SPECIFICATIONS
Ø43
G ½
OPERATING CONDITIONS
Water supply pressure : 0.05 ~ 0.75 MPa.
1.
2. Ensure that water supply is clean
( No Sand, Dirt, Etc.).
ATTENTION
1.
Don t use abrasive cleaning material such
as; detergents containing hydrochloric acids,
thinner, polishing powder, and nylon brush.
2.
As the product model is constantly updated,
the actual product may not look the same as
it shown in the diagram, but the basic
installation principles are the same.
S060187S
SPECIFICATIONS
Ø43
G ½
OPERATING CONDITIONS
1.
Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean
( No Sand, Dirt, Etc.).
ATTENTION
1.
Don t use abrasive cleaning material such
as; detergents containing hydrochloric acids,
thinner, polishing powder, and nylon brush.
2.
As the product model is constantly updated,
the actual product may not look the same as
it shown in the diagram, but the basic
installation principles are the same.
S060187S
MAINTENANCE
Always wipe chrome plated area with dry soft
cloth, and sometimes wipe it with cloth soaked
in mild soap.
INSTALLATION
100
MAINTENANCE
Always wipe chrome plated area with dry soft
cloth, and sometimes wipe it with cloth soaked
in mild soap.
INSTALLATION
100
TROUBLESHOOTING
PROBLEM
Water l eaks arou nd the han dle
Handle is Loose
Handle
Faucet
1. CONNECTING NUT
2. B OLT
Packing
Ø25 Hole
Washer
Lock Nut
TROUBLESHOOTING
PROBLEM
Water l eaks arou nd the han dle
Handle is Loose
Handle
Faucet
1. CONNECTING NUT
2. B OLT
Packing
Ø25 Hole
Washer
Lock Nut
CHECK
SOLUTION
POINT
Tighten
1
Tighten
2
R5
CHECK
SOLUTION
POINT
Tighten
1
Tighten
2
R5
