x 75mm Carriage Bolts (58) and two M10 Nylon Locknuts (84). Press the Stabilizer Endcaps (36) onto the Rear Stabilizer (35) as shown.
  • Page 7 4. Identify the Left Pedal Arm (21), which is marked with a “Left” sticker. Attach a Pedal (19) to the Left Pedal Arm with three M4 x 19mm Screws (68) and three Star Washers (85). Attach the other Pedal (not shown) to the Right Pedal Arm (not shown) in the same way.
  • Page 8 Attach the Left Pedal Arm (21) to the Left Upper Body Leg (6) with an M8 x 23mm Shoulder Screw (65), an M8 Washer (64), and a Pedal Leg Cover (23). Grease Apply grease to a Large Wave Washer (20) and slide it onto the Left Crank Arm (42).
  • Page 9 10. Insert the Left Upper Body Arm (4) into the Left Upper Body Leg (6) and attach it with two M8 x 45mm Button Bolts and two M8 Nylon Locknuts (59). Make sure that the Nylon Locknuts are in the hexagonal holes in the Left Upper Body Arm.

  • Page 10: How To Use The Elliptical Exerciser

    HOW TO USE THE ELLIPTICAL EXERCISER HOW TO MOVE AND LEVEL THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER EXERCISER To move the elliptical exerciser, stand in front of it, To mount the elliptical exerciser, firmly hold the upper place one foot against one of the wheels, and firmly body arms and carefully step onto the pedal that is in hold the upper end of the upright.

  • Page 11: Console Diagram

    CONSOLE DIAGRAM FEATURES OF THE CONSOLE prompt you to vary your pedaling pace while guiding you through an effective workout. The console offers a selection features designed to make your workouts more effective. When you use the To use the manual mode of the console, follow the manual mode of the console, you can change the steps beginning on page 12.

  • Page 12: How To Use The Manual Mode

    The third section of HOW TO USE THE MANUAL MODE the display will show the approximate num- ber of calories you Turn on the console. have burned and the resistance level of the To turn on the console, press any button or begin pedals.
  • Page 13 As you exercise, the HOW TO USE A SMART PROGRAM display will prompt you to keep your ped- aling pace near the Turn on the console. pace setting for the current segment. To turn on the console, press any button or begin When the word “faster”...

  • Page 14: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the elliptical Switch. Loosen, but do not remove, the indicated exerciser regularly. Replace any worn parts immedi- M4 x 16mm Screw (60). Slide the Reed Switch slight- ately. The elliptical exerciser can be cleaned with a ly closer to or away from the Magnet, and then soft cloth and mild detergent–do not use abrasives retighten the Screw.

  • Page 15: Conditioning Guidelines

    CONDITIONING GUIDELINES Fat Burning WARNING: To burn fat effectively, you must exercise at a relative- ly low intensity level for a sustained period of time. Before beginning this or any exercise pro- During the first few minutes of exercise, your body gram, consult your physician.

  • Page 16: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 17: Part List

    PART LIST—Model No. WLEL1946.0 R1107A Key No. Qty. Description Key No. Qty. Description Frame Clamp Upright Reed Switch/Wire Front Stabilizer Flywheel Left Upper Body Arm Flywheel Axle Right Upper Body Arm Flywheel Bearing Left Upper Body Leg “C” Magnet Right Upper Body Leg “C”...

  • Page 18: Exploded Drawing

    EXPLODED DRAWING A—Model No. WLEL1946.0 R1107A...
  • Page 19 EXPLODED DRAWING B—Model No. WLEL1946.0 R1107A 28 59 29 59...

  • Page 20: How To Order Replacement Parts

    • the MODEL NUMBER of the product (WLEL1946.0) • the NAME of the product (WESLO Momentum 635 elliptical exerciser) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
