Model No. WLEL2947.0
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
(closed on holidays)
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Keep this manual for future
reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WLEL2947.0
Summary of Contents for Weslo WLEL2947.0
- Page 1 Model No. WLEL2947.0 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY.
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical exerciser. 1. Read all instructions in this manual and all 8. Wear appropriate exercise clothes while warnings on the elliptical exerciser before using the elliptical exerciser. -
Page 4: Before You Begin
SYSTEM elliptical exerciser. The WESLO FIT BODY tacting us. The model number is WLEL2947.0. The SYSTEM is an incredibly smooth exerciser that serial number can be found on a decal attached to the moves your feet in a natural elliptical path, minimizing elliptical exerciser (see the front cover of this manual). -
Page 5: Assembly
ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call toll-free 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a phillips screwdriver , an adjustable wrench... - Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Attach the Rear Stabilizer (35) to the Frame (1) with two M10 x 75mm Carriage Bolts (58) and two M10 Nylon Locknuts (84). Press the Stabilizer Endcaps (36) onto the Rear Stabilizer (35) as shown.
- Page 7 5. Apply a small amount of the included grease to a Wave Washer (27) and slide it onto one end of the Pivot Axle (16). Next, slide an M8 Washer (64) and a Grease Pivot Cover (14) onto an M8 x 23mm Button Screw (65), and tighten the Button Screw into the Pivot Axle.
- Page 8 8. The Console (10) requires four “AA” batteries (not Battery included); alkaline batteries are recommended. Cover Remove the battery cover from the Console and insert four batteries into the Console. Make sure that the batteries are oriented as shown by the dia- gram inside the battery compartment.
-
Page 9: How To Use The Elliptical Exerciser
HOW TO USE THE ELLIPTICAL EXERCISER HOW TO MOVE AND LEVEL THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER EXERCISER To move the elliptical exerciser, stand in front of it, To mount the elliptical exerciser, firmly hold the upper place one foot against one of the wheels, and firmly body arms and carefully step onto the pedal that is in hold the upper end of the upright. - Page 10 CONSOLE DIAGRAM Before using the console, make sure that batteries are installed (see assembly step 8 on page 8). If there is a sheet of clear plastic on the display, remove the plastic. Indicators HOW TO USE THE MANUAL MODE Turn on the console.
- Page 11 To reset the display, press the On/Reset button. Follow your progress with the display. To pause the console, stop pedaling. When the console is paused, the time will flash in the dis- The console has several displays that show the play.
- Page 12 During the pro- HOW TO USE AN AEROBIC PROGRAM gram, the pace guide will prompt Turn on the console. you to keep your pedaling pace To turn on the console, press the On/Reset button near the target or begin pedaling. The entire display and the pace setting for pace guide will light for a moment;...
- Page 13 Whenever the resistance is about to change, the HOW TO USE A CROSSTRAINER PROGRAM resistance level will flash in the display for a few seconds. The resistance of the pedals will then automatically change to the resistance level pro- Turn on the console. grammed for the next segment.
- Page 14 Perform the first strength exercise when Continue the crosstrainer program. prompted. When you have performed the recommended When the number of repetitions, step onto the exerciser and first begin pedaling. The pedals will automatically strength adjust to the resistance level programmed for the exercise next segment.
-
Page 15: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the elliptical Switch. Loosen, but do not remove, the indicated exerciser regularly. Replace any worn parts immedi- M4 x 16mm Screw (60). Slide the Reed Switch slight- ately. The elliptical exerciser can be cleaned with a ly closer to or away from the Magnet, and then soft cloth and mild detergent–do not use abrasives retighten the Screw. -
Page 16: Conditioning Guidelines
CONDITIONING GUIDELINES Fat Burning WARNING: To burn fat effectively, you must exercise at a relative- ly low intensity level for a sustained period of time. Before beginning this or any exercise pro- During the first few minutes of exercise, your body gram, consult your physician. -
Page 17: Part List
PART LIST—Model No. WLEL2947.0 R1006A Key No. Qty. Description Key No. Qty. Description Frame Flywheel Upright Flywheel Axle Front Stabilizer Flywheel Bearing Left Upper Body Arm “C” Magnet Right Upper Body Arm “C” Magnet Bracket Left Upper Body Leg Magnet... -
Page 18: Exploded Drawing
EXPLODED DRAWING A—Model No. WLEL2947.0 R1006A... - Page 19 EXPLODED DRAWING B—Model No. WLEL2947.0 R1006A 28 59 29 59...
-
Page 20: How To Order Replacement Parts
• the MODEL NUMBER of the product (WLEL2947.0) • the NAME of the product (WESLO FIT BODY SYSTEM elliptical exerciser) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
